Fourier MultiLogPRO User manual

Weather Station
User Guide
Fourier Education


Contents
1INTRODUCTION...................................................................................................1
2WHAT’S NEW .......................................................................................................1
3PARTS LIST..........................................................................................................2
4STATION INSTALLATION ....................................................................................4
4.1INSTALLATION OPTIONS......................................................................................4
4.1.1Standard Cable Connection ................................................................... 4
4.1.2Wireless Connection .............................................................................. 4
4.2ASSEMBLING THE WEATHER STATION .................................................................5
4.2.1Choosing a Location .............................................................................. 5
4.2.2Mounting the Tripod ............................................................................... 6
4.2.3Securing the Tripod................................................................................ 6
4.2.5Preparing the Rain Collector .................................................................. 6
4.2.6Preparing the Anemometer (Wind Sensor)............................................ 7
4.2.7Preparing to Install the Weather Station Components........................... 9
4.2.8Installing the Anemometer and the Antenna Shelf............................... 10
4.2.9Installing the Solar Panel ..................................................................... 14
4.2.10Installing the Radiation Shield.............................................................. 14
4.2.11Installing the Rain Collector ................................................................. 14
4.2.12Installing the Antenna (Wireless Connection Only) ............................. 14
4.2.13Installing the Main Weather Station Box .............................................. 14
4.2.14Wiring the Weather Station .................................................................. 15
A. Wireless Connection ..............................................................................16
B. Cable Connection ..................................................................................18
4.2.15Programming MultiLogPRO ................................................................. 20
4.2.16Connecting the Weather Station to the Computer ............................... 21
A. Wireless Connection ..............................................................................21
B. Cable Connection ..................................................................................22
4.2.17Wiring Diagram..................................................................................... 22
4.3POWERING THE WEATHER STATION..................................................................23
5WORKING WITH WEATHERLAB.......................................................................25
5.1INSTALL THE SOFTWARE...................................................................................25
5.1.1System Requirements.......................................................................... 25
5.1.2Installation ............................................................................................ 25
5.2OVERVIEW .......................................................................................................27
5.3GETTING STARTED...........................................................................................29

5.3.1Establish Communication with the Weather Station ............................29
5.3.2Operating Modes ..................................................................................30
5.3.3Start Recording.....................................................................................33
5.3.4Stop Recording.....................................................................................33
5.3.5Saving Data ..........................................................................................33
5.3.6Station Settings ....................................................................................34
5.3.7Setup the Weather Station ...................................................................35
5.3.8Open Files ............................................................................................36
5.3.9Change Units Settings..........................................................................36
5.3.10Print 37
5.4VIEW THE DATA ................................................................................................39
5.4.1Display Screens....................................................................................39
5.4.2Online View ..........................................................................................39
5.4.3Offline View...........................................................................................40
5.4.4Display Options ....................................................................................41
5.4.5One Graph Display ...............................................................................41
5.4.6Four Graph Display ..............................................................................42
5.4.7Table 42
5.4.8The Cursor............................................................................................42
5.4.9Zooming and Panning ..........................................................................43
5.4.10Format the Graph .................................................................................44
5.4.11Export Data to EXCEL..........................................................................44
5.4.12Copy the Graph as a Picture ................................................................44
5.5CUSTOMIZE YOUR WEATHER STATION ..............................................................45
5.5.1Advanced Mode....................................................................................45
5.5.2Change Sensor Properties ...................................................................45
5.5.3Use other Fourier Sensors ...................................................................47
5.5.4Define a New Sensor............................................................................47
5.5.5Calibrate Sensor...................................................................................48
5.6MONTHLY REPORTS .........................................................................................49
5.6.1About Monthly Reports .........................................................................49
5.6.2Generating a Monthly Report ...............................................................51
5.6.3Report Settings.....................................................................................51
5.6.4Heating & Cooling Degree Days ..........................................................52
5.7TOOLBAR BUTTONS ..........................................................................................54
5.7.1Main (Upper) Toolbar ...........................................................................54
5.7.2Online Graph (Lower) Toolbar..............................................................54
5.7.3Offline Graph (Lower) Toolbar..............................................................55
5.8MATHEMATICAL CALCULATIONS ........................................................................57

6WORKING WITH MULTILOGPRO .....................................................................59
6.1GENERAL .........................................................................................................59
6.1.1External Connections ........................................................................... 59
6.1.2AC/DC Adaptor..................................................................................... 61
6.2STAND-ALONE OPERATION...............................................................................61
6.2.1Front Panel Layout ............................................................................... 61
6.2.2Input Modes.......................................................................................... 62
6.2.3Quick-Start ........................................................................................... 63
6.2.4Working with the MultiLogPRO Menus ................................................ 65
6.2.5Graphic Display .................................................................................... 69
6.2.6Measuring Timing Events..................................................................... 70
6.2.7Select Sensors Manually...................................................................... 74
6.2.8Load the Last Setup ............................................................................. 75
6.2.9Configure Your MultiLogPRO............................................................... 76
6.2.10Internal Clock and Calendar................................................................. 77
6.2.11Clear the Memory................................................................................. 78
6.2.12Choose the Right Setup ....................................................................... 78
6.2.13Programming Rules and Limitations .................................................... 81
6.3SENSOR CALIBRATION......................................................................................82
6.3.1Hardware Offset Calibration................................................................. 82
6.3.2MultiLogPRO Automatic Zero Calibration ............................................ 82
6.3.3pH Temperature Compensation........................................................... 83
6.3.4DO2 Calibration.................................................................................... 83
6.3.5WeatherLab Sensor Calibration........................................................... 83
6.3.6Factory Calibration (no calibration required)........................................ 83
7THE RECEIVER..................................................................................................84
7.1OVERVIEW .......................................................................................................84
7.2GETTING STARTED...........................................................................................84
7.2.1Locating the Receiver .......................................................................... 84
7.2.2Connecting the Antenna....................................................................... 85
7.2.3Powering the Receiver ......................................................................... 85
7.2.4Connecting the Receiver to a Computer.............................................. 85
7.3LED INDICATORS .............................................................................................86
8EXPERIMENT NOTES, THE INFLUENCE OF NATURAL VENTILATION ON
INDOOR CLIMATE .............................................................................................87
8.1INTRODUCTION.................................................................................................87
8.2EQUIPMENT......................................................................................................87
8.3EQUIPMENT SETUP PROCEDURE ......................................................................87

8.4EXPERIMENTAL PROCEDURE.............................................................................88
8.5DATA ANALYSIS................................................................................................89
8.6QUESTIONS ......................................................................................................89
8.7FURTHER SUGGESTIONS ..................................................................................90
9SPECIFICATIONS ..............................................................................................91
10APPENDIX: FIGURES ........................................................................................93
11INDEX 94

Introduction 1
1 Introduction
The MultiLogPRO Weather Station is a high performance weather station for
educational purposes.
The MultiLogPRO Weather Station consists of a data logger – the
MultiLogPRO, six sensors, a solar power supply, a mounting tripod and the
MultiLogPRO WeatherLab software.
The station measures: Temperature, humidity, and barometric pressure, rainfall,
wind speed and wind direction.
The temperature and humidity sensors are in fact, a two in one sensor located
inside the Radiation Shield. The Barometric Pressure sensor is in the sensor
adaptor inside the Weather Station main box and the other three are external
sensors.
The MultiLogPRO is placed in the Weather Station main box to protect it from
harsh weather conditions
The power is supplied from a solar panel and rechargeable battery.
The MultiLogPRO is connected to the computer either by a 30m long cable or
by a RF transmitter and receiver.
The software records the data from the MultiLogPRO, displays, saves and
analyzes it. Please refer to Section 5 for further details.
2 What’s New
Entirely new user interface
New Run button on the toolbar
New toolbar with new icons
Support for Windows Vista and Windows 7 Operating Systems
Support for 32 bit and 64 bit versions of Windows
Support for number of COM ports extended to 256
Improved handling of data for the wireless connection

2 Parts List
3 Parts List
3.1 Case
3.2 Mounting Tripod and bag
3.3 Magnet antenna with antenna
shelf**
3.4 Wind sensor (Anemometer)
Figure 1: Anemometer
3.5 Rain Collector mounted on tray
Figure 2: Rain collector, base and cone
3.6 MultiLogPRO
Figure 3: MultiLogPRO
3.7 Radiation Shield with
Temperature and Humidity dual
sensor mounted inside
Figure 4: Radiation shield with
the temperature and
humidity dual sensor
mounted inside

Parts List 3
3.8 Solar Panel on shelf
Figure 5: Solar Panel
3.9 Weather Station main box
containing items 3.9.1 to 3.9.9
3.9.1 Two rechargeable 12V
batteries
3.9.2 Adaptor box for the rain
and wind sensors and
containing the barometric
pressure sensor
3.9.3 Charge controller
3.9.4 Transmitter**
3.9.5 Two sensor cables
3.9.6 MultiLogPRO –
transmitter communication
cable**
3.9.7 MultiLogPRO and
transmitter power cable
3.9.8 Charge controller –
batteries cable
3.9.9 Charge controller – Solar
panel cable
3.10 Serial communication cable
adaptor
Figure 6: Serial communication cable
adaptor
3.11 30 meters communication
cable:
9 – pin D type plug*
3.12 1.5 meters communication
cable:
9 – pin D type plug
3.13 Receiver**
3.14 Whip antenna for receiver**
3.15 Computer – Receiver
communication cable:
9 – pin D type plug to stereo
phone plug**
3.16 AC-DC power adaptor for the
receiver or MultiLogPRO**
3.17 WeatherLab software CD
3.18 Compass
3.19 10 black nylon cable ties
* Not used in wireless connection
** Not used in standard cable connection

4 Station Installation
4 Station Installation
4.1 Installation Options
4.1.1 Standard Cable Connection
The MultiLogPRO is directly connected to the computer by 30m serial
cable.
If you are using this option skip steps 4.2.12, 4.2.14.A and 4.2.16.A of
the installation.
You won’t need items 3.3, 3.9.4, 3.9.6 and 3.13 to 3.16 from the part list.
4.1.2 Wireless Connection
The MultiLogPRO is connected to an RF transmitter and the data is
transmitted to a receiver that is connected to the computer.
If you are using this option skip steps 4.2.14.B and 4.2.16.B of the
installation.
You won't need item 3.11 from the part list.
The transmission range is 300m if the transmitter and the receiver are in
line of sight. If not the range is reduced considerably and depends on the
medium between the transmitter and the receiver
Note: In wireless mode, transmission is one way only, from MultiLogPRO to the
computer. There is no way of programming or operating the
MultiLogPRO via the software, therefore there are two steps to take if
you wish to reprogram your Weather Station. Firstly, temporarily connect
MultiLogPRO to the computer with the supplied communication cable
(step 4.2.15) and set it up. Secondly, set the system to transmit data by
pushing the Enter button on the MultiLogPRO itself.

Station Installation 5
4.2 Assembling the Weather Station
4.2.1 Choosing a Location
Try to position your Weather Station as follows:
1. Mount the tripod on a level surface, so that the center pole is
vertical.
2. Install in a location where wind flow is unobstructed by trees and
nearby buildings
3. Try to avoid possible obstructions from rainfall
4. If you install the Weather Station on a roof, the anemometer (wind
sensor) must be at least 1.2 m above the roofline for accurate wind
measurements
5. The Solar Radiation Shield works best in a location where there is a
steady breeze.
6. Do not install over or near water sprinklers. The Solar Radiation
Shield is not designed to protect the sensor from water sprayed
upwards.
7. Avoid placing near any space that can heat up a lot during the day.
8. The solar panel works best when the surface of the panel receives
full sunlight. Mount the Weather Station away from fences,
buildings, trees or any other obstructions that may cast shadows
over the panel.
9. The solar panel should be mounted facing south in the Northern
Hemisphere and north in the Southern Hemisphere.

6 Station Installation
4.2.2 Mounting the Tripod
1. Take the Tripod out of its bag and unfold it.
2. Pull out the extension tube to about 50cm and secure it.
3. Fasten all the screws tightly.
4.2.3 Securing the Tripod
You must secure the tripod to the surface.
Mounting on a wooden surface
Screw a hook into the floor adjacent to each leg and fasten the leg to the hook
with a nylon cable tie.
Mounting on a concrete surface
Insert rawlbolts with eyelets adjacent to each leg and fasten the leg to the hook
with a nylon cable tie.
If you want to avoid drilling into the floor you will have to place heavy weights on
each leg
Mounting on a soil surface
Hammer pegs with eyelets adjacent to each leg and fasten the leg to the hook
with a nylon cable tie.
4.2.4 Open the case and identify the various components
(see on page 2).
4.2.5 Preparing the Rain Collector
1. Remove the cone from the base by rotating the base anti-clockwise
until the latches on the cone line up with the latch openings in the
base then lift the cone away from the base.
2. Carefully remove the tie that holds the bucket in place during
shipping.
3. Place the cone back onto the base by putting the latches on the
cone into the latch openings in the base and rotating the cone

Station Installation 7
clockwise until the latches “lock” into place.
As you reattach the cone, make sure to run the cable to the cable
slot in the base, or the cone will not fit snugly against the base.
4. Place the debris screen, point down, into the cone. The screen
prevents large bits of debris from blocking the funnel hole
4.2.6 Preparing the Anemometer (Wind Sensor)
1. Open the anemometer kit and attach the drip ring. The anemometer
drip rings provide protection against icing of the wind vane and wind
cups. Follow the instructions below to attach the two drip rings:
A. Place one of the drip rings on a flat surface with the small hole
facing up.
B. Securely press the wind vane on top of the drip ring.
Note: You may want to start with the vane tilted slightly.
C. Make sure the ring fits securely between the two ridges on the
vane with the lower edge parallel to the bottom of the wind vane.
Figure 7: Installing the drip ring onto the wind vane
D. Install the small end of the other drip ring on the wind cup end of
the anemometer control head as shown below.
Note: The wind cup end of the control head has the smaller of the two stainless
steel shafts

8 Station Installation
E. Gently push up the drip ring until it reaches the groove on the
control head.
F. Make sure the lower edge of the drip ring is aligned with the lower
edge of the control head.
Figure 8: Installing the drip ring onto the anemometer control head
2. Attach the wind cups:
A. Push the wind cups onto the stainless steel shaft at the end of the
arm (see Figure 9).
Figure 9: Installing the wind cups
B. Slide the wind cups as far up the shaft as possible.
C. Use the Allen wrench provided to tighten the setscrew on the side
of the wind cups.

Station Installation 9
Note: When you let go of the wind cups, they should drop slightly.
D. Spin the wind cups. If they do not spin freely, loosen the setscrew
and lower the cups slightly. Repeat until the wind cups spin freely.
3. Attach the Wind Vane:
A. Place the wind vane on the shaft (see Figure 10)
Figure 10: Installing the wind vane
B. Slide the wind vane down the shaft as far as it will go
C. Use the Allen wrench provided to tighten the setscrew on the side
of the wind vane.
4. Check the Anemometer Base Orientation:
A. Insert the anemometer arm into the base
B. Attempt to push the #4-40 x 1 1/4” pan head screw through the
holes in the arm and the base (see Figure 15).
4.2.7 Preparing to Install the Weather Station Components
For easy mounting we advise you to slide the Weather Station
components (except for the main Weather Station box) over the tripod's
extension tube before raising it to its maximum height. Slide the
components in the following order:
1. First the Solar Panel: Slide the two -bolts that are connected to
the back of the solar panel box over the tripod’s extension tube

10 Station Installation
2. Next the Radiation Shield: Slide the two U-bolts at the back of the
Radiation Shield’s mounting bracket over the tripod’s extension
tube
3. Next the Rain Collector: Slide the two -bolts at the back of the
tray over the tripod’s extension tube
4.2.8 Installing the Anemometer and the Antenna Shelf
1. Install the Anemometer Base:
A. Hold the anemometer base against the top end of the pipe and
insert one U-bolt through the back of the base into the two lower
holes in the base so that the U-bolts wrap around the pipe (see
Figure 11)
B. Place a ¼ ” lock washer and a ¼ ” wing nut over each end of the
U-bolt and tighten the wing nuts slightly
Figure 11: Installing the Anemometer base
C. Position the anemometer so that it will face the same direction as
the solar panel (see section 4.2.9 and Figure 16 ), then fasten the
wing nuts tightly
D. Insert the other U-bolt through the back of the base into the two
upper holes and then place the antenna shelf so it sits on top of
the pipe with the U bolt passing through its holes (see Figure 12)

Station Installation 11
Figure 12: Installing the antenna shelf
E. Place a ¼” lock washer and a ¼” wing nut over each end of the U-
bolt and tighten the wing nuts (see Figure 13)
Figure 13: the anemometer base with the antenna shelf
2. Install the anemometer arm:
A. Insert the anemometer arm into the anemometer base. Guide the
anemometer cable through the slot as you insert the arm (see
Figure 14)

12 Station Installation
Figure 14: Inserting the anemometer arm to the base
B. Insert the pan head screw into one of the holes in the base and
slide it through the arm. Secure the pan head screw using the flat
washer, lock washer, and hex nut as shown in Figure 15
Figure 15: Attaching the anemometer arm to the base
3. Raise the extension tube to its maximal height and fasten tightly

Station Installation 13
Figure 16: Mounting the Weather Station
A
ntenna
Rain Collector
Anemometer
Solar panel Radiation shield
Weather Station
main box

14 Station Installation
4.2.9 Installing the Solar Panel
1. Install the solar panel facing south in the Northern Hemisphere and
north in the Southern Hemisphere so it will be exposed to the sun
2. Position the solar panel about 3cm above the lower end of the
extension tube (see Figure 16) and tighten the four wing nuts.
4.2.10 Installing the Radiation Shield
Install the radiation shield so it sits opposite and above the solar panel
(see Figure 16)
1. Position the radiation shield’s mounting bracket about 12cm above
the solar panel. Make sure that the bottom of the radiation shield is
just above the solar panel to ensure good ventilation
2. Tighten the four wing nuts
4.2.11 Installing the Rain Collector
Install the rain collector above the radiation shield (see Figure 16):
1. Position the tray about 5cm above the radiation shield’s mounting
bracket and tighten the two wing nuts
2. Level the tray horizontally.
4.2.12 Installing the Antenna (Wireless Connection Only)
Place the magnet antenna on top of the antenna shelf (see Figure 16)
4.2.13 Installing the Main Weather Station Box
1. Mount the Weather Station main box about 5cm beneath the top of
the base tube (see Figure 16) so it sits under the radiation shield
2. Unscrew the two bolts from the back of the Weather Station main
box
3. Hold the back of the Weather Station main box against the tripod's
base tube, 5cm beneath the top
Other manuals for MultiLogPRO
4
Table of contents
Other Fourier Weather Station manuals
Popular Weather Station manuals by other brands

Oregon Scientific
Oregon Scientific Alize BAR268HG user manual

Coastal
Coastal WEATHERPAK TRx user manual

Solight
Solight TE81 user manual

Eurochron
Eurochron 53166 Instructions for use

La Crosse Technology
La Crosse Technology WS-7014CH-IT instruction manual

Oregon Scientific
Oregon Scientific BAR289 user manual
