FSP Technology Nano 400 User manual

Nano UPS Quick Guide V.1.0
Package Contents
You should have received the following items inside of package:
UPS Unit
Quick Guide
-Power cable (only for the IEC-type model)
-
-
1
4Installation & Initial Startup
NOTE:
Placement & Storage Conditions
Connect to Utility and Charging
Before installation, please inspect the unit. Be sure that
nothing inside the package is damaged.
Install the UPS in a protected area that is free of excessive dust an d has adequate
air flow. Please place the UPS away from other units at least 20 cm to avoid
interference. Do NOT ope rate the UPS where the temperature and humidity is
outside th e specific limits. (Please check the specs for the limitations.)
Before initial use, please plug in the AC input cord to the
wall outlet and turn on the UPS for charging. For the best
results, suggest to charge the battery at least 8 hours
before initial use. The UPS charges its battery while
connecting to the utility with power on.
Plug in the loads to output receptacles on the rear panel of the UPS. Simply
turn on the power switch of UPS unit, then devices connected to the UPS will
be protected by UPS unit.
connect a laser printer or scanner to
the UPS unit. This may cause the damage of the unit.
Connect the Loads
CAUTION: NEVER
Turn On/Off the Unit
Indicators & Alarm Table for Operation
Turn on the UPS unit by pressing the power switch. Turn off the UPS unit by
pressing again the power switch.
2
Front View:
Back View:
AC input
Output receptacles
Circuit breaker
Power switch
UPS status indicator
Fault/Battery status indicator
(Check the Indicator & Alarm Table for the details)
1
2
3
IEC Type
1
2
3
NEMA Type Universal Type Schuko Type
Product Overview
3
Product Introduction
1
2
3
The Nano UPS provides comprehensive protection in a small and economic package.
The UPS is more compact and offers greater comprehensive power protection against
surges and spikes. This UPS will continue providing stable power to connected
equipment and enable to shutdown PC safely during power failure. Its embedded
microprocessor controller guarantees high reliability and it’s perfect for any home
or small office application.
1
2
3
2
31
8 hours
20cm 20 cm
Conditions Visual Indications Alarm
Off
Green LED lighting
Green LED flashing
every 10 seconds
Green LED flashing every
second & Red LED lighting
Sounding every 10 seconds
Sounding every second
AC mode
Battery mode
Low battery at
battery mode
Fault Red LED lighting Continuously sounding
Alarm for over-
temperature
protection
Red LED flashing every 0.5
seconds Off

Trouble Shooting
6
Use the table below to solve minor problems.
Important Safety Warning
(SAVE THESE INSTRUCTIONS)
5
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
Attention
To prevent the risk of fire or electric shock, install in a temperature and
humidity controlled indoor area free of conductive contaminants. (See the
specifications for the acceptable temperature and humidity range.)
To reduce the risk of overheating the UPS, do not cover the UPS' cooling
vents and avoid exposing the unit to direct sunlight or installing the unit near heat
emitting appliances such as space heaters or furnaces.
Do not attach non-computer-related items, such as medical equipment,
life-support equipment, microwave ovens, or vacuum cleaners to UPS.
Do not plug the UPS input into its own output.
Do not allow liquids or any foreign object to enter the UPS. Do not place
beverages or any other liquid-containing vessels on or near the unit.
In the event of an emergency, press the OFF button and disconnect the
power cord from the AC power supply to properly disable the UPS.
Do not attach a power strip or surge suppressor to the UPS.
hazardous through electric shock. Also with disconnection of this unit
from the mains, hazardous voltage still may be accessible through supply from
battery. The battery supply should be therefore disconnected in the plus and minus
pole at the quick connectors of the battery when maintenance or service work inside
the UPS is necessary.
CAUTION!
CAUTION!
If the UPS is with metal chassis, for safety purpose, grounding is a must
during UPS installation in order to reduce leakage current below 3.5mA.
Internal battery voltage is 12Vdc. Sealed, lead-acid, 6-cell battery.
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
Servicing of batterie s should be performe d or supervised by personnel
knowledgeable of batteries and the required precautions. Keep unauthorized
personnel away from batteries.
When replacing the batteries, use the same number and type of batteries.
Do not dispose of batteries in a fire. The batte ry may explod e. Do not
open or mutilate the battery or batteries. Released electrolyte is harmful to the skin
and eyes.
Unplug the UPS prior to cleaning and do not use liquid or spray deterg ent.
A battery can present a risk of electric shock and high sh ort circuit
curre nt. The following precaution should be observed before replacing batteries:
1) Remove watches, rings, or other metal objects.
2) Use tools with in sulated handles.
3) Wear rubber gloves and boots.
4) Do not lay tools or metal parts on top of batteries.
5) Disconnect charging sou rce prior to connecting or disconnecting batteries terminal.
Specifications
7
Problem Probable Cause Solution
No LED display
on the front
panel.
Alarm continuously
sounds when the
mains is normal.
Alarm sounds every
2 seconds when the
mains is normal.
When power fails,
backup time is
shorten.
The mains is normal
but green LED is
flashing.
Low battery.
Battery fault.
The UPS is not turned on.
The UPS is overload.
UPS fault
Battery defect
Charging circuit is damaged.
The UPS is overload.
Battery voltage is too low.
Battery defect.
Power cord is loose.
Charge the UPS at least 8 hours.
Replace the battery with the
same type of battery.
Press the power switch
again to turn on the UPS.
Remove some loads first.
Before reconnecting equipment,
please verify that the load
matches the UPS capability
specified in the specs.
Return the unit to service center.
Replace the battery with the
same type of battery.
Return the unit to service center.
Remove some critical load.
Charge the UPS at least 8 hours.
Replace the battery with the
same type of battery.
Reconnect the power cord
properly.
Model Nano 400 Nano 600 Nano 800
CAPACITY
INPUT
OUTPUT
BATTERY
PROTECTION
PHYSICAL
ENVIRONMENT
Voltage
Voltage Range
Freq uency
Output Voltage (AC mo de)
Output Voltage (Bat . mode)
Transfer Time
Waveform
Typ e & Number
Charging Time
Full Protection
Dimension (DxWxH mm )
Net Weight (kgs)
Humidity
Temperature
400 VA / 240 W 600 VA / 360 W 800 VA / 480 W
12 V/4.5 AH x 1 12 V/ 7 AH x 1 12 V/9 AH x 1
8 hours recover to 90% capacity
Overcharge, discharge, short circuit, and thermal protection
110/120 VAC or 220/2 30/240 VAC
90~145 VAC or 180~ 270 VAC
50 Hz or 60 Hz
same as input
120 VAC ± 10% / 230 VAC ± 10%
2-6 ms (Typical)
Simulated Sine Wave
0-90 %
0-40 C (non-condensing)
228 x 82.5 x 207
2.2 2.7 3.1
