Fly sky Fs-r7p User manual

FS-R7P 接收机 Receiver

Http://www.󽗊ysky-cn.com

产品型号：FS-R7P

适配发射机：

FS-G7P（支持 ANT 协议的发射机 )

适配模型：车、船

PWM 通道数：7

无线频率：2.4GHz ISM

发射功率：<20dBm

天线类型：单天线

遥控距离： ≥ 300 米 ( 空旷无干扰地面距离 )

无线标准：ANT（蚂蚁版自动跳频数字系统）

通道分辨率：4096 级

数据输出：PWM/PPM/i-BUS/S.BUS

输入电源：3.5 ~ 9V/DC

在线更新：支持

温度范围：-10℃ ~ +60℃

湿度范围：20% ~ 95％

防水等级：PPX4

外形尺寸：35.0mm*23.3mm*13.3mm

机身重量：8.0g

认证：CE，FCC ID: 2A2UNR7P00

FS-R7P 是一款采用 ANT 通信协议，提供 7 通道的双向

接收机，外置单天线，输出 PWM 或 PPM/i-BUS/S.BUS

信号，设计小巧紧凑，可适配多种模型车和模型船使用。

FS-R7P based on ANT protocol is a receiver which provides seven channels

and bidirectional transmission. It has an external single antenna, can output

PWM or PPM/i-BUS/S.BUS signal. It has a compact design. It can be adapted

to a variety of model cars or boats.

产品介绍 Introduction

接收机概览 Overview

产品规格 Specications

[1] CH1/P

[2]-[5]CH2- CH5

[6] 对码接口

[7] BVD/VCC( 电池电压检测 / 供电接口 )

[8] CH7

[9]SERVO

[10]LED 指示灯

[11] 天线

[12] 对码按键

[13] 传感器接口

[14] CH6

[15] 信号端

[16] + ( 电源正极）

[17] - ( 电源负极）

[18] BVD 功能配件

[19] 接电池正极

[20] 接电池负极

接口介绍 Interface Introduction

对码 Binding

CH1~CH7：输出标准的 PWM 信号（CH1 接口，

还支持输出 PPM 信号）。连接舵机或其他各

部件；

BVD/VCC：BVD 电压检测时用于连接 BVD 功

能件 , 正常操作时用于连接电源线；

BIND：对码时用于连接对码线；

SENS：用于连接 i-BUS 传感器；

SERVO：支持 i-BUS/S.BUS 信号输出，支持

i-BUS 通道扩展。

[1] CH1/P(PWM/PPM)

[2]-[5]CH2- CH5

[6] BIND interface

[7] BVD/VCC(

Battery voltage

detection/Power supply interface

)

[8] CH7

[9] SERVO

[10] LED

[11] Antenna

[12] BIND button

[13] SENS interface

[14] CH6

[15] Signal pin

[16] + (Power anode)

[17] - (Power cathode)

[18] BVD harness

[19] Connect to battery anode

[20] Connect to battery cathode

Product Name: FS-R7P

Adaptive Transmittes:

FS-G7P( Adapts transmitters with ANT protocol)

Adaptive Models: Cars or boats

PWM Channels: 7

RF: 2.4GHz ISM

Maximum Power: <20dBm (e.i.r.p.) （EU）

Antenna: Single antenna

Distance: ≥ 300m (Ground distance without interference)

2.4G Protocol: ANT

Resolution: 4096

Data Output: PWM/PPM/i-BUS/S.BUS

Input Power: 3.5 ~ 9V/DC

Online Update: Yes

Temperature Range: -10℃ ~ +60℃

Humidity Limit: 20% ~ 95%

WaterProof: PPX4

Dimensions: 35.0mm*23.3mm*13.3mm

Weight: 8.0g

Certi󽗉cation: CE, FCC ID: 2A2UNR7P00

CH1~CH7: To output PWM signal (Additional, CH1 can output PPM signal).

Can be connected to the servos, or other compatiable components.

BVD/VCC: During the battery voltage detecting process, a BVD harness

is connected here. During normal operation, the power is applied to this

interface.

BIND interface: During the binding process, a bind cable is connected to this

interface.

SENS interface: For connecting i-BUS sensors.

SERVO interface: To output i-BUS or S.BUS signal, and support channel

expansion in i-BUS type.

[18] [19]

[20]

[15] [16][16]

[16]

[17][17]

[17]

[1]

[6]

[7]

[8][9][10]

[11]

[12] [13] [14]

[2]-[5]

注：BVD 电压检测范围： 0~70V Note: BVD voltage detection range: 0~70V

本款接收机支持双向对码和单向对码 , 双向对码完成后发射机将显示接收机回传的信息。

双向对码步骤：

1. 发射机选择双向通信，然后进入对码状态；

2. 本接收机支持三种方式进入对码状态：按键对码、对码线对码和通电后按键对码

• 按键对码：按住接收机对码按键同时上电，接收机 LED 灯快闪表示进入对码状态，松开对码键；

• 对码线对码：BIND 接口连接对码线后上电，接收机 LED 灯快闪，进入对码状态。注意对码成功后需取下对码线；

• 通电后按键对码：接收机上电后未与发射机通信过，长按对码键 3 秒，接收机指示灯快闪表示进入对码状态，松开对码键。

3. 接收机 LED 灯常亮，即对码成功。发射机对码成功后自动退出对码状态，对码完成；

4. 检查发射机、接收机是否正常工作。如需重新对码，请重复以上步骤。

FS-R7P 接收机 Receiver

Http://www.󽗊ysky-cn.com

对码 Binding

The 󽗉rmware of this receiver is updated through the FlyskyAssistant (Only version 3.0 or above is supported. The 󽗉rmware of FlyskyAssistant

is available on the Flysky o󽗋cial website).

This receiver can be updated via the following two ways:

1. After the binding between the transmitter and the receiver (the LED of the receiver is solid on), connect the transmitter to the computer, then

open the FlyskyAssistant on the computer to update the 󽗉rmware.

2. Connect the transmitter to the computer. Then put the receiver to enter the forced update mode by referring to the following three ways (The

LED of the receiver operates in three-󽗊ash-one-o󽗈 manner repeatedly). Afterwards, open the FlyskyAssistant on the computer to update the

󽗉rmware.

• Power on the receiver while pressing and holding the BIND button for more than ten seconds, until the LED of the receiver operates in three-

󽗊ash-one-o󽗈 manner repeatedly, then release the BIND button.

• Power on the receiver 󽗉rst, then press and hold the BIND button for more than ten seconds, when the LED of the receiveroperates in three-

󽗊ash-one-o󽗈 manner repeatedly, then release the BIND button.

• Connect the bind cable to the signnal pins of the CH4 and BIND interface, then power on the receiver.

固件更新 Firmware update

单向对码步骤：

1. 发射机选择单向通信，然后进入对码状态；

2. 本接收机进入对码状态（进入对码状态的方式请参考双向对码时描述）；

3. 接收机 LED 灯慢闪，即对码成功。发射机则需手动将其退出对码状态，接收机 LED 灯常亮，对码完成；

4. 检查发射机、接收机是否正常工作。如需重新对码，请重复以上步骤。

注：对码时请先将发射机进入对码状态，再将接收机进入对码状态，若十秒内对码没有完成，接收机 LED 指示灯进入慢闪状态。

The receiver supports two -way binding and one-way binding. The transmitter will display the information returned from the

receiver after the two-way binding is completed.

Follow the steps below to bind in two-way binding:

1. Select [ANT 2 WAY] for RF standard of the transmitter, then put the transmitter in bind mode.

2. The receiver supports three ways to enter bind mode: BIND button binding, bind cable binding and BIND button binding after

power-on.

• BIND button binding: Press and hold the BIND button of the receiver while powering on the receiver, tthe LED of the receiver

should be 󽗊ashing, indicating that the receiver is in bind mode. Then release the BIND button.

• Bind cable binding: Insert the bind cable to the BIND interface of the receiver, then power on the receiver. The LED of the

receiver should be 󽗊ashing, indicating that the receiver is in bind mode. Note that you need to remove the bind cable from the

receiver after the binding process is 󽗉nished.

• BIND button binding after power-on: The receiver has not been connected to the transmitter when it is powered on. Press and

hold the BIND button for 3 seconds, the LED of the receiver should be 󽗊ashing, indicating that the receiver is in bind mode. Then

release the BIND button.

3. When the LED of the receiver is solid on, the binding process should be 󽗉nished. The transmitter exits the bind mode automaticlly.

4. Check to make sure the transmitter and receiver functions are working correctly, repeat steps 1 to 3 (binding process) if any

problems arise.

Follow the steps below to bind in one-way binding:

1. Select [ANT 1 WAY] for RF standard of the transmitter, then put the transmitter in bind mode.

2. Put the receiver in bind mode ( Refer to the description above for entering bind mode).

3. When the LED of the receiver is in slow 󽗊ashing state, the binding process should be completed. You need to manually put the

transmitter to exit the bind mode. Then the LED of the receiver is solid on, indicating that the binding is completed.

4. Check to make sure the transmitter and receiver functions are working correctly, repeat steps 1 to 3 (binding process) if any

problems arise.

Note: Put the transmitter in bind mode 󽗉rst, then put the receiver in bind mode. If the binding is not completed within ten seconds,

the LED of the receiver will enter its slow 󽗊ashing state.

本接收机固件更新需通过富斯遥控管家（FlySkyAssistant）完成（仅 3.0 及以上版本支持，富斯遥控管家固件可从官网 www.󽗊ysky-

cn.com 获取）。

本接收机可以通过以下两种方式进入更新：

1. 先将发射机与接收机对码后（接收机 LED 灯常亮），再将发射机与电脑连接，然后在电脑端打开富斯遥控管家，通过富斯遥控管家

进行固件更新；

2. 将发射机与电脑连接，参考如下方式使接收机进入强制更新状态（接收机 LED 灯状态三闪一灭），然后在电脑端打开富斯遥控管家，

通过富斯遥控管家进行固件更新。

进入强制更新状态的操作方式有如下三种方式：

• 按下对码按键，上电十秒钟后接收机 LED 灯状态三闪一灭，松开对码按键。

• 先给接收机上电，长按对码键十秒后接收机 LED 灯状态三闪一灭，松开对码按键。

• 先将对码线连接到接收机 CH4 和对码接口信号端，然后接通接收机电源。

FS-R7P 接收机 Receiver

Http://www.󽗊ysky-cn.com

注意事项：

• 使用前必须确保本产品与模型安装正确，否则可能导致模型发生严重损坏。

• 关闭时，请务必先关闭接收机电源，然后关闭发射机。如果关闭发射机电源时，接收机仍然在工作，将会导致遥控设备失控。失控保

护设置不合理可能引起事故。

• 确保接收机安装在远离电机或电子噪声过多的区域。

• 接收机天线需远离导电材料，例如金属棒和碳物质。为了避免影响正常工作，请确保接收机天线和导电材料之间至少有1厘米以上的距离。

• 准备过程中，请勿连接接收机电源，避免造成不必要的损失。

失控保护 Failsafe

Attentions:

• Make sure the product is installed and calibrated correctly, failure to do so may result in serious injury.

• Make sure the receiver's battery is disconnected before turning o󽗈 the transmitter, failure to do so can result out of control.

Unreasonable setting of the Failsafe may cause accidents.

• Make sure the receiver is mounted away from motors, electronic speed controllers or any device that emits excessive electrical

noise.

• Keep the receiver's antenna at least 1cm away from conductive materials such as carbon or metal.

• Do not power on the receiver during the setup process to prevent loss of control.

失控保护功能用于在接收机失去信号不受控制后，接收机按设置好的失控保护值进行通道输出以保护模型及人员安全。

本款接收机共支持两种失控保护模式 : [ 无输出 ] 和 [ 有输出 ]

[ 无输出 ] i-BUS/PPM/PWM 通道接口为无输出状态 ;

[ 有输出 ] i-BUS/PPM/PWM 通道接口输出设置的固定值。

注：

1. 因为 S.BUS 信号包含失控标志位，所以接收机可通过失控标志位将“失控状态”信息传递到后续设备，而无需通过 [ 无输出 ] 状态传递（后续设备通

过解析失控标志位信息做出相应地应对即可）；

2. 对于无失控标志位的信号 PWM/PPM/i-BUS，支持设置失控时信号 [ 无输出 ]，通过 [ 无输出 ] 状态将“失控状态”信息传递给后续设备。

The failsafe function is used to output the channel value according to the out-of-control protection value set by the user after the receiver

loses its signal and is out of control to protect the model and personnel.

It can also be set failsafe for each channel respectively. This receiver supports two failsafe modes: [ON]and [OFF]

[OFF] It is no output for the interface of i-BUS/PPM/PWM.

[ON] Outputs the failsafe values set for the interface of i-BUS/PPM/PWM.

Notes:

1. Because the S.BUS signal information contains failsafe 󽗊ag bits, the failsafe information can be transmitted to the subsequent devices by the failsafe 󽗊ag

bits ruther than by OFF state. The subsequent devices gives response according to the analysed information for the failsafe 󽗊ag bits.

2. For the signal PWM/PPM/i-BUS without failsafe 󽗊ag bits, it supports the setting of the output signal to OFF in case of failsafe, transmitting the failsafe

information to the subsequent devices by OFF state.

FS-R7P 接收机 Receiver

Http://www.󽗊ysky-cn.com

认证相关 Certications

FCC Compliance Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Warning: changes or modi󽗉cations not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o󽗈

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit di󽗈erent from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

EU DoC Declaration

Hereby, [Flysky Technology co., ltd] declares that the Radio Equipment [FS-R7P] is in compliance with RED 2014/53/EU.

The full text of the EU DoC is available at the following internet address: www.󽗊ysky-cn.com.

RF Exposure Compliance

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated

with minimum distance 20 centimeters between the radiator and your body.

Environmentally friendly disposal

Old electrical appliances must not be disposed of together with the residual waste, but have to be disposed of separately. The disposal at

the communal collecting point via private persons is for free. The owner of old appliances is responsible to bring the appliances to these

collecting points or to similar collection points. With this little personal e󽗈ort, you contribute to recycle valuable raw materials and the

treatment of toxic substances.

FCC ID: 2A2UNR7P00

本说明书中的图片和插图仅供参考，可能与实际产品外观有所不同。产品设计和规格可能会有所更改，恕不另行通知。

Figures and illustrations in this manual are provided for reference only and may di󽗈er from actual product appearance. Product design and speci󽗉catiions may be changed without notice.

Manufacturer：ShenZhen FLYSKY Technology Co., Ltd

Address: 16F, Huafeng Building, No. 6006 Shennan Road, Futian District, Shenzhen, Guangdong, China
