SERVICE MANUAL
Master instruction
SERVICE MANUAL
Master instructions
TEMPERATURE CONTROLLER EVCO
Item no.:
Operating ................................................................................................................................. 3
Screen messages ......................................................................................................................4
Error messages and error correction......................................................................................... 5
List of parameters..................................................................................................................... 6
Resistance table (Pt 1000)........................................................................................................ 10

2
Franke Foodservice Systems
Poland Sp. z o. o.
ul. Polnocna 11
81–029 Gdynia
Poland
Phone: [phone]
Fax: [phone]
Franke Foodservice Systems GmbH
Jurastrasse 3
79713 Bad Säckingen
Germany
Phone: [phone]
Fax: [phone]
Franke Foodservice Systems Europe
16.07.2013
This document reflects the technical status at the time of the revision.
We reserve the right to make technical changes.
As one of the world’s leading providers of comprehensive kitchen solutions, we support restau-
rant chains with efficient product developments and professional services. We have stood for ex-
cellent quality and maximum flexibility for over 35 years. More than 27,000 kitchen projects and
services that make your daily work easier and more profitable are a measure of our success.
You have decided to purchase a product from Franke Foodservice Systems – a great choice! We
would like to thank you for your trust and assure you that we will continue to do everything in our
power to be an excellent partner. Direct contact with you is especially important to us. That's
why our expert staff are happy to support you. Throughout the world.
Production facilitiesMain office
Revision date:
en

3
07/2013
i
set
en Status:Temperature controller Evco
Increase value
Decrease value
Start/stop/confirm button
The temperature controller shows the current temperature (actual value) in display mode. If no
button is pressed for 20 seconds during setup (setup mode), the temperature controller returns
to display mode.
Turning on/off
- Press and hold set for 4 seconds.
The temperature controller is turned on or off.
Locking/unlocking the buttons.
No processes should be currently running on the temperature controllers.
- Press and hold set and simultaneously for 2 seconds.
Loc will be shown on the display for 1 second. The buttons are now locked.
- Press and hold set and simultaneously for 2 seconds.
UnL will be shown on the display for 1 second. The buttons are now unlocked.
Displaying the set point
- Briefly press set : SEt and the set point appear.
- Wait 20seconds: The current value is displayed.
Changing the set point
- Briefly press set : SEt and the set point appear.
- Select the menu item using set .
- Set the desired set point temperature using .
- Confirm with set .
Changing from Celsius to Fahrenheit
- Briefly press set : SEt will appear.
- Press or until Uni appears on the display.
- Select the menu item using set .
- Change the units from 0=°C to 1=°F using .
- Confirm with set .
Correcting the actual value
- Briefly press set : SEt will appear.
- Press or until OFt appears on the display.
- Select the menu item using set .
- Correct the actual value using .
- Confirm with set .
Operating

407/2013
en Status:Temperature controller Evco
Configuring the setup parameters
The setup parameters should only be changed under unfavorable operating conditions. The set-
tings may only be configured as expressly instructed by Franke Foodservice Systems.
- Briefly press set : SEt will appear.
- Press or until PA appears on the display.
- Select the menu item using set .
- Press and hold until the number 72 appears on the display. While is pressed, the
numerical value of 0 is incremented until the button is released.
- Confirm with set : The first parameter is displayed.
- Use to set the value of the first parameter.
- Confirm with set : The second parameter is displayed.
- Repeat the procedure to set all parameters.
- Wait 20seconds to exit the menu.
Restoring the factory settings
In the event of a fault, the factory settings should be restored first.
- Press and hold set and simultaneously for 8 seconds until dEF flashes on the display.
The reset is complete.
Message Meaning
Loc Keyboard or active set point is locked.
- - - - The quantity to be displayed is not available (example: because the tempera-
ture sensor has not been activated)
Cln
Display flashes:
Access to the copying process for the parameter set has been created.
Data output from the device is switched off.
St
Display flashes:
Decision made to continue with the copying of the parameter set from the
device to the programming key (upload)
Data output from the device is switched off.
Display is permanently lit
The copying process from the device to the programming key (upload) is ongo-
ing.
Data output from the device is switched off.
PrG
The copying process from the programming key to the device (download) has
been successfully concluded (press any button so that the "PrG" display disap-
pears). The device will restore normal operation.
Screen messages

5
07/2013
en Status:Temperature controller Evco
Error mes-
sage Problem Remedy
AL1 Lower temperature alarm
(at sensor 1)
- Check actual temperature
- Look at parameters A1 and A3
AL2 Lower temperature alarm
(at sensor 2)*
- Check actual temperature
- Look at parameters A5 and A7
AH Upper temperature alarm - Check actual temperature
- Look at parameters A5, A6 and A5
id
Door switch input alarm
(only if parameter i0 has
the value 2 or 3)
- Check the reasons that have provoked the
activation of the input
- Look at parameters i0 and i1
iA
Multipurpose input alarm
(only if parameter i0 has
the value 0)
- Check the reasons that have provoked the
activation of the input
- Look at parameters i1 and i5 (if parameter i5 =
value 3, there will be no effect; if parameter i5 =
value 4, the compressor will be turned off)
iSd
"Device locked" alarm
(only if parameter i0 has
the value 0)
- Check the reasons that have provoked the
activation of the multipurpose input
- Switch device on/off
- Look at parameters i1, i5, i7, i8 and i9
ESt
The copying process of
the parameter set from the
device to the programming
key (upload) has failed.
- Press any button to restore normal operation
and switch off the buzzer
- Check the connection between the device and
the programming key
- Check whether the programming key is working
correctly
- Repeat the copying process
CEr The firmware on the de-
vices do not match
- Check the agreement of the firmware versions
(check manufacturing date)
- If necessary, replace device
Erd
The copying process of
the parameter set from
the programming key to
the device (download) has
failed.
- Press any button to restore normal operation
and switch off the buzzer
- Unplug/plug in the device
- Check the connection between the device and
the programming key
- Check whether the programming key is working
correctly
- Repeat the copying process
- Restore the default setting for the parameter
configuration
Pr1 Error at sensor 1 - Look at parameter P0
- Check whether the sensor (1/2/3) is working
correctly
- Check the connection between the device and
the sensor
- Check actual temperature
Pr2 Error at sensor 2*
Pr3 Error at sensor 3*
Error messages and error correction
* only relevant if the device is prepared for 2 to 3 sensors

607/2013
Parameter list of EVCO for Mc Donald’s Item No. 725.114.966 725.114.968 725.116.181 725.116.183 725.118.046 725.118.048 725.118.058 725.118.062 #470.778 replace-
ment of
725.109.323 725.109.327 725.109.324 725.111.001 725.109.325 725.109.933 725.109.329 725.109.968
Description Unit Range Par. GSFP COOLING COOLING OATMEAL
MIXER
TRANSFER BIN
PRODUCT SLIDE
WARMER DRAWER
HEATED WORKTOP
Software # 725.114.967 725.114.969 725.116.182 725.116.414 725.118.047 725.118.049 725.118.059 725.118.063
Working setpoint °C -150 300 SEt -20.0 2.0 2.0 82.0 63.0 71.0 65.0 54.0 Measure input configuration Roomprobeoffset °C-2525OFt00000-20-2 Kind of probe PTC PT1000 P0 PT1000 PT1000 PT1000 NTC PT1000 PT1000 PT1000 PT1000 Decimal point No Yes P1 Yes Yes Yes Yes Yes Yes Yes Yes Unit of measure °C °F Uni °C °C °C °C °C °C °C °C Quantity to show during the normal operation Probe Set point P5 Probe Probe Probe Probe Probe Probe Probe Probe Regulators Workingdifferential °C0.150r01 1 1 221 1 1 Minimum working setpoint °C -150 300 r1 -23 -2 -2 60 20 20 20 20 Maximum working setpoint °C -150 300 r2 -5 10 10 90 70 80 70 60 Cooling or heating action Cold Hot r5 Cold Cold Cold Hot Hot Hot Hot Hot Loads protection Minimum time between two activation in succession of load min 0 240 C1 5 5 5 0 2 2 2 2 Minimum time the load remains turned off min0240C21 1 1 00000 Minimum time the load remains turned on sec0240C360606010 60606020 Time the load remains turned off during the probe error min 0 240 C4 10 10 10 1 10 10 10 10 Time the load remains turned on during the room error min 0 240 C5 6 6 6 0 1 1 1 1 Defrost Defrostinterval h099d004300000 Defrostduration min099d310121500000 Defrost when you turn on the instrument NoYesd4 NoNoNoNoNoNoNoNo Defrost delay when you turn on the instrument min099d500000000 Temperature shown during the defrost Probe Limited
in defrost d6 Limited in
defrost
Limited in defrost
Limited in defrost
Limited in defrost
Limited in defrost
Limited in defrost
Limited in defrost
Limited in defrost
en Status:Temperature controller Evco
List of parameters

7
07/2013
Parameter list of EVCO for Mc Donald’s Item No. 725.114.966 725.114.968 725.116.181 725.116.183 725.118.046 725.118.048 725.118.058 725.118.062 #470.778 replace-
ment of
725.109.323 725.109.327 725.109.324 725.111.001 725.109.325 725.109.933 725.109.329 725.109.968
Description Unit Range Par. GSFP COOLING COOLING OATMEAL
MIXER
TRANSFER BIN
PRODUCT SLIDE
WARMER DRAWER
HEATED WORKTOP
Software # 725.114.967 725.114.969 725.116.182 725.116.414 725.118.047 725.118.049 725.118.059 725.118.063
Temperature alarms Threshold first temperature alarm °C-150300A1 -5-5-5-12-10-10-10-10 First temperature alarm delay min 0 240 A2 60 60 60 0 60 60 60 60 Kind of first temperature alarm Disabled Relative
Max A3 Relative
Min
Relative Min
Relative Min
Relative Min
Relative Min
Relative Min
Relative Min
Relative Min
Alarms delay since setpoint modification min 0 240 A4 60 60 60 5 60 60 60 60 Threshold second temperature alarm °C-150300A56661010101010 Second temperature alarm delay min 0 240 A6 60 60 60 0 10 10 10 10 Kind of second temperature alarm Disabled Relative
Max A7 Relative
Max
Relative Max
Relative Max
Relative Max
Relative Max
Relative Max
Relative Max
Relative Max
Serial modbus connection Write to OEM default 0 write E9 Write Write Write Write Write Write Write Write
en Status:Temperature controller Evco

807/2013
Parameter list of EVCO for Mc Donald’s Item No. 725.118.078 725.118.100 725.118.102 #470.778 replace-
ment of KFC.106.833 725.115.889 -
Description Unit Range Par. COOLING COOLING COOLING
Software # 725.118.079 725.118.101 725.118.103
Working setpoint °C -150 300 SEt 2.0 2.0 4.0 Measure input configuration Room probe offset °C -25 25 OFt 0 -4 0 Kind of probe PTC PT1000 P0 PT1000 PT1000 PT1000 Decimal point No Yes P1 Yes Yes Yes Unit of measure °C °F Uni °C °C °C Quantity to show during the normal operation Probe Set point P5 Probe Probe Probe Regulators Working differential °C 0.1 50 r0 1 1 1 Minimum working setpoint °C -150 300 r1 -2 -2 2 Maximum working setpoint °C -150 300 r2 10 10 10 Cooling or heating action Cold Hot r5 Cold Cold Cold Loads protection Minimum time between two activation in succession of load min 0 240 C1 5 5 5 Minimum time the load remains turned off min 0 240 C2 1 1 1 Minimum time the load remains turned on sec 0 240 C3 60 60 60 Time the load remains turned off during the probe error min 0 240 C4 10 10 10 Time the load remains turned on during the room error min 0 240 C5 6 6 6 Defrost Defrost interval h 0 99 d0 2 4 2 Defrost duration min 0 99 d3 12 12 15 Defrost when you turn on the instrument No Yes d4 No No No Defrost delay when you turn on the instrument min 0 99 d5 0 0 0 Temperature shown during the defrost Probe Limited
in defrost d6 Limited in
defrost
Limited in defrost
Limited in defrost
en Status:Temperature controller Evco

9
07/2013
Parameter list of EVCO for Mc Donald’s Item No. 725.118.078 725.118.100 725.118.102 #470.778 replace-
ment of KFC.106.833 725.115.889 -
Description Unit Range Par. COOLING COOLING COOLING
Software # 725.118.079 725.118.101 725.118.103
Temperature alarms Threshold first temperature alarm °C -150 300 A1 -5 -5 -5 First temperature alarm delay min 0 240 A2 60 60 60 Kind of first temperature alarm Disabled Relative
Max A3 Relative Min Relative
Min
Relative Min
Alarms delay since setpoint modification min 0 240 A4 60 60 60 Threshold second temperature alarm °C -150 300 A5 6 6 6 Second temperature alarm delay min 0 240 A6 60 60 60 Kind of second temperature alarm Disabled Relative
Max A7 Relative Max Relative
Max
Relative Max
Serial modbus connection Write to OEM default 0 write E9 Write Write Write
en Status:Temperature controller Evco

°C +0 +1 +2 +3 +4 +5 +6 +7 +8 +9
-200 185.201 189.522 193.840 198.154 202.465 206.772 211.076 215.376 219.672 223.965
-190 228.255 232.541 236.824 241.103 245.379 249.651 253.920 258.186 262.449 266.708
-180 270.964 275.217 279.467 283.713 287.956 292.197 296.434 300.667 304.898 309.126
-170 313.350 317.572 321.791 326.006 330.219 334.429 338.635 342.839 347.040 351.238
-160 355.433 359.626 363.815 368.002 372.186 376.367 380.545 384.721 388.894 393.064
-150 397.232 401.397 405.559 409.719 413.876 418.030 422.182 426.331 430.478 434.622
-140 438.764 442.904 447.040 451.175 455.307 459.436 463.563 467.688 471.810 475.930
-130 480.048 484.163 488.276 492.386 496.495 500.601 504.705 508.806 512.906 517.003
-120 521.098 525.191 529.281 533.370 537.456 541.540 545.622 549.702 553.780 557.856
-110 561.930 566.002 570.072 574.139 578.205 582.269 586.331 590.391 594.448 598.504
-100 602.558 606.611 610.661 614.709 618.756 622.800 626.843 630.884 634.923 638.960
-90 642.996 647.030 651.062 655.092 659.120 663.147 667.172 67 1.195 675.217 679.236
-80 683.254 687.271 691.286 695.299 699.310 703.320 707.328 711.335 715.340 719.344
-70 723.345 727.346 731.344 735.341 739.337 743.331 747.324 751.315 755.304 759.292
-60 763.278 767.263 771.247 775.229 779.210 783.189 787.166 791.143 795.117 799.091
-50 803.063 807.033 811.003 914.970 818.937 822.902 826.865 830.828 834.789 838.748
-40 842.707 846.663 850.619 854.573 858.526 862.478 866.428 870.377 874.325 878.271
-30 882.217 886.160 890.103 894.044 897.985 901.923 905.861 909.797 913.732 917.666
-20 921.599 925.530 929.461 933.390 937.317 941.244 945.169 949.093 953.016 956.938
-10 960.859 964.778 968.696 972.613 976.529 980.444 984.358 988.270 992.181 996.091
0 1000.000 1003.908 1007.814 1001.720 1015.624 1019.527 1023.429 1027.330 1031.229 1035.128
10 1039.025 1042.921 1046.816 1050.710 1054.603 1058.495 1062.385 1066.274 1070.162 1074.049
20 1077.935 1081.820 1085.703 1089.585 1093.467 1097.347 1101.225 1105.103 1108.980 1112.855
30 1116.729 1120.602 1124.474 1128.345 1132.215 1136.083 1139.950 1143.817 1147.681 1151.545
40 1155.408 1159.270 1163.130 1166.989 1170.847 1174.704 1178.560 1182.414 1186.286 1190120
50 1193.971 1197.821 1201.670 1205.518 1209.364 1213.210 1217.054 1220.897 1224.739 1228.579
60 1232.419 1236.257 1240.095 1243.931 1247.766 1251.600 1255.432 1259.264 1263.094 1266.923
70 1270.751 1274.578 1278.404 1282.228 1286.052 1289.874 1293.695 1297.515 1301.334 1305.152
80 1308.968 1312.783 1316.597 1320.411 1324.222 1326.033 1331.843 1335.651 1339.458 1343.264
90 1347.069 1350.873 1354.676 1358.477 1362.277 1366.077 1369.875 1373.671 1377.467 1381.262
100 1385.055 1388.847 1392.638 1396.428 1400.217 1404.005 1407.791 1411.576 1415.360 1419.143
110 1422.925 1426.706 1430.485 1434.264 1438.041 1441.817 1445.592 1449.366 1453.138 1456.910
120 160.880 1464.449 1468.217 1471.984 1475.750 1479.514 1483.277 1487.040 1490.801 1494.561
130 1498.319 1502.077 1505.833 1509.589 1513.343 1517.096 1520.847 1524.598 1490.801 1494.561
140 1535.843 1539.589 1543.334 1547.078 1550.820 1554.562 1558.302 1562.041 1565.779 1569.516
150 1573.251 1576.986 1580.719 1584.451 1588.182 1591.912 1595.641 1599.368 1603.095 1606.820
160 1610.544 1614.267 1617.989 1621.709 1625.429 1629.147 1632.864 1636.580 1640.295 1644.009
170 1647.721 1651.433 1655.143 1658.852 1662.560 1666.267 1669.972 1673.677 1677.380 1681.082
180 1684.783 1688.483 1692.483 1695.879 1699.575 1703.271 1706.965 1710.658 1714.349 1718.040
190 1721.729 1725.418 1729.105 1732.791 1736.475 1740.159 1743.842 1747.523 1751.203 1754.882
200 1758.560 1762.237 1765.912 1769.587 1773.260 1776.932 1780.603 1784.273 1787.941 1791.609
210 1795.275 1798.940 1802.604 1806.267 1809.929 1813.590 1817.249 1820.907 1824.564 1828.220
220 1831.875 1835.529 1839.181 1842.832 1846.483 1850.132 1853.779 1857.426 1861.072 1864.716
230 1866.350 1872.001 1875.642 1879.282 1882.921 1886.558 1890.194 1893.830 1897.463 1901.096
240 1904.728 1908.359 1911.988 1915.616 1919.243 1922.869 1926.494 1930.117 1933.740 1937.361
250 1940.981 1944.600 1948.218 1951.835 1955.450 1959.065 1962.678 1966.290 1969.901 1973.510
260 1977.119 1980.726 1984.333 1987.938 1991.542 1995.145 1998.746 2002.347 2005.946 2009.544
270 2013.141 2016.737 2020.332 2023.925 2027.518 2031.109 2034.699 2038.288 2041.876 2045.463
PT 1000 –200.0 .... 850.00 °C
en
Resistance table (Pt 1000)
Unit
Sensor
Resistance in Ohm

11
07/2013
en Status:Temperature controller Evco

G:\FCE_Engineering\220_FAB_Zukaufteile_Manuals\Temperaturregler\Evco\Evco_Master.indd
France
Poland
Italy Spain
United KingdomGermany
Franke Foodservice Systems GmbH
Jurastrasse 3
79713 Bad Säckingen
Germany
Phone: [phone]
Fax: [phone]
Franke Foodservice Systems GmbH
France
Phone: [phone]
Fax: [phone] 83
Email: [e-mail]
Franke Foodservice Systems
Poland Sp. z o. o.
ul. Polnocna 11
81-029 Gdynia
Poland
Phone: [phone]
Fax: [phone]
Franke Foodservice Systems GmbH
Italy
Phone 1: 0039 345 76 60 050
Phone 2: 0039 347 34 06 220
Fax: [phone] 8700
Email: [e-mail]
Email: [e-mail]
Franke Foodservice Systems GmbH
Rodríguez San Pedro, 2, 6º
Edificio Inter - Oficina 603
28015 Madrid
Spain
Direct phone: [phone]
Direct fax: [phone]
Franke Foodservice Systems GmbH
Unit 2A Broom Business Park
Bridge Way
Chesterfield
S419QG
UK
Phone: [phone]
Fax: [phone]
en
Locations
