Frigidaire FAS296P2A1 User manual

Product No. FAS294P2A1 FAS296P2A1
Series heavy duty heavy duty
Volts 230/208 230/208
BTU-Cooling 28500/28000 BTU 28500/28000 BTU
Wiring Diagram 81902546 81902546
Owner's Guide frig819042060en frig819042060en
Installation Instructions 819042102en 819042102en
Market North America North America
M40L0004.eps M40C0009.eps M40M0009.eps 81902546.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995437885
05/05/26
(EN/SERVICE/KC)
099
ROOM AIR
CONDITIONER
Model No.
FAS294P2A /
FAS296P2A
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995437885 FAS294P2A / FAS296P2A
05/05 2
CABINET, FRONT, CONTROLS

FAS294P2A / FAS296P2A Publication No: 5995437885
# Functional Parts 3 05/05
* Non-Illustrated Parts
CABINET, FRONT, CONTROLS
Model Index: AFAS294P2A (FAS294P2A1)
BFAS296P2A (FAS296P2A1)
POS. NO PART NO. DESCRIPTION
4 5304447780 A B Cover, ionizer
5 5304447944 A B Vent, fresh air, with lever
7 # 5304447782 A - Remote Control, transmitter
7 # 5304447883 - B Remote Control, transmitter
8A 5304448484 A B Front Assembly, complete panel, includes 8, 9, 10, 11, 12, 13, 14
8 5304447783 A B •Panel, front grille
9 5304447784 A B •Filter, air, plastic frame
10 5304447785 A B •Louver, horizontal
11 5304447786 A B •Clip, air vent
12 5304447787 A B •Frame, front assembly
13 5304447788 A B •Louver, vertical
14 5304447789 A B •Dial, louver adjuster
15 5304447790 A B Frame, shutter panel, LH
16 5304447792 A B Retainer, shutter lock
17 5304447793 A B Shutter, accordion panel, RH/LH
18 5304447794 A B Retainer, shutter mount, cabinet sides
19 5304447795 A B Rail, shutter track, top
20 5304447796 A B Cabinet, wrapper/sleeve
21 5304447797 A B Bracket, cab mounting
22 5304447798 A B Screw, cab leveling
23 5304447799 A B Bracket, angle, cab support
24 5304447791 A B Frame, shutter panel, RH
25 5304447800 A B Console, control cover
26 # 5304447801 A B PC Board, display/input
27 5304447949 A B Clip, cable clamp
28 5304447803 A B Cover, front plate, control box
29 # 5304447861 A B PC Board, control/power
30 5304447805 A B Control Box
31 # 5304447973 A B Capacitor, fan motor
32 # 5304447807 A B Sensor, temperature, evap/indoor
33 5304447808 A B Strap, capacitor mtg.
34 # 5304447964 A B Capacitor, run
35 # 5304447937 A B Transformer
36 # 5304447951 A B Power Cord, LCDI, with test/reset
37 # 5304447940 A B Ionizer, clean air

Publication No: 5995437885 FAS294P2A / FAS296P2A
05/05 4
COOLING & AIR FLOW SYSTEMS

FAS294P2A / FAS296P2A Publication No: 5995437885
# Functional Parts 5 05/05
* Non-Illustrated Parts
COOLING & AIR FLOW SYSTEMS
Model Index: AFAS294P2A (FAS294P2A1)
BFAS296P2A (FAS296P2A1)
POS. NO PART NO. DESCRIPTION
1 5304447972 A B Base, unit chassis
3 5304447963 A B Plug, drain
41 5304447813 A B Bulkhead, panel, left side
42 # 5304447974 A B Blower Wheel, centrifugal fan
43 5304447975 A B Scroll, blower housing, top
44 5304447816 A B Cover, blower scroll, top plate
45 # 5304447817 A B Shroud, fan housing
46 # 5304447976 A B Fan Blade, axial flow
47 # 5304447977 A B Motor, fan
48 5304447978 A B Bracket, fan motor mount
49 5304447979 A B Scroll, blower housing, bottom
50 5304447822 A B Bulkhead, panel, right side
51 # 5304447980 A B Evaporator
52 # 5304447981 A B Capillary Tube
53 # 5304447982 A B Compressor Assembly, w/electricals, drier, grommets
54 # 5304447983 A B Condenser
55 # 5304447984 A B Discharge Tube
56 # 5304447985 A B Suction Tube

Publication No: 5995437885 FAS294P2A / FAS296P2A
05/05 6
WIRING DIAGRAM
81902546
