FMI XeVG-5BIN User manual

FMI BRANDS INC.
309-19133 26th Avenue | Surrey, B.C. Canada V3Z 3V7 | Toll Free 1-888-514-1663 | Fax [phone]
D.XeVG-310.000.V0
Model number XeVG-5BIN
Series number 310
Owner’s
Manual
VERTICAL GARDEN

VERTICAL GARDEN
Owner & Safety Manual
D.XeVG-310.000.V0
En-1 OUTLAND LIVING VERTICAL GARDEN OWNER & SAFETY MANUAL
Model number XeVG-5BIN, Series number 310
NOTE TO INSTALLER:
Leave this guide with the consumer.
NOTE TO CONSUMER:
Please retain this guide for future use.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read the
installation, operating and maintenance instructions thoroughly
before installing or servicing this equipment.
CAUTION:
Watch for sharp edges.
Wear protective gloves if necessary.

En-2
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SUPPLIED PARTS & HARDWARE LIST:
F
B
G
C
A
D
E
H
ITEM DESCRIPTION
ATOP FRAME (x1)
BBOTTOM FRAME (x1)
CREAR LEGS (x1)
DTOP END CAP (x2)
EPLANTER BINS (x5)
FBIN HANGERS (x5)
GM6 SCREWS (x4)
HDRAIN PLUG (x1)

VERTICAL GARDEN
Owner & Safety Manual
D.XeVG-310.000.V0
En-3 OUTLAND LIVING VERTICAL GARDEN OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY
STEP 1
Mount the Rear Legs
(part C) onto the
Bottom Frame (part
B). Fix with (2x) M6
screws (part G).
STEP 3
Install the plastic Planter
Bins (part E) by hooking
the lip edge on the rear
frame channel and
placing bins on the Bin
Hangers (part F).
STEP 2
Mount the Top Frame (part A) to
the Bottom Frame (part B). Fix
with (2x) M6 screws (part G).
STEP 4
Add your preferred volume of Potting Soil Mix. (Soil not included).
Plan your budget for 14L (12.5 Quarts) of soil mix per bin and/or
adjust the volume of soil to suit your need.
SOIL BUDGET ASSUMPTION:
Each planter bin is 595mmLx200mmWx160mmH
(23.4”Lx7.9”Wx6.3”H)
SOIL BUDGET/1 BIN SOIL BUDGET/5 BINS
0.5 cubic foot (ft3)2.5 cubic feet (ft3)
.02 cubic yard (yd3).09 cubic yard (yd3)
12.5 Imperial Quart (qt) 62.3 Imperial Quarts (qt)
14 Litres (L) 70 Litres (L)
FRAME CHANNEL

En-4
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 1: ASSEMBLY (continued)
IMPORTANT: FACE THIS WAY FRONT.
Note the pre-drilled drainage hole location in each plastic planter
bin. Ensure the drain holes are placed front facing on the hangers
so water drains into each bin below, in a cascading fashion, as
shown in the illustration. Otherwise, water drainage will occur on
the ground (or floor) below.
FACE THIS WAY FRONT
TOP VIEW
PLASTIC PLANTER BIN
DRAIN HOLE
DETAIL A
A
Gardening Indoors or on a Patio Deck? Install the supplied Drain
Plug (part H).
a. Using the drain plug in the lowest bottom bin prevents water
drainage and allows you to garden indoors, or on your patio
deck, with your OUTLAND Vertical Garden.
b. Fit the drain plug up into the bottom bin drain hole from
underneath. See DRAWING DETAIL. Fitting it up from
underneath allows you to remove it, in the future, should you
desire to manually drain the bottom planter bin.
c. Removing the drain plug allows excess water to drain out of the
lowest plastic planter bin. When indoor, or patio gardening, place
a tray under the bottom bin before removing the drain plug.
DRAIN PLUG
TO DRAIN BIN
REMOVE PLUG

VERTICAL GARDEN
Owner & Safety Manual
D.XeVG-310.000.V0
En-5 OUTLAND LIVING VERTICAL GARDEN OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY (continued)
IMPORTANT
• Always ensure Vertical Garden stands straight and level.
IMPORTANT
• Always ensure all fasteners are firmly tightened.
SET UP INSPECTION SEQUENCE:
The Vertical Garden should be inspected before use and at least
annually. More frequent cleaning and/or adjustments may be
required as necessary.
Prior to each use:
• Ensure placement is on a level and firm surface able to hold the
fully loaded weight of the frame, which is approximately 30-40Kg
(65-90lb)
• Ensure no parts are missing and all fasteners are firmly tightened.
Your OUTLAND Vertical Garden is ready to use indoors or
outdoors.
Outdoor Gardening? No need to install the drain plug. Gardening
without the drain plug allows excess rain water to flow through the
bins to the ground below.
DRAIN PLUG
CASCADING DRAINAGE
WATER
WATER
WATER
WATER

En-6
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 2: MAINTENANCE
Your Outland Vertical Garden is meant for indoor or outdoor use
and requires periodic maintenance to keep it in good condition.
• Should any part of this appliance become soiled or dirty,
wipe down with a damp wet cloth. Use only water based
cleaners.
• Check fasteners and ensure firmly tightened.
• Should you experience water dripping from the drainage
holes in ways which are obviously unintended, or detrimental
to your home, we recommend the following trouble shooting:
i. confirm the vertical garden is sitting level
ii. confirm each bin is sitting level on the bin hanger
iii. confirm each drainage hole is positioned above the bin
below
iv. confirm your lovely plants aren’t redirecting flow
v. confirm the drain plug stopper is securely installed in
the lowest bottom bin drainage hole
vi. If you’ve exhausted the above and pesky water
seepage is still finding its way (because we all know it
sometimes does!), we recommend to find a small piece
of hose or tubing to fit snugly inside the problematic
drainage hole(s). Align the tubing so the flow of
dripping water actually falls where you want it to fall.
IMPORTANT
Do not use petroleum based, flammable or corrosive cleaning
products on or near this unit.
This appliance is NOT a toy.
SECTION 3: STORAGE
Your Vertical Garden has been designed to conveniently store away
when not in use.
We recommend to store your Vertical Garden under cover during
winter, or when not in use.
Follow these instructions to ready for storage:
1Remove plastic Planter Bins from frame.
2 Remove Rear Legs.
3 Store conveniently. See you next season.
NOTES:
• The Vertical Garden measures approximately 49” High
and stands in a compact footprint of 26” Wide x 29” Deep.
(1242mmHx664Wx733mmD).
• The planter bins are 6.3” (160mm) Deep.
WARNING:
Do not climb on the Vertical Garden or use it as a ladder or
serious injury, property damage and/or death may occur.
• Note that plants grown in containers typically need to be
watered more frequently than plants grown in the ground. We
recommend to monitor your soil moisture and water regularly.
• For best results, consult your local nursery for gardening tips
when purchasing your garden materials.
HERE IS A LIST OF ANNUALS FLOWERS WHICH YOU MAY
LIKE TO TRY IN YOUR VERTICAL GARDEN:
• Alyssum
• Begonia
• Browallia
• Coleus
• Geraniums
• Impatiens
• Latana
• Lobelia
• Marigolds
• Periwinkle
• Nasturtiums
• Pansies
• Petunias
• Salvia
• Sanvitalia
• Snapdragons
• Thunbergia
• Zinnias
THIS LIST OF RECOMMENDED CROPS FOR YOUR
VERTICAL GARDEN IS BY NO MEANS COMPLETE, BUT
SHOULD HELP PROVIDE SOME IDEAS TO START YOUR
GREEN THUMB:
• Lettuce (leaf varieties)
• Spinach
• Radish
• Baby Carrots
• Beets
• Onions (Green, Scallion)
• Asian Greens (Tatsoi, Pak
Choy, Mizuna, Gai-lon)
• Herbs (Basil, Thyme,
Tarragon, Rosemary,
Oregano, Cilantro, Dill,
Savory, Mint, Sage, Chives,
Bay, Parsley, Coriander,
Sorrel, Lemongrass)

VERTICAL GARDEN
Owner & Safety Manual
D.XeVG-310.000.V0
En-7 OUTLAND LIVING VERTICAL GARDEN OWNER & SAFETY MANUAL
STOP:
Do not return this product to the store.
If you need help or parts, call the OUTLAND Hotline: [phone]
Get help for:
Missing/damaged parts • Assembly • Troubleshooting • Warranty Assistance • Product Information
1 YEAR LIMITED WARRANTY
Customers in Canada and USA
All components are warranted by the manufacturer for a period of 1 year after date of purchase by the
original owner against defects in materials and workmanship under normal use. This warranty does NOT
cover normal wear and weathering, assembly and/or maintenance OR use in a commercial application.
At FMI Brands’ sole discretion, products under warranty will be repaired and/or replaced at no charge to
the customer. Any returns sent back to FMI Brands must be sent via prepaid freight and in the original
retail packaging.
Please register your OUTLAND Living product for proof of purchase and warranty at
http://outlandliving.com/register-products/
For more warranty information and details please contact FMI Brands Inc. at [e-mail]
FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT
WWW.OUTLANDLIVING.COM
The owner’s manual is available as a free download from www.outlandliving.com
Replacement part orders can be sent by mail to the address on the cover of this booklet, or faxed to [phone]. Should you have any questions
or comments regarding this product, please do not hesitate to contact FMI Brands Inc. at [phone] or E-Mail to [email protected].
