FlashLogic FLC-AL-CH6 User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
PLEASE VISIT www.flash-it.com FOR COMPLETE PRODUCT DETAILS
Audiovox Electronics Corp.
INSTALL GUIDE
flc-al(Dl)-ch6
available for: flcaN
CH6
The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2011
Rev. Date: August 30, 2011
Doc. No.: ##6085##
20110829

INSTALL TYPE SELECTION
XX-XX PAGE X-XADS-AL(DL)-CH6 PAGE 2-4
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS DOWNLOADABLE SOFTWARE RS232 COMMUNICATION 2-WAY COMPATIBILITY PRIORITY UNLOCK DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM POWER LIFTGATE TRUNK/HATCH RELEASE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) DOOR STAT OUTPUT TRUNK STAT OUTPUT TACHOMETER OUTPUT DATA/MUX STARTER CTRL BRAKE PEDAL STAT OUTPUT* E-BRAKE OUTPUT
CHRYSLER
300M 99-04 1 • • • • • • • • • • • •
300M w/Alarm 99-04 3 • • • • • • • • • • • • • •
Concorde 99-04 1 • • • • • • • • • • • •
Concorde w/Alarm 99-04 3 • • • • • • • • • • • • • •
LHS 99-01 1 • • • • • • • • • • • •
LHS w/Alarm 99-01 3 • • • • • • • • • • • • • •
Neon 00-05 3 • • • • • • • • • • • • •
Pacifi ca 04-08 2 • • • • • • • • • • • • • • • •
PT Cruiser 01-05 3 • • • • • • • • • • • • • •
Sebring Sedan/Convertible 01-06 1 • • • • • • • • • • • • •
Sebring Sedan/Convertible w/Alarm 01-06 3 • • • • • • • • • • • • • • •
Town & Country 01-03 4 • • • • • • • • • • • • • • • • • •
Town & Country w/Alarm 01-03 5 • • • • • • • • • • • • • • • • • •
Town & Country 04-07 2 • • • • • • • • • • • • • • • • • •
Voyager 01-034•••••••••••••••• ••
Voyager w/Alarm 01-03 5 • • • • • • • • • • • • • • • • • •
DODGE
Caravan/Grand Caravan 01-03 4 • • • • • • • • • • • • • • • •
Caravan/Grand Caravan w/Alarm 01-03 5 • • • • • • • • • • • • • • • • • •
Caravan/Grand Caravan 04-07 2 • • • • • • • • • • • • • • • • • •
Dakota 01-04 6 • • • • • • • • • • •
Dakota w/Alarm 01-04 3 • • • • • • • • • • • • •
Durango 01-03 6 • • • • • • • • • • • •
Durango w/Alarm 01-03 3 • • • • • • • • • • • • • •
Intrepid 99-04 1 • • • • • • • • • • • •
Intrepid w/Alarm 99-04 3 • • • • • • • • • • • • • •
Ram Pickup 02-05 3 • • • • • • • • • • • • •
SRT 4 03-05 3 • • • • • • • • • • • • •
Stratus Sedan 01-06 1 • • • • • • • • • • • • •
Stratus Sedan w/Alarm 01-06 3 • • • • • • • • • • • • • • •
SX 2.0 03-05 3 • • • • • • • • • • • • •
JEEP
Grand Cherokee 99-04 1 • • • • • • • • • • • • • •
Liberty 02-04 3 • • • • • • • • • • • •
Liberty 05-07 2 • • • • • • • • • • • • • •
TJ 01-06 1 • • • • • •
Wrangler 01-06 1 • • • • • •
PLYMOUTH
Neon 00-01 3 • • • • • • • • • • • • •
Visit our website
for advanced
features.
† Extra resis-
tor and relay
required.
* Brake output
available ONLY
with ignition ON.
Page 2 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

2. ProceeD with iNstallatioN See applicable wiring diagram
NOTE : eNsure all coNNectioNs are comPleteD aND ProPerly secureD Prior to coNNectiNg the wire harNesses to the moDule.
XX-XX PAGE X-X
NOTICE
XX-XX PAGE X-XVEHICLE OWNER NOTICEDETECT OEM ALARM
DETECT OEM ALARM EQUIPPED VEHICLES
1Close hood and trunk/hatch.
Enter vehicle.
Close all doors. 1Open driver’s door window.
Close hood and trunk/hatch.
Close all doors.
3Open driver’s door.
Alarm goes on,
OEM alarm equipped vehicle.
3Open driver’s door using handle
located inside vehicle.
Alarm goes on,
OEM alarm equipped vehicle.
2LOCK driver’s door twice using
OEM key.
Wait 60 seconds.
x2
2Press LOCK twice on OEM fob.
Wait 60 seconds.
x2
LOCK
WITH OEM KEYFOB WITHOUT OEM KEYFOB
Page 3 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

XX-XX PAGE X-X
WIRE CROSS REFERENCE CHART
ADS-AL(DL)-CH6 T1 PAGE X-X
TYPE 1 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR
IGNITION J1850
WIRE COLOR POSITION WIRE COLOR POSITION
CHRYSLER
300M299-04 Blue/White 4 Violet/Yellow 2
Concorde299-04 Blue/White 4 Violet/Yellow 2
LHS299-01 Blue/White 4 Violet/Yellow 2
Sebring Sedan/Convertible201-06 Blue/White 4 Violet/Pink 2
DODGE
Intrepid299-04 Blue/White 4 Violet/Yellow 2
Stratus Sedan201-06 Blue/White 4 Violet/Pink 2
JEEP
Grand Cherokee1&2 99-04 Blue/White 3 Yellow/Violet or Yellow/Black 5
TJ1&2 01-04 Blue 4 Violet/Yellow 2
TJ1&2 05-06 Pink/White 4 White/Violet 2
Wrangler1&2 01-04 Blue 4 Violet/Yellow 2
Wrangler1&2 05-06 Pink/White 4 White/Violet 2
1 With OEM Alarm
2 Without OEM Alarm
Page 4 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

TYPE 1 - WIRING DIAGRAM
Page 5 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
123456
2 4
SKIM
IMMOBILIZER MODULE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK (-) INPUT - GREEN/BLACK
LOCK (-) INPUT - GREEN/BLACK
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - GROUND
ORANGE/BLACK - GROUND
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
(NC) BROWN
(NC) BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION
J1850
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
WITH OEM ALARM ONLY
Doc. No.: ##6085##

XX-XX PAGE X-X
WIRE CROSS REFERENCE CHART
ADS-AL(DL)-CH6 T2 PAGE X-X
TYPE 2 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR
IGNITION J1850
WIRE COLOR WIRE COLOR
CHRYSLER
Pacifi ca 04-08 Pink/Gray White/Violet
Town & Country 04-07 Pink/White White/Violet
DODGE
Caravan/Grand Caravan 04-07 Pink/White White/Violet
JEEP
Liberty 05-07 Pink/LtGreen White/Violet
Page 6 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

TYPE 2 - WIRING DIAGRAM
Page 7 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
123456
2 4
SKIM
IMMOBILIZER MODULE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - GROUND
ORANGE/BLACK - GROUND
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
DISARM (-) INPUT - BROWN
DISARM (-) INPUT - BROWN
DISARM (-) OUTPUT
DISARM (-) OUTPUT
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
(NC) WHITE
(NC) WHITE
STARTER (+) INPUT - BLACK/WHITE
STARTER (+) INPUT - BLACK/WHITE
STARTER (+) OUTPUT
STARTER (+) OUTPUT
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION
J1850
IMPORTANT:
OEM ALARM EQUIPPED VEHICLES MAY CHIRP ONCE UPON
REMOTE START. TO AVOID HORN CHIRP, THE REMOTE
STARTER MUST BE SET TO UNLOCK BEFORE REMOTE
START AND TO LOCK AFTER REMOTE START.
IMPORTANT
IN ORDER TO CONTROL
THE SECOND START FEATURE
THROUGH DATA, THIS WIRE MUST
BE CONNECTED TO THE VEHICLE
STARTER WIRE IN PARALLEL
WITH THE REMOTE STARTER
STARTER (+) OUTPUT
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
WITH OEM ALARM ONLY
Doc. No.: ##6085##

XX-XX PAGE X-X
TYPE 3 - COMPONENT LOCATOR
ADS-AL(DL)-CH3 T3 PAGE X-X
C2
GREY COVERBLACK COVER
WHITE COVER
BCM
C1
C2
C3
C4
BCM: 300M, CONCORDE, INTREPID
BCM: LIBERTY
XX-XX PAGE X-XADS-AL(DL)-CH6 T3 PAGE X-X
TYPE 3 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR
ANALOG DOORLOCK IGNITION J1850
WIRE COLOR LOCATION WIRE COLOR WIRE COLOR
CHRYSLER
300M199-04 LtGreen/Orange At BCM, C4 Connector, Pin #13 (See BCM image) Blue/White Violet/Yellow
Concorde199-04 LtGreen/Orange At BCM, C4 Connector, Pin #13 (See BCM image) Blue/White Violet/Yellow
LHS199-01 LtGreen/Orange At BCM, C4 Connector, Pin #13 (See BCM image) Blue/White Violet/Yellow
Neon1&2 00-05 LtGreen Harness coming from driver door Blue/White Violet/Yellow
PT Cruiser101-05 White/DkGreen Harness coming from driver door Blue/Black Violet/Yellow
Sebring Convertible101-06 LtGreen/Orange At BCM, C4 Connector, Pin #4 or Harness from driver door Blue/White Violet/Pink
Sebring Sedan101-06 LtGreen/Orange At BCM, C4 Connector, Pin #4 or Harness from driver door Blue/White Violet/Pink
DODGE
Dakota101-04 LtGreen/Orange Driver Kick Panel LtGreen/Black Violet/Yellow
Durango101-03 LtGreen/Orange Driver Kick Panel LtGreen/Black Violet/Yellow
Intrepid199-04 LtGreen/Orange At BCM, C4 Connector, Pin #13 (See BCM image) Blue/White Violet/Yellow
Ram Pickup202-03 White/LtGreen Driver Kick Panel LtGreen/Black Violet/White
Ram Pickup102-03 LtGreen/Orange Driver Kick Panel LtGreen/Black Violet/White
Ram Pickup204-05 Purple/DkGreen Driver Kick Panel Pink/Gray White/Violet
Ram Pickup104-05 Purple/LtBlue Driver Kick Panel Pink/Gray White/Violet
SRT 41&2 03-05 LtGreen Harness coming from driver door Blue/White Violet/Yellow
Stratus Sedan101-06 LtGreen/Orange At BCM, C4 Connector, Pin #4 or Harness from driver door Blue/White Violet/Pink
SX 2.01&2 03-05 LtGreen Harness coming from driver door Blue/White Violet/Yellow
JEEP
Liberty1&2 02-04 Pink/Violet At BCM, C2 Connector, Pin #20 (See BCM image) Blue Yellow/Violet
or Violet/Black
PLYMOUTH
Neon1&2 00-01 LtGreen Harness coming from driver door Blue/White Violet/Yellow
1 With OEM Alarm
2 Without OEM Alarm
Page 8 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

TYPE 3 - WIRING DIAGRAM
Page 9 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
123456
2 4
SKIM
IMMOBILIZER MODULE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW - ANALOG OUTPUT
YELLOW - ANALOG OUTPUT
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - GROUND
ORANGE/BLACK - GROUND
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
DISARM (-) INPUT - BROWN
DISARM (-) INPUT - BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
DISARM (-) OUTPUT
DISARM (-) OUTPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION
J1850
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
WITH OEM ALARM ONLY
REFER TO
WIRING
CROSS
REFERENCE
CHART
Doc. No.: ##6085##

TYPE 4 - WIRING DIAGRAM
Page 10 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
1010 1111
1919
1212 1313 1414 1515 1616 1717
1818 2020 2121 2222 2323 2424 2525
11 22 33 44 55 66 77 88 99
2626 2727 2828 2929 3030 3131 3232 3333 3434
C1C1 C2C2 C4C4 C5C5C3C3
86
30
87
87A
85
123456
2 4
SKIM
IMMOBILIZER MODULE
21
1N4001
DIODE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
LOCK (-) INPUT - GREEN/BLACK
LOCK (-) INPUT - GREEN/BLACK
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
(NC) BROWN
(NC) BROWN
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PURPLE/GREEN
VIOLET/BROWN - SWITCH (MUX*)
PINK/WHITE - IGNITION (+)
YELLOW - STARTER (+)
RESISTOR
BETWEEN 180-210 0HMS
C3
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW - ANALOG OUTPUT
YELLOW - ANALOG OUTPUT
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION - PINK/WHITE
J1850 - WHITE/VIOLET
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
BCM IS LOCATED UNDER DRIVER’S SIDE
DASH AGAINST FIREWALL
WARNING
MULTIPLE WIRES WITH
THE SAME COLOR.
TEST WIRES AND VERIFY
PINOUT POSITION
USE ISOLATED GROUND WHEN
RUNNING FROM REMOTE
STARTER TO POWER RELAY
Doc. No.: ##6085##

TYPE 5 - WIRING DIAGRAM
Page 11 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
1010 1111
1919
1212 1313 1414 1515 1616 1717
1818 2020 2121 2222 2323 2424 2525
11 22 33 44 55 66 77 88 99
2626 2727 2828 2929 3030 3131 3232 3333 3434
C1C1 C2C2 C4C4 C5C5C3C3
86
30
87
87A
85
1414
123456
2 4
SKIM
IMMOBILIZER MODULE
1N4001
DIODE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
DISARM (-) INPUT - BROWN
DISARM (-) INPUT - BROWN
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
DISARM (-) OUTPUT
DISARM (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PURPLE/LT. BLUE
RESISTOR
BETWEEN 180-210 0HMS
C3
BCM IS LOCATED UNDER DRIVER’S SIDE
DASH AGAINST FIREWALL
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW - ANALOG OUTPUT
YELLOW - ANALOG OUTPUT
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - GROUND
ORANGE/BLACK - GROUND
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
WARNING
MULTIPLE WIRES WITH
THE SAME COLOR.
TEST WIRES AND VERIFY
PINOUT POSITION.
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION - PINK/WHITE
J1850 - WHITE/VIOLET
VIOLET/BROWN - SWITCH (MUX*)
PINK/WHITE - IGNITION (+)
YELLOW - STARTER (+)
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
USE ISOLATED GROUND WHEN
RUNNING FROM REMOTE
STARTER TO POWER RELAY
Doc. No.: ##6085##

TYPE 6 - WIRING DIAGRAM
Page 12 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
123456
2 4
SKIM
IMMOBILIZER MODULE
N/A
REMOTE STARTER
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK (-) INPUT - GREEN/BLACK
LOCK (-) INPUT - GREEN/BLACK
BRAKE (+) INPUT
BRAKE (+) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE - KEYSENSE (-) OUTPUT
ORANGE/WHITE - KEYSENSE (-) OUTPUT
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
PINK/BLACK (NC)
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - BRAKE (+) OUTPUT
GRAY/RED - BRAKE (+) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK (-) INPUT - BLUE/BLACK
UNLOCK (-) INPUT - BLUE/BLACK
(NC) RED/WHITE
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
E-BRAKE STATUS (-) OUTPUT - GREEN
E-BRAKE STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK
WHITE/RED
WHITE/RED
WHITE (NC)
WHITE (NC)
IGNITION
LT. GREEN/BLACK
KEYSENSE (-)
LT. BLUE
J1850 - VIOLET/YELLOW
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
Doc. No.: ##6085##

MODULE PROGRAMMING
XX-XX PAGE X-XADS-AL(DL)-CH6 PAGE X-X
5Turn key to OFF position.
MODULE PROGRAMMING PROCEDURE
7Module Programming
Procedure completed.
OFF
1Insert key into ignition.
2Turn key to ON position.
ON
4Wait, it may take up to
20 seconds. LED will turn solid
GREEN then will turn OFF.
3LED will turn solid RED.
6Remove key.
ADS-AL(DL)-CH6 98
ADS-DL-CH6 98
ADS-TB-CH6 98
INSTALLATION MODE SELECTION
1Press and release
programming button
to select installation mode. 2Press and hold
programming button
until LED turns solid GREEN
to register selection.
!After registration, follow Factory Reset Procedure to
change installation mode and restart this procedure.
LED fl ashes (1X) once = DATA MODE
LED fl ashes (2X) twice = STANDARD HARDWIRE MODE
Page 13 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##

XX-XX PAGE X-XCLASSIC PAGE 1-1
LED STATUS DIAGNOSTICS
DURING PROGRAMMING DURING REMOTE START WITH IGNITION OFF
Flashing RED Missing/wrong information from
fi rmware or vehicle Incorrectly programmed Incorrectly programmed or connected
Solid RED Waiting for more vehicle information Incorrectly programmed Not programmed waiting for more
vehicle information
Flashing GREEN Additional steps required to complete
programming
Correctly programmed and
operational
False ground when running status
from remote starter
Solid GREEN then OFF Correctly programmed Reset in progress Reset in progress
OFF No activity or already programmed Invalid ground when running status
from remote starter
At rest and ready for a remote start
sequence
MODULE DIAGNOSTICS
FACTORY RESET PROCEDURE
7Repeat programming procedure.
!Failure to follow procedure may result with a DTC or a
CHECK ENGINE error message.
1DISCONNECT all connectors
from module EXCEPT the black
4-PIN standard or optional data
connector.





6RECONNECT all connectors.


 
2DISCONNECT black 4-PIN
standard or optional data
connector.

4When LED fl ashes red,
RELEASE programming button.
5LED will turn solid red for 2
seconds.
RESET COMPLETED.
3PRESS AND HOLD programming
button while connecting either
4-PIN standard or optional data
connector.
IDENTIFY VEHICLE YEAR
1Locate the Vehicle Identifi cation
Number (VIN) and identify the
10th character. 2Match the VIN’s 10th character
to its corresponding year.
L > 1990 S > 1995 Y > 2000 5 > 2005 A > 2010
M > 1991 T > 1996 1 > 2001 6 > 2006 B > 2011
N > 1992 V > 1997 2 > 2002 7 > 2007 C > 2012
P > 1993 W > 1998 3 > 2003 8 > 2008 D > 2013
R > 1994 X > 1999 4 > 2004 9 > 2009 E > 2014
4 Y 1 N53 A 5 T A L 8 D 5 R 0 X

Page 14 of 14 FLC-AL(DL)-CH6 20110829
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2011
ALL IN ONE
Chrysler/DoDge/Jeep
Doc. No.: ##6085##
