Friedrich CP Line CP08 User manual

ENGLISH FRANÇAIS ESPAÑOL
Room Air Conditioner
Installation and Operation
Manual
MODEL NUMBER SERIAL NUMBER PURCHASE DATE
CP Line
920-151-00 (7-05)
CP08 ZQ08 ZQ10115 Volts
Registering Your Room Air Conditioner
Model information can be found on the name plate located on the
side of the unit near the control panel. Please complete and mail
the owner registration card furnished with this product or register
on-line at www.friedrich.com (USA only). For your future
convenience, record the model information here.
1

2

ENGLISH
Table of Contents
Introduction ..................................................................................2
Safety Precautions.......................................................................3
How to operate your Friedrich ...................................................5
Adjusting the Air Flow Direction.................................................7
Care and Maintenance.................................................................8
Hardware Location.......................................................................9
Installation Instructions ........................................................ 15
Troubleshooting Tips.................................................................17
Warranty......................................................................................18
How to operate your Friedrich ZStar ......................................6
Congratulations!
You have purchased a Friedrich
room air conditioner. The Friedrich
units are designed to give maximum
comfort and quietness.
3

Before Operating Your Unit
Make sure the wiring is adequate for your unit.
If you have fuses, they should be of the time delay type. Before you install or relocate this unit, be sure that
the amperage rating of the circuit breaker or time delay fuse does not exceed the amp rating listed in figure 1.
DO NOT use an extension cord.
The cord provided will carry the proper amount of electrical power to the unit; an extension cord will not.
Make sure that the receptacle is compatible with the wall plug provided.
This insures proper grounding. If you have a two-prong receptacle you will need to have the circuit replaced
by a certified electrician with a grounded circuit that meets all national and local codes and ordinances. You
must use the three-prong plug furnished with the air conditioner.
Figure 1
For the Best Cooling Performance and Energy Efficiency
Keep the filter clean
Make sure that your air conditioner is always in top performing condition by cleaning the filter regularly.
Instructions for removing and cleaning the filter can be found on page 8.
Provide good airflow
Make sure that the airflow to and from the unit is clear. Your air conditioner puts the air out at the top of
the unit, and takes in air at the bottom. Airflow is critical for good operation. It is just as important on the
outside of the building that the airflow around the unit exterior is not blocked.
Unit Placement
If your air conditioner can be placed in a window or a wall that is shaded by a tree or another building, the
unit will operate even more efficiently. Using drapes or blinds on the sunny side of the dwelling will also
add to your unit's efficiency.
Insulation
Good insulation will be a big help in maintaining desirable comfort levels. Doors should have weather
stripping. Be sure to caulk around doors and windows.
2
Introduction
MODEL
AMP VOLT NEMA NO.
15 125 5-15P
CIRCUIT
RATING OR
TIME DELAY
FUSE
PLUG FACE
CP08 ZQ08 ZQ10
4

ENGLISH
3
Safety Precautions
To prevent injury and property damage, follow these instructions.
■Incorrect operation due to ignoring of instruction can cause harm or damage. The seriousness is classified
by the following indications.
WARNING This symbol indicates the possibility of death or serious injury.
CAUTION This symbol indicates the possibility of injury or damage to
properties only.
■Meanings of symbols used in this manual are as shown below.
Never Do This
Always Do This
WARNING
Plug in the power plug
properly.
• Otherwise, it will cause electric
shock or fire due to heat
generation.
Do not operate or stop the
unit by inserting or pulling
out the power plug.
• It will cause electric shock or fire
due to heat generation.
Do not damage or use an
unspecified power cord.
• It will cause electric shock or fire.
• If the power cord is damaged, it must
be replaced by the manufacturer or a
Friedrich-certified service agent.
Do not modify power cord
length.
• It will cause electric shock or fire
due to heat generation.
Do not operate with wet
hands or in damp
environment.
• It will cause electric shock.
Do not direct air flow directly
at room occupants.
• This could lead to health problems .
5

4
TIMEMODETEMPPOWER
FAN
SPEED
TIMEMODETEMPPOWER
FAN
SPEED
Sharp
edges
When the air filter is to be
removed, do not touch the
metal parts of the unit.
•They are sharp and may cause
an injury.
Do not clean the air
conditioner with water.
•Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
When the unit is to be
cleaned, switch the unit off,
and unplug it.
•Since the fan rotates at high
speed during operation, it may
cause an injury.
Do not operate the unit
without the air filter or when
the front intake grille has
been removed.
•It could cause dust to
accumulate on the heat
exchanger.
Do not put a pet or house
plant where it will be
exposed to direct air flow.
•This could injure the pets
or plants.
Do not use for special
purposes.
•Do not use this air conditioner to
preserve precision devices, food,
pets, plants, and art objects.
It may cause deterioration of
quality, etc.
Do not operate switches
with wet hands .
•It may cause an electric shock.
Do not apply an insecticide
or flammable spray.
•It may cause a fire or
deformation of the cabinet.
SHARP EDGES!
The edges of the case can
be SHARP!
•Use caution when handling the
case. Grip it firmly and do not allow
it to slip while holding it.
• Use heavy gloves to handle
the case if necessary.
• DO NOT
allow the
case to slide
against
your skin!
6

ENGLISH
5
How to operate your Friedrich
Power
Temp
Fan Speed
Timer Mode
1
2
3
4
5
1
2
453
6
Control and Remote Control Operations
1. POWER
Operation begins when this button is pressed
and stops when you press the button again.
2. TEMPERATURE CONTROL
The thermostat monitors room temperature
to maintain the desired temperature.
The thermostat can be set between
60°F~86°F (16°C~30°C).
The unit takes an average of 30 minutes to
adjust the room temperature by 1°F.
3. OPERATION MODE SELECTOR
Select cooling mode to cool the room.
Select Money Saver®mode for energy
saving operation.
Select fan mode for basic ventilating fan
operation.
Select dry mode for dry operation.
4. FAN SPEED SELECTOR
For increased power while cooling, select a
higher fan speed.
3 steps: High; Low; Med
5. ON/OFF TIMER
The timer can be set to start and stop the
unit in hourly increments (up to 12 hours).
6. REMOTE CONTROL SENSOR
Inserting the Remote Control Batteries
1. Push out the cover on the back
of the remote control with your
thumb
2. Pay attention to polarity and
insert two new AAA 1.5V
batteries.
3. Reattach the cover.
NOTE: Do not use rechargeable batteries. Make sure that
both batteries are new.
•In order to prevent discharge, remove the batteries from
the remote control if the air conditioner is not going to be
used for an extended period of time
Keep the remote control away from extremely hot or
humid places.
To maintain optimal operation of the remote control, the
remote sensor should not be exposed to direct sunlight.
•The remote control can be mounted on a wall using the
mountable holder.(Friedrich does not provide this.)
7

6
How to operate your Friedrich ZStar®
Function Controls
When the air conditioner has finished cooling the room and is turned off or set to the fan
position, wait at least 3 minutes before resetting to the cooling operation again.
CAUTION
HIGH
COOL
HIGH
COOL
MED
FAN
MED
FAN
LOW
FAN
LOW
FAN
LOW COOLLOW COOL
MED
COOL
MED
COOL
1199
88
22
77
33
66
4455
Off - Turns air conditioner off.
Med Fan - Med speed fan operation without cooling.
Low Fan - Low speed fan operation without cooling.
High Cool - Cooling with high speed fan operation.
Med Cool - Cooling with med speed fan operation.
Low Cool - Cooling with low speed fan operation.
This automatically controls the temperature of the indoor air.
Turn the knob so that arrow points to the higher number for greater cooling.
Point the arrow to the lower number for more moderate cooling.
(i.e. the higher the number, the greater the cooling)
• FOR NORMAL COOLING
1. Turn the operation switch to the High Cool or the Low Cool setting.
2. Set the Thermostat control to the desired temperature mark 5(the mid-point is a good starting position).
If the room temperature is not satisfactory after a reasonable time, adjust the control to a cooler or warmer
setting, as appropriate.
• FOR MAXIMUM COOLING
1. Turn the Operation Knob to the High Cool setting.
2. Set the Thermostat control to the largest (9) temperature mark.
• FOR QUIETER OPERATION
1. Turn the Operation Knob to the Low Cool setting.
2. Set the Thermostat control as needed.
8

7
VENTCLOSE OPEN Part
A
Adjusting the Air Flow Direction
Vent Control
For maximum cooling efficiency, CLOSE the vent. This will allow internal air circulation.
OPEN the vent to discharge stale air.
NOTE : Before using the ventilation feature, position
the vent lever by pulling Part A out straight
and snapping it into place.
Adjusting the Air Flow Direction
Airflow can be adjusted by changing the direction of the air conditioner's louvers.
• Adjusting Horizontal Air Flow Direction
Adjusting the vertical louvers left and right will
change horizontal airflow.
• Adjusting Vertical Air Flow Direction
Adjusting the horizontal louver up and down will
change vertical airflow. The louver can be
adjusted by pressing in at the top or button of the
horizontal louver.
Adjusting horizontal air flow Adjusting vertical air flow
• Recommended orientation of louvers
Adjust louvers to face upwards when cooling to maximize cooling efficiency.
ENGLISH
9

8
Drain pipe
Drain cap
Care and Maintenance
Turn the power off and unplug the power plug before cleaning the air conditioner.
Air Filter
The air filter behind the inlet grille should be checked and cleaned at least once every 2 weeks (or as
necessary) to maintain optimal performance of the air conditioner.
How to remove the air filter
1. The grille may be opened from the top for easy
maintenance after installation.
2. Open the inlet grille by pulling out on the exposed
door on the top of the unit (based on installation).
3. Pull the tab slightly to release the filter. Pull the
filter in the same direction as the opening.
4. Clean the filter with warm, soapy water.
5. Rinse off and gently shake off excess water from
the filter. Make sure filter is completely dry before
replacing it.
Drainage
The base pan may overflow due to high humidity. To drain
the excess water, remove the drain cap from the back of
the unit and secure the drainpipe.
When pressing the drainpipe into place, apply force in the
direction away from the fins to avoid injuring yourself.
10
