FOS 12R Hybrid
User Manual
Congratulations on purchasing this 280W moving Beam
Light Thank you for extending your trust in our technology!

Voltage : 110W~240V/50-60Hz
Lamp : OSRAM 280W
Power consumption: 470W
Lens : high precision optical lens
Color wheel: 13 dichroic filters + white
Rotating Gobo Wheel, with 9 bidirectional and indexable gobos
(outside diameter: 15,4 mm, image diameter: 13 mm)
Static Gobo wheel with 14 fixed gobos, at variable rotation
Prism 1: 8-facet circular prism rotating in both directions at different speeds Prism 2: 6-facet
linear prism rotating in both directions at different speeds Zoom: parallel beam angel
2.5°-20° change
Wash effect : adjustable Wash effects angle
Focus: linear adjustment
Dimmer : 0-100% linear adjustment
Strobe : Double lens strobe (0.5-9 times/ second)
automatically accurate positioning
Fixation option: Pan/Tilt-lock mechanism
Control mode : Standard DMX512, Automatic and Master/ slave mode Channel : 16 CHs /
24 CHs
Controller can open the lamp and reset, including delaying function Carton Size:
490x365x710mm
G.W: 19 Kg
FOS 12R Hybrid
FOS Technologies - 2

2/11
by the warranty.
This product leaves our works in a perfect condition.Please observe all notes in these operating instructions to
warrant this condition and the safe operation of hte product!
Any damage caused as a result of the non-compliance with these operating instructions leads to the expiration of
any warranty claim.The manufacturer does not accept liability for any damage to property or for personal injury
resulting from the improper handling of the product,or non-observance of the operating instructions.
Store these operating instructions in a safe place for later reference and pass them to any new holder when selling
or lending or leaving this device in the hands of any other party.
Application According to Purpose
This product is a lighting effect which creates specila light effects with one lamp.Togenerate these effects,the
product must be connected to mains and a DMX-512 compatible controller.
This product is designed for AC110~240V/50~60Hz operation and exclusively for indoor use.
If used for any purpose other than described in these operating instructions,the device may suffer damage and the
warranty expires.Also,any other use is linked with risks such as short circuits,fire,electrical shock,etc.
The manufacturer's serial number must never be removed as otherwise the warranty expires.
Notes on safety
1. Before Operation
Prior to the initial operation of this product,please do the followings
-Read these operating instructions with great care;
-Study and observe all instructions carefully;
-Ensure that everybody and anybody involved in the installation,operation,transport and storage of this product is
suitably qualified;
-Verify whether any visible damage was caused during transport.lf the power cord.housing or the light are
damaged,do not operate the device;contact your specialized dealer immediately.
2. Supply Voltage,Mains Cord and Connection to Mains
The handling of supply voltage,mains cords and connections to mains calls for particular care considering the risk
from a life-threatening electric shock,the risk of fire and the risk of short circuits please observe the following notes
in particular:
Products operating on supply voltage should be kept out of the reach of children.Therefore ensure the permanent
supervision if children are in the immediate vicinity of the product!
For commercial facilities the regulations on the prevention of accidents of the respective trade association must be
observed.The operation of this equipment at schools,training facilities,and hobbyorself-help workshops must be
supervised responsibly by trained personnel.
Check the product regularly for any damage to the mains cord! Should you discover any damage to the malns cord,
do not operate or disconnect this product! Secure the product against accidental operation and contact your
specialized de-alert.
Always separate the product from mains by holding the mains plug by the handling surface .Never disconnect by
holding the line cord ! Be sure to connect the product exclusively to AC110~127V/59~60Hz!
Always insure during installation,operation, transport and when storing the product that the mains cord is not
exposed to possible mechanical damage, or damage caused by humidity,fluids,heat or cold!
The products cable entry must not be exposed to stress from pull! Create the mains connection once the product
has been installed only .Always connect the mains plug last !
The producct must only be connected to a proper outlet of the public supply grid .Connect the mains cord to suitable
outlets only ! Use entensions cords in compliance with specifications only! Do not allow the mains cord to come into
contact with other cords!
Ensure during installation ,operation,transport and storage that none of the cables are freely exposed!
Never touch the mains cord ,mains plug and outlet with wet or damp hands !
When not using the product, and proform to cleaning always disconnect the product from mains! To do so, hold the
mains plug by the handling surface and never pull the mains cord!
Never connect the device to dimmer packer!
3. Housing
ATTENTION
：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT
！
FOS Technologies - 3
For reason
FOSs of Technologiessafety - 1
and approval(CE) the personal reconstruction and/or modification of this product is
prohibited.Please observe that damage caused by modifications performed manually to this device is not
covered

3/11
Always insure during installation,operation,transport and when storing the product that no shocks or other forces
impact the housing !
The housing must not touch onto any other devices or objects during operation!
Easily flammable materials,e.g. decoration material and other surfaces and objects,must maintain a minimum
distance of 3m to the housing !Walls must maintain a minimum distance of 50cm to the housing!The device must be
installed on a fireproof surface only (no carpet)1 Always ensure a proper circulation of air.
Do not touch the housing during operation it will heat up .The housing is safe to touch approx .5 minutes following
the end of operation!
The device must never be carried via the projector anns.Use the caring handles only !
Fluids must not enter the housing as this could reduce the protective insulation and may trigger short circuits which
may lead to fatal electro shocks !If fluids have entered, disconnect the mains plug immediately and secure the
product against unintentional operation and contact yours specialized dealer! Damage caused as a re-suit of fluids
entering the housing is exempt from warranty .
No metal parts or other items must enter the housing as this may reduce the protective insulation or trigger short
circuits which may lead to fatal electric shocks !If metal parts or other items have entered ,disconnect the mains plug
immediately,secure the product against unintentional operation and contact your specialized dealer!Damage caused
by metal parts or other items in the housing is exempt warrantably.
4. Operating Environment
The product must be operated
and stored in a dry environment
only !
Splash water ,rain,humidity,fog may reduce the protective insulation which may lead to fatal electric shocks!The limit
value for relative humidity is 50% at 45℃.A minimum distance of 1.5m to a fog machine must be observed ;fog
saturation in the room must not reduce the visibility to below 10m .
The product must be operated at a temperature range of between -5℃ and 45℃ only.Protect the product against
direct exposure to sunlight or other heat,such as from radiators! If the product is taken from a cold environment into
a warm environment it must only be taken into operation once it has reached ambient temperature,since the
condensation created by the difference in temperature may destroy the device!
Protect the product against dust!Dust may reduce the protective insulation,which may cause fatal electric shocks!
The product must be operated at altitudes ranging between 20m below and 3000m above sea level only!
The product must not be operated during thunder storms;risk of destruction from surge voltages!
The product must be operated at a minimum distance of 1.5m to lit objects only!
5. Installation
6.
This product can be operated suspended or as stand-alone system.
Should your lighting effect show any signs of damage,do not install the device!In this case,have your lighting effect
repaired by your specialized dealer.The manufacturer does not accept responsibility or liability for damage to
property or personal injury resulting from an improperly installation!
As a stand-alone system the device must be installed vertically on an absolute planar,firm,fireproof,shock and
vibration-free surface.The installation of this lighting effect must be carried out by trained and professional staff!The
installation of this lighting must only be carried out with the appropriate materials!
The suspended installation of this lighting effect necessitates a suitable suspension system!The lighting effect must
never be fixed swinging freely in the room.No individuals should linger underneath the lighting effect during
suspended installation!
It is a must to install this device with a second independent fixture.Such second fixture must guarantee in the event
of failure of the main fixture that no assembly parts will fall down.Use the fixture on the undersurface only.
The light effect unit must be attached via two certified hooks and omega bracket to a tie-bar system.Use the screw
threads on the undersurface only.
It must be ensured that an expert inspects the mechanical and safety-relevant installation prior to the initial
operation and following major modifications,prior to the renewed operation.It must be ensured that an expert
inspects the mechanical and safety-relevant installation at least once a year.It must be ensured that an expert
inspects the mechanical installation and the installation of relevance to safety within the framework of an
acceptance test at least every four years.
ATTENTION
：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT
！
ATTENTION
：
RISK OF HORT CIRCUIT！
FOS Technologies - 4

4/11
The installation fixture must be as such that it can withstand for a period of 60minutes 10 times the load capacity
without harmful deformation.
It is prohibited for any individual to unnecessarily stay or pass beneath the installation during any type of assembly
work
.
The light effect unit must be secured by a safety arrester cable if fly-mounted.The cable must withstand 12 times the
weigh of the light effect unit Use arrester cables equipped with quick closing links.The dropping distance must not
exceed 20 cm.Defect arrester cables or arrester cables that have already been exposed to stress must not be used.
6. Operation
Controls
Link all DMX devices with a DMX-512 controller by using a standard,3-pin DMX cable.Connect the output of the first
device with the input of the second device and the output of the second device with the input of the third device and
so on.
Connect the mains plug to an outlet.
Operating the product for the first time may generate smoke and odour,this is not a defect.Avoid dis/connecting the
product repeatedly and quickly from/with mains!Always wait 15 minutes prior to the next dis/connection!
The device starts not until a self-testing and starting time.If the moving head is ready to start,push and roll the
function wheel.The LCD display shows the options,as below:
7. Lamps
During operation,the lamps will
reach temperatures of up to 600OC.Touching the lamps may cause serious burns!Objects coming into contact with
the lamps during and shortly after operation may catch fire!
Disconnect the product from mains prior to installing or before changing a lamp!Allow a lamp to cool for
approx.15minutes before exchanging it!
Never touch a lamp with bare hands!If damaged or deformed,a lamp must be exchanged!
When exchanging the lamp be sure to use suitable lamps only.Lamps with greater performance generate excessive
heat for the product;risk of fire!Damage resulting from the use of an unsuitable lamp is exempt from warranty!
Never connect the lighting effect to the mains prior with opened housing.
8. Fuse
Disconnect the product from the
mains prior before changing a
fuse.
Only replace the fuse by a fuse of same type and rating! An incorrect fuse could damage of destruct the lighting
effect.
Replace a fuse by levering the fuse holder cover with an appropriate screwdriver.Remove the old fuse and place the
fuse inside the holder.Replace the fuse holder and insert it.
Never connect the lighting effect to the mains prior with opened housing.
9. Cleaning
The product must be freed
regularly from dust,other deposits and contamination as this may reduce the protective insulation,which may lead to
a fatal electric shock!
Before cleaning,always disconnect the product from mains!
This product should be cleaned with a moist cloth only;never use aggressive cleaning agents,solvents or benzine
ATTENTION
：
RISK OF SHORT CIRCUIT！
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
ATTENTION
：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT
！
ATTENTION
：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT
！
FOS Technologies - 5

5/11
for cleaning.
Ensure that the product is completely dry before operating it again again after cleaning!
To avoid damage caused during
transport,wrap the product in its original packaging only and handle it with great care during transport!
10.
Menu setting
Main Menu Sub menu Sub menu Function
Setting Function Introduction
Characteristic
Setting
Move Mode
DMX Mode
Choose receive signal
Mode
Wireless Mode
Auto Mode
Channel Mode
Precision
Choose work channel
mode
Streamline
Customize
Pan Reverse Closed Pan scan normal
Open Tilt scan reverse
Tilt Reverse Closed Tilt scan normal
Open Tilt scan reverse
X degree 540 Pan 540 degree
360 Tilt 360 degree
Sensor Detect
Open Open scan Correction
function
Closed Closed scan Correction
function
No DMX Signal
Cleared All back to first date after
signal disconnect
Kepp All keep the final date
after signal disconnect
Color function Half color Half color open
Full color Half color closed
Shortest distance
Open Effet wheel from closed
to first
Close Effect wheel from move
direction to first
Back back to the last menu
Advanced Zero
Adjustment
Manually
Controlled
Use
Management
Back
Reset esume to factory setting
Save Save changed setting
Back Back to main menu
Light Reset All Motor YES All motor Self-Test
ATTENTION
：
FRAGILE!
FOS Technologies - 6

6/11
NO Return to last step
Part Motor YES Small Motor Self-Test
NO Return to last step
XY Motor YES Motor Self-test
NO Back to last step
Test Start
Auto
Enter Internal setting program
Back Back to last
Sound Enter Sound controlled to
interal setting program
Back Back to last step
Controller simulation
CH1---CH32 hand controlled to
channel function
Back Back to main menu
Information
search
Channel level CH1---CH32 channel DMX date
Other info
Display fixtures work and
software information
Error info Erroe info feedback
back Back to main menu
DISPLAY
SETTING
Backlit brightness 1-7 level Date valu higher display
brighter
Backlit delay keep on Display keep on
30 second
No operating 30 seconds
display become dark
20 second No operating 20 second
display become dark
10 second No operating 10 second
display become dark
Menu return no back No operating menu keep
same
Menu return 10 second No operating 10 second
back to main menu
20 second No operating 20 second
back to main menu
30 second No operating 30 second
back to main menu
Backlight blinking closed display keep same
without signal
open display flash without
signal
back Back to last step
save save changed date
back Back to main menu
Hand controlled hand controlled for lamp
on/off
LAMP
Lamp default lamp on choose channel
FOS Technologies - 7

7/11
SETTING Hand controlled lamp on/off by hand
Lamp on lamp controlled by
controller for you choose
back Back to main menu
Info reverse by 180
degree
Chinese- English
changed
Back menu
11. DMX Chart：
Standard
Mode
Simple Mode DMX value Function
Proportional
1 1 0-255 Pan
2 0-255 Pan fine
3 2 0-255 Tilt
4 0-255 Tilt fine
5 3 0-255 Pan/ Tilt speed
6 4 Macro
0-19 Blank
20-24 Half power function
25-129 Blank
130-139 Lamp on
140-149 Pan/ Tilt reset
150-159
160-169 Effect reset
170-199
200-209 Completr reset
210-229
230-239 Lamp off
240-255
7 5
COLOR
0-3 White proportional
3-13 Deep red proportional
13-22 Deep blue proportional
22-31 Yellow proportional
31-40 Green proportional
40-49 Magenta proportional
49-58 Light Yellow proportional
58-67 Light red proportional
67-76 Deep Yellow proportional
76-85 Pink proportional
85-94 Light Blue proportional
94-103 Light Green proportional
FOS Technologies - 8

8/11
103-113 CTO proportional
113-122 Amber proportional
122-129 White proportional
130-134 Deep red step
135-138 Deep blue step
139-143 Yellow step
144-147 Green step
148-152 Magenta step
153-157 Light Yellow step
158-161 Light red step
162-166 Deep Yellow step
167-171 Pink step
172-176 Light Blue step
177-180 Light Green step
181-185 CTO step
186-189 Amber step
190-215 Forwards rainbow effect
from fast to slow step
216-217 Stop step
218-243 Backwards rainbow
effect from slow to fast step
244-255
Random colour selection
by audio control
8 Colour wheel - fine
positioning
9 6 Speed of Rot. Gobo
selection from max. to
min.
10 7
Static gobo
0-3
4-9 Gobo1 step
10-15 Gobo2 step
16-21 Gobo3 step
22-27 Gobo4 step
28-33 Gobo5 step
34-39 Gobo6 step
40-45 Gobo7 step
46-51 Gobo8 step
52-57 Gobo9 step
58-63 Gobo10 step
64-69 beam reducer 1
70-75 beam reducer 2
76-81 beam reducer 3
Shaking gobos from slow to fast
88-95 Gobo1
96-103 Gobo2
104-111 Gobo3
112-119 Gobo4
120-127 Gobo5
128-135 Gobo6
FOS Technologies - 9

9/11
136-143 Gobo7
144-151 Gobo8
152-159 Gobo9
160-167 Gobo10
168-175 beam reducer 1
176-183 beam reducer 2
184-191 beam reducer 3
192-199 White
202-221 Static gobo from fast to slow
224-243 Static gobo from slow to fast
244-255 Random gobo selection by audio control
11 8
Rotating gobo wheel
0-4
5-7 Gobo1
Index - set indexing on
channel 12
8-10 Gobo2
11-13 Gobo3
14-16 Gobo4
17-19 Gobo5
20-22 Gobo6
23-25 Gobo7
26-28 Gobo8
29-31 Gobo9
32-34 Gobo1
Rotation - set rotation
on channel 12
35-37 Gobo2
38-40 Gobo3
41-43 Gobo4
44-46 Gobo5
47-49 Gobo6
50-52 Gobo7
53-55 Gobo8
56-59 Gobo9
Shaking gobos from slow to fast
60-67 Gobo1
Index - set indexing on
channel 12
68-75 Gobo2
76-83 Gobo3
84-91 Gobo4
92-99 Gobo5
100-107 Gobo6
108-115 Gobo7
116-123 Gobo8
124-129 Gobo9
130-137 Gobo1
Rotation - set rotation
on channel 12
138-145 Gobo2
146-153 Gobo3
154-161 Gobo4
162-169 Gobo5
170-177 Gobo6
178-185 Gobo7
186-193 Gobo8
FOS Technologies - 10

10/11
194-199 Gobo9
202-221 gobo wheel rotation from fast to slow
224-243 gobo wheel rotation from slow to fast
244-255 Random gobo selection by audio control
12 9 Rot. gobo indexing and rotation
13 0-255 gobo indexing fine
14 10 20-49 6-facet linear rotating
prism -indexing
set indexing on channel
15
50-75 6-facet linear rotating
prism- rotation
set rotation on channel
15
76-104 8-facet circular rotating
prism- Indexing
set indexing on channel
15
105-127 8-facet circular rotating
prism-rotation
set rotation on channel
15
6 Prism/gobo macros
128-135 Macro 1
136-143 Macro 2
144-151 Macro 3
152-159 Macro 4
160-167 Macro 5
168-175 Macro 6
176-183 Macro 7
184-191 Macro 8
192-199 Macro 9
8 Prism/gobo macros
200-207 Macro 1
208-215 Macro 2
216-223 Macro 3
224-231 Macro 4
232-239 Macro 5
240-247 Macro 6
248-255 Macro 7
15 11 Prism rotation and indexing
16 12
Frost
0-64 open
65-255 Frost from 0% to 100%
17 13
ZOOM
0-255 Zoom from max. to
min.beam angle
18 0-255 Zoom fine
19 14 0-255
Fo
cus
20 0-255 Focus fine
21 0-255 open
22 15
Shutter/Strobe
FOS Technologies - 11

11/11
0-31 Shutter closed ( Lamp
power reduced to 230 W)
32-63 Shutter open, Full lamp
power
64-95 from slow to fast
96-127 Shutter open
128-143 From fast to slow
144-159 from slow to fast
160-191 Open
192-223 Random strobe-effect
from slow to fast
224-255 Shutter open, Full lamp
power
23 16
Dimmer
16 0-255 Dimmer intensity from
0% to 100%
24 *
FOS Technologies - 12
