Forward Industries Smart Side Table REFS-KBBM1115 User manual

Smart Side Table
PRODUCT REFS-KBBM1115 / KBBM1116/KBBM1117
Assembly Instruction
Thank you for purchasing the Smart Side Table. In order to make the best use of this product and to use it safely, please read the manual
carefully before use and keep it for future reference.
Imported By: Forward Industries, 33401. U.S.A
Issue 1-06/07/2020

①
Safety and Care Advice
1. The maximum weight that can be placed on this product is 33 LBS.
2. This product must not be used as a seat.
3. Always use the original AC power adapter and power cable, otherwise it may cause slow wireless charging,
poor bluetooth speaker function. In extreme cases, an incompatible AC power adapter may burn out.
Specifications
2.0 CH Bluetooth Table speaker
Bluetooth version: 4.2
Bluetooth transmit distance: Up to 32.8 feet
Bluetooth frequency: 2.402-2.480GHz
Drive units: 3" 4Ω 12W x 2pcs
RMS: 20W (10W*2)
Working voltage: DC 12V 2A
Wireless Charging: 5W (5V 1A)
Power Supply: AC adapter ,100-240V～50 / 60Hz
Function
Bluetooth
Hands free
Wireless charger function
TWS function ( true wireless stereo )

②
Main Components
Main Body Qty 1 (19*12.6*13 inch)
Legs Qty 4 ( 6.7 inch )
Legs Qty 4 ( 10 inch )
Note : two size legs options supplied
Accessories
Power Adapter Qty 1 (59 inch )
EVA pad Spare Parts（If required）
Qty 4 (1.18 inch)

③
Assembly Steps
Step 1
Place main body
upside down on to a
clean fat surface.
Note: Ensure the surface
is suitably protected to
prevent any scratches or
damage to the main body
.
Screw legs into
position on the underside
of main body .
Note: Two different legs
length options are
supplied.

④
Step 2
With help, carefully turn
the side table over into
the standing position.
Step 3
Plug the power
adapter into the ‘DC
IN’ port on the back of
main body .
Plug the adapter into an
electric socket for mains
power.

⑤
Controls / Functions
Front Back Top
1. POWER / TWS
2. PLAY / PAUSE / PHONE
3. VOLUME -
4. VOLUME +
5. MIC
6. BLUETOOTH MODE LED INDICATOR
7. TWS MODE LED INDICATOR
8. DC IN
9. WIRELESS CHARGING SYMBOL

⑥
Power On / Off
1. Connect the power adapter with the DC IN port (please make sure you use the original adapter supplied).
You will hear "Power on" from the speaker. The speaker will automatically enter Bluetooth mode as default,
and you will hear "Bluetooth, waiting for connection".
2. Press and hold the [ ] button to turn the unit off. You will hear "Power off".
3. Press and hold the [ ] button to turn the unit back on.
Bluetooth Connection and Play ( LED indicator: the left LED light )
1. With the power on and the unit in Bluetooth mode, it will automatically switch to pairing state. The blue
LED light will flash slowly. The Bluetooth device name is ‘KBBM Side Table’.
2. A phone or other device can now be paired with the unit.
3. You will hear "Bluetooth is Connected" after pairing. The blue LED light will become constant. If pairing
fails, the blue LED light will flash quickly.
4. During music playback, the music can be paused by short pressing the
【 】
button. It will play again after a
further short press of the【 】button.
5. When this unit is connected to a smart phone, press and hold the【 】button to switch off the Bluetooth
connection. You will hear "Bluetooth disconnected, waiting for connection".
6. Another device can be connected by repeating paring with Ralph. It is not possible to have two devices
connected simultaneously.
7. The best distance between smart phone and speaker is ≤ 32.8 feet.
Volume control
1. Press the
【➕】
button to increase the volume. The speaker will automatically defaults to mid volume when
switched on. You will hear the voice prompt“ Maximum volume”when volume is max. Meanwhile, please
increase the volume of the phone to maximum.
2. Press the 【➖】button to decrease the volume.
Phone calls when connected
1. If you receive a call whilst your Phone is connected via Bluetooth, the speaker will sound your ring tone.
Short press the
【 】
button to answer the phone and speak to the MIC. Short press the
【 】
button again to
hang up, or long press to decline the call.
2. Double press the【 】button to redial the phone number of the last call.
Wireless Charging
1. If you have a mobile device with wireless charging capability, it can be charged by placing it on the
wireless charging symbol on the top of the unit.
2. Make sure that the smart phone is within the charging area. Once charging begins, the charging signal will
be show on the phone screen. You can remove your smart phone form the charging area at any time to end
the charging process.
3. The wireless charger will charge compatible mobile devices even when the unit is turned off, providing the

⑦
AC adapter is connected, to a mains power source that is switched on.
4. Some phone cases may inhibit the wireless charging function. It may be necessary to remove the phone
cases to improve wireless charging efficiency.
TWS Function ( LED indicator: the right LED light )
1. If you have two side tables, you can listen to music in TWS mode via Bluetooth. Turn on both tables.
Double click the 【 】button of one speaker. The speaker will enter TWS paring mode. Your will hear an
acoustic signal and the orange LED indicator flash rapidly. After TWS pairing, the orange LED of main
speaker will become constant, and the LED of sub-speaker will flash slowly.
2. To switch off TWS pairing, press the【 】button of one speaker.
Automatic Power Off
The speaker will automatically turn off, if none of it’s functions are used after 10 minutes.
Disposal
If disposal of this product becomes necessary, please do this in an environmentally responsible way.
Contact your local government office or authority for suitable disposal or recycling options in your local area. Do
not dispose of this product, or it’s components, with your general domestic waste.
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.

⑧
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
After Sales Support /Product Returns
If you have questions regarding the operation of your koble purchase, or in the unlikely event you need to return
the unit because it is faulty or is no longer wanted, please contact our product returns department at
[email protected],or service number: 561-465-0030, Option 0.
Address: Forward Industries, 105. South Narcissus Avenue Suite 412, West Palm Beach, FL 33401
