FOS Technologies FOS Ultra Par User manual

FOS Ultra Par
7*40W RGBW 4in1 LED
User Manual

CATALOGUE
1. Safety Instruction .................................................................................................. 2
2. Technical Specifications......................................................................................... 4
3. How to set the lighting .......................................................................................... 5
Control Panel ................................................................................................. 5
Main Functions .............................................................................................. 5
The main functions are shown below ............................................................ 6
4. How to control the lighting.................................................................................... 7
The Master/Slave Machine Built-in Function................................................. 7
Universal DMX Controller .............................................................................. 7
5. DMX512 Channel................................................................................................... 8
6. DMX512 Connection.............................................................................................. 9
7. Fault Handling ....................................................................................................... 9
8. Cleaning andmaintenance .................................................................................10
1
1. The DMX indicator must be on. If not, check the DMX signal connector and signal line to see if
the
connection is correct.
2. If the DMX indicator is on, but there is no response to channel control, and check the
address code is set correctly.
3. If the DMX signal transmission is intermittent, to check if the Canon is in good connection
with the signal line.
4. Try it again with another controller.
5. Check whether the DMX signal line is too close to the high voltage line, which can damage
or
interfere with the signal circuit.
C. Out of control by Sound
1. Make sure the light does not receive DMX signal.
2. Check if the microphone for damage.
D. One certain channel does not work
1. The drive line may be damaged or loose.
2. The drive circuit may be damaged.
8. Cleaning and maintenance
Lightings must be cleaned regularly so that the lighting effect is better. The cleaning
frequency
depends on the environment. Wet, smoggy, dirtier environments tend to dust the
lenses.
yUse a soft linen and a special glass cleaner;
yCarefully wipe the cadres.
yClean the exterior of the light once every 20 days at least once every 30 days or 60 days.
10

1. Safety Instruction
Warning
yPlease keep this manual as a future reference, if you sell the product to other users,
make sure they have access to this manual as well.
yBefore using the lighting, please check carefully to make sure that there is no damage
caused by transportation. If yes, please do not use and contact the dealer for the first time.
yThe lighting is only suitable for indoor to dry environment.
yThe installation and operation of lights should be carried out by professionals.
yUse safety harness when fixing equipment.
yThe equipment must be installed in a well-ventilated area, at least 50 cm from the
adjacent plane.
yMake sure the ventilation holes are unobstructed to avoid overheating when the
lightings are working.
yEnsure that the power supply voltage is in line with the requirement of the equipment
before operation.
yPlease earth the conductive body in case of electric shock.
yPlease do not use the light in more than 40 đenvironment.
yThe shortest distance between all exterior surface and combustible materials is 2.5m.
yIt is forbidden to connect the lighting directly to the dimmer.
yA small amount of smoke or peculiar smell may occur during the work of the new
lighting, which will disappear after a few minutes.
yDo not place combustible materials near the lighting when it is working, in case of fire
danger.
yPlease check whether the power line is broken before turning on the lighting, please
replace it immediately if there is any damage.
yLightings runtime surface temperature of 60 đ, please do not touch with bare hands.
yAvoid long time to turn on lighting, so as not to shorten the life of lighting.
yAvoid the metal and other conductive body into the interior of the lighting, so as to
avoid electric shock or fire. If any foreign body enters the lighting, please cut off the power
immediately.
yAvoid operation in dirty and dusty environment, and regularly clean and maintain the
lighting.
yChildren are not allowed to contact/operate lighting.
Please read this manual carefully, which includes important
information about installation, using, and maintenance.
2
6. DMX512 Connection
DMX IN
In order to reduce the signal error and avoid signal transmission problems or
signal interference, a 120ohm 1/4W resistor can be added between the pin2
and pin3 of DMX connection of the last lighting.
DMX OUT
1. Connect the lighting with the XLR signal line, one end receives the outlet of the light, and the otherend
receives the input port of the next light. XLR signal lines can only be used in series, not in parallel.DMX512
signal transmission is very fast. The signal line is damaged, the welding place is not secure, the contact is not
good, it will affect the signal transmission, causing the system to close.
2. When a unit of power supply circuit, DMX output and input is by-pass connection, so that can continueto
maintain the DMX line connected.
3. On the last light, the DMX wire needs an amplifier. Welding a 120 - ohm quarter w resistor between pni2
and responsible, within XLR plugs into 3 - pin and insert it in the end of a light DMX.
4. Each light, want to have an address to receive information from the console, range between 0-512 (usually 0
and 1 and 1 equal).
5. The 3-core XLR connector is more common than the 5-core XLR.
3 core XLR: PIN 1: GND, PIN 2: negative signal, PIN 3: positivesignal.
5 core XLR: PIN 1: GND, PIN 2: negative signal, PIN 3: positive signal , Pin4/5:unused.
7. Fault Handling
Here are some of the problems that are common in working and some Suggestions for breaking down:
A. Lighting does not work, no lights.
1. Check the power contact condition and whether the fuse is in good condition.
2. Detect the voltage.
B. Out of Control by DMX
9

yDo not touch the wire when the lighting is working in case of electric shock.
yAvoid winding of power cord and other wire.
yPlease use the same model when replacing the fuse.
yIf there is a serious malfunction, please stop using it immediately.
yDo not open the lighting again.
yPlease replace the lighting housing and lens when there is obvious damage.
yThe interior of the lighting is not available.
yPlease do not open the shell of the lighting without authorization.
yIf necessary, please contact the nearest authorized service center.
yPlease cut off the power when the lightings are not used or repaired for a long time.
yPlease use the original packing material for re-shipment.
yTo avoid fire or electric shock, do not expose the lighting to rain or wet areas.
yPlease do not look directly when the lighting is working.
yThe product may emit harmful optical radiation.
:
:DUQLQJ

yDo not expose the lighting to rain or humidity in order to prevent or reduce the dangerof
electric shock and fire.
yShut off for 5 minutes.
yThe lighting housing, when the lens has obvious damage, please replace it in time.
yAttention
There is no spare parts inside the lamp, please do not open the shell withoutauthorization.
Please contact the nearest technical service center if necessary.
yInstallation
The lightings should be screwed to the bracket. Make sure the installation is strong
enough to prevent flicking and sliding at run time. Also make sure the fixtures are stable
and support the weight of more than 10 times the equipment. At the same time, whenthe
installation of the equipment, can use under 12 times the product of the weight of the
safety rope.
Equipment must be installed by professionals. The lighting is to be installed onthe
human body, and there will be no passers-by or seats.
If AC 230V~50Hz power supply is used, do not connect more than 5 lamps in series, please
use another power supply to provide power for the next set of 5 lamp sets;
If AC 120V~60Hz power supply is used, do not connect more than 3 lamps in series. Please
use another power source to provide power for the next set of 3 lamps.
3
5. DMX512 Channels
After power on, connect to the console. When the DMX512 console signal is not
received, an "X" appears behind the DMX ADDR menu. When the DMX512 console signal is
received, the "X" behind the DMX ADDR menu will automatically disappear, and then the
control console signal will be controlled.
In the address code state, if there is no access console after multi-machine connection, the
master-slave online function can be realized to operate one of the devices, while the rest
devices in the address state follow the host to run programs synchronously. DMX512 signal
must be cut off when the master-slave is online.
11 Channel Mode
No. Function Descriptions
CH1 0-255
CH2 Dimmer 0-255 Master dimmer 0-100%
Red intensity 0-100%
Green intensity 0-100%
Blue intensity 0-100%
White intensity 0-100%
CH3 Strobe 0-255 Strobe from slow to fast
CH4 Red dimmer 0-255
CH5 Green dimmer 0-255
CH6 Blue dimmer 0-255
CH7 White dimmer 0-255
CH8 Preset colors 0-255 Preset colors
CH9 Programs
Program speed
CH10 0-255 speed from fast to slow
CH11 Reset 194-255 reset
8
Zoom Zoom 0-100%
0-020 No function
21-255 Built-in programs

2. Technical specifications
32:(56833/<$&9+=+=
32:(5&2168037,21˖:
/,*+76285&(˖h:LQ5*%:/XPLQXV/('
&21752/02'(˖'0;ǃ5'0ǃ0DVWHU6ODYHǃ$XWR
6752%(˖6(OHFWURQLFVWUREH
',00(5˖OLQHDUO\DGMXVWDEOH
%($0$1*/(ee
'0;&+$11(/6˖&+
',63/$<˖2/('',63/$<
3527(&7,215$7(˖,3
1:˖.J
',0(16,216,=(hhPP
3$&.,1*6,=(hhPP
)HDWXUH8QLTXHVWUXFWXUHGHVLJQIRFXVPRUHVPRRWK'RXEOHKDQJHUGHVLJQFDQEH
SODFHGRQJURXQGIRUXVHDYDULHW\RILQVWDOODWLRQVFKHPHV0XOWLSOHEXLOWLQ
SURJUDPV5*%:FDQPL[PRUHZRQGHUIXOFRORUV%XLOWLQ5'0HDV\WR
RSHUDWH3HUIHFWGLPPLQJEXLOWLQGLPPLQJFXUYHRSWLRQDO2SWLFDODQJOH
DGMXVWDEOHPRUHGLYHUVLILHGDSSOLFDWLRQVQRIOLFNHURXWSXWGLHFDVWERG\
ZDWHUSURRIJUDGH,3
4
4. How to control the lighting
The lighting can be controlled in two ways as below
1. The Master/Slave Machine Built-in Function;
2. DMX Controller.
No need to turn off the power of the lighting, and the new address code can be setimmediately.
Open the lighting, it began to receive DMX signal.
Master/Slave Built-in Function
String many sets of lightings, first walk in the lighting of 1, 2, 3 (host, the host indicator, voice
control indicator lights flashing, signal input connectionless),
will control the other lamps and
lanterns (vice machine, machine signal connection indicator)and the host with step effect.
Universal DMX Controller
When using the general DMX control controller to control the lighting, please set the startingaddress
(1-512) for the light to receive the DMX letter number.
Press MENU button up to show Address, Press ENTER button, to show flashing; UseUP/DOWN
button to select address code; Press ENTER to save or not save and return to the last menu;Please
click the MENU button to return the Main Menu.
If you want to use this function, please refer to the DMX512 address of the first 4 lightings inthe
diagram below˖
11CHS Mode:
001 Ƚ
Ƚ
012
Ƚ
Ƚ
023 Ƚ
Ƚ
034 ……
7

3. How to set the lighting
Control Panel
䕿
1 LCD: Displays menu options and selected features;
䕿
2 Button  

MENU Select Function
DOWN Select the next menu option
UP Select the previous menu option
ENTER Confirm the selected function

䕿
3 POWERCON Input: connect lamp to supply power ˗ 
䕿
4 POWERCON Output: connect the next lamp and provide power;
䕿
5 DMX Input: input DMX signal using 3-core XLR signal line;
䕿
6 DMX Output: connect the next lamp with the 3-core XLR signal line and output the
DMX signal;
Main Function
To select a preset feature, press the MENU button to select the MENU option you want.
Press ENTER button to ENTER the selected function, the display screen will blink, then
use the UP/DOWN button to select the desired function, press ENTER button to confirm.
To return to the main MENU, press the MENU button.
5
The main funcons are shown below
No English Display Descriptions
1DMX Addr 001 Set DMX address 001-512
Manual adjustment of RED intensity 0-100%
Manual adjustment of GREEN intensity 0-100%
Manual adjustment of intensity 0-100%
Manual adjustment of WHITE intensity 0-100%
2Key_ADJ
R-Dim
000-255
G-Dim
000-255
Manual adjustment of GREEN intensity 0-100%
B-Dim
000-255
CCT
Brightness
000-255
Manual adjustment of color temperature
Manual zoom 0-100%
CCT
000-255
W-Dim
000-255
3
Focus 000-255 4
Test Mode
PROG 1/16
Press OK to enter, press up and down to select the
built-in program, and press OK to enter. Press the
menu buon to return to the superior menu.
PROG-SPEED
1/16
Press "OK" to enter, press "up" and "down" to select
the built-in program speed, press "OK" to enter, and
then press "Menu" to return to the superior menu.
Auto/Sound
Press "OK" to enter, press "up" and "down" to select,
press "OK" to enter, then press "Menu" to return to
the superior menu.
5
Setting
Dim mode
1/2/3/4
Press "OK" to enter, press "up" and "down" to
select,press "OK" to enter, then press "Menu" to
return to the superior menu.
DMX Keep
On/OFF
Press "OK" to enter, press "up" and "down" to
select,press "OK" to enter, then press "Menu" to
return to the superior menu.
DMX Prio
On/OFF
Press "OK" to enter, press "up" and "down" to
select,press "OK" to enter, then press "Menu" to
return to the superior menu.
BackLight
On/OFF
Press "OK" to enter, press "up" and "down" to
select,press "OK" to enter, then press "Menu" to
return to the superior menu.
Language
EN
Press "OK" to enter, press "up" and "down" to
select,press "OK" to enter, then press "Menu" to
return to the superior menu.
7
6
system System informaons
6
