We do Your Level Best We do Your Level Best




































Model: LD31 & LD32
DeltaSpan Submersible Level Transmitter
Quick Start
Warranty
Flowline warrants to the original purchaser of its products that such products will be
free from defects in material and workmanship under normal use and service in
accordance with instructions furnished by Flowline for a period, which is equal to the
shorter of one year from the date of purchase of such products or two years from the
date of manufacture of such products. Flowline's obligation under this warranty is
solely and exclusively limited to the repair or replacement, at Flowline's option, of the
products or components, which Flowline's examination determines to its satisfaction to
be defective in material or workmanship within the warranty period. Flowline must be
notified pursuant to the instructions below of any claim under this warranty within thirty
(30) days of any claimed lack of conformity of the product. Any product repaired or
replaced under this warranty will be warranted only for the remainder of the original
warranty period.
Returns
Products cannot be returned to Flowline without Flowline's prior authorization. To
return a product that is thought to be defective, go to www.flowline.com, and submit a
customer return (MRA) request form and follow the instructions therein. All warranty
and non-warranty product returns to Flowline must be shipped prepaid and insured.
Flowline will not be responsible for any products lost or damaged in shipment.
Limitations
This warranty does not apply to products which: 1) are beyond the warranty period or
are products for which the original purchaser does not follow the warranty procedures
outlined above; 2) have been subjected to electrical, mechanical or chemical damage
due to improper, accidental or negligent use; 3) have been modified or altered; 4)
anyone other than service personnel authorized by Flowline have attempted to repair;
5) have been involved in accidents or natural disasters; or 6) are damaged during
return shipment to Flowline. Flowline reserves the right to unilaterally waive this
warranty and dispose of any product returned to Flowline where: 1) there is evidence
of a potentially hazardous material present with the product; or 2) the product has
remained unclaimed at Flowline for more than 30 days after Flowline has dutifully
requested disposition. This warranty contains the sole express warranty made by
Flowline in connection with its products. ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED. The remedies of
repair or replacement as stated above are the exclusive remedies for the breach of
this warranty. IN NO EVENT SHALL FLOWLINE BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY KIND INCLUDING PERSONAL OR
REAL PROPERTY OR FOR INJURY TO ANY PERSON. THIS WARRANTY
CONSTITUTES THE FINAL, COMPLETE AND EXCLUSIVE STATEMENT OF
WARRANTY TERMS AND NO PERSON IS AUTHORIZED TO MAKE ANY OTHER
WARRANTIES OR REPRESENTATIONS ON BEHALF OF FLOWLINE. This warranty
will be interpreted pursuant to the laws of the State of California. If any portion of this
warranty is held to be invalid or unenforceable for any reason, such finding will not
invalidate an
y
other
p
rovision of this warrant
y
.
Technical Support
For complete product documentation, video training, and technical
support, go to www.flowline.com.
For phone support, call 562-598-3015 from 8am to 5pm PST, Mon - Fri.
(Please make sure you have the Part and Serial number available.)
Flowline Inc. 10500 Humbolt St, Los Alamitos, CA 90720
QS301031 Rev.B
©2011 Flowline, Inc.
All Rights Reserved
Made in USA 10500 Humbolt Street, Los Alamitos, CA 90720 USA
Tel: 562.598.3015 Fax: 562.431.8507 www.flowline.com


We do Your Level Best We do Your Level Best
We Do Your Level Best
The LD31 Series DeltaSpan consists of a piezoresistive sensing element, encased in
316 SS housing. Superior lightning and surge protection utilizing dual arrestor
technology, grounded to case, eliminates both power supply surges and lightning
ground strike transients. Bullet nose design protects diaphragm from damage.
The LD32 Series DeltaSpan consists of a piezoresistive sensing element, encased in
316 SS housing. It is perfect for wastewater and slurry applications with features to
protect the unit from these demanding applications. Superior lightning and surge
protection utilizing dual arrestor technology, grounded to case, eliminates both power
supply surges and lightning ground strike transients. Large diameter 316 SS
diaphragm seal is non-clogging and damage resistant to floating solids.
Both units come equipped with a 270-pound tensile strength, shielded, vented cable.
Ventilation tube in the cable automatically compensates for changes in atmospheric
pressure above the tank. The vent tube has a filter attached to the end that will block
particles, such as dust, dirt, and water droplets, from entering the tube.
This Quick Start includes everything you’ll need to get the DeltaSpan up and running.
For complete information, please refer to DeltaSpan documentation located at
www.flowline.com.
Compensated Temperature Range
LD31 0 to 140° F ( -18 to 60° C)
LD32 0 to 180° F ( -18 to 82 °C)
Pressure Range Max. Distance Measured
5 11.5’ / 3.5M
10 28’ / 7.4M
15 34’ / 10.5M
20 46’ / 14.0M
Electrical Installation
An external power supply delivering 13-30 VDC with minimum current
capability of 40 mA DC (per transmitter) is required to power the control
loop. The Current Output diagram (shown below) shows the connection of
the power supply, transmitter and receiver.
The maximum receiver load resistance (RLmax) for the DC power supply
voltage (Vsup) is expressed by the formula: RL Max = V sup - 13V
0.02A
Shielded cable should always be used for control loop wiring.
Maximum Loop Resistance is 850 ohms @ 30 VDC.
Troubleshooting
If you face any issues not addressed in this quick start, please refer to the
DeltaSpan Manual located on Flowline website at www.flowline.com.
Safety Concern
Where personal safety or significant property damage can occur due to a spill, the
installation must have a redundant backup safety system installed.
Welcome to the DeltaSpan Quick Start
The DeltaSpan Quick Start is meant to show some of the more common setup solutions
to getting the DeltaSpan up and running quickly. If you run into an issue that is not
addressed here or wish to install or set up with a non-standard configuration, please
address the DeltaSpan Manual or refer to the Flowline website at www.flowline.com.
Current Output

