FrSky X8R User manual



www.frskyrc.com

05/02/13



InstructionManualforFrSkyXJTModule

Introduction

ThankyouforpurchasingFrSkyXJTtelemetrymodule.Inordertofullyenjoythebenefitsofthissystem,pleasereadthe

instructionmanualcarefullyandsetupthedeviceasdescribedbelow.

Overview



Specifications

OperatingVoltageRange:3.7~15V

OperatingCurrent:180mA(@5V),120mA(@12V)

OutputPower:100mW

ModuleSlot:JR/GraupnerType

Modulations:PXXorCPPM(autodetected)

Modes:D8,D16orLR12(selectable)

TelemetryInterface:SmartPort,RS232SerialPort

UpgradeInterface:SmartPort,RS232SerialPort

What’sNew!

TwoautodetectedmodulationsofPXX(modeselection,bind,modelmatch,rangecheck,failsafe,etc.onradio

side)orCPPM.

ThreeselectablemodesofD8(existing8chtwoway),D16(new16chtwowayfullduplextransmission)andLR12

(new12choneway,approx.threetimesrangeofcurrentV8&DserieswhenpairingwithnewLRseriesreceivers,suchas

L9R).

SmartPortenabled,realizingtwowayfullduplextransmission.

Detectthemoduleantenna’sworkingstatusandgivesoundwarningsifthemoduleantennaisbrokenordoesnot

haveintactcontact,etc.

Superlowerlatency(approx.1/3ofcurrentsystems)andhigherprecision(transmitter’shardwareandsoftware

supportrequired,suchasFrSkytransmitters).



www.frskyrc.com

05/02/13



BindingProcedure

Bindingistheprocessofuniquelyassociatingaparticularreceivertoatransmittermodule.Atransmittermodulecanbe

boundtomultiplereceivers(nottobeusedsimultaneously).Areceivercanonlybeboundtoonetransmittermodule.

Followthestepsbelowtofinishthebindingprocedure.

1. TurnonthetransmitterwhileholdingtheF/SbuttonontheXJTmodule(seeModeandCompatibilitytable

above).Releasethebutton.TheREDLEDontheXJTmodulewillflash,indicatingthetransmitterisreadyto

bindtothereceiver.

2. ConnectthebatterytothereceiverwhileholdingtheF/Sbuttononthereceiver.TheREDLEDonthereceiver

willflash,indicatingthebindingprocessiscompleted(pleaserefertothecorrespondingreceiver’sinstruction

manualfordetails)

3. Turnoffboththetransmitterandthereceiver.

4. Turnonthetransmitterandconnectthebattery.TheREDLEDonthereceiverindicatesthereceiveris

receivingcommandsfromthetransmitter.Thereceiver/transmittermodulebindingwillnothavetobe

repeated,unlessoneofthetwoisreplaced.

Note:Afterbindingprocedureiscompleted,recyclethepowerandcheckifthereceiverisreallyundercontrolbylinked

transmitter.

RangeCheck

Apreflightrangecheckshouldbedonebeforeeachflyingsession.Reflectionsfromnearbymetalfences,concrete

buildingsortreescancauselossofsignalbothduringrangecheckandduringtheflight.



Followthestepsbelowtoperformtherangecheck.

1. Placethemodelatleast60cm(twofeet)abovenonmetalcontaminatedground(e.g.onawoodenbench).

2. Thereceiverantennasshouldbeseparatedinthemodel,anddonottouchtheground.

3. Themoduleantennashouldbeinaverticalposition.

4. Turnonthetransmitterandthereceiver,presstheF/SbuttonontheXJTmodulefor4secondstoenterrange

checkmode,theREDLEDwillbeoff,GREENLEDwillflashrapidly.Theeffectivedistancewillbedecreasedto

1/30offullrange.

5. Walkawayfromthemodelwhilesimultaneouslyoperatingthecontrolsonthetransmittertoconfirmall

controls’normaloperation(pleaserefertothecorrespondingreceiver’sinstructionmanualfordetails).

6. PresstheF/SbuttonontheXJTmodulefor1~4secondstoexitrangecheckmode,REDLEDwillbebackon,

indicatingnormaloperationisback.

SafeFlyingDistance

FrSkytelemetrysystemhasafeaturetoreturntheReceivedSignalStrengthIndication(RSSI)ofthereceivertothe

transmitter.Thetransmitterdevelopsaninternalvoltagerepresentingthereceiversignalstrength.Alarmsare

programmedinthetransmittertowarnthepilotwhenthemodelisnearingmaximumcontrolrange.Seethetablebelow

forreference.



NumberBeepAlarmingMeaning

0NoBeepThesignalstrengthisstrong

1SingleBeepThesignalstrengthisadequate

2ConstantdoubleBeepsThemodelisfar,butsaferange

3ConstanttripleBeepsThemodelinnearmaximumrange

ConstantBeepsThemoduleantennaisbroken,ordoesnothaveintactcontact,etc.



SmartPort(S.Port)isasignalwirefullduplexdigitaltransmissioninterfacedevelopedbyFrSkyElectronic

Co.,Ltd.AllproductsenabledwithSmartPort(includingXJTmodule,X8Rreceiver,newhublesssensors,newSmart

Dashboard,etc),serialportuserdataandotheruserinput/outputdevicescanbeconnectedwithoutlimitationsfor

numbersorsequencesatahightransmissionspeed.



www.frskyrc.com

05/02/13



FrSkyElectronicCo.,Ltd.

Tel:(86)51085187718Fax:(86)51085187728

Email:frsky@frskyrc.comTechnicalSupport:[email protected]



www.frskyrc.com

05/02/13



InstructionManualforFrSkyX8RReceiver

Introduction

ThankyouforpurchasingFrSkyX8R8/16chfullduplextelemetryreceiver.Inordertofullyenjoythebenefitsofthis

system,pleasereadtheinstructionmanualcarefullyandsetupthedeviceasdescribedbelow.

Overview



Specifications

Dimension:46.3x26.8x13.6mm(LxWxH)

Weight:14g

NumberofChannels:1~8chfromconventionalchanneloutputs,1~16chfromSBUSport

WithRSSIoutput:analogvoltageoutput(0~3.3V)

OperatingVoltageRange:3.0~10V

OperatingCurrent:100mA

OperatingRange:fullrange(>1.5km)

Compatibility:FrSkyXJTmoduleinD16mode(Switch1isOFF,Switch2isOFF)orD8mode(Switch1isOFF,Switch2is

ON),DFT/DJT/DHT/DHTUinD_mode

FirmwareUpgradeable

What’sNew!

Morenumberofchannels:1~8chfromconventionalchanneloutputs,1~16chfromSBUSport

WithRSSIoutput:analogvoltageoutput(0~3.3V)

SmartPortenabled,realizingtwowayfullduplextransmission.



BindingProcedure

Bindingistheprocessofuniquelyassociatingaparticularreceivertoatransmittermodule.Atransmittermodulecanbe

boundtomultiplereceivers(nottobeusedsimultaneously).Areceivercanonlybeboundtoonetransmittermodule.



SmartPort(S.Port)isasignalwirefullduplexdigitaltransmissioninterfacedevelopedbyFrSkyElectronic

Co.,Ltd.AllproductsenabledwithSmartPort(includingXJTmodule,X8Rreceiver,newhublesssensors,newSmart

Dashboard,etc),serialportuserdataandotheruserinput/outputdevicescanbeconnectedwithoutlimitationsfor

numbersorse

uencesatahi

htransmissions

eed.



www.frskyrc.com

05/02/13



Followthestepsbelowtofinishthebindingprocedure.

1.TurnonthetransmitterwhileholdingtheF/Sbuttononthemodule(pleaserefertothemoduleinstructionmanualfor

switchpositions).Releasethebutton.TheREDLEDontheXJTmodulewillflash,indicatingthetransmitterisreadytobind

tothereceiver.

2.ConnectthebatterytothereceiverwhileholdingtheF/Sbuttononthereceiver.TheREDLEDonthereceiverwillflash,

indicatingthebindingprocessiscompleted.

3.Turnoffboththetransmitterandthereceiver.

4.Turnonthetransmitterandconnectthebattery.TheREDLEDonthereceiverindicatesthereceiverisreceiving

commandsfromthetransmitter.Thereceiver/transmittermodulebindingwillnothavetoberepeated,unlessoneofthe

twoisreplaced.



Note:Afterbindingprocedureiscompleted,recyclethepowerandcheckifthereceiverisreallyundercontrolbylinked

transmitter.

RangeCheck

Apreflightrangecheckshouldbedonebeforeeachflyingsession.Reflectionsfromnearbymetalfences,concrete

buildingsortreescancauselossofsignalbothduringrangecheckandduringtheflight.Followthestepsbelowtoperform

therangecheck.

1.Placethemodelatleast60cm(twofeet)abovenonmetalcontaminatedground(e.g.onawoodenbench).

2.Thereceiverantennasshouldbeseparatedinthemodel,anddonottouchtheground.

3.Themoduleantennashouldbeinaverticalposition.

4.Turnonthetransmitterandthereceiver,presstheF/SbuttonontheXJTmodulefor4secondstoenterrangecheck

mode,theREDLEDwillbeoff,GREENLEDwillflashrapidly.Theeffectivedistancewillbedecreasedto1/30(atleast30m).

5.Walkawayfromthemodelwhilesimultaneouslyoperatingthecontrolsonthetransmittertoconfirmallcontrols’

normaloperation.

6.PresstheF/SbuttonontheXJTmodulefor1~4secondstoexitrangecheckmode,REDLEDwillbebackon,indicating

normaloperationisback.

Failsafe

Failsafeisausefulfeatureinwhichallcontrolsmovetoapresetpositionwheneverthecontrolsignalislostforaperiodof

time.X8Rsupportsfailsafefunctionforallchannels.Followthestepsbelowtosetfailsafepositionsforeachchannel:

1.Bindthereceiverfirstandturnonboththetransmitterandthereceiver;

2.Movethecontrolstothedesiredfailsafepositionforallchannels;

3.PressbrieflytheF/Sbuttononthereceiver(lessthan1second).TheGreenLEDwillflashtwice,indicatingthefailsafe

positionhasbeensetinthereceiver.

Todisablethefailsafefunction,rebindthereceiver.



Failsafeisrecommendedtosetwhensystemisfirstlyused,orreceiverhasbeenrebound.Followstepsbelowtoset

failsafe.



Option1.Howtosetfailsafetoauserdeterminedstateonlostsignal:

1)Bindthereceivertothetransmittermodulefirstandturnonboththetransmitterandthereceiver;

2)Movethecontrolstodesiredfailsafepositionforallchannels;

3)PressbrieflytheF/Sbuttononthereceiverandyouaredone.



Option2.Howtosetfailsafefornopulsesonlostsignal:

1)JustpressbrieflytheF/Sbuttononthereceiverwhilethetransmitterisoffandyouaredone.

Note:Iffailsafeisnotset,failsafedefaultwillholdlastpositionbeforesignalislost.Inthiscase,thereexistsriskthat

yourmodelwillflyawayorcauseinjury.



FrSkyElectronicCo.,Ltd.

Tel:(86)51085187718Fax:(86)51085187728

Email:frsky@frskyrc.comTechnicalSupport:[email protected]



www.frskyrc.com

05/02/13



InstructionManualforFrSkyL9RReceiver

Introduction

ThankyouforpurchasingFrSkyL9R9/12chlongrangenontelemetryreceiver.Inordertofullyenjoythebenefitsofthis

system,pleasereadtheinstructionmanualcarefullyandsetupthedeviceasdescribedbelow.

Overview



Specifications

Dimension:46.3x26.8x13.6mm(LxWxH)

Weight:14g

OperatingVoltageRange:3.0~10V

OperatingCurrent:70mA

NumberofChannels:1~9chfromconventionalchanneloutputs,1~12chfromSBUSport

WithRSSIoutput:analogvoltageoutput(0~3.3V)

OperatingRange:threetimesoftheoperatingrangeforV8orDseries

Compatibility:FrSkyXJTmoduleinLR12mode(Switch1isON,Switch2isOFF)

What’sNew!

Morenumberofchannels:1~9chfromconventionalchanneloutputs,1~12chfromSBUSport

WithRSSIoutput:analogvoltageoutput(0~3.3V)

Longeroperatingrange:threetimesoftheoperatingrangeforV8orDseries

BindingProcedure

Bindingistheprocessofuniquelyassociatingaparticularreceivertoatransmittermodule.Atransmittermodulecanbe

boundtomultiplereceivers(nottobeusedsimultaneously).Areceivercanonlybeboundtoonetransmittermodule.



Followthestepsbelowtofinishthebindingprocedure.

1.TurnonthetransmitterwhileholdingtheF/SbuttonontheXJTmodule(settoLR12mode,Switch1isONwhileSwitch

2isOFF).Releasethebutton.TheREDLEDontheXJTmodulewillflash,indicatingthetransmitterisreadytobindtothe

receiver.

2.ConnectthebatterytothereceiverwhileholdingtheF/Sbuttononthereceiver.TheREDLEDonthereceiverwillflash,

indicatingthebindingprocessiscompleted.

3.Turnoffboththetransmitterandthereceiver.

4.Turnonthetransmitterandconnectthebattery.TheREDLEDonthereceiverindicatesthereceiverisreceiving



www.frskyrc.com

05/02/13



commandsfromthetransmitter.Thereceiver/transmittermodulebindingwillnothavetoberepeated,unlessoneofthe

twoisreplaced.



Note:Afterbindingprocedureiscompleted,recyclethepowerandcheckifthereceiverisreallyundercontrolbylinked

transmitter.

RangeCheck

Apreflightrangecheckshouldbedonebeforeeachflyingsession.Reflectionsfromnearbymetalfences,concrete

buildingsortreescancauselossofsignalbothduringrangecheckandduringtheflight.



Followthestepsbelowtoperformtherangecheck.

1.Placethemodelatleast60cm(twofeet)abovenonmetalcontaminatedground(e.g.onawoodenbench).

2.Thereceiverantennasshouldbeseparatedinthemodel,anddonottouchtheground.

3.Themoduleantennashouldbeinaverticalposition.

4.Turnonthetransmitterandthereceiver,presstheF/SbuttonontheXJTmodulefor4secondstoenterrangecheck

mode,theREDLEDwillbeoff,GREENLEDwillflashrapidly.Theeffectivedistancewillbedecreasedto1/30.

5.Walkawayfromthemodelwhilesimultaneouslyoperatingthecontrolsonthetransmittertoconfirmallcontrols’

normaloperation.

6.PresstheF/SbuttonontheXJTmodulefor1~4secondstoexitrangecheckmode,REDLEDwillbebackon,indicating

normaloperationisback.



Failsafe

Failsafeisausefulfeatureinwhichallcontrolsmovetoapresetpositionwheneverthecontrolsignalislostforaperiodof

time.L9Rsupportsfailsafefunctionforallchannels.



Followthestepsbelowtosetfailsafepositionsforeachchannel:

1.Bindthereceiverfirstandturnonboththetransmitterandthereceiver;

2.Movethecontrolstothedesiredfailsafepositionforallchannels;

3.PressbrieflytheF/Sbuttononthereceiver(lessthan1second).TheGreenLEDwillflashtwice,indicatingthefailsafe

positionhasbeensetinthereceiver.

Todisablethefailsafefunction,rebindthereceiver.



Failsafeisrecommendedtosetwhensystemisfirstlyused,orreceiverhasbeenrebound.Followstepsbelowtoset

failsafe.



Option1.Howtosetfailsafetoauserdeterminedstateonlostsignal:

1)Bindthereceivertothetransmittermodulefirstandturnonboththetransmitterandthereceiver;

2)Movethecontrolstodesiredfailsafepositionforallchannels;

3)PressbrieflytheF/Sbuttononthereceiverandyouaredone.



Option2.Howtosetfailsafefornopulsesonlostsignal:

1)JustpressbrieflytheF/Sbuttononthereceiverwhilethetransmitterisoffandyouaredone.

Note:Iffailsafeisnotset,failsafedefaultwillholdlastpositionbeforesignalislost.Inthiscase,thereexistsriskthat

yourmodelwillflyawayorcauseinjury.



FrSkyElectronicCo.,Ltd.

Tel:(86)51085187718Fax:(86)51085187728

Email:frsky@frskyrc.comTechnicalSupport:[email protected]

Other manuals for X8R

This manual suits for next models

Table of contents

Other FrSky Measuring Instrument manuals

FrSky

FrSky FAS40 ADV User manual

FrSky

FrSky DHT-U User manual

FrSky

FrSky SMART PORT Airspeed ASS70 ADV User manual

FrSky

FrSky FAS40 ADV User manual

FrSky

FrSky FLD-02 User manual

Popular Measuring Instrument manuals by other brands

Suaoki

Suaoki D40 user manual

Elster

Elster BK-G1.6 operating instructions

Endress+Hauser

Endress+Hauser Deltabar FMD71 technical information

Duratool

Duratool D03128 manual

Vega

Vega VEGAPULS 65 Quick setup guide

Tonghui

Tonghui TH2618B Operation manual

Tenmars

Tenmars TM-801 user manual

MSR

MSR 145 user manual

TPS

TPS WP-82 manual

PCB Piezotronics

PCB Piezotronics 003C30 Installation and operating manual

Tenma

Tenma 72-10465 manual

Endress+Hauser

Endress+Hauser Proline Promag 50 Brief operating instructions

Siemens

Siemens SITRANS F Coriolis FCT030 Function manual

KLINGER

KLINGER CMF V Series instruction manual

Keysight

Keysight M8290A Getting started guide

Acterna

Acterna MS1400 Operation manual

R&S

R&S ZPH manual

Datacolor

Datacolor ColorReader DC10-2 user guide
