ASSEMBLY INSTRUCTIONS FOR THE
ARCHED OPEN SKY PERGOLAS
866.332.2403 (TOLL FREE); 7am –7pm Pacific Time, Monday-Saturday

P| 1
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
CONTENT OF BOXES
No.
1
2
3
4
5
6
7
8
9
Drawing
Hurricane
Gale Wind
Standard
Description
Posts
Single Supports
Supports with
In-Between Blocking-A
Arched Rafters
Main Knee Braces
Secondary Knee Braces
Slats
Boots
If ordered
Standard, Gale Wind or
Hurricane Anchors Bases.
If ordered.
Qty.
Will vary
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent.

P| 2
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
HARDWARE LIST
No.
A
B
C
D
E
F
G
H
I
J
Drawing
Description
½´´ X 3 ½´´ Anchor Bolts
(To attach the anchor bases to the ground).
5/16´´ X 3´´ Lag Bolts
(To attach the anchor bases to the posts).
3/8´´ X 6 ½´´ Bolts
(To attach the supports to the posts. / To
attach the supports together. / To attach the
main knee braces to the supports).
3/8´´ X 6´´ Bolts
(To attach the arched rafters to the posts).
3´´ Deck Screws
(To attach the arched rafters to the
supports. / To attach the slats to the arched
rafters. / To attach the boots to the posts).
5/16´´ X 5´´ Bolts
(To attach the secondary knee braces to the
arched rafters).
3/8´´ X 9´´ Bolts
(To attach the knee braces to the posts).
3/8´´ Nuts
5/16´´ Nuts
Washers
Note: Dimensions of your hardware will vary depending on size.

P| 3
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
No.
.
1
2
3
4
5
6
7
8
9
DESCRIPTION
Posts
Single Supports
Supports with
In-Between Blocking-A
Arched Rafters
Main Knee Braces
Secondary Knee Braces
Slats
Boots
Standard Anchor Bases
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.

P| 4
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
NOTE: In order to know where the post needs to be placed, check the numbers on them. If the post is not marked, then place the
single Supports on the ground to locate the markings for each post position and clearly set your bearings. (“Don´t attach yet, only
place them on the ground to begin with”).
Step 1: Install the anchor bases (9) with ½´´ X 3 ½´´ anchor bolts (A). Please see the “How to anchor your pergola document”
for all details. Set your post (1) in the saddle of the anchor bases. Drill a ø ¼´´ hole in the post prior to anchoring to facilitate the
ratcheting of the hardware. After that, use 5/16´´ X 3´´ lag bolts (B) to attach each post to its respective anchor base.
Step 2: Use 3/8´´ X 6 ½´´ bolts (C) to attach the single supports (2) to the posts. Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
1
1
1
1
2
2
9
5/16´´ X 3´´ Lag Bolts
3/8´´ X 6 ½´´ Bolts

P| 5
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
Step 3: Place the supports with in-between blocking (3), into the post notches as shown and attach to the post with the single
support bolts. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 4: Attach the single supports to the supports with in-between blocking (3), use 3/8´´ X 6 ½´´ bolts (C).
3/8´´ X 6 ½´´ Bolts
3
3
3
3

P| 6
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
Step 5: Use 3/8´´ x 6´´ bolts (D) to attach the perimeter arched rafters (4) to the posts and 3´´ deck screws (E) to attach to the
supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 6: Attach the main knee braces (5) to the supports with 3/8´´ x 6 ½´´ bolts (C) and to the posts with 3/8´´ x 9´´ bolts (G).
Each part has a series of numbers that indicate where to attach the part with the corresponding number.
4
4
5
5
5
3´´ Deck Screws
5
3/8´´ X 6´´ Bolts
3/8´´ X 9´´ Bolts
3/8´´ X 6 ½´´ Bolts

P| 7
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
Step 7: Attach the Secondary knee braces (6) to the rafters with 5/16´´ x 5´´ bolts (F) and to the posts with 3/8´´ x 9´´ bolts (G).
Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 8: Use 8´´ x 3´´ deck screws (E) to attach the central arched rafters (4) to the supports. Each part has a series of numbers
that indicate where to attach the part with the corresponding number.
4
3´´ Deck screws
6
6
6
6
5/16´´ X 5´´ Bolts
3/8´´ X 9´´ Bolts

P| 8
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
Step 9: Attach the Slats (7) to the arched rafters with 8´´ x 3´´ deck screws (E). Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
Step 10: Finally, attach the boots (8) to the posts with 3´´ deck screws (E). Each part has a series of numbers that indicate where
to attach the part with the corresponding number.
7
8
8
3´´ Deck Screws
8
3´´ Deck Screws
8

P| 9
ARCHED OPEN SKY PERGOLAS
www.ForeverRedwood.com
This completes the Pergola assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question,
