Frigidaire FEC30S7E User manual

FEC30S6A.eps CFEC30S7E1.eps MFEC30S7E1.eps 387621700-1.eps 387621700-
2.eps
Product No. FEC30S7EB1 FEC30S7EC1 FEC30S7ES1
Series 30" elec 30" elec 30" elec
Color black stainless white
Market North America North America North America
Wiring Diagram 387621700 387621700 387621700
Owner's Guide 318200628 318200628 318200628
Installation Instructions 318205403 318205403 318205403
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995532685
09/02/05
(EN/SERVICE/ECL)
377
30” ELECTRIC
COOKTOP
Model No.
FEC30S7E
This Publication Supersedes
Publication # 5995532628
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995532685 FEC30S7E
02/09 2
CONTROL PANEL

FEC30S7E Publication No: 5995532685
# Functional Parts 3 02/09
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEC30S7E (FEC30S7EB1)
BFEC30S7E (FEC30S7EC1)
CFEC30S7E (FEC30S7ES1)
POS. NO PART NO. DESCRIPTION
2 318196634 A B - Knob, control, black
2 318196633 - - C Knob, control, white
2A 318196631 A B - Knob, dual control, black
2A 318196630 - - C Knob, dual control, white
3 387316100 A B C Bushing, knob, sealing
4 387559700 A B C Bracket, support, switch mtg.
5 # 305458905 A B C Switch, surface element
5A # 305458904 A B C Switch, surface element, dual
7 319224001 A B C Screw, switch mtg., M4 x 7

Publication No: 5995532685 FEC30S7E
02/09 4
MAIN TOP/SURFACE UNITS

FEC30S7E Publication No: 5995532685
# Functional Parts 5 02/09
* Non-Illustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AFEC30S7E (FEC30S7EB1)
BFEC30S7E (FEC30S7EC1)
CFEC30S7E (FEC30S7ES1)
POS. NO PART NO. DESCRIPTION
1 305379396 A - - Maintop Assembly, glass/steel, black
1 305379394 - B - Maintop Assembly, glass/steel, black/stainless
1 305379395 - - C Maintop Assembly, glass/steel, white
6 387372900 A B C Spring, surface element
8 # 374063522 A B C Element, surface, 6", 1200W
9 # 305440405 A B C Element, surface, 6/9", 1200/2500W, dual
10 # 305440407 A B C Element, surface, 9", 2700W
11 # 387372700 A B C Light Assembly, indicator, hot surface
12 387558700 A B C Box, burner, inner
13 330447900 A B C Screw, B4, 2 x 9, 5
14 387683500 A B C Support, burner box
* 305351200 A B C Rivet, 3, 2 x 6
15 387627600 A B C Spacer, burner box, plastic
16 387559400 A B C Box, burner, outer
17 387174602 A B C Bracket, spring, cooktop mtg.
18 387627700 A B C Bracket, retainer, cooktop
* 305376102 A B C Screw
* 305309606 A B C Screw
19 387683300 A B C Bracket, surface element
* 305376101 A B C Screw, bracket, surface element
20 387727700 A B C Retainer, wiring
* # 318078564 A B C Box & wires assy
* # 387629100 A B C Harness, wiring, main
* 305452800 A B C Screw, ground

Publication No: 5995532685 FEC30S7E
02/09 6
WIRING DIAGRAM
387 6217 00 REV. B
Page 1
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATENCION: DESCONECTE LA ENERGIA ANTES DE REALIZAR EL MANTENIMIENTO DEL ELECTRODOMESTICO.
ATTENTION: COUPER LE COURANTAVANT D´EFFECTUER LA REPARATION.
BL - BLUE /AZUL / BLEU
BK - BLACK / NEGRO / NOIR
W - WHITE / BLANCO / BLANC
O - ORANGE / NARANJA / ORANGE
BR - BROWN / MORENO / BRUN
COLOR CODE / CODIGOS /
CODE COULEUR
G - GREEN / VERDE / VERT
SW. - SWITCH
INTERRUPTOR
INTERRUPTEUR
P. L. - PILOT LIGHT
LAMPARA PILOTO
LAMPE TEMOIN
R. F. - RIGHT FRONT
FRENTE DERECHO
AVANT DROIT
R. R. - RIGHT REAR
TRASERO DERECHO
ARRIERE DROIT
L. F. - LEFT FRONT
FRENTE IZQUIERDO
AVANT GAUCHE
L. R. - LEFT REAR
TRASERO IZQUIERDO
ARRIERE GAUCHE
R. C. - REAR CENTER
TRASERO CENTRO
ARRIERE CENTRE
L. C. - LEFT CENTER
CENTRO DE IZQUIERDO
CENTRE GAUCHE
H. S. - HOT SURFACE
SUPERFICIE CALIENTE
SURFACE CHAUDE
LEGEND 1 / LEYENDA 1 / LEGENDE 1
4(3) 2(1)
HS
LIMITER / LIMITADOR / LIMITEUR
E. G. O. / A. K. O.
1A 2A
1B 2B
LIMITER / LIMITADOR / LIMITEUR
CERAMASPEED / EIKA
CODE / CODIGO /
CODE STYLE / ESTILO / STYLE
CODE
1
2
3
4
5
6
GAUGE /
MEDIDA
16
20
10
12
14
16
TEMP.
CALIBRE
200°C
200°C
150°C
150°C
150°C
150°C
cUL
UL3122 or UL3135
UL3122 or UL3135
3321
3321
3321
3321
UL
3321
3321
3321
3321
NOTE: USE PAGE 2 FOR GAGE AND
WIRE COLOR.
NOTA: UTILIZAR LA PAGINA2 PARA EL
CALIBRE Y ELCOLOR DE LOS CABLES.
NOTE: UTILISER LA PAGE 2 POUR LE
CALIBRE ET LACOULEUR DU FIL.
***
*
*
***
***
R - RED / ROJO / ROUGE
MODEL WITH BRIDGE ELEMENT / MODELO Y ELEMENTO RADIANTE
SUPERIOR DE PUENTE / MODELE AVEC ELEMENT PONT
L2
R-6
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
UNIT /
ELEMENTO /
ELEMENT
4
P2
L1
BK-6
BL-2
*** ***
BK(BR)-1 BK(BR)-1
BK-2
BK-2
L. F. SW.
L. F.
R-6
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
UNIT /
ELEMENTO /
ELEMENT
4P2
SW.
BK-6
P12
BL-2
W-1 W-1
BK-2
BK-2
L. R. L. R. SW.
L. R.
UNIT /
ELEMENTO /
ELEMENT
L. C.
4aP2
SW.
BL-1
L. F.
P12
MODEL WITH DOUBLE ELEMENT / MODELO Y ELEMENTO DE DOBLE /
MODELE AVEC ELEMENT DOUBLE
L2
R-6
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
4
P2
L1
BK-6
BL-2
*** ***
BR-1 BR-1
BK(BL)-2
BK-2
SW.
L. F.
UNIT /
ELEMENTO /
ELEMENT
4aP2
SW.
BL-1
P12
OUTER / EXTERIOR / EXTERIEUR
INNER / INTERIOR / INTERIEUR
MODEL WITH 4 UNITS / MODOLO Y4 ELEMENTOS / MODELEAVEC 4 ELEMENTS
MODEL WITH REGULAR ELEMENT / MODELO Y ELEMENTO REGULARE /
MODELE AVEC ELEMENT REGULIER
L2
R-6
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
UNIT /
ELEMENTO /
ELEMENT
4P2
SW.
L1
BK-6
P12
BL-2
*** ***
BK(BL)-2
BK-2
SW.
SEE LEGEND 2 / VER LEYENDA 2 / VOIR LEGENDE 2
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
BK ON / EN / SUR L. F.
W
BK ON / EN / SUR R. R.
BR ON / EN / SUR R. F.
ON / EN / SUR L. R.
LEGEND 2 / LEYENDA 2 / LEGENDE 2
MODEL WITH 5 UNITS / MODOLO Y5 ELEMENTOS / MODELEAVEC 5 ELEMENTS
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
POSITION / POSICION / POSITION
BR ON / EN / SUR L. F.
W
BK ON / EN / SUR R. R.
BR ON / EN / SUR R. F.
ON / EN / SUR L. R.

FEC30S7E Publication No: 5995532685
# Functional Parts 7 02/09
* Non-Illustrated Parts
WIRING DIAGRAM
387 6217 00 REV. B
Page 2
MODEL WITH OTHERS / OTROS MODELOS / AUTRE MODELES MODEL WITH SIMMER SELECT / LOS MODELOS CON SELECTOR DE
HIRVEA FUEGO LENTO / MODELE AVEC SELECTEUR MIJOTANT
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATENCION: DESCONECTE LAENERGIA ANTES DE REALIZAR EL MANTENIMIENTO DELELECTRODOMESTICO.
ATTENTION: COUPER LE COURANTAVANT D´EFFECTUER LAREPARATION.
INSIDE
INTERIOR
INTERIEUR
L1
L2
GND
OUTSIDE
EXTERIOR
EXTERIEUR
BX
BK-3
R-3
G-3
INSIDE
INTERIOR
INTERIEUR
L1
L2
GND
OUTSIDE
EXTERIOR
EXTERIEUR
BX
BK-3
R-3
G-3
NW-4
BK-4
R-6
W-6
MODEL WITH REGULAR ELEMENTAND SELECTOR / MODELO Y ELEMENTO Y SELECTOR /
MODELE AVEC ELEMENT REGULIER ET SELECTEUR
SELECTOR /
SELECTOR /
SELECTEUR
A
B
2
NL2
R-6
O-6
SW.
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
UNIT /
ELEMENTO /
ELEMENT
4P2
SW.
L1
BK-5
P12
BL-2
MODEL WITH WARMING ELEMENT / MODELO Y ELEMENTO DE CALENTADOR /
MODELE AVEC ELEMENT RECHAUD
*** ******
BK-1 BK-1
BK-2
BK-2
L2
BK-2
P. L.
H. S.
BL-2
LIMITER /
LIMITADOR /
LIMITEUR
*
WARMING UNIT /
ELEMENTO DE CALENTADOR /
ELEMENT RECHAUD
4P2
SW.
L1
BL-2
P12
BL-2
*** ***
BK-2 BK-2
BK-2
BK-2
R. C. R. C. SW.
R. C.
REMARK: FOR CONNECTING THE PLATFORM SEE INSTALLATION SHEET OR USE AND CARE GUIDE.
NOTA: PARA CONECTAR LAPARRILLADE COCINAR, VER LA HOJADE INSTALACION O ELMANUAL DELUSUARIO.
REMARQUE: POUR BRANCHER LATABLE DE CUISSON VOIR LE FEUILLET D´ INSTALLATION OU LE MANUELD` UTILISATION ET D´ ENTRETIEN.
