Signature Features
Eortless™ Temperature
Control
Our air conditioners maintain the preset
room temperature, so you will remain
comfortable at all times.
Ready-Select™ Controls
Easily select options with the touch of a
button.
Eortless™ Clean Filter
Our anti-microbial filter cleans the air,
removing harmful bacteria.
Remote Control
Allows you to precisely control the
temperature and fan speed from across
the room.
Mini Compact
Air Conditioner
Product Dimensions
Height 12-1/2"
Width 18-1/2"
Depth 16-3/8"
More Easy-To-Use Features
Energy and Cost Savings
The unit operates at a low voltage –
conserving energy and saving you money.
Multi-Speed Fan
Features two different fan speeds, for
more cooling flexibility.
Sleep Mode
Quiet operation keeps you cool without
keeping you awake. Plus, Sleep Mode
gradually increases room temperature
after being activated.
Quickly Cools
Comfort Control Design
Easily control the direction of your cool
air, wherever your unit is.
Eortless™ Restart
Automatically resumes operating at its
previous settings when power is restored
to your unit.
Clean Filter Alert
Notifies you when your filter needs to be
cleaned.
Power Cord
Comes with an extra long three-prong
cord that makes extension cords
unnecessary.
SpaceWise® Adjustable Design
Optional Side Panels extend so you can
adjust your unit to fit your window.
24 Hour On/O Timer
ENERGY STAR®
Home Comfort
FRA065AT7
Performance
Cool
BTUs
6,000

Specifications
subject to change.
Performance
BTU (Cool)
Dehumidification (Pints / Hour)
Cool Area (Sq. Ft.)
Energy Eciency Ratio
Electrical
Volts
Amps (Cool)
Watts (Cool)
Length of Power Cord (Min. / Max.)
Plug Type (NEMA)*
Features
Electronic Controls
Fan Speeds (Cool / Fan)
Low Voltage Start-Up
Auto Cool Function
Energy Save
Sleep Mode
Filter Check
24 Hour On / O Timer
Clean Air Ionizer
Remote Control
Air CFM (High / Med / Low)
Air Direction Control
Fresh Air / Exhaust Vent / Closed
Filter Type
Filter Access
Slide-Out Chassis
Cabinet Louvers
Rear Grille
Window Mounting Kit
Certifications
ENERGY STAR®
Performance
Specifications
Refrigerant
Shipping Weight (Approx.)
Product Dimensions
A - Height
B - Width
C - Depth
Window Dimensions
D -Height (Min.)
E -Width (Min. / Max.)
14"
23" / 36"
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
*Plug Type (NEMA)
(A) 5-15P
Accessories information available
on the web at frigidaire.com
RAC Compact Models_Window
Frigidaire Baseline
C
B
A
E
D
12-1/2"
18-1/2"
16-3/8"
6,000
1.3
216
10.7
115
5.4
560
6' / 6.5'
LCDI (A)
Ready-Select™ Controls
3 / 3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Full-Function
176 / 153 / 123
8-Way
No / No / Yes
Antimicrobial Mesh
Tilt-Out
Yes
Pleated Quick Mount
Yes
AHAM
R410a
51 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FRA065AT7 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Home Comfort
FRA065AT7 Mini Compact Air Conditioner
