Freespirit Recreation ReadyLight Installation instructions

INSTRUCTIONS FOR ASSEMBLY
AND OPERATION

THANKS FOR
PURCHASING
READYLIGHT!
… and congratulations. You’re
now part of the ReadyLight family,
and own one of the best mobile
lighting solutions available on
the market today. ReadyLight’s
intuitive, all-in-one design,
adventure-tested materials and
intelligent engineering guarantee
many years of fun memories and
reliable performance.
Ready? Let’s light it up!

READYLIGHT HEAD
TRIPOD SWIVEL CLAMP FASTENERS, LOCK WASHERS,
HEX-KEY WRENCH
2 FASTENERS REQUIRED;
2 EXTRAS ARE PROVIDED
PACKAGE CONTENTS
4

TRIPOD LEGS TRIPOD ROD TRIPOD ROD
LOCK NUT
5

AC POWER ADAPTER
DC POWER ADAPTER / CAR CHARGER
GROUND STAKES
PACKAGE CONTENTS
6

CARRYING CASE
CARRYING CASE
7

ASSEMBLE TRIPOD
1
Loosen tripod rod lock
nut by turning nut
counterclockwise. Pull
up and away from end
of rod.
2
Insert the three tripod legs
into the slots in the tripod rod.
8

Use the supplied stakes
to firmly anchor your
ReadyLight to the
ground.
3
Slide tripod rod lock nut
down onto tripod legs,
begin threading, and turn
clockwise to tighten the
assembly.
4
Your assembled tripod
should look like this:
9

5
Using two of the supplied
fasteners, two lock washers,
and the hex key wrench,
secure tripod swivel clamp to
ReadyLight head as shown.
ASSEMBLE HEAD
10

6
7
Insert end of tripod
rod into tripod swivel
clamp. Once rod is in,
move locking lever
back to the locked
position to secure.
Angle of ReadyLight
head can be adjusted
by loosening and
tightening triangular
knob.
Release locking
lever on swivel
clamp …
11

Master
ON /OFF
switch
Place in ON
position to use
or charge light.
Move to OFF
position when
finished using
light.
Charge
indicator
light
Glows RED
when light
is charging;
glows GREEN
when light is
fully charged.
Power
supply
input
Allows light
to be charged
with supplied
A/C and D/C
charging
adapters.
Full size
USB power
output
1 AMP power
supply for cell
phones, speak-
ers, cameras,
etc. Turns off
when light
experiences
low power.
MAIN PANEL
12

Place master
ON / OFF switch
in ON position.
This allows your
ReadyLight to
receive a charge.
Charging source:
Connect to the A/C
or D/C adapter,
OR position your
ReadyLight in direct
sunlight and it will
automatically begin
solar charging.
Give your ReadyLight
time to charge:
AC/DC............ 6 hours
Solar ............ 24 hours
1 32
CHARGING
13

Turn on light:
Press and hold ON / OFF
button for 1–2 seconds …
… lights will first activate
at their brightest (5 WATT)
setting.
1
MAIN LIGHT OPERATION
14

Momentarily depress
ON / OFF button a second time:
Lights will dim to their low
(2.5 WATT) setting.
To repeat the cycle of light
functions, continue to depress
the ON / OFF button.
Press and hold ON / OFF
button to turn off light.
Red indicator lights will flash
quickly when batteries are low
on power.
2
3
Momentarily depress
ON / OFF button a third time:
Main lights will deactivate
and red warning lights will
turn on and blink slowly.
15

Charge indicator light
Hidden under main lens.
Lights red when charging.
Mini USB charging port
Allows for charging of light
independent of main light.
Low power indicator light
Hidden under main lens.
When charging is required,
light turns red.
ON / OFF switch
Press and hold 1–2 seconds
to turn on light.
LED spot light
Fold-out hook
Lets you hang your light just
about anywhere.
Powerful base magnet
Firmly secures light to main
ReadyLight. Also allows light
to adhere to any ferrous metal
surface.
PORTABLE LIGHTS
16

PORTABLE OPERATION
To activate light:
Press and hold ON / OFF
button for 1–2 seconds. Main
light activates at its brightest
setting.
Momentarily tap button once:
Main light dims.
Tap button a second time:
Main light deactivates.
Spot light activates.
Tap button a third time:
Spot strobe light activates.
To repeat the cycle of lighting
functions, momentarily
depress the ON / OFF button
again.
Press and hold ON / OFF button
to turn off light.
17

MAIN LIGHT
BATTERY TYPE.....................................................................................Lithium-Ion
BATTERY CAPACITY.....................................................................7. 4V 7 80 0m A H
DC POWER..................................................................................... 12V CLA charger
AC/DC CHARGE TIME ................................................................................. 6 hours
SOLAR CHARGE TIME.................................................................... up to 24 hours
RUN TIME ................................................................................ 15 hours / 30 hours
MAXIMUM POWER .............................................................................................15W
BRIGHTNESS SETTINGS ........................................................................5W / 2.5W
LUMENS............................................................................................... 350lm / 175lm
CHARGING TEMPERATURE, CELSIUS.....................................................0°—50°
DISCHARGE TEMPERATURE, CELSIUS...............................................-20°—50°
EXTERNAL USB POWER SUPPLY............................................................... 5V 1A
PORTABLE LIGHTS
BATTERY TYPE.....................................................................................Lithium-Ion
BATTERY CAPACITY..................................................................... 3.7V 1200mA H
WATTAGE, SINGLE UNIT .................................................................................... 1W
WATTAGE, ALL 4 UNITS.....................................................................................4W
LUMENS, SINGLE UNIT................................................................................... 50lm
LUMENS, ALL 4 UNITS..................................................................................200lm
RUN TIME, SINGLE UNIT........................................................................... 5 hours
CHARGE TIME ............................................................................................... 5 hours
WORKING TEMPERATURE, CELSIUS ..................................................-20°—50°
TOTAL LIGHT SPECIFICATIONS
LUMENS..............................................................................................................500lm
RENDERING INDEX...........................................................................................Ra80
CCT ...................................................................................................................... 6500K
SERVICE LIFE..................................................................................... 20,000 hours
WORKING HUMIDITY ...................................................................................... ≤95%
SHELL MATERIAL .............................................................Flame-retardant ABS
INGRESS PROTECTION ..................................................................................... IP63
SPECIFICATIONS
18

19

20495 Murray Rd, Suite 120
Bend OR 97701
(844) READY-LT • www.readylight.com
