Forward Industries KBAO2221 User manual

Smart Desk
KBAO2221
Imported By: Forward Industries, 33401
Assembly Instrucons
Product REF: KBAO2221
08/12/20

1
When using an electrical furnishing, basic precauons should always be followed, includ-
ing the following:
Read all instrucons before using (this furnishing).
DANGER – To reduce the risk of electric shock:
· Always unplug this furnishing from the electrical outlet before cleaning or servicing.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
· Unplug from outlet before pung on or taking off parts.
·Close supervision is necessary when this furnishing is used by, or near children, invalids,
or disabled persons.
· Use this furnishing only for its intended use as described in these instrucons. Do not use
aachments not recommended by the manufacturer.
·Never operate this furnishing if it has a damaged cord or plug, if it is not working properly,
if it has been dropped or damaged, or dropped into water. Return the furnishing to a
service center for examinaon and repair.
· Keep the cord away from heated surfaces.
· Never operate the furnishing with the air openings blocked. Keep the air openings free of
lint, hair, and the like.
· Never drop or insert any object into any opening.
· Do not use outdoors.
· Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
· To disconnect, turn all controls to the off posion, then remove plug from outlet.
·For chairs and similar furnishings with movable parts such as foot supports the following
statement: “WARNING: Risk of Injury – Keep children away from extended foot support (or
other similar parts).″
·For grounded products the following statement: “WARNING: Risk of Electric Shock – Con-
nect this furnishing to a properly grounded outlet only. See Grounding Instrucons.″
· For loading always put heavier items at the boom and not near the top in order to help
prevent the possibility of the furnishing pping over.
·If a surface is not intended to support video monitors such as televisions or computer
monitors, one of the following statements: “Warning: Risk of Injury to Persons – do not
place video equipment such as televisions or computer monitors on ________″where the
blank is filled in to idenfy the parcular surface.
“Warning: Risk of Injury to Persons – do not use this furnishing to support video equip-
ment such as televisions or computer monitors.″
·Each surface intended to support a load shall have a corresponding statement in the use
instrucons specifying the maximum intended load for that surface in pounds (kilograms),
· Mount furnishings at the correct height.
Important Safety Instrucons

2
For Household use only.
Save These Instrucons
In a double-insulated product, two systems of insulaon are provided instead of ground-
ing. No grounding means is provided on a double-insulated product, nor is a means for
grounding to be added to the product. Servicing a double-insulated product requires
extreme care and knowledge of the system, and is to be done only by qualified service per-
sonnel. Replacement parts for a double-insulated product must be idencal to the parts
they replace. A double-insulated product is marked with the words “DOUBLE INSULATION″
or “DOUBLE INSULATED.″ The symbol (square within a square) is also able to be marked on
the product.
Servicing of Double-Insulated Products

1. The maximum weight that can be placed on this product is 265lbs.
2. This product must not be used as a seat.
3. Always use the original AC power adapter and power cable supplied, otherwise it may
cause slow wireless charging. In extreme cases, an incompable AC power adapter
may overheat.
Input: 100-240V~, 50/60Hz, 4.0A
Safety and Care Advice
Specificaons
3

Foot Qty 2
(23.62’’ x 3.15’’ x 1.42’’)
Desk top Qty 1
(49.21’’ x 25.51’’ x 5.43’’)
Leg Qty 2
(7.68’’ x 5.40’’ x 25.95’’)
NO Component Name Qty
Desk Top
Leg
Foot
1
2
3
1
2
2
2
2
3
1
3
Main Components
Please check you have all the parts listed below
4

M6*0.63’’ Screw Qty 8 M8*0.39’’ Screw Qty 12 M5 Allen Key Qty 1
M4 Allen Key Qty 1 78.74’’ Electric Cable Qty 1
For missing or damaged parts, call our Customer Helpline: [phone], opon 0. or
email [email protected].
Fixings, Fings and Tools
Please check you have all the parts listed below
Note: The quanes below are the correct amount to complete the assembly. In some cases
more fings may be supplied than are required.
5

M8*0.39’’ Screw Qty 12
M5 Allen Key Qty 1
M6*0.63’’ Screw Qty 8
M4 Allen Key Qty 1
Assemble Legs 3 to
Top 1 using Fxings B .
Assemble Feet 2 to
Legs 3 using Fxings A .
Note: Ensure the longer
secon of the feet are
located at the front as
shown.
Assembly Steps
Step 1
Step 2
3
2
2
2
3
B
B
A
3
Back
Front
Back
Front
Shown Upside Down
1
6

Complete all cable
connecons as shown.
Step 3
Warning!!!
Do Not Connect to a power
source at this stage.
Front
!
1
2
3
①Cable to Motor
②Cable to Motor
③Cable to Power
Connecons
Power
Key Pad
Motor
Motor
Control Box
Connecons
Control Box
Connecons
7

With help, carefully
turn the desk over into
it’s final locaon and
connect to a power
source.
Step 4 Two People Required.
Warning!!!
The desk is heavy!
To avoid injury, li with care.
!
8

Up Key
Down Key
Memory Keys
USB Port
USB Port
Acvaon
You will need to acvate the memory keypad once the desk is fully assembled, and con-
nected to a power source. If the frame doesn’t seem to be working properly, rest assured
that most issues can be resolved using the acvaon process.
1.If the handset is locked, first step is to unlock.
2.Begin by pressing and holding the “Up” and “Down” keys at the same me.
3.Connue to hold as the frame lowers itself all the way down. You will hear a slight beep
sound followed by a brief flash on the display.
4.Release the “Up” and “Down” Keys.
5.Press the “Up” Key once to engage the motors, your desk should be acvated and
ready to go.
Memory Funcon
To preset a specific height, use the “Up” and “Down” Keys to reach the required height.
Press the “Up” and “1” keys at the same me for about 2 seconds.
“P1” should appear on the display.
Repeat the procedure to set a second preset height, using key "2".
“P2” should appear on the display.
Repeat the procedure to set a second preset height, using key "3".
“P3” should appear on the display.
Cenmeters and Inches Seng
The display can be changed to show cenmeters (C) to Inches (I).
Press the “1” “2” and “3” Keys together for about 5 seconds.
“C-I” should appear on the display.
Either press buon “1” display show the desk is in metric mode or press buon “2”
display the desk is in Imperial (inches) mode.
Desk Height Adjustment
1 2 3
KEY PAD
9

If you have a wireless charging compable device, please put the phone on the wireless
charging indicator and check if the phone is successfully connected to the charging func-
on. If not, move the mobile phone near the logo unl the connecon is successfully.
Some phone cases may inhibit the wireless charging funcon or it’s efficiency. It may be
necessary to remove the phone case if difficules are experienced.
Wireless charging will only work with wireless charging compable mobile devices.
Wireless charging funcon
10

This symbol is intended to alert the user to the presence of important operang and main-
tenance instrucons in this user manual.
a. In order to avoid accidents, do not open any electrical covers. Refer to a professional if
the circuit is faulty.
b. Do not expose the unit to damp or moisture.
c. Keep the unit away from containers holding liquid. If any liquid enters into the unit, it
may br damaged.
d. Do not expose the unit to dust or smoke.
e. If the unit will not be used for a long me, please unplug the power.
f. When using the unit, if smoke appears, or if there is a peculiar smell, please turn off the
power, pull out the socket and seek professional help.
g. Pull out the plug before cleaning the surface of the machine. It can be cleaned with a
damp cloth and soap.
This symbol is intended to alert the user to the presence of un-insulates “dangerous volt-
age” within the product’s enclosure that may be of sufficient magnitude to cause an elec-
tric shock.
WARNINGS!! Please read carefully
!
!
11

If you have quesons regarding the operaon of your purchase, or in the unlikely event
you need to return the unit because it is faulty or is no longer wanted, please contact our
product returns department at [email protected], or (561)
465-0030, opon 0. Address: 105 South Narcissus Avenue, Suite 412, West Palm Beach,
FL 33401.
If disposal of this product becomes necessary, please do this in an
environmentally responsible way. Contact your local government office or
authority for suitable disposal or recycling opons in your local area. Do not
dispose of this product, or it’s components, with your general domesc waste.
Aer Sales Support / Product Returns
Disposal
12

13
R
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following
two condions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operaon.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a
parcular installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
· Reorient or relocate the receiving antenna.
· Increase the separaon between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
FCC Statement
