1.1. DataNet Introduction
The Wireless Intelligent Logging Network
Fourier Systems next generation data logging system is the
DataNet, a 16-bit, mobile data acquisition network based on
the innovative and reliable ZigBee technology. This solution
provides an intelligent sensor mesh system with 100% data
receipt and no data loss.
The DataNet system is comprised of a family of data logging
units, as well as a Receiver to manage the intelligent network
and Repeaters to extend the transmission range. The data
loggers measure a broad range of parameters and include
models that feature between one and four inputs for direct
measurement and recording of PT-100, thermocouple, 0 to 1
V, 4 to 20 mA, contact, frequency and pulse sensors, as well
as internal temperature and relative humidity sensors. These
models range from loggers with graphic display, AC or battery
power supply, and power amplification, to models with no
display and battery power only.
Data is transmitted from the end units to a Receiver
connected to a central computer. The system leverages the
ZigBee protocol, a 2.4 GHz license-free frequency RF band,
to ensure full data integrity. By adding DataNet Repeater units
to the network, you can extend the transmission range and
form a reliable mesh network of up to 65,000 units.

2
With its high resolution and fast Analog to Digital converter
(ADC), DataNet data loggers meet the majority of data
acquisition requirements in most industrial applications. Every
DataNet logger unit is embedded with a unique serial number
and can be loaded with a descriptive comment for safe
identification. An internal clock and calendar keeps track of
the time and date of every sample measured.
DataNet loggers can automatically activate external alarm
events when data is outside a specified range. Email and
SMS notifications can be sent to predefined contacts.
The DataNet system is powered by the powerful DataNet
software. The Windows ™based software is the central
management interface of the DataNet network. Data is
monitored online and can be displayed in graphs or tables.
You can analyze data with various mathematical tools, or
export data to a spreadsheet.
The software also enables you to configure, calibrate or
update the firmware of DataNet units wirelessly.
Key DataNet benefits include:
•Reliable transmission ensuring no data loss
•Long-range monitoring
•Ability to constantly expand transmission range by adding
additional Repeaters, or turning loggers into Repeaters
•Portable units facilitating easy deployment in various
environments
•Remote programming and firmware updates
•65,000+ possible end units
•16-bit resolution
•Low-power consumption
•Long battery life
•Minimal costs thanks to wireless infrastructure

3
1.2. What is ZigBee?
ZigBee is a standards-based protocol built around the IEEE *
802.15.4 wireless protocol, providing the network
infrastructure required for wireless, low power network
applications.
The mesh network eliminates single points of failure by
providing multiple pathways for data to travel.
* IEEE is the Institute of Electrical and Electronics Engineers,
a non-profit organization dedicated to furthering technology
involving electronics and electronic devices.
1.3. The ZigBee Concept
The Coordinator: This device creates and maintains the
network. Once the network is up and running, the coordinator
behaves as just another device on the network. There is only
one Coordinator in a ZigBee network.
The Router: A router relays data packets/messages between
devices on the network and increases the distance between
these devices.
The End Unit: This device sends and receives information to
other devices on the network. It is usually a control or a
sensor unit, often battery operated. A ZigBee end unit cannot
relay messages.
ZigBee Terminology DataNet Terminology
Coordinator Receiver
Router Repeater
End Unit Data Logger
ZigBee enables mesh networking which supports a wireless,
yet integrated environment with communication between

4
many coordinators, routers and end units in environments
where multiple applications are being monitored.
1.3.1. ZigBee Mesh Network
Operation
Figure 1: ZigBee network diagram
In a mesh network, all the router units are aware of their
environment meaning a router knows with units are close by.
When a router sends a message to a specific unit, it relays the
message until it gets to the destination.
Network recovery from a unit failure
In a mesh network, when a router fails, the network
automatically finds a different path via a different router for the
message relay.
This ensures maximum protection against a network
breakdown.
1.3.2. Why is ZigBee Technology Key
for Data Logging?
ZigBee technology has proved to be ideal for data acquisition
networks which require meter reading, parametric display of
data such as temperature or humidity and responsive action
when parameters are crossed. This is due to the fully
automated, flexible and reliable nature of the protocol. With

5
the Mesh Network system, the ZigBee standard redresses
misbalances in any data logging system, responding to
weaknesses, inefficiencies, new network structure (with the
additional or removal of devices) through self correction.
1.4. The DataNet System
The basic DataNet system will contain at least one of the
following units:
•DataNet data logger – Part Number DNL804, DNL808,
DNL810, DNL910, DNL920, DNL910-PA, DNL920-PA
•Receiver/Repeater unit – Part Number DNR900
•Mini Repeater – Part Number DNR800
•Mini-USB cable
•Power adapter (one per DataNet unit ordered)
•DataNet Software CD
1.4.1. The Data Logger
There are seven distinct data logger models compatible with
the DataNet system. These are the so-called end units of the
system. These loggers support up to four external sensors
and two internal sensors, temperature and humidity,
depending on the specific model. Data is recorded and stored
to the logger’s internal memory and transmitted over the
network to the DataNet software running on the PC.
The data logger is programmed to consume as little power as
possible during operation, in order to conserve the battery life.
When not transmitting or recording data the units are in sleep
mode and they wake up when needed.

6
The battery for the DNL910 and DNL920 is rechargeable and
can run up to several months on one charge, depending on
the logger configuration.
The DNL910-PA and DNL920-PA loggers include power
amplification (PA), enabling longer transmission range
compared to the non-PA units, and as a result have high
power consumption. The PA units therefore must be
connected to AC power at all times otherwise its battery will
drain after a few hours.
The battery for the DNL804, DNL808 and DNL810 is not
rechargeable and can run up to ten months before being
replaced, depending on the logger configuration.
Refer to section 3.9.6 for more information.
Note: Battery life depends on the logger sampling rate,
transmission rate, type of sensor, network architecture and
number of measured sensors.
The seven DataNet models can be divided into two groups:
•DataNet loggers (with LCD)
•Mini DataNet loggers (without LCD)
DataNet Loggers (with LCD)

Part Number: DNL920 and DNL920-PA Part Number: DNL910 and DNL920-PA

7
Four external channel RF data logger
with two internal sensors, Humidity and
Temperature.
* PA model includes Power Amplifier for
long-range transmission.
Four external channel RF data logger
with internal Temperature sensor.
* PA model includes Power Amplifier for
long-range transmission.
Transmission Range: Up to 80 m line of
sight
Memory Capacity: ~59,000 samples
Power supply: AC or battery operated
Transmission Range: Up to 80 m line
of sight
Memory Capacity: ~59,000 samples
Power supply: AC or battery operated
Mini DataNet Loggers (without LCD)
PN: DNL804 PN: DNL810 PN: DNL808
Single channel RF data
logger supporting external
4 to 20 mA input
Dual channel RF data
logger with internal
Temperature and Humidity
sensors.
Single channel RF data
logger supporting
external temperature
NTC 10KΩprobe
Transmission Range: Transmission Range: Transmission Range:

8
Up to 80 m line of sight
Memory Capacity:
~59,000 samples
Power supply: Battery
operated
Up to 80 m line of sight
Memory Capacity:
~59,000 samples
Power supply: Battery
operated
Up to 80 m line of sight
Memory Capacity:
~59,000 samples
Power supply: Battery
operated
1.4.2. The Receiver/Repeater
Note: The DNR900 can work in one of two modes, Receiver
or Repeater. The DNR800 only works as a Repeater.
The Receiver, PN DNR900, acts as a bridge between the
DataNet network and the PC. It is connected to the PC via
USB cable and is used to create the network to which you add
your data loggers. The Receiver is externally powered but
also includes a rechargeable battery for back up (in case the
external power fails).
Note: Each Receiver can detect up to 8 data loggers and 16
Repeaters. To detect more data loggers, Repeaters are
required.
The Repeater is considered the backbone of the network, as
it enhances the network range by receiving and transmitting
between end unit and Repeater until it reaches the PC. There
are two Repeater models, the DNR900 with LCD and the
DNR800 Mini Repeater, without LCD. Both are externally
powered via the AC adapter but the DNR900 also includes a
rechargeable battery back up (in case the external power
fails).
The Repeaters are the end units’ parent units, meaning each
Repeater has specific end units under their responsibility
(their children). They route the transmissions to and from the
end units to the Receiver (or other Repeaters in the network).

9
Each Repeater holds the data sent to the end units while the
end units are in sleep mode. At a specific interval the end unit
wakes up and receives the data from its parent (Repeater).
Note: Each Repeater can detect up to 24 data loggers and 16
Repeaters including the parent unit. If the number of loggers
exceeds this capability, additional Repeaters are required.
Receiver/Repeater with LCD

Part Number: DNR900
Repeater Transmission Range: 800 m line of sight
End Units per Receiver: ~65,000

10
Mini Repeater (without LCD)

Part Number: DNR800
Repeater Transmission Range: 800 m line of sight
End Units per Receiver: ~65,000
1.4.3. Hardware Accessories
The DataNet system includes the following accessories:
•Mini-USB cable for connecting PC to DataNet Receiver
•Power adapter to power DataNet Receiver, Repeater and
data loggers
