Frigidaire FAH105N2 User manual

Product No. FAH105N2T
Series TTW/Builder
Volts 230/208
BTU-Cooling 10000 BTU
Owner's Guide 309000856
Market North America
P40L2012.eps FAH105N2T.eps 309201101.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995412961
04/11/16
(EN/SERVICE/KC)
099
ROOM AIR
CONDITIONER
Model No.
FAH105N2
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995412961 FAH105N2T
11/04 2
RECOMMENDED SPARE PARTS

FAH105N2T Publication No: 5995412961
# Functional Parts 3 11/04
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
POS. NO PART NO. DESCRIPTION
1 5303303077 Strap, capacitor mtg.
2 # 5303306706 Capacitor, 370 V, 6+30 mfd
3 309636101 Screen, safety, wire mesh, cabinet rear
4 309629001 Partition, shroud, galv-steel
5 309335201 Baffle, air
6 # 309373601 Tube, suction
7 309203101 Support, control box
8 # 309201004 PC Board, power, 230 V
9 # 309373501 Tube, discharge
10 # 5304417604 Tube, process, cond. outlet
11 # 309632307 Evaporator
12 # 309373701 Tube, capillary, top
13 # 5304430632 Overload Protector
14 # 309202701 Compressor Assembly, w/electricals, & mtg grommets
15 # 309201302 PC Board, input/display, 115 V
16 # 309373801 Tube, capillary, bottom
17 309200201 Enclosure, input pcb, control panel
18 # 309330102 Tube, anti gurgle, bottom
19 # 309336101 Tube, anti gurgle, top
20 309201401 Overlay, control display
21 # 309343109 Power Cord, electric, 18 AWG, 230 V, type C
22 309632006 Base, compressor mt., with studs
23 309628705 Tray, evap base
24 # 309632507 Condenser
25 5308017123 Holder, thermistor clip, 3/8 inch, with seal
26 309205001 Clip, filter, deflector
27 309200101 Panel, front grille
28 # 309342611 Remote Control, transmitter, with batteries
29 309335001 Baffle, splash/motor
30 309628204 Filter, air, molded plastic, grey
31 309628104 Louver, vertical
32 309628004 Louver, horizontal
33 309324004 Link, vertical louver, with handle
34 309622901 Plate, scroll cover
35 309112101 Clamp, blower wheel mt, compression
36 309631701 Blower Wheel
37 309622801 Housing, blower scroll
38 309627401 Bulkhead
39 309111201 Grommet, wire protector
40 # 309647501 Motor, fan, 3 speed
41 # 309629102 Fan Blade
42 309200301 Control Box
43 309628901 Shroud, fan
44 309628802 Cover, fan, top
45 309628603 Trim, frame, side
46 309627504 Cabinet, wrapper
47 309628604 Trim, frame, top & bottom

Publication No: 5995412961 FAH105N2T
11/04 4
WIRING DIAGRAM
