FROST NOVA2 N1933 Install guide

1
Ø28,00 mm
40,00 mm
25,00 mm
10,50 mm
2,00 mm
Shelf not included
Shelf Thickness: 6 - 10 mm
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
NOVA2
SHELF CLAMP
Exclusion of liability
FROST accepts no liability whatsoever
for damage to persons or property that
occurs or has occurred as a result of
improper installation or maintenance,
particularly if the safety instructions
and other points to note listed are not
or have not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents and serious injuries.
N1933
2 pcs. a set
4
2
N1933
Shelf not included
3
1

Cleaning and maintenance
Surfaces should be cleaned with a microbre cloth, glass
cleaner or other non abrasive and gentle agents.
Attention:
Never use solvents or aggressive household cleaners like
bleach, acids (e.g. descalers) or ammonia-based bathroom
cleaner to clean the product. Steel wool and hard brushes
can permanently damage the surfaceof the steel.
2
N1933 O1933
N1933-C N1933-GO
N1933-B N1933-w
SHELF CLAMP
4x 4x
D7.8 - DB3.5 - L40.5 D6 - H40
AB
4x 1x
CD
M5x5 2,5MM
4x
E
M8x8
1x
F
4,0 MM
Bavne Allé 6E
DK-8370 Hadsten
[phone]
[e-mail]
www.frost.dk
Material: Stainless steel, AISI 304
Design: Bønnelycke mdd
Manufacturer: FROST A/S
