Fluke PLS RBP5 User manual

1
Introduction
The RBP5 is a rechargeable battery pack for use with PLS point and
line laser levels.
To register your product or to view, print, or download the latest
manual or manual supplement, visit www.plslaser.com.
Charging: Solid RED
Fully charged: OFF
PN 5083921
01/2020, 6012642 A (English)
© 2020 Fluke Corporation. All rights reserved.
Specications are subject to change without notice.
All product names are trademarks of their respective companies.
RBP5
Rechargeable Battery Pack
Instructions

2
Safety Information
A Warning identies hazardous conditions and procedures that are
dangerous to the user.
Note
The product that uses the battery pack contains a laser.
The battery pack does not contain a laser.
*W Warning
To prevent eye damage and personal injury:
• Read all safety information before you use the RBP5.
• Carefully read all instructions.
• Do not alter the RBP5 and use only as specied, or the
protection supplied by the RBP5 can be compromised.
• Do not use the RBP5 if it operates incorrectly.
• Do not use the RBP5 if it is altered or damaged.
• Use the RBP5 only as specied or hazardous laser
radiation exposure can occur.
• Do not look into the laser. Do not point laser directly at
persons or animals or indirectly o󰀨 reective surfaces.
• Do not look directly into the laser with optical tools (for
example, binoculars, telescopes, microscopes). Optical
tools can focus the laser and be dangerous to the eye.
• Do not open the RBP5. Refer to PLS laser levels safety
information when operating the laser levels. The laser
beam is dangerous to eyes.
• Do not disassemble the battery.
• Repair the RBP5 before use if the battery leaks.
• Batteries contain hazardous chemicals that can cause
burns or explode. If exposure to chemicals occurs, clean
with water and get medical aid.
• The RBP5 battery pack must be properly installed to PLS
laser levels before operation.

3
• Remove the RBP5 if PLS laser level is not used for an
extended period of time, or if stored in temperatures above
50 °C. If RBP5 battery pack is not removed, battery leakage
can damage PLS laser level.
• Replace the RBP5 battery pack when the low battery indicator
of PLS laser level shows to prevent incorrect measurements.
• RBP5 battery pack can be charged while operating the
PLS laser level, but we do not specify charge time.
• Use only Fluke approved power adapters to charge the battery.
• Do not short the battery terminals together.
• Do not disassemble or crush battery cells and battery packs.
• Do not keep cells or batteries in a container where the
terminals can be shorted.
• Do not put battery cells and battery packs near heat or re.
Do not put in sunlight.
• Do not use the RBP5 around explosive gas, vapor, or in
damp or wet environments.

4
Symbols
The table below lists the symbols that can be used on the Product or
in this document.
Symbol Description
Consult user documentation.
WWARNING. RISK OF DANGER.
*WARNING. LASER RADIATION. Risk of eye damage.
Center positive power port.
PConforms to European Union directives.
Conforms to relevant Australian Safety and EMC
standards.
Conforms to relevant South Korean EMC standards.
Conforms to the Appliance E󰀩ciency Regulation (California
Code of Regulations, Title 20, Sections 1601 through 1608),
for small battery charging systems.
=
This product complies with the WEEE Directive marking
requirements. The a󰀩xed label indicates that you must
not discard this electrical/electronic product in domestic
household waste. Product Category: With reference to
the equipment types in the WEEE Directive Annex I, this
product is classed as category 9 “Monitoring and Control
Instrumentation” product. Do not dispose of this product as
unsorted municipal waste.
Indicates a Class 2 laser. DO NOT STARE INTO BEAM
The following text may appear with the symbol on the
product label: “IEC/EN 60825-1:2014. Complies with 21
CFR 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice 50, dated June 24, 2007.” In addition, the
following pattern on the label will indicate wavelength and
optical power: λ = xxxnm, x.xxmW.

5
Specications
Battery Lithium-ion, 3.6 V, 5200 mAh
Operating time (estimated) 12 to 100 hours
Charging time 6 to 8 hours (when removed from PLS laser)
Temperature
Operating -10 °C to 50 °C (14 °F to 122 °F)
Storage -20 °C to 50 °C (-4 °F to 122 °F)
Battery Charging 0 °C to 45 °C (32 °F to 113 °F)
Altitude
Operating 2000 m
Storage 12 000 m
Size (H x W x L) 106 mm x 64 mm x 30 mm
(4.2 in x 2.5 in x 1.2 in)
Weight 165 g (5.8 oz)
Safety IEC 62133
Electromagnetic Compatibility (EMC)
International
IEC 61326-1:
Basic Electromagnetic Environment
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio
frequency energy that is necessary for the internal function of the equipment itself.
Class A: Equipment is suitable for use in all establishments other than domestic
and those directly connected to a low-voltage power supply network that supplies
buildings used for domestic purposes. There may be potential diculties in
ensuring electromagnetic compatibility in other environments due to conducted
and radiated disturbances.
Emissions that exceed the levels required by CISPR 11 can occur when the
equipment is connected to a test object.
Korea (KCC)
Class A Equipment (Industrial Broadcasting &
Communication Equipment)
Class A: Equipment meets requirements for industrial
electromagnetic wave equipment and the seller
or user should take notice of it. This equipment is
intended for use in business environments and not to
be used in homes.
USA (FCC) 47 CFR 15 subpart B. This product is considered
an exempt device per clause 15.103.

6
LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and
workmanship for three years from the date of purchase. This
warranty does not cover fuses, disposable batteries, or damage from
accident, neglect, misuse, alteration, contamination, or abnormal
conditions of operation or handling. Resellers are not authorized
to extend any other warranty on Fluke’s behalf. To obtain service
during the warranty period, contact your nearest Fluke authorized
service center to obtain return authorization information, then send
the product to that Service Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR
THEORY. Since some states or countries do not allow the exclusion
or limitation of an implied warranty or of incidental or consequential
damages, this limitation of liability may not apply to you.
Fluke Corporation Fluke Europe B.V. ООО «Флюк СИАЙЭС»
P.O. Box 9090 P.O. Box 1186 125167, г. Москва,
Everett, WA 98206 5602 BD Eindhoven Ленинградский проспект дом 37,
U.S.A. The Netherlands корпус 9, подъезд 4, 1 этаж
11/99
