Fluidmaster EVERYTHING User manual

K-400H-038
‘THE EVERYTHING’TM
3˝ TOILET TANK REPAIR KIT
HOW-TO VIDEO
VISIT: FLUIDMASTER.COM
K-400H-038 PRODUCT PAGE
VIDEO
HELPFUL
TOOLS INCLUDED!
FRENCH - Page 23
*See back page for important product warnings and warranty information.

2
GETTING STARTED
PARTS OVERVIEW
PERFORMAX®FILL VALVE FLUSH VALVE
TOOLS
Rubber Washer (x2)
Stainless Steel Washer (x2)
Large Hex Nut (x2)
Stainless Steel Bolts (x2)
Locknut
Shank
Washer
Rell Tube
Tank Water Level
Adjustment Screw
Bowl Water Level Dial
Rell Clip
Red WrenchGreen Tool
Red Tank-to-Bowl Gasket
Overow Pipe
3” Universal Flapper
Locknut
Tank Lever

3
STEP 1: PREPARE TANK
SEE INSTRUCTION VIDEO ON WEBSITE FOR REFERENCE.
B: DRAIN WATER
Flush toilet to drain most of the water from tank.
FLUSH
A: TURN OFF WATER
HOW-TO VIDEO
VISIT: FLUIDMASTER.COM
K-400H-038 PRODUCT PAGE

4
STEP 2: REMOVE OLD PARTS
A: REMOVE CONNECTOR
Remove water supply connector from
bottom of ll valve by twisting con-
nector nut to the left.
B: REMOVE OLD LOCKNUT
Use green tool to twist locknut to the
left below tank to remove locknut from
ll valve.
C: REMOVE OLD FILL VALVE
Including rell tube, rell clip and
shank washer. Drain any excess
water into the back panel of
empty packaging by removing ll
valve from tank. (Pull ll valve up)
D: DISCONNECT
FLAPPER CHAIN
Towel
(Optional)
NOTE: Inspect water
supply connector. Replace it if
it is worn, or you don’t know
how old it is, to prevent ooding
and property damage.
Green Tool
Tank Lever

E: REMOVE TANK FROM BOWL
Use green tool to twist large hex nut to
the left and remove bolts from tank.
G: REMOVE GASKET
Remove tank-to-bowl gasket from
below the tank.
F: LAY TANK ON ITS SIDE
Place on a safe and secure surface.
H: REMOVE FLUSH VALVE
LOCKNUT
Using red wrench, twist locknut left
to remove. Remove old ush valve
from tank.
5
Screwdriver
(Optional)
Red Wrench
Green Tool
NOTE: Bolts can be
loosened from inside tank.

6
STEP 3: INSTALL FLUSH VALVE
NOTE: Do not cover tank bolt holes with ush valve. If ush valve covers
a bolt hole, turn ush valve slightly to the right (overow tube to the right)
to clear the bolt hole. In some cases, placing bolts in the holes rst may
be necessary.
A: INSERT FLUSH VALVE INTO TANK HOLE
Position overow pipe toward back of tank.

7
STEP 3: INSTALL FLUSH VALVE (CONTINUED)
B: USE RULER ON THE RED WRENCH TO MEASURE
AND ADJUST NEW FLUSH VALVE
Mark the ush valve 1” below bottom of tank lever hole.
NOTE: The top of the overow pipe must be at minimum of 1” below
the tank lever hole.
TOP OF
OVERFLOW PIPE
Overow
Pipe
Lever Hole 1"
BOTTOM OF
TANK LEVER HOLE
Adjusted
Height
C: ADJUST FLUSH VALVE HEIGHT
Twist to unlock, pull or push to correct
height, twist to lock in place.

8
STEP 4: INSTALL TANK-TO-BOWL GASKET
B: Apply red tank-to-bowl gasket to
bottom of ush valve locknut, fully
covering locknut.
Red Wrench
A: INSTALL LOCKNUT
Holding ush valve in place, turn right to screw locknut
onto bottom of ush valve and hand-tighten to secure. Use
red wrench to go ½ turn beyond hand-tight.
Do not overtighten.

9
STEP 5: SECURE TANK TO BOWL
A: INSTALL RUBBER WASHERS
Place one rubber washer on each
tank bolt.
B: INSERT BOLTS INTO TANK
Place tank bolts through bottom
holes of tank.
C: SECURE TANK ONTO BOWL
Set tank onto bowl. Place metal
washer and large hex nut on each
bolt under toilet bowl. Using green
tool, twist right to tighten hex nuts
evenly until tank is snug and does
not rock. Do not overtighten.
Rubber
washer
Rubber
washer
Tank
Metal washer
Large hex nut
Bowl
Green Tool

10
STEP 6: ADJUST FLAPPER
A: REMOVE FLAPPER
Remove apper from ush valve by
pulling the frame of the apper up one
side at a time.
B: ADJUST FOR MOST EFFICIENT FLUSHAdjust from
0 to 10 to nd the perfect ush for your setup.
Hint: The higher the number,
the longer the apper stays
open for more water ushed.
FLAPPER SETTINGS
AMERICAN STANDARD
CATO
ELJER
GERBER
GLACIER BAY
KOHLER
MANSFIELD
ST. THOMAS
PEGASUS
TOTO
VITRA
Cadet 3
Titan
Avalanche
2-Pc High Efficiency
Cimarron
Maverick
Arlington
Palermo
Westminster
Drake
Clayton
Vespin
Corina
8
8
0
6
3
1
5
0
6
9
6
0
6
5
SETTINGBRAND MODEL
Note: Flapper dial is pre-set to maximum setting (10). If toilet model
not listed, keep apper at
default setting 10.

11
STEP 7: ADJUST HEIGHT OF NEW FILL VALVE
A: TWIST FILL VALVE TO ADJUST HEIGHT
Top of ll valve cap should measure roughly 3”
above top of overow pipe when installed.
TWIST
LEFT
NOTE:
Increasing height allows
more water to ll in the tank.
HOLD
Do Not Move Lock Ring
**The top of the overow pipe must be a minimum of 1" below tank lever hole.
Fill Valve Cap
Overow Pipe
*Lever Hole
TOP OF FILL VALVE CAP
TOP OF
OVERFLOW PIPE
3"

12
STEP 8: INSTALL NEW FILL VALVE
A: PUSH REFILL TUBE
ONTO REFILL PORT
B: ATTACH REFILL CLIP
TO OTHER END OF
REFILL TUBE
Rell Clip
Rell Tube
C: INSERT FILL VALVE
Position rell tube to face ush
valve making sure ll valve parts
do not interfere with lever arm.
TOP
DOWN
VIEW
Rell Tube
Lever Arm
Overow
Pipe
Fill Valve

D: INSTALL LOCKNUT
Using green tool, twist right to
screw locknut onto ll valve shank
(below tank). Tighten 1/4” beyond
hand-tight.
Do Not Overtighten*.
E: ATTACH REFILL CLIP TO
OVERFLOW PIPE
Note: If rell tube is too long to t
inside tank with lid closed, remove
rell tube from ll valve rell port, cut
tube and reattach to port.
Scissors
(Optional)
STEP 8: INSTALL NEW FILL VALVE (CONTINUED)
13
*Overtightening may crack the ll valve or tank causing ooding. Make sure the oat cup
does not touch the tank walls or tank lever and ush valve.
Green Tool

14
If the removed tank lever is bent, proceed to Step A1 below. If the
lever is not bent then proceed to Step A2 below.
STEP 9: INSTALL LEVER & FLAPPER CHAIN
A1: FOR SIDE OR ANGLE MOUNT:
BEND NEW LEVER ARM
To bend lever, start bend 2” after 90
degree elbow until bend matches the old
lever. Do not bend arm quickly or back
and forth repeatedly.
A2: FOR FRONT MOUNT:
MEASURE LEVER ARM
Measure length of old lever
arm next to new lever arm. If
necessary, trim new arm (with
a hacksaw) at the cut line.
B: INSTALL LEVER
Slide lever through tank hole. Slip
locknut over lever arm (at side of nut
facing handle). Hand-tighten locknut
clockwise (reverse thread).
*Do not overtighten.
C: CONNECT FLAPPER CHAIN
Attach clip to the tank lever directly
above the apper. Leave roughly ½”
of slack (small ‘J’ shape) in the chain.
Mini Hack Saw
(Optional)
ONLY BEND
LEVER HERE

15
STEP 10: FINISHING STEPS
A: ATTACH WATER SUPPLY
CONNECTOR TO FILL VALVE
*Hand-tighten only. Do not overtighten.
B: TURN ON WATER
Check for leaks.
C: WATER LEVEL
After the tank stops lling, water level should ll the tank to
roughly ½” below top of overow pipe to ensure a proper ush.
(Does not need to be exact.)
1/2"
Overow Pipe
Top of
Overow Tube
Water Level
Lever Hole
* Overtightening may damage ll valve or coupling nut, potentially causing ooding.
Make sure the oat cup does not touch the tank walls or tank lever and ush valve.
**The top of the overow pipe must be a minimum of 1" below tank lever hole.

16
STEP 11: FINE-TUNE TANK WATER LEVEL
A: FLUSH THE TOILET TO
CHECK THE TANK WATER
LEVEL
After the water stops lling the
tank, the water level should be
roughly ½ inch below the top
of overow pipe to ensure a
proper ush.
B: WATER LEVEL IS TOO LOW
Turn the tank water level adjustment screw clockwise to
raise the oat. Flush to reset water level.
WATER LEVEL IS TOO HIGH
Turn the water level adjustment screw counterclockwise to
lower the oat. Flush to reset water level.
1/2"
Overow
Pipe
See Step 7A for Full Tank view.
Tank Water Level
Adjustment Screw
+
–

17
STEP 12: FINE-TUNE FLUSH
A: TEST FLUSH
Drop 3 squares of toilet paper in
bowl then ush.
MORE
WATER
FLUSHED
LESS
WATER
FLUSHED
B: ADJUST FOR MOST EFFICIENT FLUSH
Continue to adjust dial down one setting and ush until toilet
is unable to ush paper properly.
C: FINAL SETTING
Once unable to ush, adjust dial up one for nal setting.
Hint: The higher the number,
the longer the apper stays
open for more water ushed.
Note: Turn o water. Remove apper for easy adjustment (see Step 6).

18
STEP 13: FINE-TUNE BOWL WATER LEVEL
A: FILL BOWL WITH A GALLON OF WATER
Wait 1 minute until the bowl water level recedes
down and stops.
B: MARK THE WATER LEVEL IN THE BOWL
With a pencil, draw a line at the top of the water level
in bowl. (Pencil mark will easily wash o).
C: FLUSH TOILET TO CHECK BOWL
WATER LEVEL
If the water level matches the line you’ve made in
the bowl when the ll valve stops lling the tank,
the water level is correct, proceed to Step 13.
TOO HIGH
TOO LOW
If the water level matches the line in the bowl and the
ll valve is STILL FILLING, then the bowl water is
TOO HIGH, proceed to Step 12D.
If the valve shuts o and the water level does NOT
match the line in the bowl, the water level is TOO
LOW, proceed to Step 12D.
E: FLUSH TOILET,
CHECK BOWL WATER LEVEL
Repeat Steps 12D and 12E until water level in bowl
matches the line when the ll valve shuts o.
D: ADJUST THE BOWL WATER LEVEL
TOO HIGH:
Turn the dial clockwise.
TOO LOW:
Turn the dial counter-clockwise.
LESS WATER
MORE WATER

19
Still not working exactly right?
See the next page for Troubleshooting.
YOU DID IT!
We knew you could!
Share your success story
with friends and family!
#FixedMyToilet
#Fluidmaster
STEP 14: FLUSH THE TOILET
A: FLUSH THE TOILET
If you’re satised with the ush, YOU’RE DONE!

20
REPLACE FILL VALVE SEAL
• Place cap assembly on top of gray valve body by
aligning cap arm and adjustment rod next to rell tube.
• Press down on top cap while rotating top & arm clockwise to locked position.
A: Remove cap (see above).
B: Replace seal with a *genuine Fluidmaster
242 Seal.
C: Replace valve cap.
*Always use genuine Fluidmaster parts when installing or repairing. Fluidmaster will not be
responsible or liable for use of non-Fluidmaster parts during installation or repair.
TROUBLESHOOTING
IF THE FILL VALVE: • DOES NOT TURN ON
• WON’T TURN OFF
• WON’T REFILL TANK
REMOVE CAP AND CHECK FOR DEBRIS
A: Turn o water supply, then ush toilet.
B: With right hand push oat up, grip and
hold shaft under oat.
C: With left hand twist cap and lever arm
counterclockwise to unlock cap. Let cap
hang on oat cup.
D: Hold empty cup upside down over un-
capped valve to prevent splashing.
E: Turn water supply on and o a few times,
then leave it turned o.
F: Replace valve cap.
• Place cap assembly on top of gray valve
body by aligning cap arm and adjustment
rod next to rell tube.
• Press down on top cap while rotating top &
arm clockwise to locked position.
See Our Troubleshooting HOW-TO VIDEO
http://bit.ly/2yAdZn7
VIDEO
Seal
Cap
