Freezimer HIM-35B User manual
Follow Freezimer
Visit us:www.freezimer.com
THIS INSTRUCTION CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ
AND KEEP FOR FUTURE REFERENCE.
1
DESCRIPTION
Upper cover Buttons
Control panel
Water tray
Bullet evaporator
Motor support
Rear housing
Transparent lid
Micro switch support
Ice shovel board
Ice basket
Liner
Front housing
Ice shovel
The indicator lights in green when select small ice.
The indicator lights in green when select large ice.
The indicator lights in green when the ice maker
is cleaning.
The indicator lights in red when the water tank is
lack of water.
The indicator lights in red when the ice basket is full.
1. Turn on/off the appliance
2. Hold the “CLEAN” button for 3 seconds to start up
the self-cleaning function.
Confirm choice of large ice mode or small ice mode.
ADD WATER
ICE FULL
SELECT
NO/OFF
CLEAN
SMALL
LARGE
CLEAN
CONTROL PANEL OPERATION
LARGE
SMALL
ICE FULL
NO/OFF
CLEAN
Plug the ice maker into the wall outlet and press “ ” to start.
SELECT
Press “ ” button to select the ice size, “ ” means Large ice,
“ ” means Small ice.
The ice-making cycle will last approximately 6-8 minutes, depending on the
ambient temperature and water temperature.
ADD WATER
NO/OFF
CLEAN
The ” ” indicator will light up when the water tank is lack of water and the
ice-making cycle will stop automatically. About 5 seconds later, the ice maker
will restart its ice making function automatically.
Use a diluted solution of water and vinegar to clean the inside and outside of the ice
maker. Do not spray ice maker with chemicals or diluted agents such as acids,
gasoline or oil. Rinse thoroughly before starting.
When the efficient and quiet ice making process is over, you need to press
CLEAN button for 3 seconds to enter the self-cleaning mode.
Reuse the machine after being idled for a period of time, it may not have enough
water to pump for air retard, in this case, the water shortage indicator
“ADD WATER” will light up, repress ON/OFF button to restart the ice maker is okay.
If the compressor takes a strike action for shortage water, fully water or
interruption of power supply, it will delay for 3 minutes to start up after restarted.
TROUBLESHOOTING
1. Please note, if a power failure occurs due to disconnection of the power cord, or the power button
has been pushed off during an ice making cycle, small ice chips may form and lodge in the automatic
shovel causing it to jam. If this occurs, the ice chips may be removed by disconnecting the power
cord and gently pushing the shovel to the rear of the cabinet and removing the ice chips, then
restarting.
2. Please check if the water reservoir is flat when the ice shovel can not remove the ice to the ice
basket. If not, please push the ice shovel gently by finger, then press ON/OFF button to restart.
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS
The compressor works
abnormally with a buzzing
noise
The ice made is too large
and with pieces sticking
together
The ice making process was
correct, but no ice came
out?
All indicators twinkle
simultaneously
The machine has been
working, but the water has
been warming
When the ice is full, the
machine does not display
the ICE FULL Icon.
The voltage is lower than
recommended.
Ice of previous cycles left in the
water tray.
1.The compressor has no
refrigerant.
1.Water tray is blocked by ice
cube.
2.The motor is stuck, or the
motor falls o, or the motor is
damaged.
3.The micro switch was
destroyed.
Ice full sensor damaged
Sunlight interference.
2.Compressor damaged.
3.Fan motor damaged.
Solenoid broke down.
Stop the Ice maker and do not
restart until the voltage is normal.
1.Unplug the power to take out the
ice which blocking the tray, then
plug the power and press the
POWER button, the machine will
restart 3minutes later.
Water shortage indicator
light is on
Indicator lights on display
are not on
1.There is no water.
2.The pump is full of air.
Blown fuse/ No power.
1.Add to some water until it reaches
MAX position.
Take out the ice under the standby
state.
2.Press POWER button to restart.
Replace fuse / Turn power on.
Call the service hotline.
Replace the solenoid valve.
1.Replace the ice full sensor.
2.Making ice indoor.
3.Call the service hotline.
2.Call the service hotline.
HIM-35B
15kg (33lb) / 24 hours
700g / 1.54lb (Max)
R600a
2.2L / 2.32qt
120 V
60 Hz
2.2 A
14.1" X 9.65" X 11.54"
15.67" X 11.3" X 13.2"
8.7Kg (19.2 lb)
9.8Kg (21.6 lb)
Model number:
Daily ice output:
Ice storage capacity:
Refrigerant:
Water tank capacity:
Voltage:
Frequency:
Current:
Max overall dimensions
(W×D×H):
Packing dimensions
(L×W×H):
N.W. :
G.W. :
www.freezimer.com
Icewox
This symbol indicates the refrigerant R600a and the non-metal- lic materials of
the appliance are flammable. ltys a warning symbol.Warning:Risk of fire/flam-
mable materials.
WARNING: When positioning the appliance,ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance Children aged from 3to 8years are allowed to load and unload refrigerat-
ingappliances.To avoid contamination of foodplease respect the follow- inginstructions.
fl Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
fl Clean regular surfaces that can come in contact with food and accessible drainage systems.
fl Clean water tanks if they have not been used for 48 h;flush the water system connected to a
water supply if water has not been drawn for 5 days. fl lf the refrigerating appliance is left
empty for long periods,switch off, defrost, clean,dry,and leave the door open to prevent mould
developing within the appliance. Regardingthe information pertainingto the use of the
appliance,thanks to refer to the below paragraph of the manual.
Made in China
www.freezimer.com
E-Mail: service@freezimer.com
Manufacturer: Iceplus Tech (DongGuan) Co., Ltd
Iceplus Tech Industrial Zone, Room 201, No.9, Yangwu Tangxing Road,
Qishi Town, Dongguan
+44(0)7825478124
+49(0)211-97538868
