Fly Sky FS-SRM User manual

FS-SRM 接收机 Receiver
http://www.flysky-cn.com
Copyright ©2021 Flysky Technology co., ltd
产品型号：FS-SRM适配遥控器：ANT协议发射机（如FS-ST8）适配模型：穿越机通道个数：1无线频率：2.4GHz ISM发射功率：小于20dBm无线标准：ANT通道分辨率：1024级天线类型：双天线遥控距离：>380米输入电源：3.5V ~ 9V/DC数据输出：PWM/PPM/i-BUS/S.BUS在线更新：支持工作电流： 70mA 左右/5V温度范围：-10℃ ～ +60℃湿度范围：20%～95％外形尺寸：19*12.1*3mm机身重量：1.1g认证：CE，FCC ID: 2A2UNSRM00FS-SRM 是一款针对穿越机配备的新款接收机，采用ANT协议，外置双天线双向输出，可输出PWM或PPM/i-BUS/S.BUS信号，设计小巧，易于安装，可适配穿越机使用。产品介绍Introduction
接收机概览Overview
产品规格Specications [1] GND：连接地线[2] VCC：电源电压为3.5~9V[3] i-BUS 接口[4] SENS 接口[5] PPM/PWM [6] 天线[7] 对码键[8] LED对码Binding [1] GND[2] VCC [3] i-BUS interface[4] SENS interface[5] PPM/PWM[6] Antenna [7] BIND button[8] LEDProduct Name: FS-SRMAdaptive transmitters:
Transmitter with ANT protocol, such as FS-ST8
Adaptive Models: MulticoptersNumbers of Channels: 1
RF: 2.4GHz ISMMaximum Power: < 20dBm (e.i.r.p.) （EU）2.4G Protocol: ANTResolution: 1024Antenna: Two antennasDistance: >380mInput Power: 3.5V ~ 9V/DCData Output: PWM/PPM/i-BUS/S.BUSOnline Update: YesOperating Current: About 70mA/5VTemperature Range: -10℃~ +60℃Humidity Limit: 20% ~ 95%Dimensions: 19*12.1*3mmWeight: 1.1gCerti󽗉cations: CE, FCC ID: 2A2UNSRM00[3] [4] [5] [2] [1] [6] [8] [7] FS-SRM based on ANT protocol is a new receiver with two external antennas and bidirectional transmission. It outputs PWM or PPM/i-BUS/S.BUS signal and has a compact design. The design of the receiver is easily to install, and it adapts multicopters.本款接收机支持双向对码和单向对码 , 双向对码完成后发射机将显示接收机回传的信息。双向对码步骤：1.发射机选择双向通信，然后进入对码状态；2.本接收机支持两种方式进入对码状态：按键对码和通电后按键对码；•按键对码：按住接收机对码按键同时上电，接收机LED灯快闪表示进入对码状态，松开对码键；•通电后按键对码：接收机上电后未与发射机通信过，长按对码键3秒，接收机指示灯快闪表示进入对码状态，松开对码键。3.接收机LED灯常亮，即对码成功。发射机对码成功后自动退出对码状态，对码完成；4.检查发射机、接收机是否正常工作。如需重新对码，请重复以上步骤。单向对码步骤：1.发射机选择单向通信，然后进入对码状态；2.接收机进入对码状态（进入对码状态的方式请参考双向对码时描述）；3.接收机LED灯慢闪，即对码成功。发射机则需手动将其退出对码状态，接收机LED灯常亮，对码完成；4.检查发射机、接收机是否正常工作。如需重新对码，请重复以上步骤。The receiver supports two -way binding and one-way binding. The transmitter will display the information returned from the receiver after the two-way binding is completed.Follow the steps below to bind in two-way binding:1.Select[2WAY]forRFstandardofthetransmitter,thenputthetransmitterintobindmode.

FS-SRM 接收机 Receiver
http://www.flysky-cn.com
Copyright ©2021 Flysky Technology co., ltd
对码Binding
2.Thereceiversupportsthowaystoenterbindmode:BINDbuttonbindingandBINDbuttonbindingafterpower-on.•BINDbuttonbinding:PressandholdtheBINDbuttonofthereceiverwhilepoweringonthereceiver,ttheLEDofthereceivershouldbe󽗊ashing,indicatingthatthereceiverisinbindmode.ThenreleasetheBINDbutton.•BINDbuttonbindingafterpower-on:Thereceiverhasnotbeenconnectedtothetransmitterwhenitispoweredon.PressandholdtheBINDbuttonfor3seconds,theLEDofthereceivershouldbe󽗊ashing,indicatingthatthereceiverisinbindmode.ThenreleasetheBINDbutton.3.WhentheLEDofthereceiverissolidon,thebindingprocessshouldbecompleted.Thetransmitterexitsthebindmodeautomaticlly.4.Checktomakesurethetransmitterandreceiverfunctionsareworkingcorrectly,repeatsteps1to3(bindingprocess)ifanyproblemsarise.Follow the steps below to bind in one-way binding:1.Select[1WAY]forRFstandardofthetransmitter,thenputthetransmitterintobindmode.2.Putthereceiverintobindmode(Refertothedescriptionaboveforenteringbindmode).3.WhentheLEDofthereceiverisinslow󽗊ashingstate,thebindingprocessshouldbecompleted. Youneedtomanuallyputthetransmittertoexitthebindmode. ThentheLEDofthereceiverissolidon,indicatingthatthebindingiscompleted.4.Checktomakesurethetransmitterandreceiverfunctionsareworkingcorrectly,repeatsteps1to3(bindingprocess)ifanyproblemsarise.The 󽗉rmware of this receiver is updated through the FlyskyAssistant (Only version 3.0 or above is supported. The 󽗉rmware of FlyskyAssistant is available on the Flysky o󽗋cial website).This receiver can be updated via the following two ways:1.Afterthebindingbetweenthetransmitterandthereceiver(theLEDofthereceiverissolidon),connectthetransmittertothecomputer,thenopentheFlyskyAssistantonthecomputertoupdatethe󽗉rmware.2.Connectthetransmittertothecomputer.Thenputthereceivertoentertheforcedupdatemodebyreferringtothefollowingtwoways(TheLEDofthereceiveroperatesinthree-󽗊ash-one-o󽗈mannerrepeatedly).Afterwards,opentheFlyskyAssistantonthecomputertoupdatethe󽗉rmware.•PoweronthereceiverwhilepressingandholdingtheBINDbuttonformorethantenseconds,untiltheLEDofthereceiveroperatesinthree-󽗊ash-one-o󽗈mannerrepeatedly,thenreleasetheBINDbutton.•Poweronthereceiver󽗉rst,thenpressandholdtheBINDbuttonformorethantenseconds,whentheLEDofthereceiveroperatesinthree-󽗊ash-one-o󽗈mannerrepeatedly,thenreleasetheBINDbutton.固件更新 Firmware update
本接收机固件更新需通过富斯遥控管家（FlySkyAssistant）完成（仅3.0及以上版本支持，富斯遥控管家固件可从官网www.󽗊ysky-cn.com获取）。本接收机可以通过以下两种方式进入更新：1.先将发射机与接收机对码后（接收机LED灯常亮），再将发射机与电脑连接，然后在电脑端打开富斯遥控管家，通过富斯遥控管家进行固件更新；2.将发射机与电脑连接，参考如下方式使接收机进入强制更新状态（接收机LED灯状态三闪一灭），然后在电脑端打开富斯遥控管家，通过富斯遥控管家进行固件更新。进入强制更新状态的操作方式有如下两种方式：•按下对码按键，上电十秒钟后接收机LED灯状态三闪一灭，松开对码按键。•先给接收机上电，长按对码键十秒后接收机LED灯状态三闪一灭，松开对码按键。失控保护Failsafe
失控保护功能用于在接收机失去信号不受控制后，接收机按设置好的失控保护值进行通道输出以保护模型及人员安全。本款接收机共支持两种失控保护模式 : [ 无输出 ]和[有输出 ] [ 无输出 ] PWM通道接口为无输出状态; [ 有输出 ] 输出设置的固定值。注：1.对于PPM/i-BUS/S.BUS等总线信号类型不允许单个或其中几个通道为[无输出]模式，通道设置为[无输出]模式时，实际信号是保持最后输出值；2.因S.BUS信号信息包含失控标志位，各通道失控保护设置被失控标志位传达给后续设备，若连接的设备支持失控标志位解析，则失控后，输出各通道设置的失控保护值；3.对于无失控标志位的信号PPM/i-BUS，支持设置失控时信号[无输出]模式。设置为[无输出]模式后，不管各通道失控保护如何设置，失控后各通道均为[无输出]模式。

FS-SRM 接收机 Receiver
http://www.flysky-cn.com
Copyright ©2021 Flysky Technology co., ltd
失控保护Failsafe
The failsafe function is used to output the channel value according to the out-of-control protection value set by the user after the receiver loses its signal and is out of control to protect the model and personnel.It can also be set failsafe for each channel respectively. This receiver supports two failsafe modes: [ON]and [OFF] [OFF] It is no output for the interface of PWM. [ON] Outputs the failsafe values set for each channel. Notes:1.ForbussignaltypessuchasPPM/i-BUS/S.BUS,asingleorseveralofthesechannelsarenotallowedtobein[Nooutput]mode.Theactualsignalisheldatthelastoutputvaluewhenthechannelissetto[Nooutput]mode.2.BecausetheS.BUSsignalinformationcontainsfailsafe󽗊agbits,thefailsafesettingsofeachchannelarecommunicatedtosubsequentdevicesbythefailsafe󽗊agbits.Iftheconnecteddevicessupportthefailsafe󽗊agbitanalysis,thefailsafevaluessetforeachchannelareoutputafteroutofcontrol.3.ForthesignalPPM/i-BUSwithoutfailsafe󽗊agbits,itsupportsthesettingofthesignalto[Nooutput]modeincaseofoutofcontrol.Aftersettingto[Nooutput]mode,regardlessofthesettingofthefailsafeofeachchannel,eachchannelwillbein[Nooutput]modeafteroutofcontrol.Attention:• Make sure the product is installed and calibrated correctly, failure to do so may result in serious injury.• Please carefully check each power device and car frame instructions to ensure the power matching is reasonable before use. Avoid damaging power system due to incorrect matching.• Do not let the external temperature of the system exceed 90℃/194℉, because high temperature will damage the power system.• Make sure the receiver is mounted away from motors or any device that emits excessive electrical noise.• Keep the antenna of the receiver at least 1cm away from conductive materials such as carbon or metal.• Do not power on the receiver during the setup process to prevent loss of control.注意事项：•使用前必须确保本产品与模型安装正确，否则可能导致模型发生严重损坏。•关闭时，请务必先关闭接收机电源，然后关闭发射机。如果关闭发射机电源时接收机仍然在工作，将会导致遥控设备失控。失控保护设置不合理可能引起事故。•确保接收机安装在远离电机，电子调速器或电子噪声过多的区域。•接收机天线需远离导电材料，例如金属棒和碳物质。为了避免影响正常工作，请确保接收机天线和导电材料之间至少有1厘米以上的距离。•准备过程中，请勿连接接收机电源，避免造成不必要的损失。

FS-SRM 接收机 Receiver
http://www.flysky-cn.com
Copyright ©2021 Flysky Technology co., ltd
认证相关Certications
FCC Compliance StatementThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: changes or modi󽗉cations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o󽗈 and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit di󽗈erent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.EU DoC DeclarationHereby, [Flysky Technology co., ltd] declares that the Radio Equipment [FS-SRM] is in compliance with RED 2014/53/EU.The full text of the EU DoC is available at the following internet address: www.󽗊ysky-cn.com.RF Exposure ComplianceThis equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.Environmentally friendly disposalOld electrical appliances must not be disposed of together with the residual waste, but have to be disposed of separately. The disposal at the communal collecting point via private persons is for free. The owner of old appliances is responsible to bring the appliances to these collecting points or to similar collection points. With this little personal e󽗈ort, you contribute to recycle valuable raw materials and the treatment of toxic substances.FCC ID: 2A2UNSRM00本说明书中的图片和插图仅供参考，可能与实际产品外观有所不同。 产品设计和规格可能会有所更改，恕不另行通知。Figures and illustrations in this manual are provided for reference only and may di󽗈er from actual product appearance. Product design and speci󽗉catiions may be changed without notice.Manufacturer：FLYSKY Technology Co., LtdAddress: 16F, Huafeng Building, 6006 Shennan Road, Futian District, Shenzhen
