OnCell G3100
Quick Installation Guide
Fourth Edition, April 2014
Overview
There are currently six models in the OnCell G3100 series of
IP-gateways: the OnCell G3110, OnCell G3150, OnCell G3110-HSPA,
and OnCell G3150-HSPA. The main difference between the models is
the serial interface type and cellular connection speed. The OnCell
G3100 industrial RS-232, RS-232/422/485 GSM/GPRS/EDGE, or
UMTS or HSPA IP gateways are some of the most affordable, secure,
and versatile products available in the cellular networking market
today. These gateways also provide remote access and TCP/IP
support, and can be configured over a network.
Package Checklist
Before Installing the OnCell G3100 IP gateway, verify that the
package contains the following items:
Standard Accessories
•Document & Software CD
•Omni 1 dBi rubber SMA antenna (OnCell G3100 model name:
ANT-CQB-ASM-01; OnCell G3100-HSPA model name:
ANT-WCDMA-ASM-1.5)
•Din-Rail Kit
•5-pin terminal block (screw type)
•10-pin terminal block (screw type)
•Product warranty statement
•Quick Installation Guide
Optional Accessories
•Power Adaptor: 1.2 A (or above) @ 12V
•DC power supply
•Power jack to terminal block cable
•Quad-band GSM/GPRS/EDGE antennas for OnCell
G3110/G3150 series (impedance = 50 ohms):
ANT-CQB-AHSM-00-3m: Omni 0dBi/10cm, magnetic SMA
antenna, 3 m
ANT-CQB-AHSM-03-3m: Omni 3dBi/25cm, magnetic SMA
antenna, 3 m
ANT-CQB-AHSM-05-3m: Omni 5dBi/37cm, magnetic SMA
antenna, 3 m
Note: Please notify your sales representative if any of the above
items are missing or damaged.
Hardware Introduction
Front Views
Rear View
OnCell
G3110/G3150
OnCell G3110-HSPA/
OnCell G3150-HSPA
Top View
Bottom Views
OnCell G3110/G3110-HSPA
OnCell G3150/G3150-HSPA
Side Views
Reset Button
Press the Rest button continuously for 5 sec to load factory defaults:
Use a pointed object, such as a straightened paper clip or toothpick,
to press the reset button. This will cause the Ready LED to blink on
and off. The factory defaults will be loaded once the Ready LED stops
blinking (after about 5 seconds). At this point, you should release
the reset button (the default IP is 192.168.127.254).
LED Indicators
The LED indicators on the front panel of the OnCell G3100 are
described in the following table.
LED
Name
LED
Color
LED Function
Power
Green
DC Power is active
Off
Power is off, or power error condition exists.
Data
Green
Serial Tx
Amber
Serial Rx
Off
Ethernet cable is disconnected.
GSM
Amber
GSM is connected.
Off
GSM is disconnected.
GRPS
Amber
GPRS is connected.
Off
GPRS is disconnected.
UMTS
Amber
UMTS is connected.
(OnCell G3100-HSPA only)
Off
UMTS is disconnected.
(OnCell G3100-HSPA only)
HSPA
Amber
HSPA is connected
(OnCell G3100-HSPA only)
Off
HSPA is disconnected
(OnCell G3100 HSPA only)
Ready Green
Steady on: Software Ready.
Blinking slowly (1 sec): The OnCell has been
located by the OnCell Search Utility.
Off
Power is off, or is booting up.
Fault Red
Steady on: Booting up, or IP fault.
Blinking slowly (1 sec): Cannot get an IP
address from the DHCP server
Off
Power is off, or there is no error condition.
Signal
(3 LEDs) Green
Number of lit LEDs indicates signal level
(at least 2 LEDs must illuminated for data
transmission)
Digital Input and Output
Six terminals on the terminal block are reserved for the I/O ports,
with 2 terminals used for each input, and 2 terminals used for each
output.
Digital Input—Digital ON and OFF determine which power input is
used:
•+13 to +30 V for state “1” (On)
•+3 to -30 V for state “0” (Off)
Digital Output—The default for the relay output (DOUT) is open,
indicating a normal condition. If the relay output (DOUT) is shorted,
it indicates an exception.
Adjustable pull high/low resistor for RS-485 Port
DIP switches on the bottom of the OnCell G3100 are used to set the
pull high/low resistor value for each serial port.
SW
1
2
3
Pull High
Pull Low
Terminator
ON
1 KΩ
1 KΩ
120 Ω
OFF
150 KΩ
150 KΩ
–
Hardware Installation Procedure
STEP 1: Open the SIM cover, and insert the SIM card in the SIM card
slot.
STEP 2: Connect the 12-48 VDC power adaptor to the OnCell G3100
and then plug the power adaptor into a DC outlet.
STEP 3: To configure the OnCell, use an Ethernet cable to connect
the OnCell directly to your computer’s Ethernet interface.
STEP 4: Connect the OnCell G3100’s serial Ethernet port to a serial
or Ethernet device.
Software Installation Information
The Document & Software CD contains the User’s Manual, OnCell
Search Utility, and OnCell Driver Manager. Insert the CD and follow
the on-screen instructions. Please refer to the User’s Manual for
additional details on using the OnCell Search and Driver Manager.
Pin Assignments and Cable Wiring
DB9 Male Port Pinouts
Note that the OnCell G3110 only supports RS-232. The RS-422/485
pin assignments only apply to the OnCell G3150.
DB9 Male
Pin
RS-232
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
---

– 5 – – 6 – – 7 – - 8 -
www.moxa.com/support
The Americas:
[phone] (toll-free: 1-888-669-2872)
Europe:
[phone]
Asia-Pacific:
[phone]
China:
[phone] (toll-free: 800-820-5036)
2014 Moxa Inc. All rights reserved.
4W/2W RS-485/RS-422 (Terminal Block) Pinouts
Pin
RS-422/485
4-wire
RS-485
2-wire
1
TxD+(B)
---
2
TxD-(A)
---
3
RxD+(B)
Data+(B)
4
RxD-(A)
Data-(A)
5
GND
GND
Power Input and Relay Output Pinouts
PIN
Name
Function
1
V1+
DC Power input 1
2
V1-
DC Power input 1
3
V2+
DC Power input 2
4
V2-
DC Power input 2
5
Relay Output
6
Relay Output
7
I1
Digital Input
8
COM_1
Digital Input GND
9
I2
Digital Input
10
COM_2
Digital Input GND
Specifications
LAN Interface
Ethernet
10/100 Mbps, RJ45 connector
Protection
Built-in 1.5 KV magnetic isolation
Cellular Interface (for OnCell G3110 & G3150)
Standard Compliance
GSM/GPRS/EDGE
Band Selection
Quad-band 850/900 MHz, and 1800/1900
MHz
Tx Power
1 watt GSM 1800/1900, 2 watt EGSM
850/900
GPRS Multi-slot class
Class 12
GPRS Terminal Device
Class B
GPRS Coding Schemes
CS1 to CS4
SIM Control
3V
Cellular Interface (for OnCell G3110-HSPA & G3150-HSPA)
Data Rate
UMTS (DL: 384 Kbps, UL: 384 Kbps)
HSPA (DL: 14.4 Mbps, UL: 5.67 Mbps)
Standard Compliance
GSM/GPRS/EDGE/UMTS/HSPA
Band Selection
Five band 800/850/AWS/1900/2100 MHz
Quad-band 850/900/1800/1900 MHz
Tx Power
1 watt GSM1800,
2 watt GSM900,
0.25 watt UMTS/HSPA
0.5 watt EDGE900, 0.4 watt EDGE1800
GPRS Multi-slot class
Class 12
GPRS Terminal Device
Class B
GPRS Coding Schemes
CS1 to CS4
SIM Control
3V
Serial Interface
No. of Ports
1
Serial Standards
G3100: RS-232 (DB9 male connector)
G3150: RS-232 (DB9 male connector),
RS-422/485 (5-pin terminal block
connector)
Serial Communication Parameters
Parity
None, Even, Odd, Space, Mark
Data Bits
5, 6, 7, 8
Stop Bit(s)
1, 1.5, 2 (when parity = None)
Flow Control
RTS/CTS, XON/XOFF
Speed
50 bps to 921.6 Kbps
I/O Interface
Alarm Contact
1 relay output with current carrying
capacity of 1A@24 VDC
Digital Input
2 inputs electrically isolated from the
electronics
+13 to +30 V for state "1" (On)
+3 to -30V for state "0" (Off)
Power Requirements
Input Voltage
12 to 48 VDC
Data Link
400 mA (idle) to 900 mA (peak) @ 12 V
Environmental Limits
Operating temperature
Standard: -30 to 55°C (-22 to 131°F), 5 to
95% RH
Wide Temperature: -30 to 70°C (-22 to
158°F), 5 to 95% RH
Storage temperature
-40 to 75°C (-40 to 167°F)
Regulatory Approvals
EMC
CE Class A , FCC Class A, UL
Warranty
Warranty Period
5 years
