Frigidaire FEC36S8H User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEC36S8HSA 3805642599011 WHITE U.S.A.
FEC36S8HBA 3805642599061 BLACK U.S.A.
ELECTRIC - COOKTOP
Model No.
FEC36S8H
©1999 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC COOKTOP
WIRING DIAGRAM # - 318047021
OWNER’S GUIDE # - 318200608
INSTALLATION SHEET # - 318064705
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995323903
990527
-EN/SERVICE
377
Gallery
WARMING ZONE

Publication No. FEC36S8H
5995323903
05/99 2
CONTROL PANEL
69
36A 36A
36C
36
36 74
74
74
51
16
54
54A
54A
54C 54
69A
LA9923G31

FEC36S8H Publication No.
5995323903
# = Functional Part 305/99
* = Non-Illustrated Part
CONTROL PANEL
A=FEC36S8H (FEC36S8HSA)
B=FEC36S8H (FEC36S8HBA)
POS. NO PART NO DESCRIPTION
16 318096320 A B Plate instrument mtg
36 318016300 AKnob-surface white
36 318016308 BKnob-surface black
36A 318016301 AKnob-surface white
36A 318016309 BKnob-surface black
36C 318016330 AKnob-surface white
36C 318016331 BKnob-surface black
51# 5303297484 A B Light-indicator,hot surface
54 # 318120505 A B Switch-surface unit,small
54A# 318078200 A B Switch surface unit
54C# 318078801 A B Switch-6” Element
69 5303323134 A B Screw, switch mtg. ,8-32 x 3/16
69A 5303305528 A B Screw, 8-32 X 1/4
74 5303321205 A B Bushing, (4)
*5303300265 A B Screw, 8-18 X ½ chrome
*5303323131 A B Screw, 8-32 X 7/16
*5303323140 A B Screw ground

FEC36S8H Publication No.
5995323903
05/99 4
MAINTOP/SURFACE UNITS
46
163
163
170
170
163
163
23
20
20
159
162
164
15A
15
52A
52
52D
52C
52B
15B
15D
15C
16
LA9923V34

FEC36S8SH Publication No.
5995323903
# = Functional Part 505/99
* = Non-Illustrated Part
A=FEC36S8H (FEC36S8HSA)
B=FEC36S8H (FEC36S8HBA)
POS. NO PART NO DESCRIPTION
15# 318178102 A B Element-surface, 1700W
15A# 318050201 A B Element-surface,1000/1900W
15B# 318178000 A B Element-surface, 700/2100W
15C# 318178103 A B Element-warmer
15D# 318178100 A B Element-surface, 1200W
16 318079324 A-Glass Maintop & frame assy
16 318079323 -BGlass Maintop & frame assy
20 318121902 A B Bracket
23 5303297401 A B Panel-access
46 318077221 A B Box-burner
52 318122008 A B Spring-element mtg
52A 318122009 A B Spring-element mtg
52B 318122007 A B Spring-element mtg
52C 318122004 A B Spring-element mtg
52D 318122006 A B Spring-element mtg
159 318125121 A B Deflector
162 318125200 A B Deflector
163 08007817 A B Spacer
164 318125301 A B Plate-connection
170 318124900 A B Support-thermal
* # 318078514 A B Box & wires assy
*5303323129 A B Screw, 8 X ¾
*5303323140 A B Screw ground
*08016432 A B Screw, 8-18 X 3/8
*5303300265 A B Screw, 8-18 X ½ chrome
MAINTOP/SURFACE UNITS

FEC36S8H Publication No.
5995323903
05/99 6
WIRING DIAGRAM
