foc.us TM-3000 User manual

TitleMaker 3000
MODEL TM-3000
TITLEMAKER 3000 IS ONE
OF THE MOST AFFORDABLE
CHARACTER GENERATORS ON
THE MARKET TODAY BRINGING
HIGH QUALITY TITLING TO
THE VIDEOGRAPHER.
N w y u can add crisp,
dazzling pr fessi nal
l king titles t any
vide pr ducti n! The
TitleMaker 3000 is a
techn l gical breakthr ugh
in vide character generati n.
It delivers high-res luti n
titles in a milli n c l rs.
The full size keyb ard
includes accented characters
f r 21 different languages.
Advanced features include
patterns, see-thr ugh vide
effects, multi-directi n
crawl, fades and wipes,
and much m re.
AMAZING RESOLUTION
TitleMaker 3000 uses digital video
technology to produce high quality
letters with smooth curves and
sharp edges.
VERSATILE KEYBOARD
Easy to use separate full function
keyboard allows you quick and easy
access to special effects and making
changes on the fly.
A MILLION COLORS
When creating your titles, outlines,
backgrounds, and borders, you can
select from over a million colors. You
can also choose from a set of “patterns,”
such as “rainbow” to give your titles a
unique one-of-a-kind look and feel.
MULTIPLE FONT SELECTION
TitleMaker 3000 has over 200
font/size combinations, including
script, Old English, and many more.
The fonts are specifically designed
to look great on video. Each line of
text can be enhanced with drop
shadows, several grades of bold
letters, outlines, eight speed scroll
and crawl, and much more.
PROVEN SPEED
Increase your productivity with the
TM-3000’s state-of-the-art on-board
processor and user-friendly keyboard.
VERSATILE SUPERIMPOSE
Titles can be superimposed over
video or over colored or patterned
backgrounds. Video can also be
used as a “color” for titles, backgrounds,
outline/shadow areas. You can even
use dimmed or tinted video as a
background for stunning “video on
video” effects.
SPECIAL EFFECTS
There are 24 special effects for
transitions between title screens,
including cuts, fades, wipes, and
more. Each effect can be executed
at any of eight different speeds.
EXTENSIVE MEMORY
TitleMaker 3000’s memory will hold
over 16,000 characters. You can
store hundreds of projects. A long
life lithium battery ensures that your
titles will remain in memory, even
when the unit is unplugged.
CONVENIENT PREVIEW
An extra output allows you to change
titles on a secondary monitor out of the
audience’s view, without interrupting
the signal to the primary monitor.
PROJECT/PAGES
Pages can be stored under separate
projects. You can work on the pages
in one project without affecting those
in another.
INSTANT PAGE ACCESS
The page index screen displays the
first line of text from each title screen
you create for easy page identification
and access.

Specifications subject to change.
All brand and product names are trademarks
of their respective companies.
©FOCUS Enhancements, Inc. MANL-0653-03
TitleMaker 3000
M del TM-3000
APPLICATIONS
▼Corporate and Industrial video
▼Wedding and Event videography
▼Classroom Video productions
▼Bulletin and Message Board systems
▼Night Club and Restaurant
Messaging Systems
▼Public, Education, and Government (PEG)
TV Stations and Low Power TV Stations
FEATURES
▼ High Resolution titles; NTSC or PAL
▼ Over a million colors — apply separately
to letters, outline/shadow, background
and border
▼ 20 special effects (fades and wipes),
8 speeds with four-direction scroll,
and crawl
▼ Superimpose (genlock): Title over video,
or use video for letters, outlines, or borders
▼ Each line can use a different font, size,
and style and different colors for letter,
outline, and drop shadow
▼ 32 rainbow and pixel patterns, including
animated patterns, can be applied to
background, letters, outline/shadow,
and borders
▼ Background video mix: Mix colors or
patterns with video for see-through or
tinted video effects
▼ Preview output allows you to change
titles out of the audience’s view
▼ 16,000 character memory, hundred of pages
▼ Organize pages into separate "projects."
Work on one project without affecting others
▼ Page index provides rapid access to any
page and any project
▼ Multiple play modes: Play a pre-arranged
program with different settings for each
page; play pages manually (slide show);
play a sequence repeatedly (video bill
board); play one page
▼ Full keyboard includes special and
foreign characters such as ©, ü, o, ø, etc
▼ Includes pictorial characters (heart,
bullets, etc.) and elegant "curled" quotes
▼ Built-in demo shows features. Can be
modified or used as basis for new titles
▼ Video and audio inputs and outputs.
Both S-video and composite (RCA)
jacks for video in and out. Preview out is
composite only
▼ GPI trigger input allows for remote trigger
of titles from external controller
▼ 5-year lithium battery backup.
▼ Two-year warranty
PRODUCT DESCRIPTION
TitleMaker 3000 delivers high-resolution titles
in a million colors. The full size keyboard
includes accented characters for 21 different
languages. Advanced features include
patterns, see-through video effects, multi
direction scroll, crawl, and fades, and wipes.
IN
RLV S
PREVIEW
OUT CONTROL
(GPI) POWER
PREVIEW
CONTROL
POWER
ACCDEFGB
INSVLR
OUT
RLV S
OUTSVLR
OFF ON
IN OUTSTYLE
FONT &
SIZE
undo
movecopy
COLOR PATTERNCOLOR PATTERN COLOR PATTERN COLOR STYLE
mark
start mark end
POWER
DEMO
PLAY PLAY
page
down
page
up
posn
new
line
shift
new
page
shift
page
index
OK
caps
lock
tab
delete
cmd
!
1
Q
@
2
#
3
$
4
%
5
^
6
&
7
*
8
(
9
)
0
—
–
+
=
W E R T Y U I
|
\
O P{[
A
Z
S D F G H J K L
:;
"'
X C V B NM
<
,
>
.
?
/
}]
¡
´ `
¨
˜
^
°
"
Ø —
¢ £ ¥®™© • Œ
Æ ß §
♥ ✓ ◆ ■ ■
‘ ’
Ç
“ ”
¿
accent
EFFECTSFONT BACKGROUNDLETTER OUTLINE BORDERS
markposition caps lock
^
Keyboard Layout
Titlemaker 3000 Rear Panel
Controls and Connectors
A. VIDEO IN
B. VIDEO OUT
C. AUDIO IN AND OUT
D. PREVIEW OUT (FOR
A SECOND MONITOR
IF DESIRED)
E. GPI CONTROL JACK
F. POWER
G. UPSIDE-DOWN LEGENDS
FOR EASY REFERENCE
NTSC SPECIFICATIONS
High resolution:720 pixels per line, 480 lines (70ns)
Video Bandwith 5.0 MHz, S/N over 60 DB
4" high x 12" wide x 9.5" deep (100mm x 300mm 240mm)
Weight: 3lbs. (1.4kg)
110 VAC, 60 Hz supply included
UL and CSA approved
