Frigidaire GLEF378C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
GLEF378CBA GLEF378C Gallery black North America
GLEF378CQA GLEF378C Gallery bisque North America
GLEF378CSA GLEF378C Gallery white North America
Publication No.
5995386330
030221
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
GLEF378C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERVICE DATA SHEET - # 316218506
WIRING DIAGRAM - #316255178
OWNER’S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200

02/03 2
Publication No. GLEF378C
5995386330
BACKGUARD

# = Fast-moving Parts 3 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
A = GLEF378C (GLEF378CSA)
B = GLEF378C (GLEF378CBA)
C = GLEF378C (GLEF378CQA)
POS. NO PART NO DESCRIPTION
1 316239900 A B C Shield,backguard ,rear wall
13A# 316095500 A B C Switch,infinite ,drawer/zone ,warmer
14 316022500 A B C Light/Lamp,indicator ,125 V
15 316220214 A - - Support,backguard ,white ,RH
15 316220216 - B - Support,backguard ,black ,RH
15 316220218 - - C Support,backguard ,bisque ,RH
15A 316220215 A - - Support,backguard ,white ,LH
15A 316220217 - B - Support,backguard ,black ,LH
15A 316220219 - - C Support,backguard ,bisque ,LH
19 316233850 A - - Panel,backguard ,white
19 316233851 - B - Panel,backguard ,black
19 316233852 - - C Panel,backguard ,bisque
20 # 316207507 A B C Clock/Timer,electronic
20A 316220804 A - - Overlay,clock ,white
20A 316220805 - B - Overlay,clock ,black
20A 316220806 - - C Overlay,clock ,bisque
23 316220900 A B C Bracket,clock mtg
24 316246000 A - - Switch,rocker ,white ,oven light
24 # 316246001 - B - Switch,rocker ,black ,oven light
24 316246002 - - C Switch,rocker ,bisque ,oven light
24C# 316114000 A - - Switch,speed bake,white
24C# 316114002 - B - Switch,speed bake,black
24C# 316114004 - - C Switch,convection ,bisque
31 316223000 A - - Knob,control ,white
31 316223002 - B - Knob,black
31 316223003 - - C Knob,control ,bisque
46 316040201 A B C Lens,indicator light ,red
54 # 316021500 A B C Switch,infinite ,small element
54A# 316021501 A B C Switch,infinite ,large element
54B# 316238200 A B C Switch,infinite ,dual element
56 316234001 A - - Shield,backguard ,white ,inner
56 316234003 - B - Shield,backguard ,black ,inner
56 316234004 - - C Shield,backguard ,bisque ,inner
69 5303288565 A B C Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
BACKGUARD

02/03 4
Publication No. GLEF378C
5995386330
BODY

# = Fast-moving Parts 5 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
A = GLEF378C (GLEF378CSA)
B = GLEF378C (GLEF378CBA)
C = GLEF378C (GLEF378CQA)
POS. NO PART NO DESCRIPTION
1 316201300 A B C Back,main
3 316216402 A - - Panel,bodyside ,white ,RH
3 316216403 A - - Panel,bodyside ,white ,LH
3 316216404 - B - Panel,bodyside ,black ,RH
3 316216405 - B - Panel,bodyside ,black ,LH
3 316216406 - - C Panel,bodyside ,bisque ,RH
3 316216407 - - C Panel,bodyside ,bisque ,LH
3* 316021131 A - - Screw,bodyside ,8-18 X 11/16 ,white
3* 316021132 - B - Screw,bodyside ,8-18 X 11/16 ,black
3* 316021133 - - C Screw,bodyside ,8-18 X 11/16 ,bisque
5 316129200 A B C Screw,leveling ,plastic ,with stop
6 316067902 A B C Rack,oven
6A 316262900 A B C Rack,oven sump
7 316216500 A B C Hinge,oven door ,RH
7A 316216501 A B C Hinge,oven door ,LH
8 316201501 A B C Panel,sump ,oven bottom
9 316081900 A B C Pan,broiler
10 316082000 A B C Insert,broiler pan
12 # 316209901 A B C Switch,oven light/door
14 316116400 A B C Receptacle,oven light
15 5303013071 A B C Bulb/Lamp,oven light
16 08011086 A B C Lens,oven light ,glass
17 316087500 A B C Retainer,lens
18 # 316213900 A B C Latch,oven door
21 3014099 A B C Spacer,bodyside
25 3200848 A B C Shield,heat ,lower
26 316206300 A B C Support,chassis ,(2)
29 3051162 A B C Glide,drawer ,front
30 316217700 A B C Bracket,hinge ,RH ,main top
30A 316217701 A B C Bracket,hinge ,LH ,main top
37 # 316233900 A B C Probe,oven temp
41 316233400 A B C Cover,hinge cutout ,RH
41A 316233500 A B C Cover,hinge cutout ,LH
42 316206200 A B C Shield,wool ,lower
44 316246500 A B C Spacer,oven door
45 316234100 A B C Shield,wire ,vent tube
57 316081100 A B C Cover,access
58 316240300 A B C Insulation,oven bottom
58A 316047708 A B C Insulation,2" ,oven wrapper
58B 316240102 A B C Insulation,oven back
58C 316240400 A B C Insulation,oven sump
59 316208200 A B C Tube,oven vent ,lower
59A 316208302 A B C Tube,oven vent ,upper
59B 316247300 A B C Catalyst,oven vent ,ceramic
62 # 5303935061 A B C Terminal Block Kit
62* 316085600 A B C Insulator
62* 316205500 A B C Nut,hex flange ,3/8 10-32
63 316208500 A B C Plate,grounding strap
66 # 316203301 A B C Element,broil
67 # 316202200 A B C Element,bake
68 316203400 A B C Support,broil element
71 316015810 A B C Shield,rear wall ,galv steel
87 316081200 A B C Bracket,cable mtg
88 316203500 A B C Rod,auto latch
89 # 316137500 A B C Motor,latch
106 316026600 A B C Bracket,motor mtg
107 316026701 A B C Cover,fan
108# 316136300 A B C Motor,fan
109 316136400 A B C Blade,fan
110 316136500 A B C Washer,fan motor
111 316136600 A B C Nut,fan retainer
BODY

02/03 6
Publication No. GLEF378C
5995386330
BODY

# = Fast-moving Parts 7 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
A = GLEF378C (GLEF378CSA)
B = GLEF378C (GLEF378CBA)
C = GLEF378C (GLEF378CQA)
POS. NO PART NO DESCRIPTION
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template,anti-tip
170* 316116000 A B C Screw,concrete ,1.75" ,anti-tip brkt
* # 316253261 A B C Wiring Harness,main
* 316231800 A B C Cover,hole ,conv. element
* 5303305324 A - - Paint,touch-up ,white
* 5303305345 - B - Paint,touch-up ,black
* 5304414035 - - C Paint,touch-up ,bisque
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 A B C Screw,6-20 x 0.312
BODY

02/03 8
Publication No. GLEF378C
5995386330
TOP/DRAWER

# = Fast-moving Parts 9 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
A = GLEF378C (GLEF378CSA)
B = GLEF378C (GLEF378CBA)
C = GLEF378C (GLEF378CQA)
POS. NO PART NO DESCRIPTION
1 316011503 A B C Drawer
2 316231500 A B C Liner,drawer
4 316231305 A - - Panel,drawer ,white
4 316231306 - B - Panel,drawer ,black
4 316231309 - - C Panel,drawer ,bisque
7 3051163 A B C Glide,drawer ,rear
15 # 316010206 A B C Element,surface ,8" ,2200 W ,radiant
15A# 316010205 A B C Element,surface ,6" ,1200 W ,radiant
15B# 316224300 A B C Element,dual ,9"/6" ,surface ,2100W/700W,radiant
15C# 316098202 A B C Element,warmer zone ,100W
16 316251913 A - - Main Top Assy,glass/steel ,white
16 316251912 - B - Main Top Assy,glass/steel ,black
16 316251921 - - C Main Top Assy,glass/steel ,bisque
18 316235900 A B C Hinge,main top ,RH
18A 316235901 A B C Hinge,main top ,LH
26 316230200 A B C Channel,element support ,(2)
26A 316099200 A B C Bracket,chassis support ,rear
26B 316214200 A B C Bracket,chassis support ,front
52 316099400 A B C Clip,element mtg
* # 316253519 A B C Wiring Harness,surface element
* 316264000 A B C Cleaner,cooktop
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 A B C Screw,6-20 x 0.312
TOP/DRAWER

02/03 10
Publication No. GLEF378C
5995386330
DOOR

# = Fast-moving Parts 11 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
A = GLEF378C (GLEF378CSA)
B = GLEF378C (GLEF378CBA)
C = GLEF378C (GLEF378CQA)
POS. NO PART NO DESCRIPTION
3 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935191 - B - Trim kit-door,3 sided ,black ,w/tape and foil
3 5303935193 - - C Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - - Glass,door kit ,white ,outer ,w/foil tape
4 5303935200 - B - Glass,door kit ,black ,outer ,w/foil tape
4 5303935202 - - C Glass,door kit ,bisque ,outer ,w/foil tape
5 316237000 A B C Glass,oven door ,air wash
6 316222707 A B C Shield,wool ,oven door
7 316236700 A B C Insulation,oven door
8 316237100 A B C Glass,oven door ,clear ,heat barrier
9 316230605 A B C Liner,oven door
10 316001013 A B C Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10B 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 316230901 A B C Seal,oven door
14 316102207 A - C Foil,1.5" x 29" ,aluminum ,clear
14 316102208 - B - Foil,1.5" x 29" ,aluminum ,black
14A 316102202 A - C Foil,4" x 5.5" ,aluminum ,clear ,(2)
14A 316102205 - B - Foil,4" x 5.5" ,aluminum ,black ,(2)
15 316237201 A B C Bracket,glass support ,(2)
16 316117501 A B C Glass,oven door ,inner
17 316117701 A B C Spacer,door glass ,(2)
39 316203001 A - - Handle,door ,white
39 316203000 - B - Handle,door ,black
39 316203003 - - C Handle,door ,bisque
52 316201003 A - - Cap,door trim ,white
52 316201005 - B - Cap,door trim ,black
52 316201009 - - C Cap,door trim ,bisque
60B 316021110 A B C Screw,8-18 x 0.5 ,black
* 316221001 A B C Label,anti-tip
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
DOOR

02/03 12
Publication No. GLEF378C
5995386330
WIRING SCHEMATIC

# = Fast-moving Parts 13 02/03
* = Non-Illustrated Parts
GLEF378C Publication No.
5995386330
WIRING DIAGRAM
