Flowserve Limitorque MX-40 User manual

Experience In Motion
USER INSTRUCTIONS
Limitorque MX
Electronic Actuator
FCD LMENIM2314-00 – 07/08
Maintenance
and Spare Parts
Swanson Flo | 800-288-7926 | www.swansonflo.com

Swanson Flo | 800-288-7926 | www.swansonflo.com

i
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
Contents
1 Introduction 1
1.1 Premise 1
1.2 Procedure Emphasis 1
1.3 Important Notes and Warning Statements 1
1.4 Reference Documents 2
2 MX Actuator Subassembly 3
2.1 MX Actuator Subassembly Components 4
2.1.1 Product Description 4
2.1.2 Storage 4
2.1.3 Unit Weights 5
2.2 Product Identification 5
2.2.1 Initial Inspection and Recording Suggestions 5
2.3 Maintenance 6
2.3.1 Recommended Maintenance 6
2.3.2 Unit Lubrication 6
2.3.3 O-Ring and Lubrication 8
2.4 Subassembly Removal and Remounting Procedures 8
2.5 How to Order Replacement Subassemblies 9
2.5.1 Replacement Parts 9
2.5.2 Return Procedure 9
3 Remove Actuator from Mounting Adapter 11
3.1 Actuator Removal with Type B1/B4/B4E Base (Torque) 11
3.1.1 Removal (Type B1/B4/B4E Base) 11
3.1.2 Remounting (Type B1/B4/B4E Base) 12
3.2 Actuator Removal with Type A1/A1E Base (Thrust) 14
3.2.1 Removal (Type A1/A1E Base) Actuator Removal Separate from Thrust Base 14
3.2.2 Remounting (Type A1/A1E Base) Actuator Remounting Separate from Thrust Base 15
3.2.3 Removal (Type A1/A1E Base) Actuator and Thrust Base as a Unit 17
3.2.4 Remounting (Type A1/A1E Base) Actuator and Thrust Base as a Unit 18
4 Mechanical Assemblies 19
4.1 Motor 19
4.1.1 Removal 20
4.1.2 Remounting 21
4.1.3 Removal and mounting of MX-140 motor (40 RPM and greater) 22
4.1.4 Remounting 23
4.1.5 Mounting of MX-150 motor 23
4.2 Declutch 25
4.2.1 Removal 27
4.2.2 Remounting 29
4.3 Top-Mounted Handwheel (MX-05, -10, -20, and -40) 32
4.3.1 Removal 33
4.3.2 Remounting 33
4.4 Side-Mounted Handwheel Without Spur Gear Attachment (MX-10, -20, -85, -140, and -150) 35
4.4.1 Side-Mounted Handwheel Without Spur Gear Attachment (MX-85, -140, and -150) 36
4.4.2 Removal of Side-Mounted Handwheel (MX-10, -20, -85, -140, and -150) 37
4.4.3 Removal 37
4.4.4 Remounting 39
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
ii
4.5 Side-Mounted Handwheel With Spur Gear Attachment (MX-40, -85, -140, and -150) 40
4.5.1 MX-85, -140, and -150 Handwheel with SGA 41
4.5.2 Removal of Handwheel 42
4.5.3 Removal 42
4.5.4 Remounting 45
4.6 Converting Top-Mounted Handwheel to Side-Mounted Handwheel (MX-10, -20, and -40) 50
4.6.1 Removing Top-Mounted Handwheel 50
4.6.2 Installing Side-Mounted Handwheel 51
4.7 Thrust Base Type A1/A1E 53
4.7.1 Removal 56
4.7.2 Remounting 56
4.8 Torque Base Type B1 57
4.8.1 Removal 58
4.8.2 Remounting 58
4.9 Baseplate Type B4 59
4.9.1 Removal 60
4.9.2 Remounting 62
4.10 Worm Shaft 63
4.10.1 Removal 64
4.10.2 Remounting 65
4.11 Drive Sleeve (MX-05 and -10) 67
4.11.1 Removal 68
4.11.2 Remounting 69
4.12 Drive Sleeve (MX-20, -40, -85, -140, and -150) 70
4.12.1 Removal 71
4.12.2 Remounting 73
4.12.3 MX-85, -140, and -150 Optional Drive Sleeve and Baseplate Removal 74
4.12.4 MX-85, -140, and -150 Optional Drive Sleeve and Baseplate Remounting 76
4.13 Handwheel Adapter (MX-05) 77
4.13.1 Removal 78
4.13.2 Remounting 79
4.14 Handwheel Adapter (MX-10, -20 and -40)/Handwheel Worm Gear (MX-10, -20, -40, -85, -140, and -150) 81
4.14.1 Removal 83
4.14.2 Remounting 84
4.15 Clutch and Clutch Ring Components (MX-20, -40, -85, -140, and -150) 87
4.15.1 Removal 88
4.15.2 Remounting 89
5 Electronic Assemblies 93
5.1 Control Panel (CP) 93
5.2 Control Module 94
5.2.1 Removal 95
5.2.2 Remounting 98
5.2.3 Fuse Replacement 101
5.2.4 Control Module Return Options 102
5.2.5 EPROM Care and Replacement 102
Swanson Flo | 800-288-7926 | www.swansonflo.com

iii
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
5.3 Installation and Removal of SMT Controls
(most units supplied after September 2003 and before September 2007) 105
5.3.1 Installation 105
5.3.2 Removal 108
5.3.3 Fuse Replacement 108
5.3.4 Control Module Return Options 108
5.4 Mounting of SMT Controls with 54-point terminal block and four LED configuration
(some units supplied from December 2006 with majority after September 2007) 109
5.4.1 Installation 109
5.4.2 Removal 110
5.5 Mounting of Standard and Optional Controls with 54-point terminal block and four LED configuration 111
5.5.1 Installation 111
5.5.2 Removal 114
5.6 Adding Electronic Options to Your MX Actuator(Most Supplied After September 2007) 114
5.7 Restoring Power to Actuator with New Control Module 115
5.8 Terminal Block (prior to March 2007) 115
5.8.1 Removal 116
5.8.2 Remounting 118
5.9 MX Terminal Block (Supplied With Most Actuators Since March 2007) 120
5.9.1 Terminal Block Shield Installation 120
5.10 Control Module-Contactor Assembly (Not required for most actuators shipped after September 2007.
Please see Section 5.4 for power board installation with contactor.) 121
5.10.1 Removal 122
5.10.2 Remounting 123
5.11 Replacing 19 Amp Reverser on the MX-140 and -150 (Not for most actuators shipped after September 2007) 125
5.12 19 Amp Power Assembly for Units Shipped After September 2007 128
5.13 Encoder (Through hole and surface mount technology, most units prior to September 2007) 129
5.13.1 Removal 130
5.13.2 Remounting 132
5.14 Encoder Drive Cartridge (Most units prior to September 2007) 133
5.14.1 Removal 134
5.14.2 Remounting 135
5.15 Removal and Replacement of MX Encoder (Supplied With Most Actuators Since September 2007) 136
5.15.1 Removal 137
5.15.2 Remounting 137
5.16 Encoder Drive Cartridge (Supplied With Most Actuators Since September 2007) 138
5.16.1 Removal 139
5.16.2 Remounting 140
5.17 Motor Lead Harness (MX-85, -140, and -150) 141
5.17.1 Removal 141
5.17.2 Remounting 142
5.18 Solid State Motor Reverser Upgrade Instructions (Most units prior to September 2007) 143
5.18.1 Disassembly Procedure 144
5.18.2 Assembly Procedure 145
5.19 Mounting of SSMR (Solid State Motor Reverser) in units shipped after February 2008 147
5.20 Complete Conversion to SMT Controls 149
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
iv
Figures
Figure 2.1 – Typical MX Actuator 3
Figure 2.2 – MX Nameplate 5
Figure 2.3 – Oil Fill/Plug Locations (MX-05 through -40) 7
Figure 2.4 – Oil Fill and Drain Locations (MX-85, -140, and -150) 7
Figure 4.1 – Motor (MX-05, -10, -20, and -40) 19
Figure 4.3 – Motor, Support Plate and Adapter (MX-150) 24
Figure 4.4 – Declutch (MX-05 and -10) 25
Figure 4.5 – Declutch (MX-20 and -40) 26
Figure 4.6 – Declutch (MX-85, -140, and -150) 27
Figure 4.7 – Top-Mounted Handwheel (MX-05, -10, -20, and -40) 32
Figure 4.8 – Side-Mounted Handwheel (MX-10 and -20) 35
Figure 4.9 – Side-Mounted Handwheel (MX-85, -140, and -150) 36
Figure 4.10 – Side-Mounted Handwheel with SGA (MX-40) 40
Figure 4.11 – Side-Mounted Handwheel With SGA (MX-85, -140, and -150) 41
Figure 4.12 – Type A1 Thrust Base (MX-05, -10, -20, and -40) 53
Figure 4.13 – Type A1 Thrust Base (MX-85) - F16 Flange 54
Figure 4.14 – Type A1 Thrust Base (MX-85, -140, and -150) - F25 Flange 55
Figure 4.15 – Type B1 Torque Base (MX-05, -10, -20, and -40) 57
Figure 4.16 – Type B4 Baseplate (MX-05, -10, -20, and -40) 59
Figure 4.17 – Type B4 Baseplate (MX-85, -140, and -150) 60
Figure 4.18 – Worm Shaft (MX-05, -10, -20, and -40) 63
Figure 4.19 – Drive Sleeve (MX-05 and -10) 67
Figure 4.20 – MX-20 and -40 Drive Sleeve 70
Figure 4.21 – MX-85, -140, and -150 10:1 and 13:1 ratios 71
Figure 4.22 – Handwheel Adapter (MX-05) 77
Figure 4.23 – Handwheel (MX-05) 77
Figure 4.24 – Handwheel Adapter Assembly 81
Figure 4.25 – Handwheel Worm Gear Assembly 82
Figure 4.26 – MX-20 and -40 Clutch and Ring Components 87
Figure 4.27 – MX-85, -140, and -150 Clutch and Ring Components 87
6 Spare and Replacement Parts 150
6.1 Guidelines for Recommended Spare Parts 150
6.1.1 Wear Components 150
6.1.2 Bearings, O-rings, and Seals 150
6.1.3 Critical Components 151
6.2 Recommended Spare Parts for MX Actuators 151
6.2.1 Commissioning and Startup 151
6.2.2 Short-Term Duty 151
6.2.3 Long-Term Duty 151
6.2.4 Severe Duty 152
6.3 Other Concerns 152
7 Regulatory Information 154
7.1 Declaration of Conformity 154
Swanson Flo | 800-288-7926 | www.swansonflo.com

v
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
Figure 4.28 – MX-85, -140, and -150 Clutch Ring 90
Figure 5.1 – Control Panel 93
Figure 5.2 – Control Module 94
Figure 5.3 – Location of Fuses and Voltage Jumper 101
Figure 5.4 – LCS Board 102
Figure 5.5 – Main CPU Board 102
Figure 5.6 – Power Board 103
Figure 5.7 – DDC Board 103
Figure 5.8 – Location of Fuses and Voltage Jumper 108
Figure 5.9 – SMT Controls with four LEDs 109
Figure 5.10 – Option Board Assembly 113
Figure 5.11 – Restoring Power to Actuator with New Control Module 115
Figure 5.12 – Terminal Block 116
Figure 5.13 – Terminal Block 120
Figure 5.14 – Terminal Block Shield 120
Figure 5.15 – Control Module - Contactor Assembly and Wiring Diagrams 121
Figure 5.15 – (continued) 122
Figure 5.16 – Encoder 130
Figure 5.17 – Encoder Drive Cartridge 133
Figure 5.18 – Encoder 136
Figure 5.19 – Encoder Drive Cartridge 138
Figure 5.20 – Motor Lead Assembly 141
Figure 5.21 – Cutaway View of SSMR Controls Area 143
Figure 5.22 – Disassembly Procedure 144
Figure 5.23 – Solid State Reverser and Fuse Block Assembly Installation 145
Figure 5.24 – Control module reinstallation 146
Figure 5.25 – SSMR (Solid State Motor Reverser) 148
Tables
Table 2.1 – MX Actuator Subassembly Components 4
Table 2.2 – Unit weights 5
Table 2.3 – MX-05 and -10 Oil Capacities when using Oil Fill/Plug Ports 8
Table 4.1 – Motor Parts List 19
Table 4.2 – Motor Parts List 22
Figure 4.2 – Motor and Adapter (MX-140) 22
Table 4.3 – Motor Parts List 23
Table 4.4 – Declutch Parts List (MX-05 and -10) 25
Table 4.5 – Declutch Parts List (MX-20 and -40) 26
Table 4.6 – Declutch Parts List (MX-85, -140, and -150) 27
Table 4.7 – Top-Mounted Handwheel Parts List (MX-05, -10, -20, and -40) 32
Table 4.8 – Side-Mounted Handwheel Parts List (MX-10 and -20) 35
Table 4.9 – Side-Mounted Handwheel without Spur Gear Attachment Parts List (MX-85, -140, and -150) 36
Table 4.10 – Side-Mounted Handwheel Parts List (MX-40) 40
Table 4.11 – Side-Mounted Handwheel Parts List (MX-85, -140, and -150) 41
Table 4.12 – Type A1 Thrust Base Parts List (MX-05, 10, -20, and -40) 53
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
vi
Table 4.13 – Type A1 Thrust Base Parts List (MX-85) 54
Table 4.14 – Type A1 Thrust Base Parts List (MX-85, -140, and -150) - F25 Flange 55
Table 4.15 – Type B1 Torque Base Parts List (MX-05, -10, -20, and -40) 57
Table 4.16 – Type B4 Baseplate Parts List 59
Table 4.17 – Worm Shaft Parts List 63
Table 4.18 – Drive Sleeve Parts List (MX-05 and -10) 67
Table 4.19 – Drive Sleeve Parts List (MX-20, -40, -85, -140, and -150) 70
Table 4.20 – Handwheel Adapter Parts List (MX-05) 77
Table 4.21 – Handwheel Adapter Assembly Parts List 81
Table 4.22 – Handwheel Worm Gear Assembly Parts List 82
Table 4.23 – Clutch and Clutch Ring Components Parts List 87
Table 4.24 – Clutch Ring Assembly Parts List 90
Table 5.1 – Control Panel Parts List 93
Table 5.2 – Control Module Parts List 94
Table 5.3 - Voltage Jumper Positions 109
Table 5.4 - Control Board Connectors 112
Table 5.5 - Screw Part Numbers 113
Table 5.5 – Terminal Block Parts List 115
Table 5.7 – Terminal Block Parts List 120
Table 5.8 – Control Module-Contactor Assembly Parts List 121
Table 5.9 – 19 Amp Power Assembly 128
Table 5.10 – Encoder Parts List 129
Table 5.11 – Encoder Drive Sleeve Speed (RPM) 130
Table 5.12 – Encoder Drive Cartridge Parts List 133
Table 5.13 – Encoder Drive Cartridge Drive Sleeve Speed 133
Table 5.14 – Encoder Parts List 136
Table 5.15 – Encoder Drive Sleeve Speed (RPM) 136
Table 5.16 – Encoder Drive Cartridge Parts List 138
Table 5.17 – SSMR Upgrade Kit Parts List 143
Table 5.18 – SSMR Motor Fuse Table 145
Table 5.19 - SSMR Parts List 147
Swanson Flo | 800-288-7926 | www.swansonflo.com

1
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
1 Introduction
1.1 Premise
The Flowserve Limitorque MX actuator components are separated into subassembly groupings. This
manual covers the removal and remounting procedures for each subassembly group. Use these instruc-
tions when disassembly is required for service, maintenance, or parts replacement.
1.2 Procedure Emphasis
Please refer to the following methods used to emphasize text throughout this manual. Safety warnings,
cautions, and notes present material that is important to user safety. Be sure to read any safety notices
you see, as they could prevent equipment damage, personal injury, or even death to you or a co-worker.
Safety notices are presented in this manual in three forms:
c WARNING: Refers to personal safety. Alerts the user to potential danger. Failure to follow
warning notices could result in personal injury or death.
aCAUTION: Directs the user’s attention to general precautions that, if not followed, could result in
personal injury and/or equipment damage.
NOTE: Highlights information critical to the user’s understanding of the procedure.
Bold text stresses attention to the details of the procedure.
1.3 Important Notes and Warning Statements
Please read this Maintenance and Spare Parts Manual carefully and completely before attempting to
store or perform maintenance on your MX valve actuator. Further installation, setup, and operation
instructions are available in the Installation and Operation manual (LMENIM2306) located in the actuator
terminal compartment at shipment.
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
2
c WARNING: Be aware of electrical hazards within the actuator and high-pressure hazards of
the attached valve or other actuated device when installing or performing maintenance on
your MX actuator. Failure to observe these precautions could result in serious bodily injury,
damage to the equipment, or operational difficulty.
c WARNING: Do not manually operate actuator with devices other than installed handwheel
and declutch lever. Using additive force devices (cheater bars, wheel wrenches, pipe
wrenches, or other devices of this nature) on the actuator handwheel or declutch lever may
cause serious personal injury and/or damage to the actuator or valve.
1.4 Reference Documents
•Protection, Control and Monitoring features of MX Electric Actuators (Bulletin LMENTB2300)
•MX Control, Performance and Value in Multi-turn Electric Valve Actuators (Bulletin LMENBR2302)
•MX Installation Manual (Bulletin LMENIM2306)
The latest revisions to these documents are available on-line from Flowserve Limitorque’s website,
www.flowserve.com or at www.limitorque.com
Swanson Flo | 800-288-7926 | www.swansonflo.com

3
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
2 MX Actuator Subassembly
Figure 2.1 – Typical MX Actuator
1
3
4
14
9 10 13 8
7
6
5
2
11
NOTE: MX-05 with B4 base shown
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
4
2.1 MX Actuator Subassembly Components
Table 2.1 – MX Actuator Subassembly Components
No. Description
1Top-mounted handwheel
2Drive sleeve
3Worm shaft
4Motor
5Declutch lever
6Encoder
7Control panel (CP)
8Control module
9Optional bases
Thrust base type
• A1 = Standard thrust base
• A1E = Extended-reach thrust base
10 Baseplate-type B4 with stem nut options type:
• B4 = stem nut with variable bore and key
• B4E = extended-reach stem nut with variable bore and key
• BL = splined stem nut (SAE or Involute)
11 Handwheel adapter/handwheel worm gear
12 Side-mounted handwheel (not shown, but available for the MX-10, -20,-85, -140, and -150)
13 Encoder drive cartridge
14 Terminal block
2.1.1 Product Description
Your MX actuator controls the opening and closing travel of valves and other actuated devices. OPEN
and CLOSED limits are protected by an absolute encoder that provides optical sensing of valve position
and measures valve position in both motor and handwheel operation. No battery or backup power
supply is required. Output torque is derived from motor speed, temperature, and voltage. If the preset
torque is exceeded, the motor shuts off. As a result of this reliable and advanced protection technology,
all valve and other actuated devices are protected from potential damage from overload, improper
seating, and foreign obstructions.
A range of control and network options is available and can be easily added to the control capabilities
already available on a standard actuator. Contact your local Limitorque distributor or Limitorque sales
office for further information.
2.1.2 Storage
Storage Recommendations
Your MX actuator is double-sealed and weatherproof as shipped, providing all compartment covers and
cable entry plugs are left intact. Actuators should be stored in a clean, dry, protected warehouse until
ready for installation. If actuators must be stored outdoors, they should be stored off the ground, high
enough to prevent being immersed in water or buried in snow.
Swanson Flo | 800-288-7926 | www.swansonflo.com

5
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
If your unit incorporates a rising stem application, it may be shipped with a plastic cap over the drive
sleeve. If so, install a pipe plug or protective stem cover to protect the drive sleeve from possible
corrosion.
Preferred Storage Orientation
Your MX actuator should be stored with the motor and terminal compartment in the horizontal position
to obtain optimum service life.
2.1.3 Unit Weights
Table 2.2 – Unit weights
Unit lb. kg
MX-05 52 24
MX-10 65 29
MX-20 109 49
MX-40 133 60
MX-85 259 117
MX-140 300 136
MX-150 410 186
NOTE: Weights include stem nut and lubricant.
2.2 Product Identification
2.2.1 Initial Inspection and Recording Suggestions
Upon receipt of the actuator, several steps should be initially followed to ensure condition of equipment
and to establish proper record keeping.
1. After removing the actuator from the shipping carton or skid, thoroughly examine it for any physical
damage which may have occurred during shipment. If you note any damage, immediately report the
damage to the transport company and call Limitorque for further assistance.
2. A nameplate with important information is attached to each actuator. Record the following informa-
tion for use when you need to contact Limitorque with any questions about your actuator:
•Unit type/size
•Flowserve Limitorque order number
•Serial number
Figure 2.2 – MX Nameplate
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
6
2.3 Maintenance
2.3.1 Recommended Maintenance
Under normal operating conditions, the MX is a maintenance-free actuator. Therefore, for normal
applications, no formal actuator maintenance is required although visual inspection for oil leakage and
excessive noise is recommended every 1 million drive sleeve turns or every 3000 cycles. When condi-
tions are severe due to frequent operation or high temperatures, inspect the oil level and oil quality more
often. Replace any seals that permit oil leakage or water ingress. When installing pipe plugs, use PTFE
tape or paste to achieve a proper seal.
2.3.2 Unit Lubrication
Check for proper oil level every 1 million drive sleeve turns (reference Installation and Operation Manual
- Diagnostics Section to learn how to view drive sleeve turns data). Change oil every 6000 unit cycles or
if water or other foreign material is found during oil inspection.
Oil Level Inspection and Fill Criteria
(Reference Table 2.3 for oil capacities when mounted in varying positions)
•Actuator viewed in upright position (top-mounted handwheel up)
Oil level should be approximately 1 inch (25.4 mm) below the outer surface of the housing at the oil fill
port.
NOTE: Do not overfill with oil because oil will expand during actuator operation. Actuators are shipped
with an oil volume suitable for any mounting position. When checking the factory-supplied oil level,
excess oil may drain from the highest oil fill port due to the various mounting orientations of each
application.
•Actuator viewed in side-mounted position (terminal compartment up). Oil level should be up to the
bottom of the oil fill plug.
•Actuator viewed in all other positions than described previously should have the oil capacities
maintained. Fill through the highest oil fill port until the oil is at a level that will contact the bottom of
the pipe plug when installed in oil fill port.
Swanson Flo | 800-288-7926 | www.swansonflo.com

7
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
Figure 2.3 – Oil Fill/Plug Locations (MX-05 through -40)
t.9UPQNPVOUFE
IBOEXIFFMPJMDIFDLPJMmMM
t.9TJEFNPVOUFE
IBOEXIFFMPJMDIFDLPJMmMM
t0JMESBJOBMMVOJUT
t.9UPQNPVOUFE
IBOEXIFFMPJMDIFDLPJMmMM
t.9TJEFNPVOUFE
IBOEXIFFMPJMDIFDLPJMmMM
Figure 2.4 – Oil Fill and Drain Locations (MX-85, -140, and -150)
0JM1MVH
0JM1MVH
0JM1MVH
0JM1MVH
0JM1MVH
0JM1MVH
Lubrication Data
•Oil Specifications: MX actuators are oil-filled using Mobil SHC-632, which is a synthetic oil suitable for
ambient temperatures of -22°F to 250°F (-30°C to 120°C). For extreme low temperature conditions,
alternative lubricants are available - consult factory for further information.
Table 2.3 – MX-05 and -10 Oil Capacities when using Oil Fill/Plug Ports
Nominal Oil Capacities oz. liters
MX-05
10 0.3
MX-10
16 .05
MX-20
Top-mounted handwheel with handwheel up 38 1.1
Top-mounted handwheel with terminal compartment up 47 1.4
Side-mounted handwheel with terminal compartment up 43 1.3
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
8
MX-40
Top and side-mounted handwheel with handwheel up 40 1.2
Top-mounted handwheel with terminal compartment up 53 1.6
Side-mounted handwheel with terminal compartment up 53 1.6
MX-85, -140, and -150
All Configurations 192 5.7
2.3.3 O-Ring and Lubrication
O-rings and seals should be replaced any time an actuator is disassembled. Lubricate with a substance
that is compatible with Buna N seals.
2.4 Subassembly Removal
and Remounting Procedures
This manual divides each MX actuator subassembly into a Removal and Remounting procedure. Use
the following procedures to remove subassemblies for inspection, repair or replacement. Some subas-
semblies require prior subassembly removal before allowing the desired subassembly removal. Note
the First Remove instructions at the beginning of each subassembly removal procedure. Remove these
subassemblies first, and then remove the desired subassembly according to the instructions. Once
removed, evaluate subassembly components to determine requirement for a new subassembly. If a new
subassembly is required, see Section 2.5. Once components have been identified and replaced, remount
following the appropriate Remounting procedures.
2.5 How to Order Replacement Subassemblies
2.5.1 Replacement Parts
Replacement parts are sold in modular subassemblies; therefore, when part replacement is required,
order parts at the subassembly levels as shown in this manual. Parts may be ordered from your local
Limitorque representative (see www.flowserve.com) or direct from the factory:
Telephone: [phone]
Fax: [phone]
Swanson Flo | 800-288-7926 | www.swansonflo.com

9
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
Please have the following information, found on the actuator nameplate, available to help us facilitate
your order:
•Unit type/size
•Limitorque order number
•Serial number
2.5.2 Return Procedure
When parts are identified for warranty or other component replacement, a Return Material Authorization
(RMA) must be obtained from Flowserve. Contact factory for a RMA number (see contact information in
section 2.5.1). All returned parts must be accompanied by documentation with the following information
to obtain credit for returned goods:
•Return Material Authorization (RMA)
•Unit type/size
•Flowserve Limitorque order number
•Serial number
Return parts to the address listed below:
Limitorque Actuation Systems
5114 Woodall Road
Lynchburg, VA 24502
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
10
This page is intentionally blank.
Swanson Flo | 800-288-7926 | www.swansonflo.com

11
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
3 Remove Actuator
from Mounting Adapter
3.1 Actuator Removal with Type B1/B4/B4E Base (Torque)
3.1.1 Removal (Type B1/B4/B4E Base)
STEP 1
c WARNING: Hazardous Voltage! Turn off all power sources to actuator before
removing actuator from mounting plate. Power sources may include main power or
control power. If necessary, disconnect incoming power leads L1, L2, L3, and control
wiring from the terminal block.
Remove the bolts that secure the actuator
to the mounting adapter. If type B1 or B4E
base is used in addition to the standard type
B4 or B4E baseplate, you may leave the B1
base attached to the mounting adapter and
remove the actuator only. Or if required, you
may remove the bolts that mount type B1 base
to mounting adapter. This will allow actuator
removal along with optional B1 base.
1
Swanson Flo | 800-288-7926 | www.swansonflo.com

Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
12
STEP 2
c WARNING: Potential high-pressure vessel! Before disassembling your actuator,
ensure that the valve or other actuated device is isolated and is not under pressure.
Lift actuator from mounting adapter. 2
3.1.2 Remounting (Type B1/B4/B4E Base)
STEP 3
Ensure stem nut (#1-22) is secured inside
actuator drive sleeve with retaining ring
(#1-23). Lower the actuator onto the mating
component, making sure to align stem nut key
and keyway with mating component.
3
1-22
1-23
STEP 4
Ensure that the actuator and mounting adapter
flange mating holes are aligned correctly.
4
Swanson Flo | 800-288-7926 | www.swansonflo.com
