Franke MARIS FMA 839 HI User manual

MARIS
EN User manual
DE Bedienungsanleitung
FR Manuel d’utilisation
NL Gebruikershandleiding
IT Istruzioni per l'uso
ES Manual del usuario
SL Navodilo za uporabo
FMA 839 HI
FMA 839 HI LL KIT

EN FMA 839 HI / FMA 839 HI LL KIT
– 2 –
Information on the manual 3
Safety information 3
Electrical connection 9
Overview 10
Types of control 11
Controls 12
Functions 14
Suction hood controls 17
User menu (custom settings) 18
Installer menu (hob power settings) 19
The device 20
Operation 23
Cleaning and care 24
Troubleshooting 25
Maintenance and repairs 27
Disposal 27
Technical data 28
INDEX

EN
FMA 839 HI / FMA 839 HI LL KIT
– 3 –
INFORMATION ON THE MANUAL
These instructions for use are valid for various
models of the device. This means that some of
the features and functions described here may
not be available in the specific model you have
purchased.
X Please read the instructions for use carefully
before using the device.
X Keep the instructions for use safely.
X Only use the device described in these
instruction for the purposes foreseen.
Symbol Meaning
Danger warning. Danger of injury
warning.
Z Safe actions and instructions to
avoid injury or damage.
X Action. Specifies an action that
must be carried out.
 Result. Result of one or more
actions.
xRequirement that must be met
before carrying out the next action.
SAFETY INFORMATION
For your own safety and to
guarantee proper use of the
appliance, please read this
manual carefully before
installing and using the product.
These instructions must always
be kept with the appliance,
even if it is moved or sold.
Users must be fully aware of
how the appliance works and of
its safety features.
These hobs have induction
systems that comply with
the requirements of EMC
standards and with the EMF
directive, and they should
not interfere with other
electronic devices. Pacemaker
wearers and those using
other electronic implants must
consult their doctor or the
manufacturer of the implanted
device to assess whether or
not it is sufficiently resistant
against interference.
Electrical connections
must be performed by a trained
technician. Before making
the electrical connection,

EN FMA 839 HI / FMA 839 HI LL KIT
– 4 –
please read the section on
ELECTRICAL CONNECTION.
For appliances with a power
supply cable, the terminals or
section of wire between the
cable anchor point and the
terminals must be arranged
in such a way as to allow the
live wires to be pulled out
before the earth wire in the
event of the cable coming out
of its anchor.
Z The manufacturer will not
be liable for any damage
resulting from incorrect or
inadequate installation.
Z Check that the mains power
supply corresponds to
the one indicated on the
identification plate fixed to
the inside of the product.
Z Fixed electrical connections
must incorporate the cut-out
devices envisaged by current
regulations.
Z For class I appliances,
check that the domestic
power supply guarantees an
adequate earthing system.
Z Connect the suction
hood to the flue using a
suitable pipe. Please refer
to the accessories to be
purchased, indicated in the
installation manual
(for circular pipes: minimum
diameter 120 mm). The
exhaust pipe must be as
short as possible.
Z Connect the product to the
mains using an omnipolar
switch.
Z The air venting regulations
must be complied with.
Z Never connect the suction
appliance to ducts carrying
combustion fumes (heaters,
fireplaces, etc..).
Z If the suction hood is used
alongside non-electrical
appliances (e.g. appliances
with gas burners), it is
necessary to guarantee a
sufficient level of ventilation
in the room, to prevent any
exhaust backflow. When
the cooking appliance is
used together with other
appliances using non-
electrical power sources,

EN
FMA 839 HI / FMA 839 HI LL KIT
– 5 –
the negative pressure in
the room must not exceed
0.04 mbar, to prevent the
fumes being sucked back
into the room by the cooking
appliance.
Z The air must not be
discharged into a pipe that
is also used as a flue for
appliances powered by gas
or other fuels.
Z If the power cable
is damaged, it must
be replaced by the
manufacturer, by an
authorised service centre or
by a qualified technician, to
avoid any risk of danger.
Z Connect the appliance plug
to a socket that complies
with current regulations and
is in an accessible area.
Z As regards the technical
and safety measures to
be taken for exhausting of
fumes, it is important that
the regulations set by local
authorities be followed
carefully.
CAUTION: remove the
protective films before installing
the appliance.
Z Only use the screws and
other small components
supplied with the appliance.
WARNING: failure to
install the screws or fixing
elements as described in these
instructions may result in a risk
of electric shocks.
Z Never look at the light
directly through optical
devices (binoculars,
magnifying glasses...).
Z Cleaning and scheduled
maintenance must not be
carried out by children,
unless they are under the
supervision of an adult.
Z Supervise children, to make
sure they do not play with
the appliance.
Z This appliance must not be
used by persons (including
children) with limited
physical, sensory or mental
abilities, or by persons
without adequate experience
and knowledge, unless they

EN FMA 839 HI / FMA 839 HI LL KIT
– 6 –
are supervised or instructed
in use of the appliance by
the those responsible for
their safety.
Z This appliance may be used
by children over the age of
8 years and by persons with
limited physical, sensory
or mental abilities or with
insufficient experience and
knowledge, provided they
are supervised or have been
adequately instructed on
safe use of the appliance
and understand the risks
that it involves. Do not allow
children to play with the
appliance.
CAUTION: The appliance
and its accessible parts
become extremely hot during
use.
Take great care not to touch
the heating elements.
Keep children under 8 years
of age well away from the
appliance, unless they are
under constant supervision.
Z Clean and/or replace the
filters after the period
indicated (danger of fire).
See the paragraph on
Cleaning and maintenance.
Z Always guarantee adequate
ventilation of the room
when the appliance is used
in conjunction with other
appliances powered by gas
or other fuels (this does not
apply to appliances that only
recirculate the air within the
room).
Z WARNING: If the surface is
damaged, turn the appliance
off to prevent any risk of
electric shocks.
Z Do not turn the device on
if the surface is cracked or
any damage is visible in the
thickness of the material.
Z Do not touch the appliance if
your hands or body are wet.
Z Do not use steam appliances
to clean the product.
Z Do not rest metal objects
such as knives, forks,
spoons and pan lids on the
surface of the hob, as they
might overheat.
Z Use the relevant control to
turn the cooker hob off after

EN
FMA 839 HI / FMA 839 HI LL KIT
– 7 –
use, do not rely on the pan
sensors.
Z WARNING: Unsupervised
cooking on a hob using
oil and grease may be
dangerous and may cause
a fire. NEVER attempt to
put flames out with water.
On the contrary, turn the
appliance off and suffocate
the flames, for example
using a pan lid or a fire
blanket.
Z WARNING: The cooking
process must be
supervised. Short cooking
processes require continual
supervision.
Z The appliance is not
designed to be started
using an external timer or a
separate remote controlled
system.
Z WARNING: Danger of fire:
Do not rest objects on the
cooking surfaces.
Z The appliance must be
installed in such a way as
to allow disconnection from
the electrical power supply
with a contact aperture (3
mm) that ensures complete
disconnection in category III
overload conditions.
Z The appliance must never
be exposed to weather (rain,
sun).
Z Ventilation of the appliance
must comply with the
manufacturer’s instructions.
Requirements for kitchen
units
Z The cooker hob is designed
to be fitted flush with the
kitchen worktop, on a
kitchen unit with a width of
600 mm or more.
Z If the appliance is mounted
on flammable materials, the
guidelines and regulations
relating to low voltage
installations and fire
prevention must be followed
strictly.
Z For the fitted units, the
components (plastic
materials and veneered
wood) must be mounted
with heat-resistant adhesives
(min. 100 °C): the use of
unsuitable material and

EN FMA 839 HI / FMA 839 HI LL KIT
– 8 –
adhesives may result in
warping and detachment.
Z The kitchen unit must have
sufficient space to allow
for electrical connection of
the device. Wall-mounted
units above the device must
be installed at a sufficient
distance to leave the space
required to work in comfort.
Z The use of decorative
hardwood borders around
the worktop behind the
device is allowed, provided
the minimum distance
always complies with the
indications provided in the
installation drawings.
Z The minimum distance
between the fitted device
and the rear wall is indicated
in the installation drawing for
the flush-fitted device (150
mm for the side wall, 40 mm
for the rear wall and 500
mm for any wall-mounted
units above it).
Z To avoid any infiltration of
liquids between the hob
frame and the worktop,
position the adhesive seal
provided along the whole
outer edge of the hob before
installation.
Proper use
Z The suction hood has been
designed solely to eliminate
cooking fumes during
domestic use.
Z Never use the appliance
for purposes other than
those for which it has been
designed.
Z Deep-fryers must be kept
under constant supervision
when in use: the oil may
catch fire if it gets too hot.
Z Do not use the device with
an external timer or separate
remote controlled system.
Z The device must never be
installed behind a decorative
door, to prevent it from
overheating.
Z Never climb onto the device,
as this may damage it.
Z Never place hot pots and
pans on the frame, as this
may damage the silicon seal.
Z Never cut or prepare food
on the vitreous ceramic

EN
FMA 839 HI / FMA 839 HI LL KIT
– 9 –
surface, or drop hard objects
onto it.
Never drag pots and pans
across the vitreous ceramic
surface.
ELECTRICAL CONNECTION
Z Electrical connections must
be carried out by a trained
technician.
Z This appliance has a “Y” type
connection, so the power cable
must have a “neutral” wire.
The power cable must be at
least of type H05VV-F. SINGLE
PHASE, TWO PHASE and THREE
PHASE connection: min. cross-
section of wires: 2.5 mm².
External diameter of the power
cable: min. 7 mm - max. 15 mm.
Z The connection terminals can
be accessed by removing the
junction box cover.
Z Check that the domestic power
supply characteristics (voltage,
maximum power and current)
are compatible with those of the
appliance.
Z Connect the appliance as shown
in the diagram (in compliance
with reference standards in force
nationally for mains voltage).
Z It is recommended that you use
the H05V2V2-F 5x2.5mm²
power cable. When using the
H05V2V2-F 5x2.5 mm² power
cable, follow the instructions
provided here: for three phase
connection, separate the 2 wires
and remove the blue sheathing
from the grey wires.

EN FMA 839 HI / FMA 839 HI LL KIT
– 10 –
OVERVIEW
FMA 839 HI - 4-area hob with integrated hood
1
1
2
1
1
1 Cooking area
2 Control panel
Buttons and display elements
Press and hold the On/Off button for 2 seconds to turn the hob on and activate its functions. All the
Digits show . and the Timer digits show “ C L “.
At this point the hob is on but all the cooking areas and the hood are at zero power. The Hob will switch off
automatically after 20 seconds if it is not used.
Warning: For safety reasons the hob can always be turned off using the On/Off button.
Warning: The functions that can be selected will always be the ones that are illuminated/visible on the con-
trol panel, and these will always be the only ones that can be activated.
Instructions for the installer: Check the hob power setting and change it if necessary. See the paragraph “
Installer Menu (Hob power settings) “.
The hob is pre-set as standard to an absorption level of 7.4 Kw.
