FOS Technologies FOS Spot 40W User manual

1
FOS Spot 40W

2
PRODUCT SPECIFICATIONS
TECHNICAL SPECIFICATION
Voltage: 110/240 Volt AC, 50/60 Hz.
Power Consumption: 100 Watt.
Light Source: 40 Watt LED
Colors: 9 filters + White.
Gobos: 11 fixed gobos + open.
Control: Auto, Music, DMX
DMX Channels: 10 / 12.
Protection Class: IP20 (for indoor use only)
Width: 226 mm
Depth: 150 mm
Height: 325 mm
Weight: 5,1 Kg
SAFETY WARNING
This product must be installed by a qualified professional. All maintenance must be carried out by a
qualified electrician. A minimum distance of 0.5 m must be maintained between the equipment and a
combustible surface. The product must always be operated in a well-ventilated area. DO NOT stare
directly into the light source. Always disconnect the power before carrying out any maintenance. The

3
earth must always be connected to the ground. Ensure that all parts of the equipment are kept clean and
free of dust.
PROTECTION AGAINST SOLIDS AND
WATER
Only for IP-rated fixtures
The protection level of a housing is set by applied standards. For classification there is used the IP-Code.
It contains the declaration „IP“and two following numbers. The first number characterizes the protection
against harmful effects of solids, the second is rating the water protection. It is important to distinguish
whether encapsulation and harmful effect! There can be housing that is not capsuled completely but still
avoids harmful effect of solids or water.
PROTECTION EXAMPLES:
IP20: Protection against intruding objects >12,5mm „Finger protected “; No waterproofing. TYPICAL
PROTECTION FOR INDOOR USE FIXTURES
IP33: Protection against intruding objects >2,5mm; Falling water within an angle of 60° has no harmful
effect TYPICAL PROTECTION OF LED-LIGHTS USING RECESSED POWERCON AND DMX SOCKET. This
protection is linked to the mounting position of the fixture and always refers to typical mounting situation
like a Floor spot used standing on the ground.
IP54: complete protection against solids and low-pressure water from any side THIS TYPE OF FIXTURES
CAN BE USED UNDER NORMAL OUTDOOR CONDITIONS.
IP65: shielded against dust and pressurized water from any side. TYPICAL PROTECTION FOR OUTDOOR
RATED EVENTFIXTURES USING WATERPROOFED POWER AND SIGNAL LINK.
IP67: shielded against dust and protected for accidental briefly submerge. PROTECTION AGAINST
ACCIDENTIAL SUBMERGING ON TEMPORARY FLOODED AREA.
TEMPORARY USE
Event equipment is designed for temporary use. This are typical purpose as concerts, festivals, theatre,
clubs and disco use and referable venues. Long-term use, specially under outdoor conditions and fixed
outdoor installation can bring damage in aging materials and affect the coated surface. Sealings as well

4
as cables are made from rubber material and will age by long-term UV-emission as sunlight and should
be checked frequently.
LIMITATIONS OF IP PROTECTION
IP-Rating doesn´t mean unlimited outdoor use and protection against any kind of environmental
influence! Especially sunlight and included UV will bring accelerated aging. Some fixtures need special
parts or processes to fit the rated IP-Protection, like mounting covers or caps or similar. Sealings and
other plastic or rubber materials are aging parts. They must be checked frequently to ensure the
protection and safety of the fixtures. Also specified torque of screws can affect protection!
Installation
Hanging: The fixture can be mounted in a hanging position using the supporting bracket. The bracket
should be secured to the mounting truss or structure using a standard mounting clamp. Please note that
when hanging the unit, a safety cable should also be used.
UPRIGHT: The fixture can be mounted in an upright or sitting position using the supporting brackets.
NOTE! If the signal cable is over 60 m between the DMX512 controller and fixture or between
two fixtures, then a DMX signal amplifier is needed as well.
Menu Screen
You can easily navigate through menu’s options with the four buttons under the screen. Navigating in the
menu is simple! With the Up / Down buttons, you are moving through menu’s choices, pressing Enter,
you are entering the sub menu of the option you have chosen, with the Up / Down buttons you’re moving
through the sub menu’s options, with Enter, you are confirming your choice. The FOS Spot 40W offers
the following options:

5
DMXAddr: Set the DMX address
WorkMod: Choose between DMX512, AUTO, SOUND working modes.
Tool: Choose from the sub menus
• Display: On / 60S for Display on and off time.
• SundHig: 1 – 16 for Sound sensitivity.
MotorST: Set the effect wheels and Pan / Tilt positions via the sub menus:
• ColrREV: 0 – 255 color wheel position
• GoboREV: 0 – 255 gobo wheel position
• PrimREV: 0 – 255 prism position
• Pan REV: 0 – 255 Pan position
• Tilt REV: 0 – 255 Tilt position
• Xrevers: Yes or No for Pan movement reverse
• Yrevers: Yes or No for Tilt movement reverse
• XYfbstin: Activate or Deactivate the Pan / Tilt movement.
Info: Check the Software Version of the fixture and the total working time.
Reset: Performs complete reset of the fixture.
Channel Modes
10 Channels
1. Pan
2. Tilt
3. Pan / Tilt Speed
• 0 – 255 Gradual speed adjustment from fast to slow.
4. Dimmer
5. Shutter
• 0 – 3 Shutter Open.

6
• 4 – 59 Synched strobe from slow to fast
• 60 – 63 Shutter Open.
• 64 – 123 Synched strobe from slow to fast (dif. Frequency)
• 124 – 127 Shutter Open.
• 128 – 191 Sudden strobe from low to high frequency.
• 192 – 195 Shutter Open.
• 196 – 253 Sudden strobe from low to high frequency.
• 254 – 255 Shutter Open.
6. Color Wheel
• 0 – 4 Open White
• 5 – 24 Red
• 25 – 49 Green
• 50 – 74 Blue
• 75 – 99 Yellow
• 100 – 124 Magenta
• 125 – 149 Orange
• 150 – 174 Cyan
• 175 – 199 Pink
• 200 – 225 Deep Blue
• 226 – 255 Color rainbow
7. Gobo Wheel
• 0 – 4 Open
• 5 – 25 Gobo 1
• 26 – 45 Gobo 2
• 46 – 65 Gobo 3
• 66 – 85 Gobo 4
• 86 – 105 Gobo 5
• 106 – 125 Gobo 6
• 126 – 145 Gobo 7
• 146 – 165 Gobo 8
• 166 – 185 Gobo 9
• 186 – 205 Gobo 10
• 206 – 242 Gobo 11
• 243 – 255 Gobo Scroll
8. Prism

7
• 0 – 15 No Prism
• 16 – 127 Prism Insertion
• 128 – 255 Prism Rotation from slow to fast
9. Macros
• 0 – 19 No Function
• 20 – 99 Auto Run
• 100 – 199 Sound Active
• 200 – 255 No Function
10. Reset
• 0 – 240 No Function
• 241 – 255 Reset after 5 sec.
12 Channels
1. Pan
2. Pan Fine
3. Tilt
4. Tilt Fine
5. Pan / Tilt Speed
• 0 – 255 Gradual speed adjustment from fast to slow.
6. Dimmer
• 0 – 255 Linear dimming from 0 to 100%.
7. Shutter
• 0 – 3 Shutter Open.
• 4 – 59 Synched strobe from slow to fast
• 60 – 63 Shutter Open.
• 64 – 123 Synched strobe from slow to fast (dif. Frequency)
• 124 – 127 Shutter Open.
• 128 – 191 Sudden strobe from low to high frequency.
• 192 – 195 Shutter Open.
• 196 – 253 Sudden strobe from low to high frequency.
• 254 – 255 Shutter Open.
8. Color Wheel

8
• 0 – 4 Open White
• 5 – 24 Red
• 25 – 49 Green
• 50 – 74 Blue
• 75 – 99 Yellow
• 100 – 124 Magenta
• 125 – 149 Orange
• 150 – 174 Cyan
• 175 – 199 Pink
• 200 – 225 Deep Blue
• 226 – 255 Color rainbow
9. Gobo Wheel
• 0 – 4 Open
• 5 – 25 Gobo 1
• 26 – 45 Gobo 2
• 46 – 65 Gobo 3
• 66 – 85 Gobo 4
• 86 – 105 Gobo 5
• 106 – 125 Gobo 6
• 126 – 145 Gobo 7
• 146 – 165 Gobo 8
• 166 – 185 Gobo 9
• 186 – 205 Gobo 10
• 206 – 242 Gobo 11
• 243 – 255 Gobo Scroll
10. Prism
• 0 – 15 No Prism
• 16 – 127 Prism Insertion
• 128 – 255 Prism Rotation from slow to fast
11. Macros
• 0 – 19 No Function
• 20 – 99 Auto Run
• 100 – 199 Sound Active
• 200 – 255 No Function
12. Reset

9
• 0 – 240 No Function
• 241 – 255 Reset after 5 sec.
General Information
Replacing a fuse:
Always disconnect the fixture from main power before replacing a fuse. Use only the appropriate fuse,
with the same type and rating. A fuse with different rating, can damage the fixture in case of failure.
Risk of electric shock and / or fire:
The fixture must be earthed, supplied always with its nominal voltage and cleaned periodically from dust.
For cleaning use only, a moist cloth. Never use liquids or force water. After cleaning, let the fixture dry
before use.
