Forward Industries HM-ST007-001 User manual

Issue 1 -11/11/20
NIGHTSTAND
Product Refs-HM-ST007-001

1. The maximum weight that can be placed on this product is 110lbs.
2. This product must not be used as a seat.
3. Check carefully to ensure correct and complete assembly before using.
4. Don’t allow children to play near the product as their behaviour is unpredictable. The manufacturer is
not responsible for loss, injury, or damage due to improper actions or use.
5.Do not use corrosive or abrasive materials near the product. Please ensure that the cleaner used
will not pollute the environment.
6. Cleaning should not be attempted by children without supervision.
7. Please make sure there are no hazard sources in your operating environment. e.g., do not leave tools
around. Always be careful to dispose of the packaging materials in order to avoid any possible danger,
e.g. plastic bags may lead to choking hazard to children.
8. We recommend you keep the original packaging of the item in case of the need for return or future
transportation.
9. Do not use outdoors. SAVE THESE INSTRUCTIONS. For Household use only.
APPROXIMATE 1 HOUR
ASSEMBLY TIME
2 PERSON ASSEMBLY

2
Top Panel Qty 1 Front Leg (Le) Qty 1
(18.89×13.38×0.59")
Back Leg (Le) Qty 1
(25.39×2.75×0.98")
Side Panel (Le) Qty 1
(10.62×15.55×0.47")
(25.39×2.75×0.98")
34
Front Leg (Right) Qty 1
(25.39×2.75×0.98")
Back Leg (Right) Qty 1
(25.39×2.75×0.98")
56

3
Side Panel (Right) Qty 1 Apron Qty 1
(10.62×15.55×0.47")
Base Panel Qty 1
(13.77×11.81×0.59")
Stretcher Qty 1
(13.77×0.59×0.78")
(13.77×0.59×2.36")
9
Back Panel Qty 1
(14.56×14.33×0.11")
Drawer Front Qty 1
(13.62×4.72×0.59")
11 12
78
10

4
Drawer Side (Le) Qty 1 Drawer Side (Right) Qty 1
(11.81×3.93×0.47")
Drawer Back Panel Qty 1
(11.81×3.93×0.47")
Drawer Base Qty 1
(12.12×11.65×0.11")
(11.81×3.93×0.47")
15 16
13 14

5
Large Wooden Dowel Qty 20
(M6×1.18")
Small Cam Nut Qty 16
(M15×0.37”)
Cam Dowel Qty 23
(M5×1.41")
Large Cam Nut Qty 7
(M15×0.47”)
Small Wooden Dowel Qty 2
(M6×0.78")
Drawer Runner(DR) Qty 1
(11.81”)
Screw Qty 12
(M2.5×0.39")
E F
G (DR)
I
Wood Screw Qty 4
(M4×1.18”)
Drawer Runner(CR) Qty 1
(11.81”)
G (CR)
Knob Qty 1
(0.82”)
J
Drawer Runner(CL) Qty 1
(11.81”)
Drawer Runner(DL) Qty 1
(11.81”)
H (CL)
H (DL)

If you have questions regarding the operation of your purchase, or in the unlikely event
you need to return the unit because it is faulty or is no longer wanted, please contact our
product returns department at [email protected], or 561-465-0030,
Option 0.
Address: Forward Industries, 105 South Narcissus Avenue Suite 412, West Palm Beach,
FL 33401
6
Screwdriver
(Not supplied)
K
Screw Qty 3
(M4×0.62”)
Screw Qty 8
(M3×0.39”)
L

7
STEP 1
15mm
15mm
Cam Dowel Qty 23
47
3
56
12
8
Screw cam dowels
into various components
as shown.

Large Wooden Dowel Qty 20
8
STEP 2
15mm
15mm
4
7
3
56
Fit large wooden dowels
and small wooden
dowels into various
components as shown.
8
Small Wooden Dowel Qty 2
E
E
E
E

9
STEP 3
15mm
4
3
15mm
7
5
6
Small Cam Nut Qty 8
Insert small cam nuts
into side panels
and .
Locate front and rear legs
, , and in
the exact locaons shown.
Secure by ghtening
cam nuts .
FFFFFFFFFFFFFFD
4
7
2 3 5 6
FFFFFFFFFFFFFFD

10
STEP 4
STEP 5
Metal Slider(CR) Qty 1
Metal Slider(CL) Qty 1
L
L
L
Screw Qty 4
4
7
L
L
L
L
Screw Qty 2
K
K
K
10
H (CL)
G (CR)
H (CL)
G (CR)
Assemble drawer
runners and
to side panels
and using
screws .
H (CL)
G (CR)
47
L
Shown upside down
Underside
Assemble stretcher
to underside of top
panel using screws
.
K
10
1

STEP 7
Large Cam Nut Qty 1
9
8
Large Cam Nut Qty 3
9
8
4
STEP 6
Shown upside down
Underside
11
Fit large cam nut
into base panel .
Locate apron into
posion and secure by
ghtening the cam nut.
C
9
8
Fit large cam nuts
into base panel as
shown.
Locate base panel
assembly onto side
panel .
Secure by ghtening
cam nuts.
9
4
C

12
STEP 8
9
7
Large Cam Nut Qty 3
4
STEP 9
Small Cam Nut Qty 4
Repeat step 7 assembly
for side panel .
7
Stand the unit upright.
Fit small cam nuts
into side panels
and .
Locate top panel
into posion and secure
by ghtening cam nuts.
FFFFFFFFFFFFFFD
7
4
1
7

13
STEP 10
11
F
F
F
F
Screw Qty 12
F
Fit back panel using
screws .
11
F
F

14
STEP 11
15
16
13
14
12
I
I
Wood Screw Qty 4
I
Small Cam Nut Qty 4
Align grooves
16
15 I
Fit small cam nuts
into drawer side panels
and .
Assemble drawer side
panels and
and drawer front
together and secure by
ghtening the cam nuts.
Slide drawer base
into the grooves.
Assemble drawer back
panel using screws . I
13 14
13 14
12

STEP 13
15
I
Screw Qty 1
Metal Slider(DL) Qty 1
Metal Slider(DR) Qty 1
L
Screw Qty 4
KJ
Knob Qty 1
G (DR) H (DL)
12
L
L
L
L
K
J
G (DR)
H (DL)
STEP 12
Fit drawer runners
and using screws .
Fit drawer knob
using screw .
G (DR)
L
H (DL)
J
K
Locate drawer onto
runners.
L
L
H (DL)

16
I
