FOS Technologies TOURING PAR IP HEX User manual

FOS TOURING PAR IP HEX
This manual contains important information.
Please read before operating fixture.

1
1. SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light

2
2 TECHNOLOGY REFERENCE
Input voltage: A C 100-240V, 50-60Hz
18pcs *15W RGBWA+UV 6-IN-1 high power LED
Beam Angle: 25 degree
Channel : 6/9 CH
Life Time: 50,000 hours
Dimmer: 0-100% with regulated constant color control
Strobe: 10 Flashes per second (any color)
Control panel: 4 Digital LED display figures
Waterproof rate: IP65
Cover: Aluminum
N.W.:4.6kg
3 Board Instruction
MENU UP DOWN ENTER
1~Press MENU Can circulate 9 different functions. The front 2Digits
mean the function it has. (Please see the function form as follow.) And
the last 2Digits mean the function’s address, speed or parameter. Press
UP or DOWN can change the value. And press ENTERto confirm.
2~Press MENU more than 2sec. The 2Digit number will flash. Then
press UP or DOWN can change the value quickly. Then press the
ENTER to save the value you want. If you don’t want to save the value,
press MENU more than 2sec. is okay.

3
Operate Menu
:
:
1-512
Addr
Auto
Chan
Soun
Rest
Stat
6CH/9CH
Red
Yes/No
0-255
Sou1
Green
SP（1-9）
Aut1
Aut2
SC(0-9)
Strobe
0-20
Aut9
Sou2

4
4 DMX CHANNEL SHEET
9Channel
9CH
Value
Function
1
0-255
Total Dimmer 0-100%
2
0-255
Red 0-100%
3
0-255
Green 0-100%
4
0-255
Blue 0-100%
5
0-255
White 0-100%
6 0-255 Amber 0-100%
7 0-255 UV 0-100%
8 0-255 Strobe /Auto /Sound (from slow to fast )
9
0-9 No Function
10-19 RED 100% /GREEN UP / BULE 0%
20-29
RED DOWN /GREEN 100% / BULE 0%
30-39 RED 0% /GREEN 100% / BULE UP
40-49
RED 0% /GREEN DOWN / BULE 100%
50-59 RED UP /GREEN 0% / BULE 100%
60-69
RED 100% /GREEN 0% / BULE DOWN
70-79
RED 100% /GREEN UP / BULE UP
80-89
RED DOWN /GREEN DOWN / BULE 100%
90-94
White1
：
3200K
95-99
White2
：
3400K
100-104 White3：4200K
105-109 White4：4900K
110-114 White5：5600K
115-119 White6：5900K
120-124 White7：6500K
125-129 White8：7200K
130-134
White9
：
8000K

5
135-139 White10：8500K
140-144
White11
：
10000K
145-154
Auto1
155-164 Auto2
165-174 Auto3
175-184 Auto4
185-194 Auto5
195-204
Auto6
205-214 Auto7
215-224 Auto8
225-234 Auto9
235-244 Sound01
245-255
Sound02
6Channel
6CH
Value
Function
1
0-255
Red 0-100%
2
0-255
Green 0-100%
3 0-255 Blue 0-100%
4 0-255 White 0-100%
5 0-255 Amber 0-100%
6 0-255 UV 0-100%
5 FIXED EQUIPMENT
Please fasten the fixture clamp before hanging. The clamp can be

6
fasten by the little hole in the middle of the bracket, then tie with a
safety belt. The loading capacity of the safety belt should be 10 times
than the weight of the fixture itself.
6CONNECTION OF DMX-512 AND
CONNETION WITH THE LIGHT EQUIPMENT
Please connect XLR-XLR control wire with every light from the output
of DMX.
XLR connection :
ATTENTION: Please do remember to connect one circle circuit plug on
the output signal of last equipment. And this circle circuit plug was
connected a 120ohm resistance between terminals 2 and 3 of the
CANON plug, connect this circle circuit plug can avoid the signal flash
phenomena of signal DMX512 during the transmission.
7 Maintenance

7
Problems Check list Trouble Shooting
The fixture do
not work
1. If your power as same as the input
of the machine.
2. If the fuse was broken.
1. Make sure the voltage.
2. Replace the same fuse.
LED dimmed If your power us same as the input
of the machine
Make sure the voltage
input.
No DMX input 1. If the polarity is opposited in the
DMX controller.
2. If it is in DMX mode.
3. If there are 2 Master in a loop.
1. Correct the DMX
polarity.
2. Change to the DMX
mode.
3. Set one piece into
Slave mode.
Par Light Set
works
abnormality
1. Check if the serial is correct on
the Par Light display
1. Set the right serial No
on the single Par
Light
8AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）

8

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
End User
Company Name:
Add:
Sale Store
Link man:
Tel: Stamp
