Forest-Master Bulk Log Stand 2 User manual

Safe, Secure, Multiple Log Sawhorse
IMPORTANT: Read this manual fully before assembly
and use and observe all safety rules and operating
instructions
BULK LOG
STAND 2 Patent
Pending

Bulk Log Stand 2
Contents
Technical Specification 2
Exploded View 3
Parts List 4
Assembly 4
Operation 8
Safety 10
Warranty 12
2
Technical Specification
Maximum total weight of logs 150 kg
Length 640 mm
Width 590 mm
Height (stored) 690 mm
Minimum working height 720 mm
Maximum working height 1300 mm
Weight 8.2 kg

Bulk Log Stand 2 3
Exploded View
1
2
10
3
4
5
9
6
7
8

Bulk Log Stand 2
Parts List
4
Item Description Qty
1 Log securing chain 2
2 Telescopic upright 4
3 U-Support 2
4 M8 x 45 mm cap head bolt 4
5 Large washer 2
6 Small washer 2
7 Foot 2
8 Bolt tube 2
9 Wood base 1
10 Thumbscrew 4
STEP 1:
Insert the bolt tubes (8) into
the outermost holes in the
wood base (9). The tubes
should be inserted from
the side with only 2 holes
visible, until approximately
28 - 29 mm of tube is still
protruding.
Assembly

Bulk Log Stand 2 5
Assembly
STEP 2:
Insert the protruding end
of one of the bolt tubes
into the hole in the top
of a foot (7) and secure
using a M8 x 45mm bolt
(4) and small washer (6).
Ensure that the bolt is
tight before proceeding to
step 3.
STEP 3:
Using a M8 x 45mm bolt
(4) and a large washer (5),
secure the bolt tube to the
wood base.

Bulk Log Stand 2
Assembly
6
STEP 4:
Repeat the procedure for
the remaining foot. As
before, first connect the
foot to the bolt tube using
a M8 x 45 bolt and small
washer then connect the
tube to the wood with a
M8 x 45 bolt and large
washer.
STEP 5:
Insert a U-Support (3) into
one of the holes in the top
of the wood base. Ensure
the locating tube is fully
seated in the hole. Repeat
for the second U-Support.
1
2

Bulk Log Stand 2 7
Assembly
STEP 6:
Insert a telescopic upright
(2) into one of the guide
tubes of a U-Support and
secure with a thumbscrew
(10). Repeat for the
remaining telescopic
tubes.

Bulk Log Stand 2
Operation
8
STEP 1:
Adjust the height of the
telescopic uprights to suit
the quantity of logs to be
sawn. To adjust an upright,
unscrew the thumbscrew,
move the upright to the
required height and tighten
the thumbscrew.
STEP 2:
Load the logs into the
U-Supports so that the
overhangs outside of the
U-Supports are roughly
equal.
Ensure you do not exceed
the maximum total weight of
logs given on page 2.
equal equal

Bulk Log Stand 2 9
Operation
STEP 4:
Begin cutting the logs by
sawing the overhanging
ends to the required
length of log then saw
down between the two
U-Supports.
If the overhanging ends
need to be cut into multiple
logs then cut alternately
from each end in order to
keep the weight over the
centre of the stand.
STEP 3:
Take a log securing chain (1)
and place one loop over each
of the telescopic uprights of
a U-Support. Note that the
flat part of the loop to which
the chain is attached should
be angled downwards.
Allow the chain to slide
down the uprights so it rests
on the logs.
Repeat for the second
securing chain on the other
U-Support.
1 3 2

Bulk Log Stand 2
Operation
10
STEP 5:
For easy storage turn the
U-Supports so they are
roughly parallel to the side
of the wood base and lower
the telescopic uprights.
The feet can also be turned
roughly parallel to the base,
note it may be necessary to
loosen the top bolt in each
bolt tube to do this. En-
sure that when the feet are
turned back to the working
position the bolts are re-
tightened.
Saftey
IMPORTANT: Please read these instructions care-
fully. Note the safe operational requirements, warn-
ings & cautions. Use the product correctly and with
care for the purpose for which it is intended. Failure to
do so may cause damage and/or personal injury and
will invalidate the warranty. Please keep these instruc-
tions safe for future use.

Bulk Log Stand 2 11
Safety
IMPORTANT SAFETY INFORMATION
Before using the log stand always check that all nuts and
bolts are secure and that the log stand is not damaged.
Use the log stand on firm level ground only. Do not use on
sloping or uneven ground.
After securing the logs in the log stand, check the stability
and balance before starting to cut. The log stand must not be
able to tilt.
Read and observe the operating instructions of the chainsaw
you are using and wear all recommended safety gear. Always
wear safety shoes or boots in case a log is accidentally
dropped on your feet.
Only cut with the bottom of the chainsaw bar as the log
may otherwise shift away from the rotating chain, become
unstable and increase the risk of personal injury.
Clear and stack the sawn logs away from the log stand to
keep the work area clear of obstructions and safety hazards.
IMPORTANT: Check that the logs are secure and the log
stand is stable before beginning to cut.
WARNING: Do not exceed the specified maximum total log
weight as given on page 2 of this manual.

Bulk Log Stand 2
Warranty
12
Warranty
This product carries a one (1) year limited warranty against
defects in workmanship and materials. Should this product
become defective within the stated warranty period, return it
to the store with proof of purchase, and it will be replaced or
repaired free of charge.
This warranty does not apply if the product has been
subjected to physical abuse, neglect, misuse, wear and tear,
incorrect use or has been modified in any way.
This warranty in no way affects your statutory rights.
IMPORTANT: NO RESPONSIBILITY IS ACCEPTED FOR
INCORRECT USE OF THIS PRODUCT.
NOTE: It is our policy to continually improve products and as such
we reserve the right to alter data, specifications and component
parts without prior notice.
Manufactured under license for Forest Master Limited.
Head Office:
Forest Master Ltd, Industry Road, Heaton, Newcastle Upon Tyne,
NE6 5XB, United Kingdom.
Tel: [phone]
email: [email protected] - web: www.forest-master.com
