FOS Technologies FOS Spot 150W User manual

1
FOS Spot 150W

2
PRODUCT SPECIFICATIONS
TECHNICAL SPECIFICATION
Voltage: 100/240 Volt AC, 50/60 Hz.
Power Consumption: 250 Watt.
Light Source: 150 Watt LEDs, 7500K.
Beam angle: 14°.
Colors: 8 colors + White
Gobos:7 Static Gobos (including 2 beam reducers) + Open, 8 Rotating Gobos + Open.
Beam: Two rotating prisms (8F & 6F linear), frost filter and motorized focus.
Control: DMX512, sound active, auto.
DMX Channels: 15.
Protection Class: IP20 (for indoor use only).
Width: 365 mm
Depth: 230 mm
Height: 445 mm
Weight: 12,3 Kg
SAFETY WARNING
This product must be installed by a qualified professional. All maintenance must be carried out by a
qualified electrician. A minimum distance of 0.5 m must be maintained between the equipment and a
combustible surface. The product must always be operated in a well-ventilated area. DO NOT stare
directly into the light source. Always disconnect the power before carrying out any maintenance. The
earth must always be connected to the ground. Ensure that all parts of the equipment are kept clean and
free of dust.

3
PROTECTION AGAINST SOLIDS AND WATER
Only for IP-rated fixtures
The protection level of a housing is set by applied standards. For classification there is used the IP-Code.
It contains the declaration „IP“and two following numbers. The first number characterizes the protection
against harmful effects of solids, the second is rating the water protection. It is important to distinguish
whether encapsulation and harmful effect! There can be housing that is not capsuled completely but still
avoids harmful effect of solids or water.
PROTECTION EXAMPLES:
IP20: Protection against intruding objects >12,5mm „Finger protected “; No waterproofing. TYPICAL
PROTECTION FOR INDOOR USE FIXTURES
IP33: Protection against intruding objects >2,5mm; Falling water within an angle of 60° has no harmful
effect TYPICAL PROTECTION OF LED-LIGHTS USING RECESSED POWERCON AND DMX SOCKET. This
protection is linked to the mounting position of the fixture and always refers to typical mounting situation
like a Floor spot used standing on the ground.
IP54: complete protection against solids and low-pressure water from any side THIS TYPE OF FIXTURES
CAN BE USED UNDER NORMAL OUTDOOR CONDITIONS.
IP65: shielded against dust and pressurized water from any side. TYPICAL PROTECTION FOR OUTDOOR
RATED EVENTFIXTURES USING WATERPROOFED POWER AND SIGNAL LINK.
IP67: shielded against dust and protected for accidental briefly submerge. PROTECTION AGAINST
ACCIDENTIAL SUBMERGING ON TEMPORARY FLOODED AREA.
TEMPORARY USE
Event equipment is designed for temporary use. This are typical purpose as concerts, festivals, theatre,
clubs and disco use and referable venues. Long-term use, specially under outdoor conditions and fixed
outdoor installation can bring damage in aging materials and affect the coated surface. Sealings as well as
cables are made from rubber material and will age by long-term UV-emission as sunlight and should be
checked frequently.
LIMITATIONS OF IP PROTECTION
IP-Rating doesn´t mean unlimited outdoor use and protection against any kind of environmental
influence! Especially sunlight and included UV will bring accelerated aging. Some fixtures need special

4
parts or processes to fit the rated IP-Protection, like mounting covers or caps or similar. Sealings and other
plastic or rubber materials are aging parts. They must be checked frequently to ensure the protection and
safety of the fixtures. Also specified torque of screws can affect protection!
Installation
Hanging: The fixture can be mounted in a hanging position using the supporting bracket. The bracket
should be secured to the mounting truss or structure using a standard mounting clamp. Please note that
when hanging the unit, a safety cable should also be used.
UPRIGHT: The fixture can be mounted in an upright or sitting position using the supporting brackets.
NOTE! If the signal cable is over 60 m between the DMX512 controller and fixture or between
two fixtures, then a DMX signal amplifier is needed as well.
Menu Screen
You can easily navigate through menu’s options with the four buttons under the screen. Navigating in the
menu is simple! With the Up / Down buttons, you are moving through menu’s choices, pressing Enter,
you are entering the sub menu of the option you have chosen, with the Up / Down buttons you’re moving
through the sub menu’s options, with Enter, you are confirming your choice. The FOS Spot 150W offers
the following options:
Address:0 - 512
UseMode:
Channel Mode
•Standard
•User Mode*
Channel Edit: Adjust the channel values for the User Mode*.
No DMX mode:
•Keep
•Music
•Auto

5
•Scene
•Clear
Auto Prog:
•Alone
•Maste
Sound Prog:
•Alone
•Maste
SYS Set
Lang Set:
•Chinese
•English
DisplayRev:
•No
•Yes
Backlight:
•LED On
•Off (30s)
PanReverse:
•No
•Yes
TiltReverse:
•No
•Yes
Sound Sense: 0 – 80% Sensitivity Adjustment
Reset All
•No
•Yes
Advan:
Temp Protection: Off at lamp xx
Motor Correction

6
Motor Reposition
Factory Reset
Manual (Manual control of each channel)
Info:
Version: Shows the firmware version of the fixture.
Err Info:Shows the errors of the channels, if any.
Channel Modes
15 Channels
1. Pan
2. Pan Fine
3. Tilt
4. Tilt Fine
5. Pan / Tilt Speed
6. Dimmer
7. Shutter:
•0 – 3 Shutter Open
•4 – 99 Strobe
•100 - 149 Pulse from slow to fast
•150 – 199 Thunder strobe from fast to slow
•200 – 249 Random Strobe
•250 – 255 Shutter Open
8. Color Wheel
•0 – 9 Open White
•10 – 19 White & Red
•20 – 29 Red
•30 – 39 Red & Blue
•40 – 49 Blue
•50 – 59 Blue & Green
•60 – 69 Green
•70 – 79 Green & Yellow
•80 – 89 Yellow
•90 – 99 Yellow & Orange
•100 – 109Orange
•110 – 119 Orange & Pink
•120 – 129 Pink

7
•130 – 139 Pink & Deep Blue
•140 – 149 Deep Blue
•150 – 159 Deep Blue & CTO
•160 – 169 CTO
•170 – 179 CTO & White
•180 – 216 CW Rainbow
•217 – 218 Rotation Stop
•219 – 255 CCW Rainbow
9. Static Gobo Wheel
•0 – 9 Open
•10 – 19 Beam Reducer 1
•20 – 29 Beam Reducer 2
•30 – 39 Gobo 1
•40 – 49 Gobo 2
•50 – 59 Gobo 3
•60 – 69 Gobo 4
•70 – 79 Gobo 5
•80 – 89 Beam Reducer 1 Shake
•90 – 99 Beam Reducer 2 Shake
•100 – 109 Gobo 1 Shake
•110 – 119 Gobo 2 Shake
•120 – 129 Gobo 3 Shake
•130 – 139 Gobo 4 Shake
•140 – 149 Gobo 5 Shake
•150 – 201 CW Gobo scroll
•202 – 203 Stop (open)
•204 – 255 CCW Gobo scroll
10. Rotating Gobo Wheel
•0 – 9 Open
•10 – 19 Gobo 1
•20 – 29 Gobo 2
•30 – 39 Gobo 3
•40 – 49 Gobo 4
•50 – 59 Gobo 5
•60 – 69 Gobo 6
•70 – 79 Gobo 7
•80 – 89 Gobo 1 Shake
•90 – 99 Gobo 2 Shake
•100 – 109 Gobo 3 Shake
•110 – 119 Gobo 4 Shake
•120 – 129 Gobo 5 Shake

8
•130 – 139 Gobo 6 Shake
•140 – 149 Gobo 7 Shake
•150 – 159 Open
•160 – 206 CW Gobo scroll
•207 – 208 Scroll Stop
•209 – 255 CCW Gobo scroll
11. Gobo Rotation
•0 – 127 Rotation Index
•128 – 191 CW Gobo Rotation
•192 – 255 CCW Gobo Rotation
12. Prism / Frost
•0 – 63 No Prism
•64 – 127 8F Prism
•128 – 191 6F Linear Prism
•192 – 255 Frost Filter
13. Prism Rotation
•0 – 127 Prism Index
•128 – 191 CW Prisms Rotation
•192 – 255 CCW Prisms Rotation
14. Focus
15. Reset & Macro
•0 – 249 No Function
•250 – 255 Reset
General Information
Replacing a fuse:
Always disconnect the fixture from main power before replacing a fuse. Use only the appropriate fuse,
with the same type and rating. A fuse with different rating, can damage the fixture in case of failure.
Risk of electric shock and / or fire:
The fixture must be earthed, supplied always with its nominal voltage and cleaned periodically from dust.
For cleaning use only, a moist cloth. Never use liquids or force water. After cleaning, let the fixture dry
before use.
General troubleshooting
•Fixture is not working
Check if the fuse is burnout

9
•Fixture is not responding to DMX control
Check the DMX address
Check the signal cable
•Fixtures operation is being interrupted
Check the air vents and fan, if they are blocked from dust.
•Low brightness
Check the state and / or clean the front lenses.
