Fly Kan HDCAP01-M Instruction manual

HD Video Grabber
Quick User Guide
Model No.: HDCAP01-M
*Note: Not able to record HDCP content.
Version:1.0

The HD video grabber is designed to support capture 1920 x 1080 HD Video from 3840*2160@30Hz video
sources. It transfers audio/video between the grabber and your Windows 10 / 8 or macOS 10.12 or higher
version via USB port.
Packaging Contents
■1 x HD Video Grabber
■1x USB3.0 Cable
■1 x English Manual
System Requirements
■An available USB 2.0 / 3.0 port
■Windows 10, or Mac OS 10.15
Requirements
The HDCAP01-M does not support any HDCP protected video sources.
Windows OS
macOS
■CPU: Intel® Core™ i5
■DirectX 10.1 compatible GPU
■Windows® 10, 8 / 8.1
■Memory: 4 GB
■Intel CPU (PPC is not supported)
■OpenGL 3.2 compatible GPU
■macOS 10.12 or newer
■Memory: 4 GB
Features
■Requires no additional driver installation.
■Supports 3840*2160@30Hz input
■Max. capture resolution: 1920 x 1080 @ 30Hz @ JPEG mode (720p @ YUV mode)
■Compatible with UVC1.0 (Video)& UAC1.0 (Audio) protocol
■Captured Audio - Format: Stereo LPCM @ sampling rate 48Khz
■OS supported –Windows 8 / 10 and macOS 10.12 –10.15.4
Product Diagram
Interface A
Interface B
IN –Input Source
OUT –Connect device to display
Notice: Does not support HDCP.
USB –Connects to PC’s USB 2.0 / 3.0 port.
Get the Software and Install on PC
Visit https://obsproject.com and download the latest OBS according to your Windows OS 8 / 10.
You may find official guide on
https://obsproject.com/wiki/install-instructions#windows-install-directions

Hardware Installation
1. Connect USB Cable with computer and HD Video Grabber.
2. Connect HDMI Source to HDCAP01-M’s “IN”port. ( *Does not support HDCP.)
3. Connect Display with HDCAP01-M’s “OUT”port.
How to Find the System Device
At the Device Manager you can find:
+ Cameras –HDCAP01-M video
+ Sound, Video and Game controllers –HDCAP01-M audio

Run OBS and Make Configuration
1. Add your sources for video by adding “Video Capture Device”.
2. Settings on “Properties for Video Capture Device”
3. Set up your audio devices by adding “Audio input capture”.

4. Open Audio Monitoring
5. Starts the video capture by clicking “Start Recording”.
Specification
AV Input
HDMI (Max. : 3840*2160@30Hz)
AV Output
USB 2.0 / 3.0
Industry Standards
UVC1.0 / UAC1.0
Performance
Audio Specifications
2-CH Setereo Audio, LPCM, (32kHz,44.1KHz,48Khz)
Max. Captured Resolutions
1920*1080@30Hz
OS Compatibility
Windows® 8, 8.1, 10
MacOS® 10.12 to 10.15
Physical Characteristics
Color
Black
Product Dimension
10.2 x 6.2 x 1.6cm
Weight of Product
97g
Packaging Information
Package Dimension
15.5 x 13 x 2.4cm
Shipping (Package) Weight
185g
What’s In The Box
Included in Package
1 x Capture Device
1 x USB 3.0 Type A cable (0.5m)
1 x Manual
Trademarks & Brands
All of the products or name brands are trademarks of their respective holders.
