Forest MODPERGPPK Instruction manual

FIXING PACK CONTAINS:
It is vital that your pergola is on a level ground in your desired location.
4 x 60mm Screws
QTY: 13
Making British gardens great
MODULAR PERGOLA
PANEL PACK INSTRUCTIONS
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
ISSUE: 0121
FIXING PACK CODE: MODPERGPPKFP
We recommend using the following tools (not supplied):
Tape
Measure
Pozidrive
Screwdriver
Drill & 2mm
Drill Bit
Hammer Ladder Spirit Level
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
THE ROOF OF THIS BUILDING IS NOT A LOAD BEARING STRUCTURE
4 x 40mm Screws
QTY: 4
Missing something or need more information?
Call our aftersales team on
0333 777 7089
Visit our website for spare instructions and
more information
www.forestgarden.co.uk

Please make sure you have purchased and assembled
the modular pergola base kit rst. Ensure there is
enough working space when attaching your panels.
CONTINUATION..
2 x PANELS
1
2
60MM
SCREWS
Ensure the panel is in contact with the
70x70mm frame & screw to post.
Screw 3rd panel to the post. Ensure panel is
15mm down from the central beams / at the
same height as the other 2 panels.
60MM
SCREWS
15mm
60MM
SCREWS 60MM SCREWS
4 x PANELS
Repeat for other panel & screw panels
together. Screw through the fascia into the
panel for extra rigidity.
Screw the cover strip in between the 2
meeting internal panel faces.
Repeat for other panel & screw panels
together. Screw through the fascia into the
panel for extra rigidity.
Screw the cover strip in between the 2
meeting internal panel faces.
.

60MM
SCREWS
3
Repeat the same process as shown in step 1 (with 2 x panels).
6 x PANELS
DID YOU KNOW?
Part Code Description No.
885MPSLAT 885 x 45 x 1910mm Slatted Panel 2
44121910PTR
44 x 12 x 1910mm Cover Strip 1
Modular Pergola Panel Pack (MODPERGPPK)
CHECK YOU HAVE ALL YOUR PARTS.
(The parts do not have codes on them. They are listed below should you need to order one.)
TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
You can have your panels facing outwards rather than inwards. Just follow the same steps but with the
panels facing the opposite way round. Guidance is shown below.
PLEASE NOTE - The cover strip will have to be cut down to 1890mm if the panels are facing outwards to
reduce any overhang of the cover strip. Once cut, you cannot change the panels to face inwards.
60MM
SCREWS
