FreiStil Tischlerei JEREMIA User manual

FreiStil Tischlerei
Böhm und Kinstler GmbH & Co. KG
Ruppenkampstraße 16
49084 Osnabrück
Phone [phone]
Fax [phone]
Email [email protected]
Website www.freistil.com
Operating instructions
Children’s Therapeutic Bed
“JEREMIA”
Read carefully before operating!
These operating instructions must be provided to all users!

2
TABLE OF CONTENTS
1. Assembly instructions (for authorised sales agents only) Page
1.1 Assembling the bed frame 03
1.2 Assembling the bed base 03
STANDARD: Manual adjustment 03
OPTIONAL: Electric motor adjustment 04
1.3 Cable connections 04
1.4 Double motor cover 05
1.5 Installing the bed base 05
1.6 Trendelenburg positioning 05
1.7 Power cable storage 05
1.8 Transport casters 06
1.9 Side panels: Flaps, adjustable side rails, revolving doors 06 / 07
1.10 OPTIONAL: Tube posts 07
2. Operating instructions
2.1 Intended use 08
2.2 Important information on operational safety 08 / 09
2.3 Warning notices 09
2.4 Lifting unit 10
2.5 Bed base 10
2.6 Manual control unit 10 / 11 / 12 / 13
Assignment of keys, function diagram 09.1 / 13
Trendelenburg position –warning notice on page 13!!!
2.7 Side panels: Flaps, adjustable side rails, revolving doors 14 / 15
2.8 Transport casters 16
2.9 Cleaning, maintenance and reuse 16
2.10 Accessories 16
2.11 Symbols 16
3. Technical data
3.1 Bed frame 17
3.2 Lifting unit 17
3.3 Bed base 17
3.4 Motors 17
4. Annex (for authorised sales agents only)
4.1 General instructions 18
4.2 Maintenance instructions 18 / 19
Check list 20
Maintenance/safety check in accordance with § 6 of the
German Medical Device Operator Ordinance (MPBetreibV)

3
1. ASSEMBLY INSTRUCTIONS
Assembly must be performed only by trained specialist personnel. We recommend that assembly
be performed by two people, following these steps:
1.1 On the inside of the bed, there are stickers with arrows numbered from 1 to 4 (Fig. 1).
Arrange the side panels with the head and foot sections according to these numbers.
Screw the side panels to the head end and foot end according to the numbers, using the
enclosed flat head screws (8 x 60 mm) (Fig. 2).
Fig. 1 Fig. 2
1.2 Assembling the bed base.
STANDARD: Electric motor height adjustment,
manual head end and foot end adjustment.
The manual control unit and strain relief are pre-assembled.
Mount these components (Fig. 3) using the enclosed
flat head screws (6 x 50). Connect the cable of the
lifting motors to the control unit.
Then secure the protective cap to cover the connection plug.
Fig. 3
Placing and aligning the bed base in the bed frame.
OPTIONAL: Electric motor height adjustment,
electric motor head end and foot end adjustment.
The bed base and the inside of the head end are labelled with the words “head end” (Figs. 3 + 4).

4
Position the bed base in the bed frame according to the “head end” sticker (Fig. 5).
Connect the cable of the lifting motors to the double motor.
Fig. 3 Fig. 4 Fig. 5
1.3 Connect the cable to the bed base motor according to the symbol (Fig. 6):
No.: 1 Short-circuiting plug (pre-assembled)
No.: 2 “Foot end” lifting motor Anti-Trendelenburg
No.: 3 Manual control unit
No.: 4 “Head end” lifting motor Trendelenburg
(The plug for the “head end” lifting motor is also labelled with the no. 4
(Fig. 7).
Ensure that the “head end” lifting motor and the “foot end” lifting
motor are connected to the appropriate sockets.
No.: 5 Battery (pre-assembled)
Fig. 6 Fig. 7

5
1.4 Double motor cover
Secure the cover positioned over the connection
cables of the double motor. (Fig. 8).
When laying the cable, make sure that the cable
cannot be crushed or damaged!!! Fig. 9
Fig. 8
1.5 Installing the bed base
Place the bed base in the bed frame, align all of the
sides and screw to the supporting strips (using the
enclosed 5 x 90 mm wood screws) (Fig. 9).
Only for Trendelenburg/anti-Trendelenburg or fixed
upholstery.
Fig. 9
1.6 Trendelenburg positioning
The Trendelenburg + anti-Trendelenburg positions
can only be activated using the manual control unit with
locking system (Fig. 10).
Fig. 10
1.7 Power cable storage
The power cable can be hung on the bed
(Fig. 11).
Fig. 11

6
1.8 Transport casters
Caster, 100 mm, caster double stop.
To secure the lock, press the foot lever down. To release the lock,
pull the foot lever up (Fig. 12).
After moving or tilting the bed, all casters must be correctly
locked.
Fig. 12
In the Trendelenburg or anti-Trendelenburg position, the transport casters
may be locked at one end (either the head end or the foot end) only. When
moving to a tilted position, the casters at the opposite end are moved.
1.9 Moving side panels
A. Flaps (assembled)
The flaps on the long sides of the bed are locked by a patent
lock (Fig. 13).
Move the hand lever of the patent lock along the
groove to close or open the flap.
There are two patent locks on each flap.
Fig. 13
1.9 Moving side panels
B. Moving side panels
Remove the “blocks” from the guide groove. Insert the side rails evenly from above into the grooves (head end and
foot end) (Fig. 14).
Guide the side rails to the lowest position by simultaneously pressing the two locking mechanisms (Fig. 15). Reinsert
the “blocks”.
Fig. 14 Fig. 15

7
C. Doors
The four door units are numbered.
Screw the door units to the head end/foot end of the
bed frame according to the numbers using the enclosed
screws (M8 x 60 mm).
(Fig. 16).
Insert or remove spacers as required between the door unit and the head
end/foot end to achieve the correct clearance between the two door
units (7 mm).
Fig. 16
Adjusting the doors
It is possible to correct stiff or hanging doors using a size-3
Allen key by unscrewing the support foot in the outer door
hinges.
Together with a second person, pull the head end or foot end
outwards by hand and unscrew the support foot in a clockwise
direction until the desired dimension is achieved (Fig. 16.1).
Fig. 16.1
1.10 Tube posts
The tube posts are pre-assembled on the bed ends in the following models:
Flaps
Moving side panels
A spacer (Fig. 17) that can be
folded upwards (Fig. 17) is positioned
between the head end and the tube post.
Doors
The tube posts are attached to the door
units.
Fig. 17 Fig. 17.1
Manufacturer: FreiStil Tischlerei, Ruppenkampstraße 16, 49084 Osnabrück, Germany
Phone [phone], Fax [phone], [e-mail]

8
2. OPERATING INSTRUCTIONS
2.1 Intended use
The “JEREMIA” children’s therapeutic bed is designed for use in a home-care environment.
The medical treatment to be provided is the diagnosis, treatment and monitoring of illnesses under
medical supervision. It is only approved for one person and the safe working load (see type plate) must
not be exceeded. The bed should only be used within enclosed spaces and protected from excessive
moisture.
Use of the various adjustment functions can be carried out by the user by means of an IPX4 manual
control unit with closure (key)
- Manual and electric bed base adjustment
IPX4 manual control unit with closure (key) and separate locking function
- Trendelenburg/anti-Trendelenburg positioning
Make sure that the patient is always lying with their head at the “head end” of the bed.
All components of the bed must be used in accordance with the appropriate
intended use. Overloading causes damage and is not permitted.
2.2 Important information on operational safety
I. Setup and initial operation are performed by the sales agent. Prior to handing over the bed and
before each re-use, a functional check and a safety check must be performed. It must be ensured
that all functions are running smoothly, the power cable is routed correctly, and the bed base is
securely mounted in the bed frame. This also applies to any further operation of the children’s
therapeutic bed.
Incorrect routing of the power cable (e.g. kinks, shearing) may pose a serious risk to people
(electric shock).
II. The patient can weigh up to a maximum of 100 kg. Persons of any age with reduced mental
capacity are only permitted to use the system under supervision.
III. The lowest, horizontal setting of the bed frame is the safest and this is the only one that should
be used, unless another setting is required for therapy and treatment purposes.
Always lower the lifting unit to the lowest position afterwards.
IV. When adjusting the lifting unit, do not place any parts of the body
inside or underneath moving parts. There is a RISK OF CRUSHING.
V. The children’s therapeutic bed “JEREMIA” is intended for use only in dry
rooms and must only be operated and stored in dry rooms. The system must only be connected
to a conventional 230-volt socket. The cable and plug must be dry and must not be crushed or
abraded at any location. Make sure that all cables are routed and connected correctly at the
points provided.
VI. To prevent overloading and faults in the electric motors, a maximum switch-on time of two
minutes must not be exceeded.
The electric-powered adjustment of the head end and foot end must only be used to
lift and lower the upper body or legs (observe the position of the patient in the bed).
Overloading causes damage and is not permitted!
Overloading the mechanical components causes damage and is therefore not permitted.
(see operating instructions, item 2.3 + 2.4 and type plate)

9
VII. In the event of misuse, improper use, incorrect operation or incorrect assembly/repair, no
liability will be accepted. In such cases, all warranties are also excluded.
VIII. The drives must not be operated in the presence of flammable gases or vapours.
IX. The “JEREMIA” children’s therapeutic bed must only be operated with original accessories and
maintained using original parts.
X. If any malfunctions occur, inform your sales agent immediately.
In particular, disconnect the power and do not operate the device in the event of
damage to electrical or mechanical parts.
XI. Avoid the improper routing of electrical cables for other devices in the bed for medical
use. Risk of crushing between moving parts of the bed.
2.3 Warning notices
I. Patient transport permitted only in the lowest, horizontal position of the lifting unit.
II. If the patient is not supervised, the bed frame must be moved to its lowest, horizontal position.
The moving side flaps must be locked.
III. Do not leave anything in the bed that could be used to climb on or that may result in a risk of
suffocation or strangulation.
IV. Only trained persons or the nursing staff are permitted to adjust the lifting unit.
The patient themselves must not adjust the bed.
When the patient is left alone, all functions must be disabled.
V. The patient’s clinical condition may cause them to become trapped.
VI. Take care when opening and closing the moving side panels.
RISK OF CRUSHING! Open and close only under supervision.
VII. The “JEREMIA” children’s therapeutic bed must only be used on a flat, horizontal and solid
surface.
VIII. Only use in dry rooms.
IX. Do not position the bed in the vicinity of open flames or other strong sources of heat (e.g.
electric radiant heaters, gas ovens etc.).
X. The maximum user load is 100 kg.
The safe working load is 170 kg, including accessories.
The electric motor adjustment function on the head end and foot end must only be used to lift
and lower the upper body or legs (ensure that the patient is correctly positioned in the bed).
XI. RISK OF CRUSHING when lowering the bed frame onto the lower cross beam.

10
2.4 Lifting unit
The lifting unit is used for the electrical lifting and lowering of the bed base.
The maximum user load is 100 kg.
The safe working load is 170 kg, including accessories.
Overloading causes damage and is not permitted.
The lifting unit must always travel to its end position (top + bottom).
2.5 Bed base
STANDARD: Electric motor height adjustment, manual
head end and foot end adjustment.
OPTIONAL: Electric motor height adjustment,
electric motor head end and foot end adjustment.
It is not advisable to move the back section and the foot end to the uppermost position at the
same time as this will be too restricted and uncomfortable for the
patient.
In the event of a power cut or a fault in the bed base motor,
the head end and foot end of the bed base and the lifting
motors of the bed can be moved down using battery power
(Fig. 18).
If the bed is to be left unused for an extended period of
time, disconnect the battery plug from the control unit!
Fig. 18
2.6 Manual control unit
The manual control unit is used to control all electrical functions. The height adjustment and
the bed base adjustment are marked by appropriate symbols. Press lightly on the appropriate
button to move the system to the desired position.
Make sure that the manual control unit cable does not become crushed
during the adjustment. To prevent malfunctions, hang the manual control
unit on the edge of the bed when not in use, with the keypad facing outwards.
The locking key is a safety element that prevents unauthorised use of the
manual control unit and must therefore always be kept in a separate place.
The following pages shown the key assignments and function diagrams for the various manual control
units.

11
2.6 Assignment of keys
Example:1
Manual control unit for manual head and foot end adjustment
The manual control unit is used to control all electrical functions. Height adjustment is indicated
by corresponding symbols. Press lightly on the appropriate button to move the system to the
desired position.
Make sure that the manual control unit cable does not become crushed during the
adjustment. To prevent malfunctions, hang the manual control unit on the edge of the
bed when not in use, with the keypad facing outwards.
The lock for enabling and disabling the function keys is located on the back of the manual control
unit (Fig. 18.1). Turn the key to enable and disable the manual control unit. The arrow indicates the
relevant position.
The key is a safety element that prevents unauthorised use of the manual control unit and must
therefore always be kept in a separate place.
Button assignment on the manual control unit (Fig. 18.1):
1. Control panel
Lifting motor (bed base) up/down (left/right)
Fig. 18.1

12
Assignment of keys
Example: 2
IPROXX SE manual
control unit with 8
positioning keys
Electric motor head and
foot end adjustment
Accessories
Function
LED
Back rest
Foot end
Reset
Height
adjustment
Rear of IPROXX 2/SM manual control unit
AKey
CManual control unit keys locked
BManual control unit keys unlocked

13
Assignment of keys
Example: 3
IPROXX SE manual control unit with 10 positioning keys
Trendelenburg/anti-Trendelenburg positioning
Accessories
Function LED
Back rest
Foot end
Reset
Back rest +
foot end
Height
adjustment
Trendelenburg
Anti-
Trendelenburg
As the Trendelenburg position depends on the clinical indications, it may only be used
under the instruction of a doctor!!!
Rear of IPROXX 2/SM manual control unit
AKey
DManual control unit keys locked
BManual control unit keys unlocked
CUnlocked functions for patient

14
2.7 Moving side panels
A. Flaps (mounted)
The flaps on the long sides of the bed are locked by a
patent lock (Fig. 19).
Move the hand lever of the patent lock along the groove to
close or open the flap.
There are two patent locks on each flap.
Fig. 19
B. Moving side panels
To adjust the side rails, press both locking mechanisms
simultaneously. In each case, insert the index finger into
each round opening and the middle and ring fingers into the
corresponding grip plate below the round opening
(Fig. 20).
Press with your index finger toward the centre of
the bed, releasing the lock.
Then stop applying pressure to the mechanism with
your index finger; the side rail runs “free” to the
next locking socket.
Fig. 20

15
C. Doors
The four door units are numbered.
The outer doors are secured/opened using a patent lock
(Fig. 21). The middle doors are locked using a simple
patent lock. Move the hand lever of the patent lock along
the groove to close or open the door (Fig. 22). There are
two patent locks at the bottom and one at the top.
Fig. 21
Fig. 22
Adjusting the doors
It is possible to correct stiff or hanging doors using a size-3
Allen key by unscrewing the support foot in the outer door
hinges. Together with a second person, pull the head end or
foot end outwards by hand and unscrew the support foot in a
clockwise direction until the desired dimension is achieved
(Fig. 22.1).
Fig. 22.1

16
2.8 Transport casters
Caster, 100 x 30 mm, caster double stop.
To secure the lock, press the foot lever down. To release the
lock, pull the foot lever up (Fig. 23).
After moving the bed, all wheels must be correctly locked!
Fig. 23
In the Trendelenburg or anti-Trendelenburg position, the transport casters may be locked at
one end (either the head end or the foot end) only. When moving to a tilted position, the
casters at the opposite end are moved.
2.9 Cleaning, maintenance and reuse
The surfaces are smooth so that they are easier to clean and disinfect. Neither the electrical
system nor the bed frame are suitable for high-pressure cleaners. To clean, use a damp cloth with
a small amount of neutral soap then wipe until dry.
It is possible to disinfect the bed with conventional disinfectant.
Once the bed has been cleaned, disinfected and maintained, it can be used again.
Maintenance must only be performed by authorised persons. For information on maintenance,
safety checks and inspection intervals, see item 4 of the “ANNEX” to the operating instructions.
Spare parts lists can be obtained from the manufacturer!
2.10 Accessories
Accessory lists can be obtained from the manufacturer.
2.11 Symbols
Protection class II
For use in dry rooms only
Risk of crushing
Important information in the operating instructions
Type B applied part
Manufacturer: FreiStil Tischlerei, Ruppenkampstraße 16, 49084 Osnabrück, Germany
Phone [phone], Fax [phone], [e-mail]

17
3. TECHNICAL DATA
3.1 Bed frame
External dimensions: 1,072 x 2,320 mm
872 x 2,020 mm
Bed base: 1,000 x 2,000 mm
800 x 1,700 mm
Bed height: JEREMIA 1 950 –1,450 mm
JEREMIA 68 1,220 –1,720 mm
JEREMIA Vario 1,220 –1,720 mm
OK mattress 500 –1,000 mm
Side panels: JEREMIA 1 400 mm
JEREMIA 68 680 mm
JEREMIA Vario Front 600 + Rear wall 683 mm
Weight of bed frame + lifting unit approx. 165 / 168 / 160 kg
Weight JEREMIA 1 / JEREMIA 68 / JEREMIA Vario
Head end and foot end 72 / 80 / 80 kg
Bed sides 28 kg
Rear frame 0 / 13 / 13 kg
Front long side JEREMIA 1: Flaps / doors / adjustable 14 / 18 / 20 kg
JEREMIA 68 18 kg
JEREMIA Vario 10 kg
Total weight of bed frame: approx. 136 / 139 / 131 kg
Mattress Standard: Cold foam RG40, 12 cm, approx. 7 kg
3.2 Lifting unit: Rose + Krieger/Multilift
Dimensions 695 x 260 x 48 mm (L x W x H)
Weight approx. 10 kg
Travel 500 mm
Hoist power 2 x 1,000 N
3.3 Bed base: Rinovaflex “VARUS”
Bed base 99 x 196 cm
Division 2- / 4-part
Weight VARUS KF / VARUS EL approx. 12 / 15 kg
User load 100 kg
Safe working load 170 kg
3.4 Motors: Dewert –Duomat 7 Care
Mains voltage / frequency 230 VAC / 50 Hz
Motors voltage 2 x 12 VDC
Protection class II
Nominal rating Intermittent duty 2 min. / ON 18 min., OFF
Sound power level <= 65 dB (A)
Subject to technical modifications!!!

18
4. ANNEX
4.1 General instructions
- Maintenance/safety checks must only be carried out by persons with the
appropriate qualifications.
- All other laws and DGUV regulation 3 remain unaffected.
- Repair of all electrical components must be carried out exclusively by persons
authorised by the motor manufacturer.
-Inspection intervals:
When the bed is first put into use and every time it is re-used.
Maintenance/safety check once a year or every 12 months.
Visual and function check of all mechanical + electrical parts.
Electrical inspection in accordance with DIN EN ISO 62353.
- Inspections performed as part of the scheduled maintenance work can be
performed on the installed system (at site of installation). All other repairs must
be performed at a suitable place of work.
- Only the installation of original parts is permitted. The use of self-made parts will
cancel all liability and warranty obligations on the part of the manufacturer.
Spare parts lists can be obtained from the manufacturer.
- System modifications and additions require the manufacturer’s written approval.
- Complete functional checks must be performed after all maintenance and
repairs. Make sure that there are no collisions between moving parts so that
there are no hazards for patients or third parties and no damage to materials.
- Instructions and a check list form are provided below so that you can document
your work.
4.2 Maintenance instructions
The bed must undergo maintenance at least once a year or every 12 months. Only trained
technical personnel from the operating company or manufacturer are authorised to
perform this work. If there are any deviations from the requirements specified below, the
bed must be taken out of service and repaired if the limitations are safety-related.
Complete the check list (Annex) for every maintenance inspection.
- Perform a visual inspection of all the parts on the bed base (slatted frame).
If you discover any damage, these parts must be repaired or replaced immediately.
Check that the moving parts are moving freely, and lightly apply grease if necessary.

19
- Check all pinned fittings, screw joints, rivets and welding seams. There must be no cracks or
deformation and no individual parts of the joint must be missing (e.g. circlip, nut etc.).
- Perform a visual inspection of all parts of the bed:
head end and foot end/bed sides/rear wall/doors/adjustable side rails.
- Check that the locking mechanisms for the flaps/doors/adjustable side rails are working
correctly and moving freely.
- Check that the brake wheels of the bed are working correctly. The moving and braking
functions must be working correctly.
- For electrically adjustable beds, perform a visual and functional check of the drives. These
are subject to wear. If any of the following are observed, the affected drive is damaged and
must be replaced immediately: significant heat generation, significant noise, grinding or
squeaking noises, metal or plastic chips on or under the motor, restricted adjustment
range, unresponsive limit switches or drives that are slower than usual.
- For electrically adjustable beds, check the power cable and all cable routing for damage,
kinks and shear points, and check that cables are routed securely.
Caution: If the power cable or power plug are damaged, they must be replaced
immediately. If any damage is discovered, the bed must be taken out of use immediately.
- For electrically adjustable beds, check that the manual control unit is working correctly and
has no external damage.
Check the bed on a regular basis every time it is used to ensure it is working correctly. Please
correct any loose connections immediately using the appropriate tool.
If a product has any faults whatsoever, it must be taken out of use immediately.
Manufacturer: FreiStil Tischlerei, Ruppenkampstraße 16, 49084 Osnabrück, Germany
Phone [phone], Fax [phone], [email protected]

20
Maintenance/safety check in accordance with § 6 of the German Medical Device
Operator Ordinance (MPBetreibV)
This form is available to download from our website.
www.freistil.com
