FNW 7203 Quick start guide

INTRODUCTION
This instruction manual includes installation and proper use information for FNW gure 7203 and 7204 malleable
iron beam clamps.
PROPER USE
To avoid personal injury to yourself, fellow workers, or damage to property from improper use:
a. Verify beam clamps are used within listed load and temperature limits (see load charts, page 2).
b. Only install beam clamps with loads in line with threaded rod (suppled by others).
c. Do not install beam clamps with loads at angles to threaded rod or by bending threaded rod as stresses can
be transmitted unpredictably to the clamp.
d. Reverse installation of beam clamps is not allowed. *3/8" only size acceptable for reverse installation
(max load 200 lbs).
e. Only use hardware (i.e. - Clamp, Set Screw, and Hex Nut) suppled in this kit. Use of third party hardware
will void any warranty with FNW.
f. Do not overtighten set screw beyond what is outlined in these instructions. Overtightening can reduce load
capacity up to and including failure of the beam clamp.
INSTALLATION AND PROPER USE
FIGURE 7203 & 7204 MI BEAM CLAMPS
YES
Proper installation with load
in line with threaded rod.
NO
Improper installation with
load at angle to threaded rod.
NO
Improper installation with bent
threaded rod.
NO
Improper installation with
beam clam in reverse
direction. *3/8" only size
acceptable for reverse
installation (max load
200 lbs).
INSTALLATION
The FNW gure 7203 and 7204 beam clamp can be installed with, or without, a torque wrench.
With Torque Wrench
1. Place clamp, without load, onto beam.
2. Tighten the set screw to 5.0 ft-lbs (60 in-lbs).
3.Tighten the hex nut to lock the set screw in place.
Without Torque Wrench
1. Place clamp, without load, onto beam.
2. Tighten the screw set to nger tight.
3. Using a wrench, continue tightening the set screw an additional 1/4 to 1/3 turn.
4. Tighten the hex nut to lock the set screw in place.
DO NOT OVERTIGHTEN THE SET SCREW.
© 2018 FNW The FNW logo is a trademark of Ferguson Enterprises, Inc., PL Sourcing, PO Box 2778, Newport News, VA 23602 1118 1037057

LOAD & TEMPERATURE CAPACITIES
The FNW gure 7203 and 7204 brochure list their maximum load capabilities when used within the standard
temperature range of 5°F to 212°F. Extended temperature range of -22°F through 5°F and 212°F through 482°F is
permitted at the reduced load capacity of 60% maximum (i.e. extended temperature ranges reduce maximum load
capacity by 40%). The chart below lists standard and reduced capacity load capabilities depending on temperature.
WARRANTY
1. LIMITED WARRANTY: Subject to the limitations expressed herein, Seller warrants that products manufactured by Seller
shall be free from defects in design, material and workmanship under normal use for a period of one (1) year from installa-
tion but in no case shall the warranty period extend longer than eighteen months from the date of sale. This warranty is void
for any damage caused by misuse, abuse, neglect, acts of God, or improper installation. For the purpose of this section,
“Normal Use” means in strict accordance with the installation, operation and maintenance manual. The warranty for all other
products is provided by the original equipment manufacturer.
2. REMEDIES: Seller shall repair or replace, at its option, any non-conforming or otherwise defective product, upon receipt
of notice from Buyer during the Manufacturer’s warranty period at no additional charge. SELLER HEREBY DISCLAIMS ALL
OTHER EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, ALL IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS OR FITNESS FOR A PARTICULAR PURPOSE.
3. LIMITATION OF LIABILITY: UNDER NO CIRCUMSTANCES SHALL EITHER PARTY BE LIABLE TO THE OTHER FOR
INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND. BUYER HEREBY ACKNOWLEDGES
AND AGREES THAT UNDER NO CIRCUMSTANCES, AND IN NO EVENT, SHALL SELLER’S LIABILITY, IF ANY, EXCEED
THE NET SALES PRICE OF THE DEFECTIVE PRODUCT(S) PURCHASED DURING THE PREVIOUS CONTRACT YEAR.
4. LABOR ALLOWANCE: Seller makes NO ADDITIONAL ALLOWANCE FOR THE LABOR OR EXPENSE OF REPAIRING
OR REPLACING DEFECTIVE PRODUCTS OR WORKMANSHIP OR DAMAGE RESULTING FROM THE SAME.
5. RECOMMENDATIONS BY SELLER: Seller may assist Buyer in selection decisions by providing information regarding
products that it manufacturers and those manufactured by others. However, Buyer acknowledges that Buyer ultimately
chooses the product’s suitability for its particular use, as normally signied by the signature of Buyer’s technical represen-
tative. Any recommendations made by Seller concerning the use, design, application or operation of the products shall not
be construed as representations or warranties, expressed or implied. Failure by Seller to make recommendations or give
advice to Buyer shall not impose any liability upon Seller.
6. EXCUSED PERFORMANCE: Seller will make a good faith effort to complete delivery of the products as indicated by
Seller in writing, but Seller assumes no responsibility or liability and will accept no back-charge for loss or damage due to
delay or inability to deliver, caused by acts of God, war, labor difculties, accidents, inability to obtain materials, delays of
carriers, contractors or suppliers or any other causes of any kind whatever beyond the control of Seller. Under no circum-
stances shall Seller be liable for any special, consequential, incidental, or indirect damages, losses, or expense (whether or
not based on negligence) arising directly or indirectly from delays or failure to give notice of delay.
INSTALLATION AND PROPER USE
FIGURE 7203 & 7204 MI BEAM CLAMPS
Figure
Number
Rod
Size
Maximum
Pipe Size
Recommended
Maximum Recommended Load (Lbs.) Recommended Load (Lbs.) Per Temperature Range
Regular Installation
(Top Mount)
Reverse Installation
(Bottom Mount) 5°F – 212°F -22°F – 5°F or 212°F – 482°F
7203
3/8" 4" 400 200 400 240
1/2" 8" 500 Not Allowed 500 300
5/8" 8" 600 Not Allowed 600 360
3/4" 8" 800 Not Allowed 800 480
7204
3/8" 4" 400 Not Allowed 400 240
1/2" 8" 500 Not Allowed 500 300
5/8" 5" 850 Not Allowed 850 510
3/4" 6" 900 Not Allowed 900 540
