FleetLynx AMG1000ALx-VCM User manual

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 1
r04
Installation Guide (AMG1000ALx-VCM)
1.0 Safety & Regulatory Information
Important safety and regulatory information on the AMG unit may be found on on page 15
this installation guide.
2.0 Kit Contents
There are four AMG aftermarket kits for light-duty/passenger vehicles:
•AMG1000BLx-VCM kits include the “Backpack Antenna” and will be used in the
majority of cases, where both the base unit and the antenna are to be installed in
the vehicle interior. Instructions for the AMG1000BLx-VCM kit installation are not
included here, but are available online.
•AMG1000BOx-VCM kits include the “Backpack Antenna” and will be used in the
majority of cases, where both the base unit and the antenna are to be installed in
the vehicle interior. Instructions for the AMG1000BOx-VCM kit installation are not
included here, but are available online.
•AMG1000AOx-VCM kits include the “External Antenna” and should be used when it
is necessary to install the antenna on the cab exterior or if specifically requested by
the “fleet” customer. Instructions for the AMG1000AOx-VCM kit installation are not
included here, but are available online.
•AMG1000ALx-VCM kits include the “External Antenna” and should be used when it
is necessary to install the antenna on the vehicle exterior or if specifically requested
by the “fleet” customer.
This is the installation guide for the AMG1000ALx-VCM kit as shown in Figure 1.
CAUTION: Be sure to thoroughly review the safety and regulatory information before installing and
activating the AMG unit.
Advanced Mobile Gateway AMG1000
Light Duty/Passenger Vehicle

2 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


Figure 1: AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit
3.0 Recommended Tools
The following tools are recommended for the installation:
•Phillips and Square Drive screwdrivers – to unscrew the dashboard
•Carpenter knife – to separate wires C&D from covering over both wires (if needed)
•Crimp Tool – to attach add-a-circuit fuse accessory
•Zipties – to secure loose wiring and perhaps the AMG itself
Turn the truck on and check for existing lamps, warning
lights, or anything out of the ordinary:
Investigate issues as needed before beginning the install – this thorough pre-install exam
helps troubleshoot issues should any arise after installation. Please record any lamps or
warnings on the installation form.
AMG1022L
Wiring Harness for Light
Duty/Passenger Vehicles
AMG1000ALx-VCM kit contents:
AMG1020x
Advanced Mobile Gateway
AMG1021A
External Aerodynamic
Antenna
x=U if equipment is to be operated in the USAwhere:
x=C if equipment is to be operated in Canada
IMPORTANT – PLEASE COMPLETE THE
FOLLOWING TASKS BEFORE
INSTALLATION

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 3
Activate the AMG:
Step 1: Obtain Required Information
The following information is required to activate an AMG unit:
•AMG Serial Number – see Figure 2 for location of this information
•Fleet Name – the name of the fleet the vehicle belongs to
•Truck Number – the number the fleet uses to identify the vehicle
•Dealer Code – the code for the dealership where the FleetLynxunit was
purchased from
•VIN – the Vehicle Identification Number for the vehicle in which the AMG unit will be
installed
•Odometer – the vehicle odometer reading from the dash
Figure 2: AMG Serial Number
Step 2: Call 1-877-955-3122
Call this number once the information from Step 1 is obtained. A customer service agent will
then activate the unit. It will usually take a few minutes to complete.
0.
5.)43. 
1234567890
!-'5
AMG1020U
AMG Serial Number
Bottom of AMG Unit
AMG Bar Code Label (Close Up)
0.
5.)43. 
1234567890
!-'5
AMG1020U
MODEL: AMG1020U
FCC ID: OPP-AMG1020X
IC ID: 2943A-AMG1020
(877 ) 955-3122
Il est important que le numéro de série
de cet appareil soit associé au numéro
du camion qui recevra cet appareil.
It is important that the UNIT S/N is
associated with the
Truck # that
will receive this unit.
Please call
to activate
Veuillez appeler
pour activer

4 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


Identify the best location for installation:
Before the wiring harness, AMG base unit and antenna are installed, it is strongly
recommended that the vehicle cab is inspected for potential installation locations and an
installation plan is devised. Keep the following information in mind when locating a suitable
install location and plan:
1) The AMG base unit may not be installed any further than 9 feet away from the vehicle’s
interior fuse panel.
2) The external antenna (included in AMG1000ALx-VCM kits only) may be installed up to
15 feet away from the AMG base unit.
3) Antenna reception is critical for effective AMG operation, therefore the antenna must not
be obstructed by metal objects. Optimal antenna orientation is shown in Figure 3.
Figure 3: Optimal Unit Orientation
The external aerodynamic antenna mounts outside the vehicle cab (generally on the roof).
For optimal reception, the antenna should be mounted on a horizontal metal surface as
shown in Figure 3 but not be obstructed by surrounding metal objects. The mounting
surface should be no thicker than ¼”. To mount the antenna, a hole ¾” in diameter must be
drilled or punched into the surface. For roof mounts, remove any material on the underside
of the cab before creating the hole. In order to secure the antenna mounting, it is necessary
to also have access to the underside of the hole (normally inside the cab). The gasket
attached to the underside of the antenna acts as a moisture seal which prevents moisture
from entering the vehicle.
WARNING! The external antenna must only be used with the supplied cable [type=RF-195,
length=15 feet (4.5 meters), minimum attenuation=2.25dB] or similar cable with minimum
attenuation of 2.25dB. This is necessary to limit the antenna gain to no more than 3dBi in order to
comply with FCC part 24.
External antenna mounting (cab exterior):
AMG BASE UNIT
ORIENTATION
NOT CRITICAL
The mounting location
should provide access
to the cable connections
on the AMG base unit.
The mounting
location should
allow the status
LEDs to be
visible.
Mount this end facing up;
unobstructed by metal objects
Mount this side towards front of vehicle
AMG base unit mounting (cab interior):
Note: If the underside of the
threaded base bolt is exposed
to the environment, a sealant
is required.

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 5
To attach the antenna, first remove the nut. Feed the cables through the hole, seat the
antenna on the surface, and then reattach the nut. The nut should be tight (5 ft. lbs. max) in
order to properly seal the gasket. Tighten the nut with a wrench. For unforeseen conditions,
silicone may be added around the base of the antenna. Finally, feed the cables to the AMG
inside the cab.
A good install location will be one that:
• Is not visible to the driver
• Will allow the technician to be able to see all four LEDs on the unit.
• Allows easy access to the GPS, CDMA, and GSM connections on the unit
• Enables the AMG base unit to be secured via screws, such that the screws are not
visible to the driver.
PROCEED WITH INSTALLATION ONLY AFTER
THE ABOVE TASKS HAVE BEEN COMPLETED
Note: If the underside of the threaded base bolt is exposed to the environment, a sealant is required.

6 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


4.0 Connecting the AMG
4.1 AMG Base Unit Connections
The AMG base unit connectors are shown in Figure 4.
Figure 4: AMG Base Unit Connectors
4.2 Wiring Harness for Light Duty Vehicles
The wiring harness for Light Duty/Passenger Vehicles comes with two add-a-circuit devices.
Figure 5: Wiring Harness for Light Duty/Passenger Vehicles
Note: There are two cellular antenna connections, one is for GSM and the other is for CDMA. Be sure
to check connections made to the AMG unit thoroughly.
GSM
Cellular
Antenna
Connector
8 Pin
MOLEX
Connector
CDMA
Cellular
Antenna
Connector GPS
Antenna
Connector
Unit
Status
LEDs

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 7
Wiring Harness Installation Overview
Figure 6 shows the wiring harness installation overview. The following section provides the
detailed installation instructions.
Figure 6: Wiring Harness Installation Overview
VBATT (Red) IGN_SEN (Brown)
GND2 (Black)
Molex MiniFit Connector
Plugs into AMG base unit 12 43
56 875 = OWDAT
6 = CAN_L
7 = CAN_H
8 = VBATT
Pinout:
1 = GND1
2 = IGN_SEN
3 = DIG_IN1
4 = GND2
WIRING HARNESS
AMG base unit (Connector Side)
VEHICLE FUSE PANEL
GND1 (Black)
Attach the ring terminal of the
GND1 (long black) wire to a good
chassis ground point inside the
vehicle. These can usually be found
near the fuse panel and/or stereo.
Alternatively, the shorter GND2 wire
can be used if there is a chassis
ground point close to the AMG.
Connect the Ignition Sensor wire to a spare fuse
position which has a “switched” 12V (only live
with ignition and accessory) via an “add-a-circuit”
device or by direct splice, including a 3A inline
fuse, if there is not enough clearance for the
“add-a-circuit” device.
DIG_IN1 (Violet) [NOT USED]
OWDAT (Blue) [NOT USED]
CAN_H (Yellow) [NOT USED]
CAN_L (Green) [NOT USED]
These wires on the harness
are not used. They can be
bundled together and tucked
out of the way.
Add-a-Circuit
(JHFUSE-14)
Add-a-Circuit
(JHFUSE-14)
Connect the VBATT wire to a spare fuse position
which has a constant 12V (battery) via an
“add-a-circuit” device or by direct splice, including
a 3A inline fuse, if there is not enough clearance
for the “add-a-circuit” device.

8 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


4.3 Wiring Harness Installation Steps
1) Locate the vehicle’s interior fuse panel (refer to vehicle user manual).
2) Determine the best location to mount the AMG as detailed in Section 3.0, with the
stipulation that the AMG base unit must be no further than 9 feet from the vehicle’s
interior fuse panel.
3) Connect the VBATT (red) wire on the AMG wiring harness to one of the “add-a-circuit”
fuse holders (JHFUSE-14) included in the kit, using the pre-installed butt connector and
an appropriate crimp tool as shown in Figure 7.
Figure 7: Connect VBATT (Red) Wire to Add-a-Circuit Device
4) On the vehicle’s fuse panel, locate one spare fuse position which has constant 12V
(battery) and one spare fuse position which has “switched” 12V (only live with ignition
and accessory) using a DMM or 12V “circuit tester”. Refer to vehicle owner’s manual or
service manual, if necessary.
5) Disconnect the vehicle’s negative battery terminal.
6) Remove fuse and install the “add-a-circuit” into the fuse position with constant 12V as
found in step 4. The fuse removed from the panel should be installed into the
“add-a-circuit” in the lower position (10A or less ONLY), and one of the 3A fuses included
in the kit should be installed in the upper position (opposite the wire and crimp) as
shown in Figure 8.
Figure 8: Add-a-Circuit Device – Fuse Insertion
CAUTION: The spare circuits chosen should not be fused for greater than 10A.
Connect the VBATT (red) wire
on the AMG wiring harness
Crimp the wire into the
pre-installed butt connector
using an appropriate crimp
tool
The fuse removed from the
panel should be installed into
the “add-a-circuit” in the lower
position (10A or less ONLY)
One of the 3A fuses included
in the kit should be installed in
the upper position (opposite
the wire and crimp)

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 9
7) Connect the Ignition Sensor (IGN_SEN - brown) wire on the AMG wiring harness to
the other “add-a-circuit” fuse holder (JHFUSE-14) included in the kit, using the
pre-installed butt connector and an appropriate crimp tool as shown in Figure 9.
Figure 9: Connect IGN_SEN (Brown) Wire to Add-a-Circuit Device
8) Remove fuse and install the “add-a-circuit” into the “switched” 12V fuse position found
in step 4. The fuse removed from the panel should be installed into the “add-a-circuit” in
the lower position (10A or less ONLY), and one of the 3A fuses included in the kit should
be installed in the upper position (opposite the wire and crimp) as shown in Figure 10.
Figure 10: 4 Add-a-Circuit Device – Fuse Insertion
9) Attach the ring terminal of the GND1 (long black) wire to a good chassis ground point
inside the cab. These can usually be found near the fuse panel and/or stereo.
Alternatively, the shorter GND2 wire can be used if there is a chassis ground point close
to the AMG.
10)The remaining wires on the harness are not used. They can be bundled together and
tucked out of the way.
11)Plug Molex 8-pin connector into AMG.
12)Re-connect negative battery cable.
Connect the IGN_SEN (brown)
wire on the AMG wiring harness
Crimp the wire into the
pre-installed butt connector
using an appropriate crimp
tool
The fuse removed from the
panel should be installed into
the “add-a-circuit” in the lower
position (10A or less ONLY)
One of the 3A fuses included
in the kit should be installed in
the upper position (opposite
the wire and crimp)

10 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


5.0 Mounting the Unit
Once the AMG is connected to the Molex 8-pin connector as well as the Deutsch 4-pin
connector, the AMG base unit may be secured to the vehicle. An AMG is properly secured
when:
• It cannot be easily moved or jostled around
• The backpack antenna remains horizontal, with a clear line-of-sight to the sky. The
backpack antenna needs to be secured also if it has been unscrewed from the AMG.
• The 4 lights on the AMG are visible so that proper operation of the AMG may be
confirmed.
• No wires are loose or unsecured.
Securing the unit using Screws (preferred)
The unit may be secured to the vehicle using two #8 Pan Head Screws with a maximum
head diameter of 0.325". The recommended maximum torque is 6.0 in-lbs. If holes are to
be pre-drilled, space them 6 inches apart as shown in Figure 11.
Figure 11: Securing the AMG base unit using Screws
Area of the vehicle to
anchor AMG unit
#8 Pan Head Screw
Head diameter 0.325" max.
Maximum torque 6.0 in-lbs
#8 Pan Head Screw
Head diameter 0.325" max.
Maximum torque 6.0 in-lbs
6.80”
1.85”
1.80”
4.03” 3.65”
6.00”
0.175”

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 11
Securing the unit using Zip Ties
The unit may be secured to the vehicle using two zip ties as shown in Figure 12. Note that
the zip ties should be positioned inside the zip tie fences on the AMG base unit enclosure.
Figure 12: Securing the AMG base unit using Zip Ties
6.0 Mounting the Antenna
The external aerodynamic antenna mounts outside the vehicle cab (generally on the roof).
For optimal reception, the antenna should be mounted on a horizontal metal surface as
shown in Figure 13 but not be obstructed by surrounding metal objects. The mounting
surface should be no thicker than ¼”. To mount the antenna, a hole ¾” in diameter must be
drilled or punched into the surface. For roof mounts, remove any material on the underside
of the cab before creating the hole. In order to secure the antenna mounting, it is necessary
to also have access to the underside of the hole (normally inside the cab). The gasket
attached to the underside of the antenna acts as a moisture seal which prevents moisture
from entering the vehicle.
To attach the antenna, first remove the nut. Feed the cables through the hole, seat the
antenna on the surface, and then reattach the nut. The nut should be tight (5 ft. lbs. max) in
order to properly seal the gasket. Tighten the nut with a wrench. For unforeseen conditions,
silicone may be added around the base of the antenna. Finally, feed the cables to the AMG
inside the cab.
The weight of the external antenna assembly (i.e., “with cable”) is 1.39 lbs (0.63 kg).
Area of the vehicle to
anchor AMG unit
Zip Tie fences prevent the
zip ties from slipping off side
Position Zip Tie on inner
side of fence
WARNING! The external antenna must only be used with the supplied cable [type=RF-195,
length=15 feet (4.5 meters), minimum attenuation=2.25dB] or similar cable with minimum
attenuation of 2.25dB. This is necessary to limit the antenna gain to no more than 3dBi in order to
comply with FCC part 24.
Note: If the underside of the threaded base bolt is exposed to the environment, a sealant is required.

12 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


Figure 13: External Antenna Mounting
External antenna mounting (cab exterior):
Mount this end facing up;
unobstructed by metal objects
Mount this side towards front of vehicle
Note: The gasket attached to
the underside of the antenna
acts as a moisture seal which
prevents moisture from
entering the vehicle.
** Remove any material on the underside
of the cab before creating the hole.
Vehicle
Roof
¼” max.
¾” diameter
** In order to secure the antenna mounting, it is necessary to also
have access to the underside of the hole (normally inside the cab).

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 13
7.0 Confirm AMG Operation
AMG operation can be confirmed via the AMG Diagnostics Page and/or the AMG Status
Lights. The AMG Diagnostics page provides a detailed summary of AMG operation and is
accessible using an IEEE 802.11b/g enabled PC. The AMG Status Lights are located on the
side of the AMG base unit.
AMG Operation is best confirmed by viewing the AMG Diagnostics Page. In the case
where an IEEE 802.11b/g enabled PC is not available, AMG operation will have to be
confirmed by viewing AMG status lights, however, the status lights provide no information
on the Ignition Sensor connection to the AMG.
Confirming AMG Operation via the AMG Diagnostics Page
Prerequisites:
• IEEE 802.11b/g enabled PC or laptop
• AMG IEEE 802.11b/g radio must be in adhoc mode (factory-default)
• AMG serial number of the unit to be checked must be known
Procedure:
Step 1 Start the truck and wait at least 90 seconds to allow the AGM unit to acheive a
steady operational state.
Step 2 Connect the PC or laptop to the AMG ad-hoc wireless network.
For Windows XP: In Control Panel->Network and Internet, click on "Connect to
a network" under the "Network and Sharing Center" heading. In the "Wireless
Network Connection" window, find the network name with the AMG serial number
"VCM-AMG-<Serial#>". Click on the name then click "connect".
Instructions for connecting to a wireless network will vary for other
operating systems.
Step 3 When prompted, enter the security key 55555.
Step 4 Using a web browser, navigate to the AMG Diagnostics page -- http://10.10.0.1
Step 5 Review the AMG Diagnostic page details as indicated in Figure 14.
Note: The Diagnostics page does not auto-update. Refresh the page to get an updated diagnostics
view.

14 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


Figure 14: AMG Diagnositics Page
Please note the following:
• GPS reception is not expected to be optimal inside the service bay; it may be
necessary to move the vehicle outside and give the GPS device a few minutes of
satellite tracking time in order to get its lock.
• A registered CDMA modem does not mean provisioned. Provisioning happens after
the modem is activated and is registered on a home network tower. Until the CDMA
modem is able to provision, it will not be able to establish an internet connection.
If the AMG Diagnostics page is not indicating the required status, please
call 1-877-955-3122 for installation assistance.
Once all of the required status indications have been confirmed on the AMG Diagnostics
page, re-install the dashboard.
Ensure that the AMG Serial Number shown here matches
the serial number of the unit currently being checked
The CAN bus will read as “No data” for light duty kit installations
The GPS antenna status MUST read
as “OK”
Either the GSM or CDMA
connection MUST read as
“Connected to the internet”
The GSM registration status MUST read as
“Registered on a cellular network”, otherwise
indicates a provisioning problem
The CDMA registration status MUST read as
“Registered on a cellular network”, otherwise
indicates a provisioning problem
If the brown Ignition Sensor wire (IGN_SEN) is connected, then this reading
MUST reflect the actual state of the ignition
The GPS signal status MUST read as “Valid”

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 15
Confirming AMG Operation via the AMG Status Lights
Procedure:
Step 1 Start the truck and wait at least 90 seconds to allow the AGM to acheive a steady
operational state. PWR, CELL, and DATA lights should begin to maintain a green
and blinking status within 90 seconds – the GPS LED may need a few minutes
longer.
Step 2 Confirm that all four lights on the AMG are green and blinking.
• If the “DATA” light is not green and blinking – confirm the connection to the
J1939 databus is completed as described in this guide.
• If “GPS” or “CELL” light is not green and blinking (i.e., unblinking amber), and
the vehicle is in a service bay, drive the vehicle outside with a clear line-of-sight
to the sky. If the vehicle is already outside, check the position of the backpack
antenna, making sure it is parallel to the ground and not obstructed by any
metal objects.
• If the “PWR” light is not green and blinking (i.e., all lights are off or PWR is
unblinking red), please recheck the power cables and connectors.
If all four AMG status lights are not green and blinking, please call
1-877-955-3122 for installation assistance.
Once all of the required status lights have been visually confirmed, re-install the dashboard.
8.0 Return the AMG Installation Form
Upon successful confirmation of AMG operation, record the Post-Installation Information on
the Installation Form located in AMG Kit and fax the completed AMG Installation form to
[phone].
Note: This procedure is not necessary if AMG operation has already been confirmed by viewing the
AMG Diagnostics page.

16 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


9.0 Safety & Regulatory Information
Document Conventions
This document uses the following special formats to emphasize key information. Be aware of
all warnings and cautions before you begin to use AMG1000ALx-VCM.
Safety Precautions
Read and follow the following safety instructions before installing or operating an
AMG1000ALx-VCM kit.
WARNING! Whenever you see this icon and heading, the associated text addresses or discusses a
critical safety or regulatory issue.
CAUTION: Whenever you see this icon and heading, the associated text discusses an issue which
could result in damage or abuse of the equipment. Carefully read and follow these instructions.
WARNING! Before installing or operating this equipment, read all safety, installation and operating
sections. Follow all instructions - failure to do so may result in damage to the unit or severe personal
injury. Retain this manual for future reference.

Avant d'installer ou d'opérer cet équipement, lisez, toutes les sections de sécurités, d'installations et
d'opérations. Gardez ce manuel comme source de référence. Suivez toutes instructions - si non, vous
risquez d'endommager la machine ou de vous blesser sérieusement.
WARNING! Servicing should not be attempted by the user. There are no user serviceable parts
inside. Refer all servicing to factory qualified personnel.

N'essayez, pas de réparer cet équipement vous même. Référez toutes revisions nécessaire au personnel
qualifié de la manufacture.
WARNING! Cleaning - Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

Le nettoyage - n'utilisez pas de nettoyeurs aérosols ou liquides. Utilisez un tissu humide pour nettoyer.
WARNING! Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD
damage occurs when electronic components are improperly handled and can result in complete or
intermittent failures. Always follow ESD-prevention procedures when you are working on an AMG base
unit or antenna. Ensure that the unit is electrically connected to an earth ground and wear a properly
grounded ESD-preventive wrist strap. If no wrist strap is available, ground yourself by touching the
metal part of the unit.
WARNING! The installation of your AMG device must comply with vehicle wiring standards and best
practices.
WARNING! Fuse-handling equipment must be used to remove or install fuses and shunts when the
terminals are energized. The tool must be insulated for the circuit voltage.
WARNING! Disconnect all power before installing or removing a chassis. Never assume that power
is disconnected from a circuit. Always check.
Note: Keep the chassis area clear and dust-free during and after installation.

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 17
Regulatory Notices
Federal Communications Commission (FCC) Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may
cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
occupational/controlled environment
The antenna(s) used for this transmitter must be installed to provide a separation distance
of at least 8” (20cm) from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
This transmitter is approved for use with the antennas supplied with this equipment.
Maximum Antenna gains (including cable loss) are:
AMG1021B Backpack Antenna: +1.6dBi (GSM 850) and +2.9dBi (PCS1900).
AMG1021A External Antenna: -1.0dBi (GSM 850) and -1.7dBi (PCS1900).
Use of different antennas is not permitted. Failure to comply will invalidate FCC rule
compliance.
Industry Canada Compliance
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
• This device may not cause interference, and
• This device must accept any interference, including interference that may cause
undesired operation of the device.
This device has been designed to comply with safety requirements for exposure to radio
waves (SAR) in accordance with RSS-102. This device should be installed and operated with
minimum distance 20cm between the equipment and your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
• L'appareil ne doit pas produire de brouillage, et
• L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement.
Note: Do not perform any action that creates a potential hazard to people or makes the equipment
unsafe.
CAUTION: To comply with Industry Canada RF exposure requirements, a minimum separation
distance of 8 inches (20 centimeters) is required between this antenna and all persons. 

Pour conformer aux conditions d’exposition RF d’Industry Canada, une distance minimum de séparation
de 20 centimètres est exigée entre l’antenne et toutes personnes.
WARNING! Changes or modifications not expressly approved by Vecima Networks Inc. could void
the user’s authority to operate the equipment.

18 AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide


Cet artifice a été conçu pour se plier à la sécurité les exigences pour l'exposition aux ondes
radioélectriques (SAR) dans conformité avec RSS-102. Cet artifice devrait être installé et fait
marcher avec la distance minimale 20 centimètres entre l'équipement et votre corps.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante.
This radio transmitter (IC: 2943A-AMG1020) has been approved by Industry Canada to
operate with the antenna types listed below with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not included in
this list, having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Le présent émetteur radio (IC: 2943A-AMG1020) a été approuvé par Industrie Canada pour
fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible
maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus
dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement
interdits pour l'exploitation de l'émetteur.
AMG1021B Backpack Antenna - Impedance: 50 Ohm Nom.; Maximum Gain, including cable
loss: -1.0dBi (GSM 850) and -1.7dBi (PCS1900).
AMG1021A External Antenna – Impedance: 50 Ohm Nom.; Maximum Gain, including cable
loss : +1.6dBi (GSM 850) and +2.9dBi (PCS1900).

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 19
INSTALLATION STANDARD: The buyer and/or installer agrees that it is fully experienced and
properly qualified to perform the installation work provided for herein, and that it is properly licensed,
equipped, organized and financed to perform such work. The buyer and/or installer will perform all
installation work in accordance with its own methods on a best efforts basis subject to compliance with
the instructions set out herein and in accordance with generally accepted professional standards. Failure
to do so will render the Vecima Network’s Inc. warranty null and void to the maximum extent allowed
under applicable law.
LIMITED LIABILITY: Vecima Networks Inc. shall not be liable to the buyer, installer or any third party
for any indirect or consequential loss or damages including, without limitation, loss of business or profits
whether arising under any indemnity or from negligence, breach of contract or otherwise. Vecima
Networks Inc. shall also not be liable if the installation and/or use of the product voids any other
warranty which the buyer, installer, and/or any third party benefits from, including but not limited to
vehicle manufacturer warranties. The buyer, installer, or any third party’s 's total recovery from Vecima
Networks Inc. shall not exceed the price the buyer has paid for the specific unit of product giving rise to
the claim.
USE IN CRITICAL MEDICAL SYSTEMS PROHIBITED: PRODUCTS SOLD BY VECIMA ARE
NOT DESIGNED, INTENDED OR AUTHORIZED FOR USE IN LIFE SUPPORT, LIFE
SUSTAINING, NUCLEAR, OR OTHER APPLICATIONS IN WHICH THE FAILURE OF SUCH
PRODUCTS COULD REASONABLY BE EXPECTED TO RESULT IN PERSONAL INJURY, LOSS
OF LIFE OR CATASTROPHIC PROPERTY DAMAGE. IF BUYER USES OR SELLS THE
PRODUCTS FOR USE IN ANY SUCH APPLICATIONS: (1) BUYER ACKNOWLEDGES THAT
SUCH USE OR SALE IS AT BUYER’S SOLE RISK; (2) BUYER AGREES THAT VECIMA IS NOT
LIABLE, IN WHOLE OR IN PART, FOR ANY CLAIM OR DAMAGE ARISING FROM SUCH USE;
AND (3) BUYER AGREES TO INDEMNIFY, DEFEND AND HOLD VECIMA HARMLESS FROM
AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES, COSTS, EXPENSES AND
LIABILITIES ARISING OUT OF OR IN CONNECTION WITH SUCH USE OR SALE. Furthermore,
this device (AMG1020) may cause interference to other radio devices operating in the frequency band
155.1525MHz to 155.1825MHz; this frequency band is typically used by 2 way radio devices licensed
for use in accordance with United States Code of Federal Regulations, Title 47, part 90, section 90.20 -
Public Safety Pool.
LAW AND VENUE: The validity and interpretation of these terms shall be governed by the laws of the
Province of British Columbia and Canada and any such dispute shall be submitted exclusively to the
British Columbia courts. The parties agree that any conflicts of laws provisions, where applicable, are
hereby excluded by this express agreement to attorn to the specified law and venue.
PERMISSION TO REPRODUCE: Except as otherwise specifically noted, the information in this
publication may be reproduced, in part or in whole and by any means, without charge or further
permission from Vecima Networks Inc., provided that due diligence is exercised in ensuring the accuracy
of the information reproduced; that Vecima Networks Inc. is identified as the source; and that the
reproduction is not represented as an official version of the information reproduced.
WARRANTY: Vecima Networks Inc. provides this guide without warranty of any kind, either implied or
expressed, including, but not limited to, the implied warranties of merchantability and fitness for a
particular purpose. Any representation(s) in this document concerning performance of Vecima Networks
product(s) are for informational purposes only and are not warranties of future performance, either
express or implied. Vecima Networks Inc. reserves the right to revise this publication and to make
changes in content from time to time without obligation on the part of Vecima Networks Inc. to provide
notification of such revision or change.
Vecima Networks Inc.
150 Cardinal Place
Saskatoon, SK, Canada S7L 6H8
Published in Canada.
Specifications subject to change without notice.

AMG1000ALx-VCM Light Duty/Passenger Vehicle Kit Installation Guide 20
Third Party Software License Agreement
License agreement information for third party software utilized in the FleetLynx™ AMG unit
may be obtained from the document located at
http://www.fleetlynx.net/PDF/amg_thirdpartynotification_ml_r03_sd.pdf
