Fountain Opera Creamy User manual

These instructions are intended for use with the FOUNTAIN
Opera CREAMY drinks server
CREAMY
–Automatic dispenser of coffee in 2 cup sizes ( small &
large)
–manual dispenser of drink products (3 products), ,
manual dispenser of hot water
Read this user manual carefully before you use the
appliance and save it for future reference.
GENERAL SAFETY RULES
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN
COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONEL.
After removing the packaging check that the machine is
intact. If in doubt, do not use it and contact your
FOUNTAIN representative. (! Danger of injury)
The machine must be used exclusively for the preparation
of hot beverages with the FOUNTAIN cartridges. Using the
machine for a different purpose or with other cartridges is
considered improper use. In this case inappropriate use
excludes the manufacturer from all responsibilities for any
damage to the machine, persons or things. The drink
served by the machine is very hot and therefore should be
used only by adults. This appliance is not intended for use
by persons (including children)with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Keep the mains cord out of the reach of children. Do not let
the mains cord hang over the edge of the table or worktop
on which the appliance stands.
Keep the cord, the base and the machine away from hot
surfaces.
Always place the base and the machine on a dry, flat and
stable surface.(danger of tipping)
Before inserting the plug in the power socket make sure
that the machine’s operating voltage corresponds with that
of the power supply. Never insert foreign objects or hands
in the openings of the machine when it is connected to the
power or when in use. (danger of electrocution).
Never use the machine with wet hands. (danger of
electrocution).
Never top up the water tank when the machine is
connected to the power supply. (danger of electrocution).
Never clean or wash the machine when the machine is
connected to the power supply. (danger of electrocution).
Never clean or wash the machine with solvents. We
recommend warm water.
Never immerge the machine in water or other liquids. Do
not use a water jet to clean the machine.
Avoid installing the machine in places where water jets are
used for cleaning
Do not use the machine outside the home or office and
never expose it to the weather (sun, rain, …).
The machine is not suited for outdoor use
Do not use the appliance if the mains cord, the plug, the
base or the appliance itself is damaged.
If the mains cord is damaged, you must have it replaced by
Fountain; a service centre authorised by Fountain or
similarly qualified persons in order to avoid a hazard.
The machine is only intended for heating water. Do not use it
to heat up soup or other liquids or jarred, bottled or tinned
food.
Hot water can cause serious burns. Be careful when the
machine contains hot water.
Never fill the machine beyond the maximum level indication.
If the machine has been overfilled, boiling water may be
ejected from the inlet and cause scalding.
Be careful when you open the lid: the steam that comes out
of the machine is very hot.
Always make sure the water in the machine at least covers
the bottom of the machine to prevent the machine from
boiling dry.
Depending on the hardness of the water in your area, small
spots may appear on the heating element of your machine
when you use it.
This phenomenon is the result of scale build-up on the
heating element and on the inside of the machine over time.
The harder the water, the faster scale builds up. Scale can
occur in different colours.
Although scale is harmless, too much scale can influence
the performance of your machine. Descale your machine
regularly by following the instructions given in chapter
‘Descaling’.
SPECIFICATION & ELECTRICAL INFORMATION*
Electrical 230Vac, 50Hz, 1000W, 4.34 A.
Size 450mm high x 405mm wide x 360mm deep
Capacity 37 cups 125 ml
O
p
era Cream
y
User Manual
Weight 8 Kg
WARNING THIS MACHINE DISPENSES HOT WATER AT APPROX
90°C. IT IS NOT SUITABLE FOR UNSUPERVISED USE BY YOUNG
CHILDREN OR AGED OR INFIRM PERSONS
THIS MACHINE MUST BE EARTHED
THIS MACHINE IS NOT FOR USE IN COOKING AREAS
INSTALLATION*
This machine should only be installed in an indoor area
where the ambient temperature range is +5oC (41oF) to
+40oC (104oF)
1. Position the machine in the desired location, close to a
220Vac, 15A socket outlet
2. Fill the machine with water to the “MAX” water level
mark inside the tank
3. Plug the machine into the socket outlet and switch on.
Allow the water to reach operating temperature (20 –
30 minutes)
4. Disconnect and empty the machine. Dispense some of
the water through the valve into a suitable container.
This will eliminate the chance of any odor or taste from
the manufacturing process affecting your drinks
5. Repeat steps 2, 3 and 4

SETTING UP*
1. Decide on a position for each ingredient cartridge on
the machine
2. Set the stroke adjusters on the cartridge holders to the
recommended setting (see diagram below.
Recommended settings are shown on the cartridge)
3. Fit the ingredient cartridges to the machine
4. Fit the drip tray and drip tray cover
5.
USING THE MACHINE*
1. Place an empty cup under the desired ingredient
cartridge
2. Push rocking mechanism in until it stops, then allow it
to snap back (some drinks will require more than one
push, see cartridge for recommended dose)
3. Place cup under water outlet and press button until cup
is filled to the desired level.
4. Stir drink to ensure product is dissolved.
Creamy coffee:
1. Place an empty cup under the coffee outlet.
2. Select the button for the desired quantity (large or
small)
LED-indicator
Red blinking: Water warming up
Green: temperature ok
Groen blinking: during coffee/water distribution cycle
Cup volume adjustment*
Before making any adjustment ensure that the machine is
at operating temperature and green led on
The quantity of coffee for a large or small cup can be set as
follows:
1.power off the machine
2.press and hold both large and small cup button and
power on the machine to enter programming mode
3.release both buttons
4. put a small cup under the coffee outlet
5. push and hold the small coffee button until the desired
quantity is in the cup and release button.
6.repeat step 5 and 6 for the Large cup: push and hold the
button until the desired quantity is in the cup and release
button.
7 power off the machine to store the quantities in memory
and quit programming mode
Quantity in the cup can individually be increased by holding
the button pushed during
Remark: the hot water button cannot be programmed for
a preset quantity. Water will be dispensed as long as the
button is pushed.
SAFETY FEATURES*
A thermostat controls the water temperature in your
machine. In the unlikely event of failure, a thermal reset
device protects the machine. This will switch off the power
to the heater if the temperature becomes too high.
If the machine suddenly stops heating, it is probable that
this reset has operated. To re-start the machine, please
contact your dealer.
CARE & MAINTENANCE*
CLEANING
The drip tray should be removed and cleaned at least once
a week.
Stainless steel surfaces can be cleaned with a soft cloth and
proprietary products providing no abrasives are used.
DESCALING
As with any water heating appliance, lime scale will be
produced in hard-water areas. To ensure that your machine
remains efficient it should be descaled at regular intervals.
Your Fountain dealer can carry this out.
If you wish to descale the machine yourself, you will need
descaling crystals and a siphon pump to remove the
treated water from the tank. These items are available
from your Fountain dealer, along with full instructions for
their use.
WARNING
FREEZING
Your machine should not be installed in places where the
temperature could drop below 0° Celsius.
IF YOU THINK THE WATER IS FROZEN, DO NOT SWITCH
ON THE MACHINE.
Disconnect from the power supply and allow the machine to
thaw. Inspect water tank for any damage or leaks. If
undamaged, refill with water and reconnect the power
supply
Fountain S.A.
17 Avenue de L’Artisanat,
B1420 Braine L’Alleud
Belgium
Tel [phone]
Fax [phone]
Stroke adjuste
r
Adjuster setting
Rocking
mechanism
Push
Hot water
Crème coffee
LED- indicator
