Formax FD 8502AF User manual

3/2016
FD 8502AF AutoFeed
Cross Cut Paper Shredder
Oil Indicator
The “MANUAL” LED will ash after every four (4) hours of operation as an indicator to
oil the shredder cutting blades. The LED will continue to ash until oiled. NOTE: the
shedder will still operate when the LED is ashing but at a decreased load capacity.
TO OIL: Spread shredder oil onto the cutters through the feed opening, and allow the
oil to sit for a few minutes to permeate the cutting blades, then press the “REV” button
and hold for ve seconds. “MANUAL” and “REV” LED indicators on control panel will
light. The shredder will operate in reverse for one minute, then the “AUTO” LED will light
indicating the shredder is ready.
Maintenance
• Disconnect power by pulling power cord plug from wall outlet.
• To clean the exterior, wipe the surface with a soft cloth. If the surface is very dirty, use a
neutral detergent, then wipe again with a soft cloth.
CAUTION:
• Never put water directly on the surface of the shredder.
• Never clean the case with benzene or thinner, since it will cause discoloration.
• Do not dismantle the shredder. Contact your Formax Dealer for service.
Safety Devices and Other Features
Automatic Reverse Rotation
When too much paper is inserted, the cutter stops operating and automatically rotates in
reverse to discharge the jammed paper. The shredder will beep. Reduce the amount of
paper and restart the operation.
Door Switch
If the door is open, the shredder will not operate.
Automatic Stop
When the waste bin is full, the “FULL” LED will light and the cutter stops operation.
Open the door, remove the waste bin and empty. Replace the waste bin, close the door,
and press START to resume operation.
Automatic Power Shut-Off
If the shredder operates continuously for more than 30 minutes, the power is
automatically shut off.
If the motor is overloaded, the “STOP” LED will ash until it cools down. When the
ashing stops the shredder is ready to be used again.
Safety Precautions, continued
•Unplug the shredder when it is being moved, or if it is not in use for an extended
period of time.
•Do not disconnect the power by pulling only the cord.
•Keep the shredder away from direct sunlight.
•Do not sit on the shredder or place anything on top of it.
•Never open the xed switch or cover.
OPERATOR MANUAL
THIRD EDITION

Set-up Guidelines
1. Install the shredder on a level surface, away from heat sources and direct sunlight.
2. Insert plug into wall outlet with the appropriate voltage, 110V. If the outlet is shared
with another electronic device, the total current should not exceed 30A (at 110V).
Specications
Cutting Style: Cross Cut
Shred Size: 5/32” x 1-1/5”
Auto-Feed Hopper: Up to 175 sheets
Hand-Feed Hopper: 22 to 24 sheets
Speed: 35 feet per minute
Feed Opening: 16” (hand-feed hopper)
Dimensions: 24” W x 20” D x 35” H
Security Level Level 3
Bin Capacity: 33 gal.
Weight: 242 lbs.
Power supply: 110V, 50/60 Hz
Accepts credit cards, staples and paper clips in hand-feed hopper
Auto-Feed Auto-Feed
Hopper Lid
1. To use the Auto-Feed Hopper, select “Auto” .
2. Lift open Auto-Feed Hopper Lid.
3. Press down Auto-Feed Lever and load up to 175
sheets of paper to be shredded. Release lever.
NOTE: Load 8.5 x 11” paper landscape and 8.5 x 14”
and 11” x 17” paper portrait. Feeder does not accept
staples or paper clips.
4. Paper will automatically feed and be shredded.
Cutting blades will stop after shredding is complete.
5. Close lid when Auto-Feed Hopper is not in use.
Auto-Feed
Lever
* Sheet capacity varies depending on paper and power supply
ECO Mode
When the power switch on the right side of the shredder (see below) is initially turned
on, the shredder is automatically in ECO Mode. This energy-saving feature puts the
shredder into standby after 5 minutes of inactivity.
When the shredder is in standby, the ECO Mode LED on the control
panel will be lit.
To exit ECO Mode and begin shredding, press START until the Auto LED is lit.
Operation
1. Flip the power switch “ON” located on the right side of the shredder.
2. Auto Start/Auto Stop
When the START button is pushed, the “AUTO” LED will light. Insert
paper to shred. The shredder will start and stop automatically when
using this function.
3. Manual Operation
If paper is too small for the shredder’s sensors to detect, shred it
manually. Push the START button once more and the “MANUAL” LED
will light. Insert paper to be shredded. Three minutes after shredding,
the cutter automatically stops rotating.
4. Reverse Operation
Push the REV button and the “REV” LED will light and cutters will
operate in reverse. If too much paper is inserted at one time in
standard modes, the shredder will automatically operate in reverse. If
this occurs, remove the inserted paper and shred in smaller amounts.
NOTE: The maximum amount of paper to be shredded differs
according to paper quality, humidity and voltage. If the shredder is to
be used continuously, do not insert more than half of the maximum capacity.
5. Full Sensor
If the wastebasket is full, the “FULL” LED will light and the cutter will stop
automatically. Open the door, remove and empty the waste bin. Replace the waste
bin, close door, and press START to resume shredding.
Safety Precautions
To avoid personal injury, and damage to the shredder,
observe the following safety precautions. Please keep these
instructions for future reference.
NOTE: In case of emergency, ip the “Power Switch”
to cut off power and/or pull the plug out of the wall outlet.
Power switch
continued on the next page
•Keep hands, long hair, clothing, ties, jewelry and loose
items away from the feed opening and shred outlet.
•Do not use the shredder for anything other than its intended purpose. Never use
it to shred cloth, plastic, cardboard or any hard material that will cause damage to
the shredder blades.
•Do not allow children to use the machine.
•Do not operate with a damaged power cord or plug, or when the machine is
damaged in any manner.
