Frontgate Holiday 9ft downswept douglas tree User manual

9ft DOWNSWEPT DOUGLAS TREE - ITEM #61439

10b.

PARTS LIST

A. BOTTOM

B. LOWER MIDDLE

C. UPPER MIDDLE

D. TOP

HARDWARE

A. TREE STAND QUANTITY 1 PC

B. 1/4” SCREWS FOR TREE STAND QUANTITY 7 PCS

C. POWER STRIP QUANTITY 1 PC

D. REMOTE CONTROL W/ RECEIVER QUANTITY 1 SET

SKU 61439 -

9ft DOWNSWEPT DOUGLAS TREE

6127 TIPS METAL STAND

UL 1700 LIGHTS

MAX DIAMETER 74”

NUMBER OF PERSONS

RECOMMENDED FOR

ASSEMBLY: 2

Step 1

Pull apart the legs of the stand so that they are “X” shaped.

Fasten the bottom screws to lock the stand into position.

Step 2

Insert the section (A) of the tree into the stand and tighten

screws on base to secure tree pole.

Step 3

Plug power strip into the remote control receiver. Then,

plug remote control receiver into wall outlet.

Step 4

To shape your tree start with the bottom most layer of

branches, with each branch start with the tips closest to the

pole and lift each tip up and out in alternating directions.

Repeat for each branch. It is recommended to shape section

(A) before adding section (B).

Step 5

Insert the section (B) of the tree into the section (A) of the

tree. Plug light set of section (A) and section (B) into the

power strip.

Step 6

Repeat step 4 for shaping.

Step 7

Insert the section (C) of the tree into section (B) of the tree.

Plug lights from section (C) into section (B).

Step 8

Repeat step 4 for shaping.

ASSEMBLY INSTRUCTIONS

Step 9

Insert section (D) of the tree into the section (C) of the tree.

Plug lights from (D) into section (C).

Step 10

To shape the top (D) section of the tree it will be necessary to

gently bend the branches downward to the desired angle before

shaping tips.

COLOR CODE ON PLUG

RED

BLUE

GREEN

BLACK

E. EXTRA BULBS AND FUSES QUANTITY EACH 18 PCS

9ft DOWNSWEPT DOUGLAS TREE - ITEM #61439

1. Light tree one section at a time as described in assembly instructions, so you can easily identify any bulbs that may be dislodged.

Push any loose bulbs back into their sockets.

2. Separate the branch tips to form a “V” shape and ﬂuff the needles. Make sure each tip is spread out and no two branches are

touching each other. For best access to branches, shape each section prior to adding the next section as described in the initial

assembly instructions. You may want to wear cotton gloves when ﬂufﬁng needles to avoid scratches and skin irritation.

3. Starting with the bottom row, position the branches parallel to the ﬂoor. Angle the tips slightly upward like they are growing

towards the sun. With each successive row, make the upward angle of the branches more pronounced. Position inner tips to hide

the center of the tree.

4. Arrange the uppermost section of the tree so that the tips are evenly spaced and pointing upward.

5. Step back and review the tree. Adjust branches and tips as neccessary to give the tree a fuller appearance (The tree may be shape

differently (upswept /downswept /etc.) pending on one’s preference.)

1. If entire tree lighting does not light, make sure power strip cords are securely inserted in a working wall outlet.

2. If an entire section of the tree does not light, please review following actions:

a. Check that all plugs within the tree are securely connected.

b. Check fuse in power strip to determine if it may need replacement. Caution: Note that a blown fuse indicates an electrical

overload or electrical short circuit. If the fuse is blown, unplug power strip from outlet. Also unplug any additional strings

or products may be attached to the power strip. Replace the fuse following manufacturer instructions with proper fuse

rating. If the replacement fuse blows, a short circuit may be present and the product should be discarded.

c. Check fuse in plug connection on end of each light string.(See section on replacing plug fuses in this document).

STORAGE TIPS

1. This is for decorative use only - do not immerse in water or expose to heat. Keep away from ﬁre.

2. Please use water only for cleaning purpose.

3. When not in use, store neatly in a cool, dry location protected from sun light.

4. When the remote control has malfunctioned, please remove the power strip from the receiver and plug the power strip directly into

the wall.

CARE & MAINTENANCE INSTRUCTION

THE FOLLOWING STEPS WILL HELP MAKE YOUR TREE LOOK MORE REALISTIC

TROUBLE SHOOTING TIPS

Step 1

Unplug all tree sections and unplug light(s) from power strips.-

Step 2

Remove section (D) from (C) and gently press branches

upward.

Step 3

Remove section (C) from (B) and hold upside down and

branches will fold toward the pole. It is recommended to

snuggly bind branches to the pole with a length of rope or

twine, This will allow for easy handling and storage.

Step 4

Repeat step 3 for section (B).

Step 5

Untighten screws on stand and remove stand from section (A).

Repeat step 3.

Step 6

Place all tree sections, power strips, remote, and tree stand in

original box and tape shut. Store tree in cool dry area, storage

area temperature should not exceed 100ºF.

3. If some individual lights do not light up, it may be due to becoming dislodged from the socket during assembly. Note those not

lit up; check for looseness and push any loose bulbs gently back into their socket. If they still do not light up, try a replacement

light bulb (supplied by manufacturer) and follow directions in section describing how to replace light bulbs.

When using electrical products, to avoid risk of ﬁre burns, personal injury and electrical shock, basic precautions should always be

followed as stated below:

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

1. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor

applications, connect the product to a Ground Fault Circuit interrupting (GFCI) outlet. If one is not provided, contact a qualiﬁed

electrician for proper installation.

2. This seasonal use product is not intended for permanent installation or use.

3. Do not mount or place near gas or electrical heaters, ﬁreplace, candles or other similar sources of heat.

4. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.

5. Do not let lamps rest on the supply cord or on any wire.

6. For your safety, unplug the product when leaving the house, when retiring for the night or if left unattended.

7. This is an electrical product – not a toy! To avoid risk of ﬁre, burns, personal injury and electric shock it should not be played

with or placed where small children can reach it.

8. Do not use this product for other than its intended use.

9. Do not hang ornaments or other objects from cord, wire or light string.

10. Do not close doors or windows on the product or extensions cords as this may damage the wire insulation.

11. Do not cover the product with cloth, paper or any material not part of the product when in use.

12. This product is equipped with push-in lamps. Do not twist the lamps.

13. This product employs overload protection (fuse). A blown fuse indicates an overload or short-circuit situation. If the fuse blows,

unplug the product from the outlet. Also unplug any additional strings or products that may be attached to the product. Replace

the fuse as per the user servicing instructions (follow product marking for proper fuse rating) and check the product. If the

replacement fuse blows, a short-circuit may be present and the product should be discarded.

14. Read and follow all instructions that are on the product or provided with the product.

CAUTION: To reduce the risk of ﬁre and electric shock:

a. Do not install on trees having needles, leaves or branch coverings of metal or materials which look like metal, and:

b. Do not mount or support strings in a manner that can cut or damage wire insulation.

TROUBLE SHOOTING TIPS (Cont.)

IMPORTANT BASIC SAFETY INSTRUCTIONS

TO REPLACE LIGHT BULBS

CAUTION: FIRST UNPLUG YOUR PRODUCT FROM ANY POWER SOURCE.

1. To reduce the risk of overheating, replace burned-out light bulbs promptly. Use only

2.5 volt light bulbs only.

2. Grasp plug and remove from the receptacle or any other electrical outlet device. Do not

unplug by pulling on the cord.

3. Pull the light bulb and its attached plastic base straight out of light bulb holder.

4. Replace light bulb with only 2.5 volt super bright type light (provided with product).

5. If the new lamp base does not ﬁt the replacement light bulb, follow the steps below

before step 4.

a. Remove the base of burned out light by straightening light leads and gently pull bulb out.

b. Thread metal leads of new lamp through hose in old base with one lead in each hold.

c. After lamp is fully inserted into base, bend each lead up, like other lights in the light set so that the leads will touch the

contacts inside the light socket.

TO REPLACE A FUSE:

CAUTION: FIRST UNPLUG YOUR PRODUCT FROM ANY POWER SOURCE.

1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug by

pulling on cord.

2. Open fuse cover. Slide open fuse access cover on top of attachment plug towards plug’s

metal prongs or blades.

3. Remove fuse carefully.

4. Risk of ﬁre. Replace fuse ONLY with 3 Amp 120 Volt fuse. (Provided with product).

5. Close fuse cover. Return the sliding fuse cover back to its former closed position on

attachment plug.

6. Risk of ﬁre. Do not replace attachment plug because it contains a safety device (fuse)

that should not be removed. Discard product if the attachment plug is damaged

Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484 or email [email protected].

Specialists are available weekdays 8:00 a.m. to 8:00 p.m. EST or Saturday 9:30 a.m. to 6:00 p.m.

OPEN

FUSE COVER

SLIDES FORWARD

3 AMP

120 VOLT

FUSES

PULL BULB UP

TO REMOVE

PUSH BULB DOWN

TO REPLACE

USER INSTRUCTIONS
