Forever Redwood LATTICE GAZEBO User manual

Lattice Gazebos
www.foreverredwood.com
866.332.2403 (Toll Free); 7am-7pm Pacific Time, Monday-Saturday
Assembly instructions for:
LATTICE GAZEBOS

Lattice Gazebos
www.foreverredwood.com
Quantity Description Drawing
3 Front wall panels –
door and window
panels
3 Rear wall window
panels
4 Wall Posts
6 Left side & right side
walls
1 Bar tabletop
6 Roof timbers

Lattice Gazebos
www.foreverredwood.com
10 Roof panel 82
10 Rafters
10 Rafter cover
1 Rooftop panel
Quantity
Description
6
Bolts 4” x 5/16”, washers & nuts
10
Bolts 6 ½”x 3/8”, washers & nuts
4
Bolts 3 ½”x 5/16”, washers & nuts
8
Bolts 4 ½”x 5/16”, washers & nuts
4
Bolts 8” x 3/8”, washers & nuts
130
Screws 3”x 8” SS

Lattice Gazebos
www.foreverredwood.com
ASSEMBLE WALLS: Attach front wall
deckscrews (3”X 8”). (Match up the
together).
ASSEMBLY
The parts that go togetherhave the same numbers written next to the predrilled holes they attach to.
Align the parts with the numbers as shown for ease of reference.
Step 1:
door frame section to post with six
numbers to attach the two parts
Step 2:
Attach front wall door frame panel to front wall
window panel with six deckscrews (3”X 8”).
(Match up the numbers to attach the two parts
together). And repeat the steps 1 & 2 in all
walls & the post
When you finish, the walls
of the Gazebo should be as
shown.

Step 3:
Attach bar tabletop to front wall with six deckscrews (3”X 8”). (Match
up the numbers to attach the two parts together).
Step 4:
Attach the roof timbers with 4 bolts (3 ½”x 5/16”), washers & nuts as shown. (Match
up the numbers to attach the two parts together). Tap the bolt all the way into the
wood to set it. Then add a washer and nut and lightly tighten.
2 bolts
2 bolts
Step 5:
ASSEMBLE BASE OF
THE ROOF: Attach the 2
roof timbers from step 4
to the remaining 2 longer
roof timbers with 8 bolts
(4 ½”x 5/16”) washers &
nuts. (Match up the
numbers to attach the
two parts together). Tap
the bolt all the way into
the wood to set it. Then
add a washer and nut
and lightly tighten.
Lattice Gazebos www.foreverredwood.com

Step 6:
Attach 6 of the center rafters
to the rooftop with 6 bolts
(4”x 5/16”) washers & nuts.
One per rafter. (Match up the
numbers to attach the two
parts together). Tap the bolt
all the way into the wood to
set it. Then add a washer
and nut and lightly tighten.
Step 7:
Attach the corner rafters to
the rooftop with 4 bolts (8”x
3/8”) washers & nuts. (Match
up the numbers to attach the
two parts together). Tap the
bolt all the way into the wood
to set it. Then add a washer
and nut and lightly tighten.
Step 8:
Attach the 10 rafters to
base of roof with 10 bolts
(6 ½”x 3/8”) washers &
nuts. (Match up the
numbers to attach the
two parts together). Tap
the bolt all the way into
the wood to set it. Then
add a washer and nut
and lightly tighten.
Step 9:
Lift the roof into place and
attach to walls with 30
deckscrews (3” x 8”). (Match
up the numbers to attach the
two parts together).
Lattice Gazebos www.foreverredwood.com

Step 10:
Attach the Roof panel to
rafters with six deckscrews
(3”x 5/16”). And repeat the
process in all the panels.
Step 11:
Attach the cover of rafters to roof
panel with three deckscrews (3”x
8”). And repeat the process in all
the panels of roof and fill between
gaps with silicone.
