FROST NOVA2 Install guide

TOILET ROLL HOLDER 9
Fitting instruction
NOVA2
Exclusion of liability
FROST accepts no liability whatsoever
for damage to persons or property that
occurs or has occurred as a result of
improper installation or maintenance,
particularly if the safety instructions and
other points to note listed are not or have
not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents and serious injuries.
TOILET ROLL HOLDER 9
Material: Stainless steel, AISI 304
Design: Bønnelycke mdd.
Manufacturer: FROST A/S, Bavne Alle 32,
DK-8370 Hadsten
www.frost.dk
O1972 N1972
N1972-C N1972-BOC
N1972-GO N1972-BMG
N1972-B N1972-BCB
N1972-W
Cleaning and maintenance
Stainless steel surfaces should be
cleaned with a micro bre cloth, glass
cleaner or other non abrasive and gentle
agents.
Attention
Never use solvents or aggressive house-
hold cleaners like bleach, acids (e.g.
descalers) or ammonia-based bathroom
cleaner to clean the product. Steel wool
and hard brushes can permanently
damage the surfaceof the steel.
Ø310 mm
15 mm
128 mm
10 mm
180 mm
124,8 mm
217 mm
WWW.FROST.DK 1
112 mm
11 mm
101,5 mm
R3,5 mm

1. 2. 3.
5. 6.7.
Use enclosed key to open. Mark placements of screw holes.
A
6x
Ø6 x 30
A
6x Ø6
2x
Ø4 x 30
B
B
Drill the marked holes and insert wall plugs.
4x
Ø4 x 30
B
B
WWW.FROST.DK 2
Jumbo Paper
Max diameter: Ø290 mm
Max projection: 100 mm
Paper isnot included and must
be purchaged from another
supplier.
Use 2 screws to secure the toilet roll holder on the wall.
Slide the toilet roll holder down for a thight fit.
Use the 4 last screws to fully secure the toilet roll holder. Insert the jumbo paper and close the front with
the enclosed key.
