Franke FDW 908 RB XS Operation manual

Instructions for use and installation
Cooker Hood
Istruzioni per l’uso e l’installazione
Cappa
Mode d’emploi et installation
Hotte de Cuisine
Bedienungsanleitung und Installation
Dunstabzugshaube
Kullan
ım ve montaj talimatları
Davlumbaz
FDW 908 RB XS
GB
IT
FR
DE
TR

2
2
INDEX
RECOMMENDATION AND UGGE TION ..................................................................................................................... 3
CHARACTERI TIC ............................................................................................................................................................. 6
IN TALLATION ...................................................................................................................................................................... 8
U E ...................................................................................................................................................................................... 18
MAINTENANCE ................................................................................................................................................................... 20
INDICE
CON IGLI E UGGERIMENTI ............................................................................................................................................ 21
CARATTERI TICHE ............................................................................................................................................................ 24
IN TALLAZIONE ................................................................................................................................................................. 26
U O ...................................................................................................................................................................................... 36
MANUTENZIONE................................................................................................................................................................. 38
OMMAIRE
CON EIL ET UGGE TION .......................................................................................................................................... 39
CARACTERI TIQUE ......................................................................................................................................................... 42
IN TALLATION .................................................................................................................................................................... 44
UTILI ATION ....................................................................................................................................................................... 54
ENTRETIEN ......................................................................................................................................................................... 56
INHALT VERZEICHNI
EMPFEHLUNGEN UND HINWEI E ................................................................................................................................... 57
CHARAKTERI TIKEN ......................................................................................................................................................... 60
MONTAGE ........................................................................................................................................................................... 62
BEDIENUNG ........................................................................................................................................................................ 72
WARTUNG ........................................................................................................................................................................... 74
IÇERIKLER
TAV IYELER VE ÖNERILER .............................................................................................................................................. 75
ÖZELLIKLER ........................................................................................................................................................................ 78
MONTAJ ............................................................................................................................................................................... 80
KULLANIM ........................................................................................................................................................................... 90
BAKIM .................................................................................................................................................................................. 92
EN
IT
FR
DE
TR

EN
3
3
RECOMMENDATION AND UGGE TION
The Instructions for Use apply to several versions of this appliance.
Accordingly, you may find descriptions of individual features that do not
apply to your specific appliance.
IN TALLATION
• The manufacturer will not be held liable for any damages resulting from
incorrect or improper installation.
• The minimum safety distance between the cooker top
and the extractor hood is 650 mm (some models can
be installed at a lower height, please refer to the
paragraphs on working dimensions and installation).
• Check that the mains voltage corresponds to that
indicated on the rating plate fixed to the inside of the
hood.
• For Class I appliances, check that the domestic
power supply guarantees adequate earthing.
Connect the extractor to the exhaust flue through a pipe of minimum
diameter 120 mm. The route of the flue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying combustion
fumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-
electrical appliances (e.g. gas burning
appliances), a sufficient degree of aeration must
be guaranteed in the room in order to prevent the
backflow of exhaust gas. The kitchen must have
an opening communicating directly with the open
air in order to guarantee the entry of clean air.
When the cooker hood is used in conjunction with
appliances supplied with energy other than electric, the negative pressure in
the room must not exceed 0,04 mbar to prevent fumes being drawn back
into the room by the cooker hood.
• In the event of damage to the power cable, it must be replaced by the
manufacturer or by the technical service department, in order to prevent any
risks.
2°

EN
4
4
• If the instructions for installation for the gas hob specify a greater distance
specified above, this has to be taken into account. Regulations concerning
the discharge of air have to be fulfilled.
• Use only screws and small parts in support of the hood.
Warning: Failure to install the screws or fixing device in accordance with
these instructions may result in electrical hazards.
• Connect the hood to the mains through a two-pole switch having a contact
gap of at least 3 mm.
• This Cooker hood can be used in conjunction with a Gas Cook Top having
the following characteristics:
• Maximum power 12,4 kW
• 5 fire like the picture
U E
• The extractor hood has been designed exclusively for domestic use to
eliminate kitchen smells.
• Never use the hood for purposes other than for which it has been designed.
• Never leave high naked flames under the hood when it is in operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only, making
sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored
during use: overheated oil can burst into flames.
• Do not flambè under the range hood; risk of fire.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
2,6 kW
5 kW
1,9 kW
1,9 kW
1 kW

EN
5
5
• “ CAUTION: Accessible parts may become hot when used with cooking
appliances.”.
MAINTENANCE
• witch off or unplug the appliance from the mains supply before carrying out
any maintenance work.
• Clean and/or replace the Filters after the specified time period (Fire hazard).
• The Grease filters must be cleaned every 2 months of operation, or more
frequently for particularly heavy usage, and can be washed in a dishwasher.
• The Activated charcoal filter is not washable and cannot be regenerated,
and must be replaced approximately every 4 months of operation, or more
frequently for particularly heavy usage.
• Clean the hood using a damp cloth and a neutral liquid detergent.
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or
the shop where you purchased the product.

EN
6
6
CHARACTERI TIC
Components
Ref. Q.ty Product Components
1 1 Hood Canopy complete with: Controls, Light, Filters
3 1 Electric unit
4 1 Front Frame
Ref. Q.ty Installation Components
7.1 2 plashback Fixing Bracket
7.2 2 Hob Fixing Bracket
7.3 2 ide Bracket
12a 16 crews 3.5 x 9.5
12b 2 crews M4 x 8
12c 6 crews 4 x 15
Q.ty Documentation
1 Instruction Manual

EN
7
7
Dimensions

EN
8
8
IN TALLATION
This Hood is set up to be fitted inside the kitchen unit in:
• Ducting version: Evacuation to the outside.
• Recirculation version: Internal recirculation.
equence of operations - Installation
• Drilling the Support Surface and Fitting the Hood
• Connections
• Functional Check
• Disposal of Packaging
Drilling the upport urface
X
812
Warning
Once the Support surface has been drilled the Hood Canopy can be installed in two ways:
• By inserting the Hood Canopy from below ( X= 106 mm ).
• By inserting the Hood Canopy from above ( X= 113 mm ).
IMPORTANT
The minimum distance between the opening for the hob and the one for the hood must be of at
least 3-5 cm according to the strength of the material used for the working top.

EN
9
9
7.2
12a
7.2
12a
Inserting the Hood Canopy into the support surface from below
• Insert the Hood Canopy from below into the
support worktop, drilled as described above.
• With the aid of a
support, lift the Hood
Canopy until the front
comes out of the
Worktop.
• Insert the Brackets 7.2, as indicated in the
figure, into the slots provided and fix them
with the screws 12a provided.
• Centre the Hood Canopy with respect to the
Cooking Hob slot.
• Using the 2 screws 12c provided, fix the
Hood Canopy to the worktop and remove
the supports.
Warning:
If the cooker top is made from a material that does not allow the screws 12c to be inserted, use
a small amount of silicone to glue the Brackets 7.2 to the top and allow it to dry completely
before proceeding with installation.

EN
1
0
10
7.2
12a
7.2
12a
Inserting the Hood Canopy into the support surface from above
• Insert the Brackets 7.2, as
indicated in the figure, into the
slots provided and fix them with
the screws 12a provided.
• Insert the Hood Canopy into the
cooker top, drilled as described
above.
• Centre the Hood Canopy with
respect to the Cooking Hob slot.
• Fix the Hood Canopy with the 2
screws 12c provided.
Warning:
If the cooker top is made from a material that does not allow the screws 12c to be inserted, use
a small amount of silicone to glue the Brackets 7.2 to the top and allow it to dry completely
before proceeding with installation.

EN
1
1
11
12c
12a
7.1
12a
7.1
Fixing the Lower Brackets
• Screw the brackets 7.1 to the front of the Hood Canopy using the screws 12a provided.
• Before tightening the Brackets completely, make all the adjustments to allow them to rest on
the lower base of the worktop to avoid deformation of the upper brackets 7.2 as shown in the
figure.
• With the aid of a spirit level, set the Hood Canopy level vertically and fix it to the Lower
Surface using 2 screws 12c provided.
• Tighten the screws 12a completely.

EN
1
2
12
Fixing the quaring Brackets
• Screw the brackets 7.3 to the Hood Canopy using the screws 12b provided, without
tightening completely.
• Using the screws 12c provided, fasten the other part of the brackets 7.3 either to the side
walls of the unit or to the lower part of the cooker top.
12b
7.3
12b
7.3
12c
• Tighten the screws 12c and 12b completely.

EN
1
3
13
Fixing the Electric Unit
• Connect the Electric cables that come out of the lower
right hand part of the Hood Canopy to the Connectors
ontheElectricunit.
• Each cable connector has a corresponding connector
on the Electric Unit, so take care notto make mistakes
when connectingup.
• Fix the Electric Unit to the Hood Canopy using the
screws12aprovided.
• The position indicated in the figure is only an option,
as if necessary it may also be fitted on the left of the
Hood Canopy or even left free on the base of theunit
iftherearenostructuralorsafetyproblemsinvolved.
Warning..: Do not install the product in such a way that the wiring box is in contact with the floor.

EN
1
4
14
Connection to the Air outlet
To connect the Hood to the outlet pipe, select the
version that applies.
Standard Outlets
According to your decision (Right or Left), break the
outlet hole already marked and screw on Flange 2using
the 4 screws 12a provided.
Optional Outlets
The Hood is fitted with three other possible outlets:
Right Side
Left Side
Bottom
According to your decision, unfasten the screws fixing
the cover and fit a connector, not provided, to the outlet
(the connector shown in the figure is merely an
example).
1 1
22
30mm
220mm
55mm
112.0040.359 112.0040.360

EN
1
5
15
Connections
DUCTED VER ION AIR EXHAU T Y TEM
When installing the ducted version, connect the hood to the
chimney using either a flexible or rigid pipe ø 150 or 120 mm,
the choice of which is left to the installer.
• To install a ø 120 mm air exhaust connection, insert the
reducer flange 9 on the hood body outlet.
• Fix the pipe in position using sufficient pipe clamps (not
supplied).
• Remove any activated charcoal filters.
ø 150
9
ø 120
ELECTRICAL CONNECTION
• Connect the hood to the mains through a two-pole switch
having a contact gap of at least 3 mm..
APPLIANCE
INLET

EN
1
6
16
Warning..:
Handle
with care
Fitting the Front element
• Lift the mobile hood canopy
(see paragraph on Use) by just a
few centimetres.
• To stop movement, simply
press down on the mobile
canopy as it lifts up.
Warning: Never block the
sliding door when it is opening
or closing, except during the
operations required to fit the
frame.
• Remove the sponge guards
from the corners of the glass.
• Take the front Frame and insert
it from above, making sure that
its tabs insert into the slots
provided on the Hood and
sliding it to the left.
Warning..: All the tabs must be
inserted.
• Use a tool (hammer) to tap all
along the front Frame from
right to left until it is
completely flush.
A piece of wood or similar
element can be inserted
between the hammer and the
front Frame to prevent any
damage.
• Please refer to the paragraph on
Use for indications of how to
return the mobile canopy to the
Standard position.

EN
1
7
17
urround uction Panel
• Open the Hood Door (see
USE).
• Remove the 2 strips of adhesive
tape fastening the panel during
transport.

EN
1
8
18
U E
Control panel
Button
Function
LEDbutton
A
The buttononlyworks when thedooris open.
Press Briefly = Turns the
Lights
On/Off at maximum
intensity.
Press and hold for 2 Seconds=
Turns
the
Courtesy lights
On/Off.
B
DoorOpenor Closed
Press briefly = performs a Reset of the Filter saturation
alarm.
After 100 hours in operation the Drop symbol is
displayed to indicate saturation of the Metal Grease
Filters.
After 200 hours in operation the letter C is displayed to
indicatesaturationofthe ActivatedCharcoalfilters.
DoorOpenor Closed
Press and hold for 2 Seconds = Enables/Disables the
Activated Charcoal Filter Alarm with the Motor turned
offand no FilterAlarmtriggered.
Symbol
C
flashes twice= A.C.FilterAlarmActivated
SymbolCflashesonce =A.C. FilterAlarmDeactivated
C
DoorOpen.
Press briefly = Activates/Deactivates Delay mode,
causing automatic shutdown of the Motor and the
Lighting system from any speed with a 30’ delay. It is
disabled by pressing the same button again, turning the
motorofforclosingthedoor.
Displays the
Clock
symbol.
Works both with Door Closed and Open with Motor +
Lights =Off.
Press and hold for 4 Seconds = Enables/disables the
KeyboardLock.
All the LED buttons flash twice. During the Lock
the
LED buttons light up in sequence.
D
Onlyworkswiththe DoorOpen.
Press briefly= Enables/Disables the Intensivespeed.This
speed is timed to runfor 6 minutes. At the end of this time
thesystemwillreturn tothespeedsetpreviously.
It is disabled by pressing the same button again, turning
the motoroff orclosing thedoor.
Displays the
I
symbol.
E
Only works with the Door Open = i
ncreases the working
speed.
The numberoflightedsegmentsincreases.
F
Only works with the Door Open =
decreases
the working
speed.
The numberoflightedsegmentsdecreases.
G
Onlyworkswiththe DoorOpen.
Pressbriefly=TurnstheMotorOnorOff
LEDsturnoff
DoorOpenorClosed
Press and hold for 2Seconds withMotorand Lights Off =
Enables/Disablesthe
Remotecontrol
.
LED keysflashtwice= Remote control Enabled
LED keysflashonce =Remote control Disabled
H
Door Open =
Closes the Door
+ Lights and Motor Off
(*)
DoorClosed =Opens theDoor+LightsandMotorOn.
Warning: If the Door remains partially open for any
reason, press the Button to complete the opening or
closingcycle.
(*) While the Door is Closing it will block in an
intermediate position after approximately 6 seconds. To
finish Closing you must press the button again and hold it
untilthe
dooriscompletelyclosed.

EN
1
9
19
REMOTE CONTROL (OPTIONAL)
The appliance can be controlled using a remote control
powered by a 1.5 V carbon-zinc alkaline batteries of the
standard LR03-AAA type (not included).
• Do not place the remote control near to heat sources.
• Used batteries must be disposed of in the proper
manner.
Remote control panel
Warning..: The remote control receiver is deactivated when first supplied. To activate it, see the
paragraph Use Function of Button G.
Motor Door Closed: Opens the door, turns the motor on at speed one and turns the lights on at
maximum intensity.
Door Open: Brief pressure: Motor On / Off
Pressed for 2 Seconds: Closes the Door and Motor + Lights = Off
Only with Door Open:
Decreases the working sp
eed each time it is pressed.
Only with Door Open:
Increases the working speed each time it is pressed.
Intensive Only with Door Open:
Activates the Intensive function
Delay Only with Door Open:
Activates the Delay function
Light Only with Door Open: Brief pressure: Lights On / Off
Pressed for 2 Seconds: Courtesy lights On / Off

EN
2
0
20
MAINTENANCE
Cleaning the Comfort Panels
• Open the Comfort Panel by pulling it at the top.
• Unhook the security chain by opening the spring catch.
• Disconnect the panel from the hood canopy.
• The comfort panel must never be washed in the dishwasher.
• Clean the outside with a damp cloth and neutral detergent.
• Clean the inside using a damp cloth and neutral detergent; do
not use wet cloths or sponges, or jets of water; do not use
abrasive substances.
• On completing the operation, hook the panel and the spring
catch up to the hood canopy again and close it.
Metal grease filters
These can also be washed in the dishwasher, and need to be
cleaned whenever the “drop” symbol lights up or at least once
every 2 months use, or more frequently if use is particularly
intensive.
Resetting the alarm signal
• Turn the Lights and the Suction Motor off.
• Press button B(see paragraph on Use).
Cleaning the Filters
• Open the Door (see USE).
• Open the Comfort panel by pulling it.
• Remove the Filters one at a time, pushing them towards the
back of the unit and at the same time pulling downward.
• Wash the Filters without bending them, and leave them to dry
completely before replacing. (If the surface of the filter
changes colour as time goes by, this will have absolutely no
effect on the efficiency of the filter itself.)
• Replace, taking care to ensure that the handle faces forwards.
• Close the Comfort panel.
Lighting unit
Warning: This appliance is fitted with a white LED lamp classed
as 1M according to EN 60825-1: 1994 + A1:2002 + A2:2001
standards; maximum optical power emitted @439nm: 7µW. Do
not look directly at the light through optical devices (binoculars,
magnifying glasses…).
• For replacement contact technical support. ("To purchase
contact technical support")
