Mantis
MANTIS Page 1 of 2
www.focusinfo.com 800.338.3348
The Mantis line of digital media players from Focus Enhancements offers multiple chan-
nels of standard- or high-definition video and 32-bit graphics. Mantis players enable you
to deliver a wide range of digital signage applications across numerous locations, and
they provide the power to support the most creative and cutting-edge digital communica-
tion media elements.
Mantis Digital Media Players
Free of network hang-ups and capacity limitations, Mantis digital media players take the
worry out of loading high-definition video through standard IT networks. Media is trans-
ferred to your Mantis player using the built-in DVD drive, an external hard drive, or a
10/100 network connection. Powered by the Focus Gemini 2 Universal Media Card(s),
Mantis decodes all 18 ATSC formats to the resolution of your choice (up to 1080i), sup-
ports 4:3 and 16:9 aspect ratios, and provides precise A/V synchronization using hardware-
enabled Dolby Digital™decoding. Mantis MG supports customizable, multiple-monitor
installations with fully scalable SD- and HD-channel synchronization. With cross-channel
synchronization, video and audio are synchronized across numerous monitors, making it
possible to create large-scale, wall-style video displays.
Whether you’re managing a large-scale digital media network or individual players, Focus has
a solution for you. For a digital media network that spans multiple locations, combine Mantis
with DART Network Media Management Software (optional) and you can manage thousands
of channels, complete with the precision needed to deliver specific content to specific displays
at the right time. If you need precise time/date scheduling and automated, unattended playback
on a smaller scale, Media Messenger®Remote Media Management Software (optional) is
perfect for the job. If you’re managing individual players, WebView™(included) enables you
to set up, monitor, and control individual players with ease.
Models
Mantis digital media players are available in two models—the Mantis MC Multi-Channel
HD Media Player and the Mantis MG Enterprise Media Gateway.
Key Features
MODEL Mantis MC Mantis MG
Key Features
32-bit Graphics • •
Broadcast-Quality Conversion Scaling (Up and Down) • •
Satellite Multicast • •
Scheduled Playback • •
Interactive Playback • •
Channels (Maximum) 2 HD or 2 SD 4 HD or 8 SD
Video
Outputs: Composite, Component, or RGBHV • •
Decoding (MPEG Layers I, II) • •
Audio Outputs
S/PDIF, Dolby Digital, Analog • •
Audio Decoding (MPEG Layers I, II, III) • •
Applications
Command and Control
Events and Entertainment
Financial Services
Healthcare
Hospitality
Narrowcasting
Retail
Transportation
Mantis MC
Mantis MG

Mantis
MANTIS Page 2 of 2
www.focusinfo.com 800.338.3348
European Headquarters
COMO Computer & Motion GmbH
A Focus Enhancements Company
Lise-Meitner-Str.15
24223 Raisdorf
Germany
P [phone]
F [phone]
E [email protected]
©2007. Focus Enhancements, Inc. Specifications
are subject to change. All brand and product
names are trademarks of their respective compa-
nies. MANL-0999-03 5/07
Corporate Headquarters
Focus Enhancements
1370 Dell Avenue
Campbell, CA 95008
P 800 338 3348 (toll free)
P 408 866 8300
F 408 866 4859
E [email protected]
E [email protected]
Technical Specifications
Support
When you purchase digital signage solu-
tions from Focus Enhancements, you not
only receive reliable products that deliv-
er superior performance every day, you
also receive unconditional service and
support from a team of seasoned video
professionals. All products are backed by
comprehensive warranties and optional
support contracts that cover installation,
training, 24/7 phone support, and prior-
ity parts replacement.
Consultation
With extensive experience in design-
ing, configuring, and integrating digital
signage solutions for leading organiza-
tions around the world, the Focus team
can help you select the right products for
your needs. If you have special require-
ments, solution consultation and custom
configuration services are available.
MODELS Mantis MC Mantis MG
Base System Gemini 2 Universal Media Card
SmartCard
Gemini 2 Universal Media Card
SmartCard
4-slot AV I/O expansion chassis
Disk 120GB 160GB or 500GB
Optical Drive CD/DVD CD/DVD
Expansion
Options
— Gemini 2 (2-channel)
8-VSB digital RF output, simultaneous
NTSC/PAL outputs
Network Compatible with the Linksys™USB 200M EtherFast USB 2.0 10/100 Network
Adapter; Integrated KenCast FAZZT client (option) or integrated Skystream zBand®
client (option); FTP and HTTP auto-updating; USB dial-up modem support; Ethernet
(10/100 Mbps)
Serial and Ethernet
Control
AMX, Leightronix, Crestron, Contemporary Research certified; Visual Circuits and
LDP protocol libraries
Video Outputs Composite, Component, or RGBHV (Component or RGBHV via DB15 connector
with VGA cable)
Video Decoding MPEG-2 unencrypted DVD (.vob) files: Decodes main profile at main level and
main profile at high level; MPEG-2 streams (ISO 13818-1): Decodes transport, pro-
gram streams, and elementary streams; decodes all 18 ATSC formats up to 1920 x
1080p; data rate up to 45 Mbps; 16:9, 4:3, 5:4 aspect ratios; 4:2:0 decoding
Audio Stereo or Dolby Digital via S/PDIF, stereo analog, MPEG Layers I, II, III
Software DART Network Media Management Software: For developing and managing a
large-scale, in-store digital media network (optional)
Media Messenger Remote Media Management Software: For managing and dis-
tributing media via FTP or HTTP to single or multiple Mantis servers (optional)
WebView: HTML-based setup, monitor, and control interface; requires Internet
Explorer 5.5 or higher (included)
Physical 4.45 cm (1.75") high (1RU) x 43 cm
(17") wide x 41 cm (16") deep
13.34 cm (5.25") high (3RU) x 43.18
cm (17") wide x 43.82 cm (17.25")
deep
Weight Approximately 5.5 kg (12 lbs.) Approximately 6.8 kg (15 lbs.)
Power 100–240V AC, 50/60 Hz; 60 watts
average
100–240V AC, 50/60 Hz; 90 watts
average
Temperature Range 0o–40oCelsius continuous operation
(0o–65oC short-term)
0o–40oCelsius continuous operation
(0o–65oC short-term)
Certification FCC Part 15, Class A; CE FCC Part 15, Class A; CE
