FOS Technologies FOS ACL Line 12 User manual

FOS ACL Line 12
This manual contains important information.
Please read before operating fixture.

1
1. SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and lighting
accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials and
the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not install
charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with additional
security cable and regular inspection.
lamps consecutive working hours is not recommended more than 10
hours.
should stop using the lights in time when happens unusual conditions
during the process
lamp parts of the rotation, external accessories and paste parts should
be regular inspected, such as the emergence of loose and rock, should
be reinforced in a timely manner to prevent the accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air opening,
otherwise the dust will plug leading to poor light

2
2 TECHNOLOGY REFERENCE
Power Supply: AC 100-240V/50-60Hz
Power consumption:370 W
Light source: 12pcs*30w LED RGBW 4in1 mixing color
Beam Angle: 3 degree
Dimmer: 0-100% dimmer
Strobe rate:0-20HZ
Working Environment: -20℃-40℃
IP rate: IP20
DMX Channels: 13/53 CH
Control Mode: DMX512, Master-slave,Sound,Auto
Build-in programs
Independent control of each LED
Control panel: LCD display
Product size: 101 x 215 x 105 mm

3
3 Board Instruction
Operate Menu
Display
Details
Sub Menu / Options
DMX
Address
A001-A512 001 - 512
System
Setup
Run Mode DMX, Sound, Auto
Fixture ID 000
DMX Ch Mode 13 Ch or 53 Ch
No Signal Clean / Keep
Language En / Cn
Load Default
Check
Manual Control of each
Channel
Calibration
Balance R
Balance G
Balance B
Balance W
Mic Sense
Change Code
Test
System Test
Note Display of the PCB
firmware version

4
4DMX CHANNEL SHEET
13CH
CH
Function
DMX Value
Function
1
Tilt
0 - 255
Tilt movement
2
Tilt Fine
0 – 255
16bit tilt movement
3
Tilt Speed
0 – 255
Movement speed
4
Dimmer
0 – 255
Linear intensity
5
Strobe
0 – 3
Shutter Open
4 – 255 Strobe from slow to fast
6
Red
0 - 255
Red intensity
7
Green
0 - 255
Green intensity
8 Blue 0 - 255 Blue intensity
9 White 0 - 255 White intensity
10 Effect 1 0 - 255 Macro group 1
11 Effect 2 0 - 255 Macro group 2
12 Effect speed 0 – 63 Static
64 – 158
CW run speed from fast to slow
159 – 255 CWW run speed from slow to
fast
13
Reset
0 – 250
No function
251 – 255
Reset after 3 seconds
53CH
CH
Value
DMX Value
Function
1
Tilt
0 - 255
Tilt movement
2 Tilt Fine 0 – 255 16bit tilt movement
3 Tilt Speed 0 – 255 Movement speed
4 Dimmer 0 – 255 Linear intensity

5
5 Strobe 0 – 3 Shutter Open
4 – 255
Strobe from slow to fast
6
Red 1
0 – 255
Red 1 intensity
7
Green 1
0 – 255
Green 1 intensity
8
Blue 1
0 – 255
Blue 1 intensity
9
White 1
0 – 255
White 1 intensity
10 Red 2 0 – 255 Red 1 intensity
11 Green 2 0 – 255 Green 1 intensity
12 Blue 2 0 – 255 Blue 1 intensity
13 White 2 0 – 255 White 1 intensity
… … … …
… … … …
…
…
…
…
…
…
…
…
…
…
…
…
50
Red 12
0 – 255
Red 12 intensity
51 Green 12 0 – 255 Green 12 intensity
52 Blue 12 0 – 255 Blue 12 intensity
53 White 12 0 – 255 White 12 intensity
5 FIXED EQUIPMENT
Please fasten the fixture clamp before hanging. The clamp can be fasten
by the little hole in the middle of the bracket, then tie with a safety belt.
The loading capacity of the safety belt should be 10 times than the weight
of the fixture itself.
6CONNECTION OF DMX-512 AND
CONNETION WITH THE LIGHT EQUIPMENT

6
Please connect XLR-XLR control wire with every light from the output of
DMX.
XLR connection :
ATTENTION: Please do remember to connect one circle circuit plug on
the output signal of last equipment. And this circle circuit plug was
connected a 120ohm resistance between terminals 2 and 3 of the CANON
plug, connect this circle circuit plug can avoid the signal flash phenomena
of signal DMX512 during the transmission.
7 Maintenance
Problems Check list Trouble Shooting
The fixture do
not work
1. If your power as same as the
input of the machine.
2. If the fuse was broken.
1. Make sure the voltage.
2. Replace the same
fuse.
LED dimmed
If your power us same as the input
of the machine
Make sure the voltage
input.

7
No DMX input 1. If the polarity is opposited in the
DMX controller.
2. If it is in DMX mode.
3. If there are 2 Master in a loop.
1. Correct the DMX
polarity.
2. Change to the DMX
mode.
3. Set one piece into
Slave mode.
Par Light Set
works
abnormality
1. Check if the serial is correct on
the Par Light display
1. Set the right serial No
on the single Par
Light
8AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：
(customers）

8

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by
the end-user and point-of-sale, or else the warranty will not work (warranty period and terms,
see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product in
normal state, you can made under the provisions of the warranty, show the warranty card and
purchase bills(copy), and enjoy free maintenance service in a specific service center or the
manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
