FLOS ROMEO SOFT T1 User manual

REV. 2
DATE 19/10/2021
1
ROMEO SOFT T1
Designed by Philippe Starck, 1998
F6107007
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.

EN
2
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
01. RF03203
–Romeo soft T1 cover ring
02. RF6100100
–Kit of silicone seats for cover ring
03. RF05286
–Fabric lamp shade
04. RF03201
–Acid-etched diffuser
05. RF6110200
–Contact rod small parts kit
06. RF05369
–S1/T1 bracket ring
07. RF04169
–E27 lamp holder
08. RF32262
– Led dimmer 1004P LFP100-240V 4-150WHL 4-25W
09. RF02813
–T1 grey support bracket
11. RF6138100
–Kit of transparent pads for base
ROMEO SOFT T1
F6107007
REV. 2
DATE 19/10/2021

EN
3
RF03203
ROMEO T1 COVER RING
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007

4
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
Fig.1
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
RF03203
ROMEO T1 COVER RING
R
Q
G
R
O
D
NQ
Position the fabric lamp shade (N) on the support ring (D) ensuring to insert the
hook threaded screws (R) into the apposite holes present in the support ring (D),
fasten the small bolts (Q).
Collocate the silicone seats in there apposite holes underneath the cover ring (O).
Rest the covering ring (O) on the pins (G).

EN
5
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
REV. 1
DATE 19/10/2021
RF6100100
KIT OF SILICONE SEATS FOR COVER RING
ROMEO SOFT T1 F6107007
Romeo
Soft F
p.05
Romeo
Soft T1
p.05

6
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
Fig.1
REV. 1
DATE 19/10/2021
RF6100100
KIT OF SILICONE SEATS FOR COVER RING
ROMEO SOFT T1 F6107007
R
Q
G
R
O
D
Q
N
Position the fabric lamp shade (N) on the support ring (D) ensuring to insert the hook threaded screws
(R) into the apposite holes present in the support ring (D), fasten the small bolts (Q).
Collocate the silicone seats in there apposite holes underneath the cover ring (O).
Rest the covering ring (O) on the pins (G).

EN
7
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF05286
FABRIC LAMP SHADE
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007

8
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/10/2021
RF05286
FABRIC LAMP SHADE
ROMEO SOFT T1 F6107007
D
P
M
L
Fig.1
Place the glass shade (P) on the support ring (D).
Rest the covering ring (M) on the internal glass diffuser (L).

9
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/10/2021
RF03201
ACID-ETCHED DIFFUSER
ROMEO SOFT T1 F6107007
Romeo
Soft T1
p.09
Romeo
Moon T1
p.07

10
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
Fig.1
REV. 1
DATE 19/10/2021
RF03201
ACID-ETCHED DIFFUSER
ROMEO SOFT T1 F6107007
I
Remove the lamp bulb (I) if still present on the lamp device.

11
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/10/2021
Fig.2
RF03201
ACID-ETCHED DIFFUSER
ROMEO SOFT T1 F6107007
Insert the diffuser (H).
H

12
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/10/2021
RF03201
ACID-ETCHED DIFFUSER
ROMEO SOFT T1 F6107007
Insert the lamp-bulb (I).
Fig.3
I

13
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/10/2021
RF03201
ACID-ETCHED DIFFUSER
ROMEO SOFT T1 F6107007
Fig.4
Place the glass shade (P) on the support ring (D).
Rest the covering ring (M) on the internal glass diffuser (L).
P
D
M
L

EN
14
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF6100200
KIT OF SCREWS/BOLTS FOR ROMEO
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
Romeo
Moon F
p.12
Romeo
Soft F
p.12
Romeo
Moon T1
p.12
Romeo
Soft T1
p.14

15
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Rest the support ring (D) on the support brackets (E) and lock it by fastening it with the screws (F).
EN
Fig.1
E
F
D
RF6100200
KIT OF SCREWS/BOLTS FOR ROMEO
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007

16
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Position the fabric lamp shade (N) on the support ring (D) ensuring to insert the hook threaded screws
(R) into the apposite holes present in the support rind (D), fasten the small bolts (Q).
Rest the covering ring (O) on the pins (G).
EN
Fig.2
RF6100200
KIT OF SCREWS/BOLTS FOR ROMEO
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
R
Q
G
R
O
D
Q
N

EN
17
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF05369
SUPPORT RING
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
Romeo
Moon T1
p.16
Romeo
Soft T1
p.17

18
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Rest the support ring (D) on the support brackets (E) and lock it by fastening
it with the screw/pivots (F).
EN
Fig.1
E
F
D
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
RF05369
SUPPORT RING

19
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Insert the diffuser (H).
EN
Fig.2
H
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
RF05369
SUPPORT RING

20
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Insert the lamp-bulb (I).
EN
Fig.3
I
REV. 1
DATE 19/10/2021
ROMEO SOFT T1 F6107007
RF05369
SUPPORT RING
